DICOM PS3.3 2020a - Information Object Definitions​

Page 401​

Functional Group Macro​

Section​



Usage​

Respiratory Synchronization​

C.7.6.16.2.17​

U​



Irradiation Event Identification​

C.7.6.16.2.18​

C - Required if Irradiation Event UID (0008,3010) was​





present in any of the Classic Images that were converted.​

PET Frame Type​

C.8.22.5.1​

M​



Temporal Position​

C.7.6.16.2.23​

U​



UnassignedSharedConvertedAttributes​C.7.6.16.2.25.1​

M - May not be used as a Per-Frame Functional Group​

Unassigned Per-Frame Converted​

C.7.6.16.2.25.2​

M - May not be used as a Shared Functional Group​

Attributes​







Image Frame Conversion Source​

C.7.6.16.2.25.3​

C - Required if created by conversion from a DICOM​





source; may not be used as a Shared Functional Group​

A.73 Corneal Topography Map IOD​

A.73.1 Corneal Topography Map IOD Description​

TheCornealTopographyMapIODisgeneratedbyophthalmiccornealtopographymappingdevices,suchasreflection-basedtopography​ and elevation-based tomography instruments to generate curvature and/or elevation measurements of corneal anterior and posterior​ surfaces that are presented topographically using a monochromatic image and a pseudo-color map.​

A.73.2 Corneal Topography Map IOD Entity-Relationship Model​

This IOD uses the E-R Model in Section A.1.2, with only the Image IE below the Series IE.​

A.73.3 Corneal Topography Map IOD Modules​

Table A.73.3-1 specifies the Modules of the Corneal Topography Map IOD.​

Table A.73.3-1. Corneal Topography Map IOD Modules​

IE​

Module​

Reference​

Usage​

Patient​

Patient​

C.7.1.1​

M​



Clinical Trial Subject​

C.7.1.3​

U​

Study​

General Study​

C.7.2.1​

M​



Patient Study​

C.7.2.2​

U​



Clinical Trial Study​

C.7.2.3​

U​

Series​

General Series​

C.7.3.1​

M​



Clinical Trial Series​

C.7.3.2​

U​



Corneal Topography Map Series​

C.8.30.1​

M​

Equipment​

General Equipment​

C.7.5.1​

M​



Enhanced General Equipment​

C.7.5.2​

M​

Frame of​

Frame of Reference​

C.7.4.1​

M​

Reference​







Image​

General Image​

C.7.6.1​

M​



General Reference​

C.12.4​

U​



Image Pixel​

C.7.6.3​

M​



Palette Color Lookup Table​

C.7.9​

M​



Corneal Topography Map Image​

C.8.30.2​

M​



Corneal Topography Map Analysis​

C.8.30.3​

M​

- Standard -​

Page 402​

DICOM PS3.3 2020a - Information Object Definitions​



IE​

Module​

Reference​

Usage​



Ophthalmic Photography Acquisition Parameters​

C.8.17.4​

M​



Acquisition Context​

C.7.6.14​

M​



ICC Profile​

C.11.15​

U​



SOP Common​

C.12.1​

M​

A.73.4 Corneal Topography Map IOD Content Constraints​

The following constraints on Image Attributes take precedence over the descriptions given in the Module Attribute Tables.​

A.73.4.1 Prohibited Modules​

The Curve Module (Retired), Overlay Plane Module and VOI LUT Module shall not be used in a Standard Extended SOP Class of​ the Corneal Topography Map.​

A.74 Breast Projection X-Ray Image IOD​

A.74.1 Breast Projection X-Ray Image IOD Description​

TheBreastProjectionX-RayImageInformationObjectDefinitionspecifiesanimagesetthathasbeencreatedbyadigitalmammography​ projection radiography imaging device.​

Note​

The preferred IOD for traditional digital mammography is Digital Mammography X-Ray Image.​

The Breast Projection X-Ray Image IOD is used in two SOP Classes as defined in PS3.4 Storage Service Class, a SOP Class for​ storageofimagesintendedforpresentation,andaSOPClassforstorageofimagesintendedforfurtherprocessingbeforepresentation.​ These are distinguished by their SOP Class UID and by the Enumerated Value of the mandatory Attribute in the DX Series Module,​ Presentation Intent Type (0008,0068).​

A.74.2 Breast Projection X-Ray Image IOD Entity-Relationship Model​

This IOD uses the E-R Model in Section A.1.2, with only the Image IE below the Series IE.​

A.74.3 Breast Projection X-Ray Image IOD Module Table​

Table A.74-1 specifies the Modules of the Breast Projection X-Ray Image IOD.​

Table A.74-1. Breast Projection X-Ray Image IOD Modules​

IE​

Module​

Reference​

Usage​

Patient​

Patient​

C.7.1.1​

M​



Clinical Trial Subject​

C.7.1.3​

U​

Study​

General Study​

C.7.2.1​

M​



Patient Study​

C.7.2.2​

U​



Clinical Trial Study​

C.7.2.3​

U​

Series​

General Series​

C.7.3.1​

M​



Clinical Trial Series​

C.7.3.2​

U​



DX Series​

C.8.11.1​

M​



Enhanced Mammography Series​

C.8.11.10​

M​

Frame of​ Frame of Reference​

C.7.4.1​

M​

Reference​





- Standard -​



DICOM PS3.3 2020a - Information Object Definitions​

Page 403​

IE​

Module​

Reference​

Usage​



Synchronization​

C.7.4.2​

C - Required if time​







synchronization was applied.​

Equipment​General Equipment​

C.7.5.1​

M​



Enhanced General Equipment​

C.7.5.2​

M​

Image​

Enhanced Mammography Image​

C.8.31.1​

M​



Breast View​

C.8.21.6​

M​



Image Pixel​

C.7.6.3​

M​



Enhanced Contrast/Bolus​

C.7.6.4b​

C-Requiredifcontrastmediawas​







applied.​



Device​

C.7.6.12​

U​



Intervention​

C.7.6.13​

U​



Acquisition Context​

C.7.6.14​

M​



Multi-frame Functional Groups​

C.7.6.16​

M​



Multi-frame Dimension​

C.7.6.17​

U​



Patient Orientation​

C.7.6.20​

M​



Specimen​

C.7.6.22​

U​



SOP Common​

C.12.1​

M​



Common Instance Reference​

C.12.2​

U​



Frame Extraction​

C.12.3​

C - Required if the SOP Instance​







was created in response to a​







Frame-Level retrieve request​

A.74.3.1 Breast Projection X-Ray Image IOD Content Constraints​

A.74.3.1.1 Modality Attribute​

Modality (0008,0060) shall have the value MG.​

A.74.3.1.2 Overlay Plane Module, Curve Module and VOI LUT Module​

The Overlay Plane Module, Curve Module (Retired), VOI LUT Module and Softcopy Presentation LUT Module shall not be used in a​ Standard Extended SOP Class of the Breast Projection X-Ray Image.​

Note​

The VOI LUT function is provided by a Frame VOI LUT Functional Group.​

A.74.4 Breast Projection X-Ray Image Functional Group Macros​

Table A.74-2 specifies the use of the Functional Group Macros used in the Multi-frame Functional Groups Module for the Breast​ Projection X-Ray Image IOD.​

Table A.74-2. Breast Projection X-Ray Image Functional Group Macros​

Functional Group Macro​

Section​

Usage​

Frame Content​

C.7.6.16.2.2​

M - May not be used as a Shared Functional​





Group.​

Referenced Image​

C.7.6.16.2.5​

U​

- Standard -​

Page 404​

DICOM PS3.3 2020a - Information Object Definitions​

Functional Group Macro​

Section​

Usage​

Derivation Image​



C.7.6.16.2.6​

C - Required if the Image Type (0008,0008)​







Value 1 equals DERIVED or Value 1 is​







ORIGINALandPresentationIntentTypeequals​







FOR PRESENTATION. May be present​







otherwise.​

Frame Anatomy​



C.7.6.16.2.8​

M​

Identity Pixel Value Transformation​



C.7.6.16.2.9b​

M​

Frame VOI LUT With LUT​



C.7.6.16.2.10b​

M​

Contrast/Bolus Usage​



C.7.6.16.2.12​

C - Required if the Enhanced Contrast/Bolus​







Module is present.​

Frame Display Shutter​



C.7.6.16.2.16​

U​

Irradiation Event Identification​



C.7.6.16.2.18​

M​

X-Ray Frame Characteristics​



C.8.19.6.1​

U​

X-Ray Field of View​



C.8.19.6.2​

M​

X-Ray Frame Pixel Data Properties​



C.8.19.6.4​

M​

X-Ray Frame Detector Parameters​



C.8.19.6.5​

U​

X-Ray Calibration Device Usage​



C.8.19.6.6​

U​

X-Ray Frame Acquisition​



C.8.19.6.8​

U​

X-Ray Collimator​



C.8.19.6.12​

M​

Breast X-Ray Positioner​



C.8.31.2​

C - Required if X-Ray Source moves relative​







to the Patient. May be present otherwise.​

Breast X-Ray Detector​



C.8.31.3​

C - Required if X-Ray Detector plane is not​







normal to the X-Ray beam vector. May be​







present otherwise.​

Breast X-Ray Geometry​



C.8.31.4​

M​

Breast X-Ray Acquisition Dose​



C.8.31.5​

M​

Breast X-Ray Isocenter Reference System​

C.8.31.6​

M​

X-Ray Grid​



C.8.31.7​

U​

X-Ray Filter​



C.8.31.8​

U​

A.74.4.1BreastProjectionX-RayImageFunctionalGroupMacrosContentConstraints​

A.74.4.1.1 Frame Anatomy Functional Group Macro​

The Defined CID for the Anatomic Region Sequence (0008,2218) shall be CID 4013 “Anatomic Region for Mammography”.​

A.75 Parametric Map IOD​

A.75.1 Parametric Map IOD Description​

The Parametric Map Information Object Definition (IOD) specifies a multi-frame image representing pixels with real world values.​ Parametric Maps are either integer or floating point.​

The Parametric Map IOD does not include the full set of acquisition parameters of any acquired images from which they were derived,​ e.g., cardiac phase. An application rendering or processing the Parametric Map may need to access the source images for such in-​ formation.​

The Parametric Map IOD requires the presence of VOI LUT (window) information with the intent that at a minimum the image be​ renderable without special processing. The output space is defined as P-Values to achieve consistency.​

- Standard -​

DICOM PS3.3 2020a - Information Object Definitions​

Page 405​

Note​

•​The VOI LUT mechanism specifically supports floating point values, and there is no expectation that it be limited to integer​ input or output ranges.​

•​Even though the output of the VOI LUT is not constrained to be integer values, implicit scaling of the output range to the​ input range of an integer-based Palette Color LUT can be used to apply pseudo-color for display. Pseudo-color mapping​ information may be encoded with the image. This may be applied at the discretion of the receiving application or it may​ use a separate DICOM Color Palette IOD or some other mechanism.​

TheParametricMapIODencodesoneormoreparametersasanimage.OtherImageIODsmaybeusedtoencoderelatedinformation,​ and instances of them may be referenced from the Parametric Map, as the source from which a parameter was derived, or some​ other relationship.​

Note​

•​The Blending Presentation State IOD may be used to describe how (selected frames of) a Parametric Map instance may​ besuperimposedon,say,framesofacquiredimagesforanatomicalreferenceencodedasinstancesofotherImageIODs,​ as well as the relative opacity and pseudo-color applicable to the overlying frames.​

•​Commonality of the same Frame of Reference UID also allows an application to relate Parametric Map instances and​ other Image instances, in the absence of explicit references.​

•​The Parametric Map IOD is not restricted to encoding only a single parameter in one instance. Since it is a multi-frame​ object, and since the type of parameter is encoded in the Real World Value Mapping Functional Group Macro, which may​ vary on a per-frame basis, the parameter may also vary from frame-to-frame. In such cases, the Multi-frame Dimension​ Module may be used to highlight this, by specifying the Quantity Definition Sequence (0040,9220) as a Dimension Index.​

A.75.2 Parametric Map IOD Entity-Relationship Model​

This IOD uses the E-R Model in Section A.1.2, with only the Image IE below the Series IE.​

A.75.3 Parametric Map IOD Module Table​

Table A.75-1. Parametric Map IOD Modules​

IE​

Module​

Reference​

Usage​

Patient​

Patient​

C.7.1.1​

M​



Clinical Trial Subject​

C.7.1.3​

U​

Study​

General Study​

C.7.2.1​

M​



Patient Study​

C.7.2.2​

U​



Clinical Trial Study​

C.7.2.3​

U​

Series​

General Series​

C.7.3.1​

M​



Parametric Map Series​

C.8.32.1​

M​



Clinical Trial Series​

C.7.3.2​

U​

Frame of​ Frame of Reference​

C.7.4.1​

M​

Reference​Synchronization​

C.7.4.2​

U​

Equipment​General Equipment​

C.7.5.1​

M​



Enhanced General Equipment​

C.7.5.2​

M​

Image​

General Image​

C.7.6.1​

M​



General Reference​

C.12.4​

U​



Image Pixel​

C.7.6.3​

C - Required if integer pixels​



Floating Point Image Pixel​

C.7.6.24​

C - Required if 32 bit floating point pixels​



Double Floating Point Image Pixel​

C.7.6.25​

C - Required if 64 bit floating point pixels​

- Standard -​
