DICOM PS3.3 2020a - Information Object Definitions​

Page 411​

IE​

Module​

Reference​

Usage​



Frame Extraction​



C.12.3​

C - Required if the SOP Instance was​







created in response to a Frame-Level​







retrieve request​



A.77.4 Wide Field Ophthalmic Photography 3D Coordinates Image IOD Content Constraints​

The following constraints on Series and Image Attributes take precedence over the descriptions given in the Module Attribute Tables.​

A.77.4.1 Bits Allocated, Bits Stored, and High Bit​

These Attributes shall be determined based upon the Photometric Interpretation (0028,0004) :​



Photometric Interpretation (0028,0004)​

BitsAllocated(0028,0100)​Bits Stored (0028,0101)​High Bit (0028,0102)​

MONOCHROME2​

8​

8​

7​



16​

16​

15​

RGB​

8​

8​

7​

YBR_FULL_422​







YBR_PARTIAL_420​







YBR_ICT​

YBR_RCT​

A.77.4.2 Contrast/Bolus Agent Sequence​

For Contrast/Bolus Agent Sequence (0018,0012), the defined CID 4200 “Ophthalmic Imaging Agent” shall be used.​

A.77.4.3 ICC Profile Module​

The ICC Profile Module shall be present for color images. If the color space to be used is not calibrated (i.e., a device-specific ICC​ Input Profile is not available), then an ICC Input Profile specifying a well-known space (such as sRGB) may be specified.​

A.78 Tractography Results IOD​

A.78.1 Tractography Results IOD Description​

TheTractographyResultsIODencodestractographyresultsintoacollectionoftracksets.Atracksetcollectsasetoftrackscontaining​ the set of x, y and z coordinates of each point making up the track. Additional quantities like Fractional Anisotropy values, color, de-​ scriptive statistical values, etc. may be associated with track set, track or point.​

A.78.2 Tractography Results IOD Entity-Relationship Model​

This IOD uses the E-R Model in Section A.1.2, with only the Tractography Results IE below the Series IE.​

A.78.3 Tractography Results IOD Module Table​

Table A.78-1 specifies the Modules of the Tractography Results IOD.​

Table A.78-1. Tractography Results IOD Modules​

IE​

Module​

Reference​

Usage​

Patient​

Patient​

C.7.1.1​

M​



Clinical Trial Subject​

C.7.1.3​

U​

- Standard -​

Page 412​

DICOM PS3.3 2020a - Information Object Definitions​



IE​

Module​

Reference​

Usage​

Study​

General Study​

C.7.2.1​

M​



Patient Study​

C.7.2.2​

U​



Clinical Trial Study​

C.7.2.3​

U​

Series​

General Series​

C.7.3.1​

M​



Tractography Results Series​

C.8.33.1​

M​



Clinical Trial Series​

C.7.3.2​

U​

Frame of​

Frame of Reference​

C.7.4.1​

M​

Reference​







Equipment​

General Equipment​

C.7.5.1​

M​



Enhanced General Equipment​

C.7.5.2​

M​

Tractography​

Tractography Results​

C.8.33.2​

M​

Results​

Specimen​

C.7.6.22​

U​





Common Instance Reference​

C.12.2​

M​



SOP Common​

C.12.1​

M​

A.79 RT Brachy Application Setup Delivery Instruction IOD​

A.79.1 RT Brachy Application Setup Delivery Instruction IOD Description​

InordertodeliveraBrachytherapytreatmentfractiondescribedinanRTPlanIOD,theRTBrachyApplicationSetupDeliveryInstruction​ IOD describes which part of the RT Plan is to be delivered and contains additional parameters. This information is supplied by a​ Treatment Management System (TMS) when it creates an RT Brachy Application Setup Delivery Instruction SOP instance which is​ referenced by a Unified Procedure Step (UPS) in the Unified Worklist and Procedure Step model.​

A.79.2 RT Brachy Application Setup Delivery Instruction IOD Entity-Relationship Model​

ThisIODusestheE-RModelinSectionA.1.2,withonlythePlanIEbelowtheSeriesIE.TheFrameofReferenceIEisnotacomponent​ of this IOD.​

A.79.3 RT Brachy Application Setup Delivery Instruction IOD Module Table​

Table A.79.3-1 specifies the Modules of the RT Brachy Application Setup Delivery Instruction IOD.​

Table A.79.3-1. RT Brachy Application Setup Delivery Instruction IOD Modules​

IE​

Module​

Reference​

Usage​

Patient​

Patient​

C.7.1.1​

M​



Clinical Trial Subject​

C.7.1.3​

U​

Study​

General Study​

C.7.2.1​

M​



Patient Study​

C.7.2.2​

U​



Clinical Trial Study​

C.7.2.3​

U​

Series​

General Series​

C.7.3.1​

M​



Clinical Trial Series​

C.7.3.2​

U​

Equipment​

General Equipment​

C.7.5.1​

M​



Enhanced General Equipment​

C.7.5.2​

M​

Plan​

RT Brachy Application Setup Delivery Instruction​

C.8.8.30​

M​



Common Instance Reference​

C.12.2​

M​



General Reference​

C.12.4​

U​

- Standard -​



DICOM PS3.3 2020a - Information Object Definitions​

Page 413​

IE​

Module​

Reference​

Usage​

SOP Common​



C.12.1​

M​

A.79.4 RT Brachy Application Setup Delivery Instruction IOD Content Constraints​

A.79.4.1 Modality​

The value of modality (0008,0060) shall be PLAN.​

A.80 Volumetric Presentation State Information Object Definitions​

A.80.1 Planar MPR Volumetric Presentation State IOD​

A.80.1.1 Planar MPR Volumetric Presentation State IOD Description​

The Planar MPR Volumetric Presentation State Information Object Definition (IOD) specifies information that defines a Planar MPR​ presentation from volume datasets that are referenced from within the IOD.​

It includes capabilities for specifying:​

a.​spatial registration of the input datasets​

b.​cropping of the volume datasets by a bounding box, oblique planes and segmentation objects​

c.​the generation geometry of thin and slab Multi-Planar Reconstructions​

d.​the method for rendering slab Multi-Planar Reconstructions​

e.​scalar to P-Value or RGB Value conversions​

f.​ compositing of multiple renderings​

g.​clinical description of the specified view​

h.​volume and display relative annotations, including graphics, text and overlays​

i.​ membership in a collection of related Volumetric Presentation States intended to be processed or displayed together​

j.​ the temporal position within a set of temporally related Volumetric Presentation States​

k.​recommendations for animating the view​

l.​ reference to an image depicting the view described by the Presentation State​

The Planar MPR Volumetric Presentation State IOD is used in two SOP Classes as defined in PS3.4 Storage Service Class, a SOP​ ClassforgrayscalePresentationStatesintendedforpresentingasingleinput,andaSOPClassforPresentationStatesthatcomposite​ multiple inputs into a single presentation. These are distinguished by their SOP Class UID and by the Enumerated Value of the​ mandatory Attribute in the MPR Volumetric Presentation State Display Module, Pixel Presentation (0008,9205).​

A.80.1.2 Volumetric Presentation State IOD Entity-Relationship Model​

This IOD uses the E-R Model in Section A.1.2, with only the Presentation State IE below the Series IE.​

A.80.1.3 Planar MPR Volumetric Presentation State IOD Module Table​

Table A.80.1-1 specifies the Modules of the Planar MPR Volumetric Presentation State IOD.​

- Standard -​

Page 414​ DICOM PS3.3 2020a - Information Object Definitions​

Table A.80.1-1. Planar MPR Volumetric Presentation State IOD Modules​

IE​

Module​

Reference​

Usage​

Patient​

Patient​

C.7.1.1​

M​



Clinical Trial Subject​

C.7.1.3​

U​

Study​

General Study​

C.7.2.1​

M​



Patient Study​

C.7.2.2​

U​



Clinical Trial Study​

C.7.2.3​

U​

Series​

General Series​

C.7.3.1​

M​



Clinical Trial Series​

C.7.3.2​

U​



Presentation Series​

C.11.9​

M​

Frame of​

Frame of Reference​

C.7.4.1​

M​

Reference​







Equipment​ General Equipment​

C.7.5.1​

M​



Enhanced General Equipment​

C.7.5.2​

M​

Presentation​Volumetric Presentation State Identification​

C.11.22​

M​

State​

Volumetric Presentation State Relationship​

C.11.23​

M​





Volume Cropping​

C.11.24​

C - Required if Global Crop​







(0070,120B) or any value of Crop​







(0070,1204) is YES​



Presentation View Description​

C.11.25​

M​



Multi-Planar Reconstruction Geometry​

C.11.26​

M​



MPR Volumetric Presentation State Display​

C.11.27​

M​



Volumetric Graphic Annotation​

C.11.28​

U​



Graphic Annotation​

C.10.5​

U​



Graphic Layer​

C.10.7​

C - Required if Graphic Layer​







(0070,0002) is present in the​







Volumetric Graphic Annotation​







Module or the Graphic Annotation​







Module​



Graphic Group​

C.10.11​

U​



Presentation Animation​

C.11.29​

U​



SOP Common​

C.12.1​

M​



Common Instance Reference​

C.12.2​

M​

A.80.1.4 Planar MPR Volumetric Presentation State IOD Content Constraints​

A.80.1.4.1 Presentation Input Restrictions​

Presentation Input Type (0070,1202) shall have a value of VOLUME.​

If the value of Pixel Presentation (0008,9205) is MONOCHROME, the Volumetric Presentation State Input Sequence (0070,1201)​ shall have only a single Item.​

A.80.1.4.2 Multi-Planar Reconstruction Style​

Multi-Planar Reconstruction Style (0070,1501) shall have a value of PLANAR.​

- Standard -​

DICOM PS3.3 2020a - Information Object Definitions​

Page 415​

A.80.1.4.3 Graphic Annotation Module​

The following Attributes, if present, shall have a value of DISPLAY:​

•​Bounding Box Annotation Units (0070,0003)​

•​Anchor Point Annotation Units (0070,0004)​

•​Graphic Annotation Units (0070,0005)​

•​Compound Graphic Units (0070,0282)​

The Display coordinates are relative to the Volumetric Presentation View produced by this Presentation State.​

Note​

See Annex XXX “Volumetric Presentation States (Informative)” in PS3.17 for guidance on usage of the graphic annotation​ styles available in this IOD.​

A.80.1.4.4 Volume Cropping Module​

The values of Volume Cropping Method (0070,1302) shall be selected from the following:​

Enumerated Values:​

BOUNDING_BOX​

OBLIQUE_PLANES​

INCLUDE_SEG​

EXCLUDE_SEG​

A.80.1.4.5 Volumetric Presentation State Reference Coordinate System​

All SOP Instances referenced in the Volumetric Presentation State Relationship Module shall be registered to the Volumetric​ Presentation State Reference Coordinate System. See Section C.11.23.3.​

A.80.2 Volume Rendering Volumetric Presentation State IOD​

A.80.2.1 Volume Rendering Volumetric Presentation State IOD Description​

The Volume Rendering Volumetric Presentation State Information Object Definition (IOD) specifies information that defines a Volume​ Rendering presentation from volume datasets that are referenced from within the IOD.​

It includes capabilities for specifying:​

a.​spatial registration of the input datasets​

b.​cropping of the volume datasets by a bounding box, oblique planes and segmentation objects​

c.​the generation geometry of volume rendered reconstruction​

d.​shading models​

e.​scalar to RGB conversions​

f.​ compositing of multiple volume streams and one volume stream with segmentations​

g.​clinical description of the specified view​

h.​volume-relative and display-relative annotations, including graphics, text and overlays plus optional references to structured​ content providing clinical context to annotations.​

i.​ membership in a collection of related Volumetric Presentation States intended to be processed or displayed together​

- Standard -​
