Материал: Bovine Viral Diarrhea Virus Diagnosis, Management, and Control

calves that were later challenged intranasally with the virulent BVDV 2 24515 ncp strain at 4.5 months of age (3 weeks after vaccination of the 4-month-old calves and 4 months after vaccination of the 10–14- day-old calves). At time of challenge, the neutralizing antibody titers for the 10–14-day-old seronegative calves vaccinated calves were the following: mean of 162 to BVDV 1a NADL (range of 108 to >162) and mean of 108 to BVDV 2 125C (range of 18 to >162). The neutralizing antibody titers at challenge for the 4-month-old calves vaccinated calves were the following: mean of 36 (range of 18–54) to BVDV 1a NADL and mean of 18 (range of 12–108) to BVDV 2 125C. As in the prior study, the calves were protected against clinical illness, and all but one vaccinated calf were protected against viremia.

An MLV vaccine containing the BVDV 1 ncp strain (subtype not identified, Table 13.1) was given to seronegative calves, and the cattle were held for approximately 7 months and then challenged intranasally with the BVDV 2 ncp 890 strain (Dean and Ley, 1999). The neutralizing antibody titers to BVDV 2 890 strain at time of challenge were the following: intramuscular vaccinates, mean of 78 (range 16–362) and subcutaneous vaccinates, mean of 73 (range of 23–181). Clinical signs were reduced in the vaccinated animals as compared to controls in the 21-day postchallenge period. Vaccination eliminated nasal shedding in 87% of the cattle and completely prevented viremia and leukopenia, whereas all unvaccinated cattle shed virus nasally and became viremic. This study was unique in that it demonstrated there was a long duration of immunity (7 months) and the calves were protected against BVDV viremia.

In a study by Howard et al. (1994), two inactivated vaccines were prepared using 11249 NC and Ky 1203 NC using ß-propriolactone inactivation. Three doses of each vaccine were given on day 0, week 3, and week 6. The subtypes for these two strains were not identified in the study. Subsequently, studies refer to 11249 NC and Ky 1203 NC BVDV 1a ncp strains (Nobiron et al., 2003; J. Patel, personal communication). Three weeks later the 11249 NC vaccinates were challenged with homologous virus intranasally. The neutralizing antibody titers in vaccinates to 1249 NC was a mean of 1318 (3.12 log10). Nonvaccinated controls became viremic 4–6 days postchallenge and shed virus in nasopharyngeal samples 4–8 days postchallenge; however, the vaccinated animals did not have positive nasopharyngeal swabs or viremia. In the second group, the Ky 1203 NC strain was given on days 0,

weeks 3 and 6, and cattle challenged on week 8 with the heterologous 11249 NC strain. Again, vaccinates were protected against viremia and nasopharyngeal shedding. These studies support the point that killed vaccines, although requiring multiple doses, can protect against viremia and nasopharyngeal shedding.

In another report, Makoschey et al. (2001) found protection by an inactivated BVDV 1 vaccine (Bovilis BVD) against clinical signs including thrombocytopenia after challenge with a BVDV 2 strain. This vaccine contained BVDV 1a cp strain C86 (Patel et al., 2002; J. Patel, personal communication). Calves received 2 doses of the vaccine 4 weeks apart and were challenged 4 weeks later with the BVDV 2 Giessen-1 challenge strain(s), which contained both BVDV cp and ncp biotypes. The antibody titers in vaccinates at time of challenge using the BVDV 2 challenge virus in the serologic test ranged from 5–10 log2 (1:32–1:1024). Calves were given the challenge virus both intranasally and intravenously, and the observation period was 14 days for clinical signs. After challenge, unvaccinated cattle developed signs of respiratory disease, diarrhea with erosions and hemorrhage of the digestive tract, and depletion of lymphocytes in lymphatic organs. These signs were absent or markedly less severe in vaccinates. The unvaccinated and vaccinated animals were evaluated for thrombocytopenia and leukopenia for 22 days postchallenge. Beneficial effects of vaccination indicated protection against leukopenia and thrombocytopenia compared to unvaccinated cattle. Vaccinated calves did not shed virus after challenge and had reduced numbers of BVDV isolates from plasma and blood cells. Thus the inactivated BVDV 1 vaccine gave protection against heterologous BVDV 2 infection and disease and reduced viral shedding and viremia.

In another study, two doses of an inactivated vaccine containing BVDV 1 PT 810 strain and BVDV 2 890 strain were given to cattle 28 days apart (Beer et al., 2000). The BVDV PT 810 strain is a BVDV 1c strain (Giangaspero and Harasawa, 1999). Vaccinated and nonvaccinated animals were challenged intranasally with the BVDV 1 PT810 strain 38 days after vaccination. The neutralizing antibody titers in vaccinates at time of challenge ranged from 1:10–1:8192 using the homologous virus BVDV 1c PT 810 in the serotest. Vaccinated cattle had reduced viral shedding in nasal samples, reduced leukopenia, and reduced viremia as compared to controls. This is another example where an inactivated BVDV vaccine given in multiple doses provided protection

after homologous challenge as measured by leukopenia, viremia, and viral shedding.

A Japanese study recently demonstrated protection by a Japanese MLV BVDV vaccine containing BVDV 1 ncp strain 12-43 in calves against a U.S. strain of BVDV 2 (Shimazaki et al., 2003). Four weeks after vaccination, the vaccinated (n = 3) and unvaccinated calves (n = 2) were challenged intravenously with the BVDV 2 890 ncp strain. The vaccinated calves were seronegative to the BVDV 2 890 strain at the time of challenge; however, the neutralizing titers to BVDV 1 ncp were >1:64. The vaccinated calves did not develop clinical signs or fever nor have hematological changes (decreased WBC) after challenge. The vaccinated animals were protected against blood leukocyte infection. The authors suggested that other studies be performed to confirm effectiveness of the vaccine against BVDV 2 strains isolated in Japan.

PROTECTION AGAINST FETAL

INFECTION/DISEASE

In the 1990s attention was directed towards developing new vaccines or evaluating existing vaccines to protect the fetus against BVDV infection/disease. Until then vaccine licensure relied on efficacy of protection against acute disease or infection for postnatal exposure of calves. Also label claims by manufacturers required extensive, long-term studies to generate supporting data for the label claim. An inactivated vaccine, Bovidec (C-Vet) containing a Compton prototype virus, was given to heifers as either two or three doses each, 3 weeks apart near the time of breeding (Brownlie, et al., 1995). The vaccine strain in Bovidec vaccine is a BVDV 1a ncp strain (J. Patel, personal communication). Pregnant heifers were exposed intranasally between 25 and 80 days gestation with BVDV Pe 515 NC C1. Vaccinated heifers were protected against viremia postchallenge. There was no evidence of infection in the live calves born to vaccinated dams or in the 2 aborted fetuses from the vaccinates. Thus vaccination gave 100% protection to the 15 fetuses of 15 vaccinated dams. There was, however, fetal infection in 14/15 fetuses in the unvaccinated group as indicated by PI status of newborn calves, infected aborted fetuses, or active immune response prior to birth.

The MLV BVDV 1a NADL vaccine strain was evaluated for protection of fetuses against BVDV 1 strain (BJ ncp strain) (Cortese et al., 1998c). Twelve heifers were vaccinated once, and there were 6 nonvaccinates. Thirty days after vaccination the heifers

were synchronized with a prostaglandin product and then housed with 10 BVDV-free bulls. They remained with bulls for 7 days. Approximately 110 days after vaccination (approximately 75 days gestation) all 18 heifers were challenged intranasally with the BJ ncp strain, a BVDV 1 a strain (K.V. Brock, personal communication). Mean neutralizing antibody titers to the BVDV 1a BJ strain and BVDV 1a NADL strain at time of challenge was 1:40 (BJ) and 1:20 (NADL) for 10 vaccinates and 1:10 (BJ) and <1:5 (NADL) for 2 vaccinates. The vaccinated animals did not become viremic postchallenge, but 4 of 6 nonvaccinated animals did 6–8 days after challenge. All 6 unvaccinated heifers carried their fetuses to term and gave birth to PI calves as determined by multiple virus isolations. Of the 12 vaccinated heifers, there were 2 with PI calves. Thus fetal protection was demonstrated against homologous BVDV 1 challenge in 10 of 12 (83.3%) of the vaccinated heifers.

The ability of the BVDV 1a MLV NADL vaccine to provide protection against heterologous BVDV 2 was evaluated (Brock and Cortese, 2001) among 19 vaccinated and 6 unvaccinated heifers. Forty-five days after vaccination, the cattle were synchronized with prostaglandin and exposed to 10 BVDV-free bulls for 1 week. Thirty days later, the heifers were examined by ultrasound. All open animals were given a second dose of prostaglandin and were exposed to bulls again for 7 days. Thus challenge appears to have been approximately 4–5 months after vaccination. Mean neutralizing antibody titers in vaccinated animals at the time of challenge was 1:36 to both BVDV 1a (NADL) and BVDV 2 (PA 131). At 75 days gestation, the pregnant heifers were exposed intranasally to PA 131 strain, a ncp BVDV 2 strain. After challenge, 5 of 6 nonvaccinates were viremic (between days 5 and 8), but none of the 19 vaccinates became viremic. The experiment was terminated at 150–180 days gestation, and spleen, thymus, and small intestine of fetuses were collected for virus isolation. All 6 fetuses from the nonvaccinates were PI while 6 of 19 vaccinated dams had PI fetuses. Thus 11 of 19 (57.9%) pregnant heifers given a BVDV 1a NADL vaccine strain were protected against PI. While protection was demonstrated against BVDV 2, it was not complete and was less than protective against homologous BVDV 1 (83.3%) demonstrated previously (Cortese et al., 1998c).

A two-step vaccination protocol, first dose with an inactivated BVDV vaccine (Mucobovin) followed by an MLV BVDV vaccine (Vacaviron), was

evaluated for fetal protection (Frey et al., 2002). The inactivated BVDV vaccine contained BVDV 1b ncp NY-1 strain and a Border Disease virus strain, Aveyronite. The MLV vaccine contained the BVDV 1a cp C24V strain. Heifers were vaccinated with the two-step vaccination program starting with the inactivated BVDV vaccine followed by MLV vaccine 4 weeks later. Neutralizing antibody titers in vaccinates 16 weeks after first vaccination indicated BVDV 1 titers of 1:100–1:600, and BVDV 2 titers of 1:10–1:240. Five months after the first vaccination (at 30–120 days of gestation), the heifers were challenged with a mixture of BVDV 1 ncp 22146/ Han 81 and BVDV 2 ncp (strain not identified). A transient viremia was seen 5–9 days after challenge in the nonvaccinated heifers, and BVDV 1 was isolated from 1 heifer and BVDV 2 from the remaining 5. One vaccinate was positive for BVDV 2 on one collection day, but the other vaccinates remained nonviremic. All vaccinated heifers (n = 9) gave birth to calves that were not viremic, did not have evidence of congenital fetal damage, and all precolostral sera were BVDV seronegative. The 6 calves born to nonvaccinates had evidence of fetal infection; 1 was stillborn, 1 died 2 days after calving, and 4 were underdeveloped and had signs of ocular defects. Precolostrum serum samples were positive for BVDV 2 by virus isolation. This study demonstrated that a combination of killed BVDV 1b and Border Disease virus vaccine followed by an MLV BVDV 1a vaccine conferred protection against challenge with both BVDV 1 and BVDV 2, and also against transplacental infection with BVDV 2.

A unique study was performed to evaluate the ability of an inactivated BVDV 1a vaccine to protect heifers exposed to PI animals 6 months after initial vaccination (Patel et al., 2002). The use of PI animals to introduce challenge virus mimics the most likely route of exposure under field conditions. Two doses of an inactivated vaccine (Bovilis BVDV) containing BVDV 1a cp strain C 86 were given to 20 heifers 4 weeks apart. Approximately 100 days later, the heifers were synchronized followed by two services. There were 11 vaccinated and 7 unvaccinated animals. Six months after the second vaccination (at about 87 days of gestation) the heifers were challenged. The neutralizing antibody titers in vaccinates at the time of challenge to BVDV 1a ranged from 1:64–1:256. Three PI heifers were introduced into the pen for 2 weeks to initiate challenge. The PI cattle were infected with a BVDV 1a ncp strain (J. Patel, personal communication). All 7 nonvaccinated heifers became viremic, as detected by virus

isolation from serum and/or leukocytes. Only 5 of 11 vaccinated calves were found to be viremic as determined by viral isolation from leukocytes; all were negative for virus in serum. Virus was detected in nasal samples of 5 of 7 nonvaccinates and 2/11 vaccinates. The vaccinated heifers had two abortions (not related to BVDV) and 9 normal calves. These 9 calves were negative for BVDV and BVDV antibodes in precolostral serum. All 7 nonvaccinated heifers delivered BVDV-infected calves. This study demonstrated that two doses of an inactivated BVDV 1a vaccine gave complete protection against homologous viral challenge of pregnant heifers 6 months after vaccination.

The results of these trials evaluating efficacy of BVDV vaccines under challenge conditions indicate protection for both postnatal acute infections/disease and fetal infections. Challenge in many trials was relatively soon after vaccination, 2–4 weeks after last dose of initial immunization, which is presumably at a peak of immunity. In other trials, the cattle were challenged approximately 6 months after vaccination. Interestingly, all of the above studies indicated protection against postnatal acute disease. In some, but not all studies, vaccination eliminated viremia and nasal shedding in postchallenge vaccinated animals. Thus, it may be difficult to totally eliminate nasal shedding from the respiratory tract or viremia (systemic infection) in even highly immune cattle after challenge. It is important that any BVDV vaccine protects against viremia, because viremia indicates the potential for fetal infections. Likewise, elimination of nasal shedding in exposed vaccinated cattle is important to prevent further transmission of BVDV. There appears to be increased interest in protection against different BVDV subtypes, particularly against BVDV 2.

The protection against fetal infection/disease varied from approximately 60–100%. Fetal protection is extremely important to prevent or minimize PI calves. Elimination of PI cattle will likely reduce BVDV transmission. In the two reports using the MLV BVDV 1a vaccinal strain there was protection (83%) against homologous BVDV 1a challenge; however, there was reduced protection against heterologous BVDV 2 challenge, (58%). Although protection was demonstrated, the MLV BVDV 1a vaccine did not provide 100% protection. Thus even though the vaccines may have efficacy demonstrated for licensure, vigilance for PI cattle in vaccinated cattle is important because there may be potential for PI calves born to vaccinated cows/heifers.

Up to this point, this review has focused on killed

and modified live whole virus vaccines produced by classic methods. However, several experimental vaccines for delivering BVDV immunogens have been reported in the literature. Predominantly these vaccines focus on the delivery of the E2 glycoprotein by various methods, including recombinant protein from baculovirus constructs (Bolin and Ridpath, 1996; Bruschke et al., 1997), expression as constituent of recombinant adenovirus (Elahi et al., 1999) and as a DNA construct (Harpin et al., 1999; Norbiron et al. 2003).

GOALS FOR VACCINE DEVELOPMENT

There are significant goals for BVDV vaccines that, if accomplished, would greatly provide better control measures for BVDV. The first involves fetal protection. In order to completely eliminate the birth of PI calves, vaccines need to provide 100% lifetime protection of pregnant heifers/cows against viremia. The second goal involves the prevention of acute infection in nonpregnant animals. Acute BVDV disease remains a problem for both calf and dairy production. Stocker/feeder beef production operations are faced with acute disease caused by BVDV (Fulton et al., 2000a; Fulton et al., 2002a). The goal of vaccination in these animals would be to eliminate clinical signs and virus shedding. In addition, current management practices require a rapid onset of protective immunity for vaccination to be effective. The marketing of beef cattle in North America typically involves assembly of calves from diverse sources, resulting in comingling of calves with unknown vaccination status. Likewise, many cattle of unknown vaccination status are delivered directly to feedlots. Cattle are usually vaccinated against BVDV along with other viral immunogens shortly after purchase at auctions and/or delivery to the feedlot. The period immediately after comingling is critical for exposure to pathogens.

Current BVDV vaccine onset of immunity has not been thoroughly investigated, although efficacy trials have been successful when challenge occurred 14 days after the last dose of initial immunization. The duration of immunity should be established for each vaccine, particularly those with a fetal protection label claim. For example, beef breeding cattle, particularly under range conditions may not always be able to be gathered for vaccinations due to large pastures; hence the need for vaccines inducing durable immunity.

There is an ongoing debate regarding the importance of BVDV vaccines in controlling acute respi-

ratory disease in postnatal calves. A review of field studies on vaccine efficacy in bovine respiratory disease did not demonstrate benefits by BVDV vaccines (Perino and Hunsaker, 1997). In contrast, a later study demonstrated that BVDV immunity was a predictor of illness and performance parameters in feedlot calves (Fulton et al., 2002b). In that study, there was a correlation between higher levels of BVDV 1a antibodies and lower morbidity rate. Calves with low antibody levels to BVDV 1a and BVDV 2 had decreased net value to owners (carcass value minus total feedlot costs). Calves treated twice or more had lower levels of antibody to BVDV 1a than those treated once or not at all. Thus, BVDV immunity appears to demonstrate benefit against disease and for increased profitability. Herds with high morbidity and treatment costs are often shown to follow incomplete vaccination programs.

Finally, there are safety issues that should be addressed. These include assurances that MLV vaccines do not cross the placenta and infect the fetus. The bovine fetus is very susceptible to the field or vaccinal strains of BVDV. In addition, there also needs to be better efficacy studies to heterologous BVDV subtypes.

REFERENCES

Baker JC: 1987, Bovine viral diarrhea virus: a review.

J Am Vet Med Assoc 190:1449–1458.

Barkema HW, Bartels CJ, van Wuijckhuise L, et al.: 2001, Outbreak of bovine virus diarrhea on Dutch dairy farms induced by a bovine herpesvirus 1 marker vaccine contaminated with bovine virus diarrhea virus type 2. Tijdschr Diergeneeskd

126:158–165.

Baxi MK, Deregt D, Robertson J, et al.: 2000, Recombinant bovine adenovirus type 3 expressing bovine viral diarrhea virus glycoprotein E2 induces an immune response in cotton rats. Virology 278:234–243.

Beer M, Hehnen HR, Wolfmeyer A, et al.: 2000, A new inactivated BVDV genotype I and II vaccine. An immunization and challenge study with BVDV genotype I. Vet Microbiol 77:195–208.

Beer M, Wolf G, Pickler J, et al.: 1997, Cytotoxic T- lymphocyte responses in cattle infected with bovine viral diarrhea virus. Vet Microbiol 58:9–22.

Bittle, JL.: 1968, Vaccination for bovine viral diarrheamucosal disease. J Am Vet Med Assoc 152:861.

Bolin SR: 1988, Viral and viral protein specificity of antibodies induced in cows persistently infected with noncytopathic bovine viral diarrhea virus after vaccination with cytopathic bovine viral diarrhea virus. Am J Vet Res 49:1040–1044.

Bolin SR: 1995, Control of bovine viral diarrhea infection by use of vaccination. Vet Clin North Am: Food Anim Pract 11:615–625.

Bolin SR, McClurkin AW, Cutlip RC, Coria MF: 1985a, Severe clinical disease induced in cattle persistently infected with noncytopathic bovine viral diarrhea virus by superinfection with cytopathic bovine viral diarrhea virus. Am J Vet Res 46:573–576.

Bolin SR, McClurkin AW, Cutlip RC et al: 1985b, Response of cattle persistently infected with noncytopathic bovine viral diarrhea virus to vaccination for bovine viral diarrhea and to subsequent challenge exposure with cytopathic bovine viral diarrhea virus. Am J Vet Res 46:2467–2470.

Bolin SR, Ridpath JF: 1995, Assessment of protection from systemic infection or disease afforded by low to intermediate titers of passively acquired neutralizing antibody against bovine viral diarrhea virus in calves. Am J Vet Res 56:755–759.

Bolin SR, Ridpath JF: 1996, Glycoprotein E2 of bovine viral diarrhea virus expressed in insect cells provides calves limited protection from systemic infection and disease. Arch Virol 141:1463–1477.

Bolin SR, Ridpath JF: 1998, Prevalence of bovine viral diarrhea virus genotypes and antibody against those viral genotypes in fetal bovine serum. J Vet Diagn Invest 10:135–139.

Brock KV, Chase CCL: 2000, Development of a fetal challenge method for the evaluation of bovine diarrhea virus vaccines. Vet Microbiol 77:209–214.

Brock KV, Cortese VS: 2001, Experimental fetal challenge using type II bovine viral diarrhea virus in cattle vaccinated with modified-live virus vaccine.

Vet Therapeutics 2:354–360.

Brownlie J, Clarke MC, Hooper, LB et al.: 1995, Protection of the bovine fetus from bovine viral diarrhoea virus by means of a new inactivated vaccine. Vet Rec 137:58–62.

Brownlie J, Clarke MC, Howard CJ: 1984, Experimental production of fatal mucosal disease in cattle. Vet Rec 114:535–536.

Brownlie J, Clarke MC, Howard CJ: 1989, Experimental infection of cattle in early pregnancy with a cytopathic strain of bovine viral diarrhoea virus. Res Vet Sci 46:307–311.

Bruschke, CJM, Moormann RJM, van Oirschot JT, van Rijn PA: 1997, A subunit vaccine based on glycoprotein E2 of bovine viral diarrhea virus induces fetal protection in sheep against homologous challenge. Vaccine 15:1940–1945.

Bruschke CJM, van Oirschot JT, van Rijn PA: 1999, An experimental multivalent bovine virus diarrhea virus E2 subunit vaccine and two experimental con-

ventionally inactivated vaccines induce partial fetal protection in sheep. Vaccine 17:1983–1991.

Carman S, van Dreumel T, Ridpath J, et al.: 1998, Severe acute bovine viral diarrhea in Ontario, 1993–1995. J Vet Diagn Invest 10:27–35.

Collett MS: 1996, Genomic structure of BVDV. In:

Bovine Viral Diarrhea Virus: A 50 year review. Cornell University Press, Ithaca, NY.

Compendium of Veterinary Products: 2003, Seventh Edition. North American Compendiums, Port Huron, MI, pp. 302–309.

Cortese VS, Ellis J, Whittaker R: 1997, BVDV virus transmission following attenuated vaccines to BVDV seronegative cattle. Large Animal Pract, September/October pp. 18–24.

Cortese VS, Grooms DL, Ellis J, et al.: 1998c, Protection of pregnant cattle and their fetuses against infection with bovine viral diarrhea virus type 1 by use of a modified-live virus vaccine. Am J Vet Res 59:1409–1413.

Cortese VS, West KH, Hassard LE, et al.: 1998b, Clinical and immunological responses of vaccinated and unvaccinated calves to infection with a virulent type II isolate of bovine viral diarrhea virus. J Am Vet Med Assoc 213:1312–1319.

Cortese VS, Whittaker R, Ellis J, et al: 1998a, Specificity and duration of neutralizing antibodies induced in healthy cattle after administration of a modified-live virus vaccine against bovine viral diarrhea. Am J Vet Res 59:848–850.

Dean HJ, Leyh R: 1999, Cross-protective efficacy of a bovine viral diarrhea virus (BVDV) type 1 vaccine against BVDV type 2 challenge. Vaccine 17:1117–1124.

Done JT, Terlecki S, Richardson C, et al.: 1980, Bovine virus diarrhoea-mucosal disease virus: pathogenicity for the fetal calf following maternal infection. Vet Rec 106:473–479.

Dubois WR, Cooper VL, Duffy JC, et al.: 2000, A preliminary evaluation of the effect of vaccination with modified live viral diarrhea virus (BVDV) on detection of BVDV antigen in skin biopsies using immunohistochemical methods. Bovine Pract 34:98–100.

Duffel SJ, Sharp MW, Winkler CE, et al.: 1984, Bovine virus diarrhoea-mucosal disease virusinduced fetopathy in cattle: efficacy of prophylactic maternal pre-exposure. Vet Rec 114:558–561.

Elahi SM, Shen SH, Talbot BG, et al.: 1999, Recombinant adenoviruses expressing the E2 protein of bovine viral diarrhea virus induces humoral and cellular immune responses. FEMS Microbiol Letters 177:159–166.

Ellis J, West K, Cortese V, et al.: 2001, Effect of maternal antibodies on induction and persistence of
