Page 396​

DICOM PS3.3 2020a - Information Object Definitions​

NostandardmechanismisprovidedforinclusionofannotationswithintheimageSOPInstanceitself,andimplementersarediscouraged​ from using private extensions to circumvent this restriction.​

Grayscale Softcopy Presentation State Storage Instances that are generated during conversion shall be referenced from the Image​ SOP Instance by using the Referenced Grayscale Presentation State Sequence in the Enhanced CT Image Module. See Sec-​ tion C.8.15.2.​

Note​

The Curve Module (Retired) has been retired from DICOM. It is still not permitted to be present. See PS3.3-2004.​

A.70.4 Legacy Converted Enhanced CT Image Functional Group Macros​

Table A.70-2 specifies the use of the Functional Group Macros used in the Multi-frame Functional Groups Module for the Legacy​ Converted Enhanced CT Image IOD.​

Table A.70-2. Legacy Converted Enhanced CT Image Functional Group Macros​

Functional Group Macro​

Section​

Usage​

Pixel Measures​

C.7.6.16.2.1​

M​

Frame Content​

C.7.6.16.2.2​

M - May not be used as a Shared Functional Group.​

Plane Position (Patient)​

C.7.6.16.2.3​

M​

Plane Orientation (Patient)​

C.7.6.16.2.4​

M​

Referenced Image​

C.7.6.16.2.5​

C - Required if Referenced Image Sequence (0008,1140)​





was present in any of the Classic Images that were​





converted.​

Derivation Image​

C.7.6.16.2.6​

C - Required if Source Image Sequence (0008,2112) was​





present in any of the Classic Images that were converted.​

Cardiac Synchronization​

C.7.6.16.2.7​

U​

Frame Anatomy​

C.7.6.16.2.8​

C-RequiredifBodyPartExamined(0018,0015)ispresent​





andcontainsavaluedefinedinAnnexL“Correspondence​





of Anatomic Region Codes and Body Part Examined​





DefinedTerms”inPS3.16,orAnatomicRegionSequence​





(0008,2218)waspresentinanyoftheClassicImagesthat​





were converted.​

Frame VOI LUT​

C.7.6.16.2.10​

M​

Contrast/Bolus Usage​

C.7.6.16.2.12​

U​

Respiratory Synchronization​

C.7.6.16.2.17​

U​

Irradiation Event Identification​

C.7.6.16.2.18​

C - Required if Irradiation Event UID (0008,3010) was​





present in any of the Classic Images that were converted.​

CT Image Frame Type​

C.8.15.3.1​

M​

CT Pixel Value Transformation​

C.8.15.3.10​

M​

Temporal Position​

C.7.6.16.2.23​

U​

UnassignedSharedConvertedAttributes​C.7.6.16.2.25.1​

M - May not be used as a Per-Frame Functional Group​

Unassigned Per-Frame Converted​

C.7.6.16.2.25.2​

M - May not be used as a Shared Functional Group​

Attributes​





Image Frame Conversion Source​

C.7.6.16.2.25.3​

C - Required if created by conversion from a DICOM​





source; may not be used as a Shared Functional Group​

- Standard -​

DICOM PS3.3 2020a - Information Object Definitions​

Page 397​

A.71 Legacy Converted Enhanced MR Image IOD​

A.71.1 Legacy Converted Enhanced MR Image IOD Description​

The Legacy Converted Enhanced Magnetic Resonance (MR) Image Information Object Definition (IOD) specifies an image that has​ been converted from images originally created by a magnetic resonance imaging device.​

A.71.2 Legacy Converted Enhanced MR Image IOD Entity-Relationship Model​

This IOD uses the E-R Model in Section A.1.2, with only the Image IE below the Series IE.​

A.71.3 Legacy Converted Enhanced MR Image IOD Module Table​

Table A.71-1 specifies the Modules of the Legacy Converted Enhanced MR Image IOD.​

Table A.71-1. Legacy Converted Enhanced MR Image IOD Modules​

IE​

Module​

Reference​

Usage​

Patient​

Patient​

C.7.1.1​

M​



Clinical Trial Subject​

C.7.1.3​

U​

Study​

General Study​

C.7.2.1​

M​



Patient Study​

C.7.2.2​

U​



Clinical Trial Study​

C.7.2.3​

U​

Series​

General Series​

C.7.3.1​

M​



MR Series​

C.8.13.6​

M​



Clinical Trial Series​

C.7.3.2​

U​

Frame of​ Frame of Reference​

C.7.4.1​

M​

Reference​Synchronization​

C.7.4.2​

U​

Equipment​General Equipment​

C.7.5.1​

M​



Enhanced General Equipment​

C.7.5.2​

U​

Image​

Image Pixel​

C.7.6.3​

M​



Contrast/Bolus​

C.7.6.4​

U​



Enhanced Contrast/Bolus​

C.7.6.4b​

U​



Multi-frame Functional Groups​

C.7.6.16​

M​



Multi-frame Dimension​

C.7.6.17​

U​



Cardiac Synchronization​

C.7.6.18.1​

U​



Respiratory Synchronization​

C.7.6.18.2​

U​



Bulk Motion Synchronization​

C.7.6.18.3​

U​



Acquisition Context​

C.7.6.14​

M​



Device​

C.7.6.12​

U​



Specimen​

C.7.6.22​

U​



Enhanced MR Image​

C.8.13.1​

M​



SOP Common​

C.12.1​

M​



Common Instance Reference​

C.12.2​

U​



Frame Extraction​

C.12.3​

C - Required if the SOP​







Instance was created in​







response to a Frame-Level​







retrieve request​

- Standard -​

Page 398​

DICOM PS3.3 2020a - Information Object Definitions​

A.71.3.1 Legacy Converted Enhanced MR Image IOD Content Constraints​

The General Image Module, Overlay Plane Module, VOI LUT Module, Supplemental Palette Color Lookup Table Module and​ Graphic Annotation Module shall not be used in a Standard Extended SOP Class of the Legacy Converted Enhanced MR Image.​

Note​

In order to annotate images, whether during acquisition or subsequently, SOP Instances of the Grayscale Softcopy​ Presentation State Storage or the Structured Report Storage SOP Classes that reference the image SOP Instance, may be​ used.​

NostandardmechanismisprovidedforinclusionofannotationswithintheimageSOPInstanceitself,andimplementersarediscouraged​ from using private extensions to circumvent this restriction.​

Grayscale Softcopy Presentation State Storage Instances that are generated during conversion shall be referenced from the Image​ SOP Instance by using the Referenced Grayscale Presentation State Sequence in the Enhanced MR Image Module. See Sec-​ tion C.8.15.2.​

Note​

The Curve Module (Retired) has been retired from DICOM. It is still not permitted to be present. See PS3.3-2004.​

A.71.4 Legacy Converted Enhanced MR Image Functional Group Macros​

Table A.71-2 specifies the use of the Functional Group Macros used in the Multi-frame Functional Groups Module for the Legacy​ Converted Enhanced MR Image IOD.​

Table A.71-2. Legacy Converted Enhanced MR Image Functional Group Macros​

Functional Group Macro​

Section​

Usage​

Pixel Measures​

C.7.6.16.2.1​

M​

Frame Content​

C.7.6.16.2.2​

M - May not be used as a Shared Functional Group.​

Plane Position (Patient)​

C.7.6.16.2.3​

M​

Plane Orientation (Patient)​

C.7.6.16.2.4​

M​

Referenced Image​

C.7.6.16.2.5​

C-RequiredifReferencedImageSequence(0008,1140)​





was present in any of the Classic Images that were​





converted.​

Derivation Image​

C.7.6.16.2.6​

C - Required if Source Image Sequence (0008,2112)​





was present in any of the Classic Images that were​





converted.​

Cardiac Synchronization​

C.7.6.16.2.7​

U​

Frame Anatomy​

C.7.6.16.2.8​

C - Required if Body Part Examined (0018,0015) is​





present and contains a value defined in Annex L​





“Correspondence of Anatomic Region Codes and Body​





Part Examined Defined Terms” in PS3.16, or Anatomic​





RegionSequence(0008,2218)waspresentinanyofthe​





Classic Images that were converted.​

Pixel Value Transformation​

C.7.6.16.2.9​

U​

Frame VOI LUT​

C.7.6.16.2.10​

U​

Real World Value Mapping​

C.7.6.16.2.11​

U​

Contrast/Bolus Usage​

C.7.6.16.2.12​

U​

Respiratory Synchronization​

C.7.6.16.2.17​

U​

MR Image Frame Type​

C.8.13.5.1​

M​

Temporal Position​

C.7.6.16.2.23​

U​

- Standard -​



DICOM PS3.3 2020a - Information Object Definitions​

Page 399​

Functional Group Macro​

Section​



Usage​

Unassigned Shared Converted Attributes​C.7.6.16.2.25.1​

M - May not be used as a Per-Frame Functional Group​

Unassigned Per-Frame Converted​

C.7.6.16.2.25.2​

M - May not be used as a Shared Functional Group​

Attributes​







Image Frame Conversion Source​

C.7.6.16.2.25.3​

C - Required if created by conversion from a DICOM​





source; may not be used as a Shared Functional Group​

A.72 Legacy Converted Enhanced PET Image IOD​

A.72.1 Legacy Converted Enhanced PET Image IOD Description​

TheLegacyConvertedEnhancedPositronEmissionTomography(PET)ImageInformationObjectDefinition(IOD)specifiesanimage​ that has been converted from images originally created by a positron emission tomography coincidence imaging device.​

A.72.2 Legacy Converted Enhanced PET Image IOD Entity-Relationship Model​

This IOD uses the E-R Model in Section A.1.2, with only the Image IE below the Series IE.​

A.72.3 Legacy Converted Enhanced PET Image IOD Module Table​

Table A.72-1 specifies the Modules of the Legacy Converted Enhanced PET Image IOD.​

Table A.72-1. Legacy Converted Enhanced PET Image IOD Modules​

IE​

Module​

Reference​

Usage​

Patient​

Patient​

C.7.1.1​

M​



Clinical Trial Subject​

C.7.1.3​

U​

Study​

General Study​

C.7.2.1​

M​



Patient Study​

C.7.2.2​

U​



Clinical Trial Study​

C.7.2.3​

U​

Series​

General Series​

C.7.3.1​

M​



Enhanced PET Series​

C.8.22.1​

M​



Clinical Trial Series​

C.7.3.2​

U​

Frame of​ Frame of Reference​

C.7.4.1​

M​

Reference​Synchronization​

C.7.4.2​

U​

Equipment​General Equipment​

C.7.5.1​

M​



Enhanced General Equipment​

C.7.5.2​

U​

Image​

Image Pixel​

C.7.6.3​

M​



Intervention​

C.7.6.13​

U​



Acquisition Context​

C.7.6.14​

M​



Multi-frame Functional Groups​

C.7.6.16​

M​



Multi-frame Dimension​

C.7.6.17​

U​



Cardiac Synchronization​

C.7.6.18.1​

U​



Respiratory Synchronization​

C.7.6.18.2​

U​



Specimen​

C.7.6.22​

U​



Enhanced PET Image​

C.8.22.3​

M​



SOP Common​

C.12.1​

M​



Common Instance Reference​

C.12.2​

U​

- Standard -​

Page 400​

DICOM PS3.3 2020a - Information Object Definitions​



IE​

Module​

Reference​

Usage​

Frame Extraction​



C.12.3​

C - Required if the SOP​







Instance was created in​







response to a Frame-Level​







retrieve request​

A.72.3.1 Legacy Converted Enhanced PET Image IOD Content Constraints​

The General Image Module, Overlay Plane Module, VOI LUT Module, Supplemental Palette Color Lookup Table Module and​ Graphic Annotation Module shall not be used in a Standard Extended SOP Class of the Legacy Converted Enhanced PET Image.​

Note​

In order to annotate images, whether during acquisition or subsequently, SOP Instances of the Grayscale Softcopy​ Presentation State Storage or the Structured Report Storage SOP Classes that reference the image SOP Instance, may be​ used.​

NostandardmechanismisprovidedforinclusionofannotationswithintheimageSOPInstanceitself,andimplementersarediscouraged​ from using private extensions to circumvent this restriction.​

Grayscale Softcopy Presentation State Storage Instances that are generated during conversion shall be referenced from the Image​ SOP Instance by using the Referenced Grayscale Presentation State Sequence in the Enhanced PET Image Module. See Sec-​ tion C.8.15.2.​

Note​

The Curve Module (Retired) has been retired from DICOM. It is still not permitted to be present. See PS3.3-2004.​

A.72.4 Legacy Converted Enhanced PET Image Functional Group Macros​

Table A.72-2 specifies the use of the Functional Group Macros used in the Multi-frame Functional Groups Module for the Legacy​ Converted Enhanced PET Image IOD.​

Table A.72-2. Legacy Converted Enhanced PET Image Functional Group Macros​

Functional Group Macro​

Section​

Usage​

Pixel Measures​

C.7.6.16.2.1​

M​

Frame Content​

C.7.6.16.2.2​

M - May not be used as a Shared Functional Group.​

Plane Position (Patient)​

C.7.6.16.2.3​

M​

Plane Orientation (Patient)​

C.7.6.16.2.4​

M​

Referenced Image​

C.7.6.16.2.5​

C - Required if Referenced Image Sequence (0008,1140)​





was present in any of the Classic Images that were​





converted.​

Derivation Image​

C.7.6.16.2.6​

C - Required if Source Image Sequence (0008,2112) was​





present in any of the Classic Images that were converted.​

Cardiac Synchronization​

C.7.6.16.2.7​

U​

Frame Anatomy​

C.7.6.16.2.8​

C-RequiredifBodyPartExamined(0018,0015)ispresent​





andcontainsavaluedefinedinAnnexL“Correspondence​





of Anatomic Region Codes and Body Part Examined​





Defined Terms” in PS3.16, or Anatomic Region Sequence​





(0008,2218)waspresentinanyoftheClassicImagesthat​





were converted.​

Pixel Value Transformation​

C.7.6.16.2.9​

M​

Frame VOI LUT​

C.7.6.16.2.10​

M​

Real World Value Mapping​

C.7.6.16.2.11​

U​

- Standard -​
