Page 1526​

DICOM PS3.3 2020a - Information Object Definitions​

ID1 ID2 ID3 ID4 ID5 ID6 ID7 ID8 ID9

Implant Template Group Member Sequence

Number of Holes

Rank

1

2

3

4

1











ID1

ID2





Length 2

ID3 ID4 ID5

3

ID6

ID7

ID8

ID9

Figure C.29.3.1.1.2-1. Implant Template Group for 2 Dimensions Example​

C.30 Unified Procedure Step Specific Modules​

The following Sections specify Modules used for Unified Procedure Steps.​

C.30.1 Unified Procedure Step Progress Information Module​

Table C.30.1-1 specifies the Attributes that describe the progress of a Unified Procedure Step (UPS).​

Table C.30.1-1. Unified Procedure Step Progress Information Module Attributes​

Attribute Name​

Tag​

Attribute Description​

Procedure Step State​

(0074,1000)​

State of the Procedure Step.​

Enumerated Values:​

SCHEDULED​

IN PROGRESS​

CANCELED​

COMPLETED​





See PS3.4 for details on Unified Procedure Step states.​

Progress Information Sequence​

(0074,1002)​

Information about work progress for the Procedure Step.​





Zero or one Item shall be included in this Sequence.​

- Standard -​

DICOM PS3.3 2020a - Information Object Definitions​

Page 1527​

Attribute Name​

Tag​

>Procedure Step Progress​

(0074,1004)​

>Procedure Step Progress​

(0074,1006)​

Description​



>Procedure Step Progress​

(0074,1007)​

Parameters Sequence​



>>Include Table 10-2 “Content Item Macro Attributes​ Description”​

>>Content Item Modifier Sequence​

(0040,0441)​

>>>Include Table 10-2 “Content Item Macro Attributes​ Description”​

>Procedure Step Communications​

(0074,1008)​

URI Sequence​



>>Contact URI​

(0074,100A)​

>>Contact Display Name​

(0074,100c)​

>Procedure Step Cancellation​

(0040,4052)​

DateTime​



>Reason For Cancellation​

(0074,1238)​

>Procedure Step Discontinuation​

(0074,100e)​

Reason Code Sequence​



>>Include Table 8.8-1 “Code Sequence Macro Attributes”​

Attribute Description​

Anumericalindicatorofprogressexpressedaspercentagecomplete.​

Note​

This is primarily for status rendering (e.g., progress bar).​ The percentage is not necessarily an accurate indication of​ total time.​

A textual description of progress.​

Note​

For example, it might contain "Annealing complete".​

Additional procedure-specific progress information provided by the​ performingdevicewhilethecurrentProcedureStepisbeingexecuted.​

One or more Items are permitted in this Sequence.​

No Baseline CIDs are defined for Concept Name Code Sequence​ or Concept Code Sequence.​

Sequence that specifies modifiers for a Procedure Step Progress​ Parameter.​

One or more Items are permitted in this Sequence.​

No Baseline CIDs are defined for Concept Name Code Sequence​ or Concept Code Sequence.​

ContactInformationtocommunicatewithperformersoftheProcedure​

Step.​

Zero or more Items shall be included in this Sequence.​

URI to communicate with performer of the procedure in progress.​ Any URI (telephone number, URL, etc.) is permitted.​

Note​

The VR of this Data Element has changed from UT to UR.​

Name of the person, department or organization to contact for more​ information about the performance of the Procedure Step.​

Date and Time at which the procedure step was discontinued.​

Atextualdescriptionofthereasonaprocedurestepwasdiscontinued.​

Coded Reason(s) for Discontinuing the Procedure Step.​

Zero or more Items shall be included in this Sequence.​

DCID 9300 “Procedure Discontinuation Reasons”.​

C.30.2 Unified Procedure Step Scheduled Procedure Information Module​

Table C.30.2-1 specifies the Attributes that describe the Unified Procedure Step (UPS) to be performed. The UPS may or may not​ be scheduled for a specific time or device, or may simply represent a piece of work that is intended to be performed.​

- Standard -​

Page 1528​ DICOM PS3.3 2020a - Information Object Definitions​

Table C.30.2-1. Unified Procedure Step Scheduled Procedure Information Module Attributes​

Attribute Name​

Tag​

Attribute Description​

ScheduledProcedureStepPriority​

(0074,1200)​

Priority of the scheduled Procedure Step​





Enumerated Values:​





HIGH​ used to indicate an urgent or emergent work item, equivalent​





to a STAT request.​





MEDIUM​used to indicate a work item that has a priority less than HIGH​





and higher than LOW. It can be used to further stratify work​





items.​





LOW​ used to indicate a routine or non-urgent work item.​

Scheduled Procedure Step​

(0040,4010)​

Date and time when the Scheduled Procedure Information was last​

Modification Date and Time​



modified or first created (whichever is most recent).​





Note​





This Attribute should be automatically updated by the worklist​





management system whenever any modification is made to​





Unified Procedure Step Scheduled Procedure Information​





Module Attributes of a Unified Procedure Step.​

Worklist Label​

(0074,1202)​

A label identifying the worklist to which the Procedure Step instance​





belongs.​

Procedure Step Label​

(0074,1204)​

A label describing the task of the Procedure Step in text appropriate for​





displaying in the user selection interface.​

Comments on the Scheduled​

(0040,0400)​

User-defined comments on the scheduled Procedure Step.​

Procedure Step​





Scheduled Station Name Code​

(0040,4025)​

Identifying names within the enterprise of the equipment for which the​

Sequence​



Procedure Step is scheduled. The names conveyed in Code Value​





(0008,0100) may be the same as the AE Titles, but do not have to be.​





Zero or more Items shall be included in this Sequence.​

>Include Table 8.8-1 “Code Sequence Macro Attributes”​ No Baseline CID is defined.​

Scheduled Station Class Code​

(0040,4026)​

Classes of the equipment for which the Procedure Step is scheduled.​

Sequence​



Zero or more Items shall be included in this Sequence.​





>Include Table 8.8-1 “Code Sequence Macro Attributes”​ No Baseline CID is defined.​

Scheduled Station Geographic​

(0040,4027)​

Geographic locations of the equipment for which the Procedure Step is​

Location Code Sequence​



scheduled.​





Zero or more Items shall be included in this Sequence.​

>Include Table 8.8-1 “Code Sequence Macro Attributes”​ No Baseline CID is defined.​

Scheduled Human Performers​

(0040,4034)​

Human performers that are scheduled to be involved or responsible for​

Sequence​



performing the Procedure Step.​





Zero or more Items shall be included in this Sequence.​

>Human Performer Code​

(0040,4009)​

Human performer that is involved or responsible for performing the​

Sequence​



Procedure Step.​





Only a single Item shall be included in this Sequence.​

>>Include Table 8.8-1 “Code Sequence Macro Attributes”​No Baseline CID is defined.​

>Human Performer's Name​

(0040,4037)​

Name of the human performer.​

- Standard -​



DICOM PS3.3 2020a - Information Object Definitions​

Page 1529​

Attribute Name​

Tag​



Attribute Description​



>HumanPerformer'sOrganization​

(0040,4036)​

Organization to which the human performer is accountable for the​





activities in the Procedure Step.​



Scheduled Procedure Step Start​

(0040,4005)​

Date and time at which the Procedure Step is scheduled to start.​

DateTime​









Expected Completion DateTime​

(0040,4011)​

DateandtimeatwhichtheProcedureStepisexpectedtobecompleted.​

Scheduled Procedure Step​

(0040,4008)​

Date and time after which the Procedure Step is meaningless or​

Expiration DateTime​



undesirable.​





Scheduled Workitem Code​

(0040,4018)​

Coded description of the Procedure Step.​



Sequence​



Only a single Item shall be included in this Sequence.​









>Include Table 8.8-1 “Code Sequence Macro Attributes”​ Baseline CID is CID 9231 “Workitem Definition”.​







Note​









ThisCIDhasgenericworkitems.Animplementationmaychoose​





to define more specific, detailed workitems.​



ScheduledProcessingParameters​

(0074,1210)​

Processing parameters to be used by the performing system when​

Sequence​



carrying out the Procedure Step.​







Zero or more Items shall be included in this Sequence.​



>Include Table 10-2 “Content Item Macro Attributes​







Description”​









>ContentItemModifierSequence​

(0040,0441)​

SequencethatspecifiesmodifiersforaScheduledProcessingParameter​





Content Item.​









One or more Items are permitted in this Sequence.​



>>Include Table 10-2 “Content Item Macro Attributes​







Description”​









Input Readiness State​

(0040,4041)​

Readiness state of the Input Information Sequence (0040,4021) and the​





referenced instances.​







Enumerated Values:​







INCOMPLETE​The Input Information Sequence is not yet complete​







and additional instance references might be added.​





UNAVAILABLE​The Input Information Sequence is complete but one​







or more of the referenced instances might not yet be​







available from the referenced source(s).​







READY​

The Input Information Sequence is complete and the​

referencedinstancesareavailablefromthereferenced​ sources.​

Note​

1.​If the Procedure Step does not require input information,​ the Input Readiness State may be READY when the Input​ Information Sequence is empty.​

2.​There is no guarantee that the referenced instances will​ still be available at the referenced location when retrieval​ is attempted.​

3.​There is no requirement to confirm the presence of​ referencedmediapriortosettingtheInputReadinessState​ to READY.​

- Standard -​

Page 1530​

DICOM PS3.3 2020a - Information Object Definitions​

Attribute Name​

Tag​

Attribute Description​

Input Information Sequence​

(0040,4021)​

References to Information Objects needed to perform the scheduled​





Procedure Step.​





Referencing unencapsulated HL7 documents is described further in​





Section C.12.1.1.6. See also Input Readiness State (0040,4041).​





Zero or more Items shall be included in this Sequence.​

>Include Table 10-3b “Referenced Instances and Access​



Macro Attributes”​





Study Instance UID​

(0020,000D)​

Unique Study identification that shall be used for the created Composite​





SOP Instances resulting from this Unified Procedure Step.​

Output Destination Sequence​

(0040,4070)​

The destination to which the performer is requested to store the output​





objects generated​

Zero or more Items shall be included in this Sequence.​

Each Item constitutes a separate storage request.​

Theperformingsystemmightnotsupporttherequestedstorageprotocol​ or not be configured for the desired destination. The performing system​ may, additionally or as a fallback, be configured to store output objects​ to a default destination or retain them locally.​

The actual location(s) to which instances are successfully stored is​ recorded in the Output Information Sequence (0040,4033).​

Whether to report failure of one or more of the storage requests as a​ failure of the work item is at the discretion of the performing system.​

>Include Table 10-3c “Storage Macro Attributes”​

C.30.3 Unified Procedure Step Performed Procedure Information Module​

Table C.30.3-1 specifies the Attributes that describe the performance and results of a Unified Procedure Step (UPS).​

Table C.30.3-1. Unified Procedure Step Performed Procedure Information Module Attributes​

Attribute Name​

Tag​

Attribute Description​

Unified Procedure Step Performed​

(0074,1216)​

Details of the Procedure Step as performed.​

Procedure Sequence​



Zero or one Item shall be included in this Sequence.​





>Actual Human Performers Sequence​

(0040,4035)​

Humanperformersthatare/wereactuallyinvolvedorresponsible​





for performing the Procedure Step.​





Zero or more Items shall be included in this Sequence.​





Note​





Initially this list will be empty. Items may be added to​





the list at or after the status transition of the Procedure​





Step State (0074,1000) to "IN PROGRESS"​

>>Human Performer Code Sequence​

(0040,4009)​

Human performer that is involved or responsible for performing​





the Procedure Step.​





Only a single Item shall be included in this Sequence.​

>>>Include Table 8.8-1 “Code Sequence Macro Attributes”​

No Baseline CID is defined.​

>>Human Performer's Name​

(0040,4037)​

Name of the human performer.​

- Standard -​

Смотрите также:

«ДОХОДЫ, РАСХОДЫ И ПРИБЫЛЬ КОММЕРЧЕСКОГО БАНКА.»
«ДОХОДЫ, РАСХОДЫ И ПРИБЫЛЬ КОММЕРЧЕСКОГО БАНКА.»
Значение, сущность и содержание социально — педагогической деятельности в организации для детей-сирот и детей, оставшихся без попечения родителей
__RGR2
__RGR2
_11_А. Франс для эл версии
_индив анализ данных
- Интерфейс 485 и оптопорт 11
:Конвергентный подход к проектированию дополнительных общеобразовательных общеразвивающих программ
