DICOM PS3.3 2020a - Information Object Definitions​

Page 1521​

Attribute Name​

Tag​

Type​

Attribute Description​

Implant Assembly Template​

(0076,0006)​

2​

The version code of the Implant Assembly Template.​

Version​

Replaced Implant Assembly​

(0076,0008)​

1C​

Reference to the Implant Assembly Template that is replaced​

Template Sequence​

by this Instance.​

Only a single Item shall be included in this Sequence.​

Required if the Instance replaces another Instance.​

Implant Assembly Template​

(0076,000A)​

1​

Indicates whether the Implant Assembly Template is derived​

Type​

from another Instance.​

Enumerated Values:​

ORIGINAL​

DERIVED​

Original Implant Assembly​

(0076,000C)​

1C​

Reference to the Implant Assembly Template Instance with​

Template Sequence​

ImplantAssemblyTemplateType(0076,000A)ORIGINALfrom​

which this Instance was ultimately derived.​

Only a single Item shall be included in this Sequence.​

Required if Implant Assembly Template Type (0076,000A) is​

DERIVED.​

Derivation Implant Assembly​

(0076,000E)​

1C​

Reference to the Implant Template Instance from which this​

Template Sequence​

Instance was directly derived.​

Only a single Item shall be included in this Sequence.​

Required if Implant Assembly Template Type (0076,000A) is​

DERIVED.​

Implant Assembly Template​

(0076,0010)​

1​

Identifies the anatomical region the implant assembly is to be​

Target Anatomy Sequence​

implanted to.​

One or more Items shall be included in this Sequence.​

>Anatomic Region Sequence​

(0008,2218)​

1​

Sequence that identifies the anatomic region of interest in this​

Instance (i.e., external anatomy, surface anatomy, or general​

region of the body).​

Only a single Item shall be included in this Sequence.​

DCID 7304 “Implant Target Anatomy”.​

ProcedureTypeCodeSequence​

(0076,0020)​

1​

Coded description of the procedure by which the assembly is​

implanted.​

One or more Items shall be included in this Sequence.​

>Include Table 8.8-1 “Code Sequence Macro Attributes”​

BCID 7301 “Intervention Types”.​

Surgical Technique​

(0076,0030)​

3​

Thesurgicaltechniqueassociatedwiththisassemblytemplate.​

MIME Type of Encapsulated​

(0042,0012)​

2​

Thetypeoftheencapsulateddocumentstreamdescribedusing​

Document​

the MIME Media Type (see RFC 2046).​

Page 1522​

Attribute Name​

Tag​

Type​

Attribute Description​

Encapsulated Document​

(0042,0011)​

2​

Encapsulated Document stream, containing a document​

encoded according to the MIME Type.​

PDF description of the surgical technique.​

Component Types Sequence​

(0076,0032)​

1​

Sets of components of which the assembly is constructed.​

One or more Items shall be included in this Sequence.​

>Component Type Code​

(0076,0034)​

1​

Label assigned to that type of component.​

Sequence​

Only a single Item shall be included in this Sequence.​

>>Include Table 8.8-1 “Code Sequence Macro Attributes”​

BCID 7307 “Implant Component Types”.​

>Exclusive Component Type​

(0076,0036)​

1​

Indicates that only one component of this Component Type​

shall be used in an assembly.​

Defined Terms:​

YES​

NO​

>Mandatory Component Type​

(0076,0038)​

1​

Indicates that at least one component of this Component Type​

has to be used in an assembly.​

Defined Terms:​

YES​

NO​

>Component Sequence​

(0076,0040)​

1​

References to implant template components used in the​

assembly.​

One or more Items shall be included in this Sequence.​

>>Include Table 10-11 “SOP Instance Reference Macro Attributes”​

>>Component ID​

(0076,0055)​

1​

Numeric ID of the Implant Template. Uniquely identifies the​

Implant Template within the SOP instance.​

The value shall start at 1, and increase monotonically by 1 for​

each Item.​

ComponentAssemblySequence​

(0076,0060)​

3​

Information about how to connect the implants from the​

component groups.​

One or more Items are permitted in this Sequence.​

See Section C.29.2.1.1.1 for details.​

>Component 1 Referenced ID​

(0076,0070)​

1​

Value of Component ID (0076,0055) present in Component​

Sequence (0076,0040) that contains the assembly implant​

components.​

The ID selects the first component of the connection.​

>Component 1 Referenced​

(0076,0080)​

1​

Value of the Mating Feature Set ID (0068,63C0) present in the​

Mating Feature Set ID​

Mating Feature Set Sequence (0068,63B0) that contains the​

Mating Feature Sets.​

DICOM PS3.3 2020a - Information Object Definitions​

Page 1523​

Attribute Name​

Tag​

Type​

Attribute Description​

>Component 1

Referenced​

(0076,0090)​

1​

Value of the Mating Feature ID (0068,63F0) present in the​

Mating Feature ID​

MatingFeatureSequence(0068,63E0)thatcontainstheMating​

Features.​

The ID selects the Mating Feature of the Mating Feature Set​

of the first component of the connection.​

>Component 2

Referenced ID​

(0076,00A0)​

1​

Value of Component ID (0076,0055) present in Component​

Sequence (0076,0040) that contains the assembly implant​

components.​

The ID selects the second component of the connection.​

>Component 2

Referenced​

(0076,00B0)​

1​

Value of the Mating Feature Set ID (0068,63C0) present in the​

Mating Feature Set ID​

Mating Feature Set Sequence (0068,63B0) that contains the​

Mating Feature Sets.​

TheIDselectstheMatingFeatureSetofthesecondcomponent​

of the connection.​

>Component 2

Referenced​

(0076,00C0)​

1​

Value of the Mating Feature ID (0068,63F0) present in the​

Mating Feature ID​

MatingFeatureSequence(0068,63E0)thatcontainstheMating​

Features.​

Page 1524​

DICOM PS3.3 2020a - Information Object Definitions​

Attribute Name​

Tag​

Type​

Attribute Description​

Implant Template Group Target​

(0078,0028)​

3​

Identifiestheanatomicalregiontheimplantistobeimplanted​

Anatomy Sequence​

to.​

One or more Items are permitted in this Sequence.​

>Anatomic Region Sequence​

(0008,2218)​

1​

Sequence that identifies the anatomic region of interest in​

this Instance (i.e., external anatomy, surface anatomy, or​

general region of the body).​

Only a single Item shall be included in this Sequence.​

>>Include Table 8.8-1 “Code Sequence Macro Attributes”​

DCID 7304 “Implant Target Anatomy”.​

Implant Template Group Members​

(0078,002A)​

1​

Contains references to all Implant Template SOP instances​

Sequence​

that are part of this group.​

One or more Items shall be included in this Sequence.​

>Implant Template Group Member​

(0078,002E)​

1​

Numeric ID of the Implant Template. Uniquely identifies the​

ID​

Implant Template within the Implant Template Group.​

The value shall start at 1, and increase monotonically by 1​

for each Item.​

>3D Implant Template Group​

(0078,0050)​

1C​

3D inter-component Matching Point. May be present if​

Member Matching Point​

Number of Surfaces (0066,0001) is present in the Instance​

referenced in the Implant Template Group Members​

Sequence (0078,002A) Item.​

See Section C.29.3.1.1.1​

>3D Implant Template Group​

(0078,0060)​

1C​

Direction cosines of the Matching Point.​

Member Matching Axes​

Required if 3D Implant Template Group Matching Point​

(0078,0050) is present.​

> Implant Template Group Member​

(0078,0070)​

1C​

One or more Items shall be included in this Sequence.​

Matching2DCoordinatesSequence​

May be present if HPGL Document Sequence (0068,62C0)​

ispresentintheInstancereferencedintheImplantTemplate​

Group Members Sequence (0078,002A) Item.​

See Section C.29.3.1.1.1​

>>Referenced HPGL Document ID​

(0068,6440)​

1​

ValueoftheHPGLDocumentID(0068,62D0)presentinthe​

HPGL Document Sequence (0068,62C0) of the Instance​

that is referenced in the Implant Template Group Members​

Sequence (0078,002A) Item.​

Shall be unique within the Sequence.​

>>2D Implant Template Group​

(0078,0090)​

1​

2D inter-component Matching Point.​

Member Matching Point​

See Section C.29.3.1.1.1.​

>>2D Implant Template Group​

(0078,00A0)​

1​

Direction cosines of the Matching Point.​

Member Matching Axes​

See Section C.29.3.1.1.1.​

Implant Template Group Variation​

(0078,00B0)​

1​

List of all Variation Dimensions that are covered by this​

Dimension Sequence​

group.​

DICOM PS3.3 2020a - Information Object Definitions​

Page 1525​

Attribute Name​

Tag​

Type​

Attribute Description​

>Implant Template Group Variation​

(0078,00B2)​

1​

Descriptive name of the variation dimension.​

Dimension Name​

>Implant Template Group Variation​

(0078,00B4)​

1​

Order in which the implant group members are sorted​

Dimension Rank Sequence​

according to this dimension.​

One or more Items shall be included in this Sequence.​

>> Referenced Implant Template​

(0078,00B6)​

1​

Value of the Implant Template Group Member ID​

Group Member ID​

(0078,002E)presentintheImplantTemplateGroupMember​

Sequence (0078,002A) that contains the Implant Template​

Group Member Items. Shall be unique within the Sequence.​

>>ImplantTemplateGroupVariation​

(0078,00B8)​

1​

TherankofthisImplantTemplateintheVariationDimension.​

Dimension Rank​

In one Implant Template Group Variation Dimension Rank​

Sequence there may be more than one Implant Templates​

with the same rank.​
