Page 1506​

DICOM PS3.3 2020a - Information Object Definitions​

Attribute Name​

Tag​

Type​

Attribute Description​

Surface Points Sequence​

(0066,0011)​

1​

The point positions representing vertices of the surface.​

Only one Item shall be included in the Sequence.​

>Include Table C.27-2 “Points Macro Attributes”​

>Segmented Property​

(0062,0003)​

3​

Sequencedefiningthegeneralcategoryofthepropertythesurface​

Category Code Sequence​

point set represents.​

Only a single Item is permitted in this Sequence.​

>>Include Table 8.8-1 “Code Sequence Macro Attributes”​

BCID 7150 “Segmentation Property Categories”.​

>Segmented Property Type​

(0062,000F)​

3​

Sequence defining the specific property the surface point set​

Code Sequence​

represents.​

Note​

"Property" is used in the sense of meaning "what the​

surface represents", whether it be a physical or biological​

object, be real or conceptual, having spatial, temporal or​

functionalextentornot.I.e.,itiswhatthesegment"is"(as​

opposed to some feature, attribute, quality, or​

characteristic of it, like color or shape or size).​

Only a single Item is permitted in this Sequence.​

>>Include Table 8.8-1 “Code Sequence Macro Attributes”​

No Baseline CID is defined.​

Surface Point Presentation​

(0080,0006)​

3​

Contains a vector of P-Values to assign a gray value to each point.​

Value Data​

The number of values shall be equal to the value of Number Of​

Surface Points (0066,0015) in the Points Macro.​

Each value shall correspond to the respective point in the Point​

Coordinates Data (0066,0016).​

Surface Point Color CIELab​

(0080,0007)​

3​

Contains a vector of color triplets to assign colors to each point.​

Value Data​

The number of triplets shall be equal to the value of Number Of​

Surface Points (0066,0015) in the Points Macro.​

Attribute Name​

Tag​

Type​

Attribute Description​

UV Mapping Sequence​

(0080,0008)​

1​

Maps each point of the Surface Points Sequence (0066,0011) in the​

Point Cloud Module or the Surface Mesh Module to the coordinates of​

a VL Photographic Image Instance.​

One or more Items shall be included in this Sequence.​

>Texture Label​

(0080,0009)​

1​

Contains a label that uniquely identifies this UV map to distinguish it​

from other Items in the Sequence.​

>U Value Data​

(0080,0010)​

1​

Contains a vector of column offsets. Each value is normalized to the​

range of 0.0 to 1.0 pointing in the pixel data of the referenced textures​

Sequence image. Each value shall correspond to the respective point​

in the Point Coordinates Data (0066,0016).​

ThenumberofvaluesmustbeequaltothenumberofpointsofthePoint​

Cloud or the Surface Mesh.​

>V Value Data​

(0080,0011)​

1​

Contains a vector of row offsets. Each value is normalized to the range​

of 0.0 to 1.0 pointing in the pixel data of the referenced textures​

Sequence image. Each value shall correspond to the respective point​

in the Point Coordinates Data (0066,0016).​

ThenumberofvaluesmustbeequaltothenumberofpointsofthePoint​

Cloud or the Surface Mesh.​

>Referenced Texture​

(0080,0012)​

1​

The image that is being mapped to the point cloud or the surface mesh.​

Sequence​

Only one Item shall be included in the Sequence.​

Page 1508​

DICOM PS3.3 2020a - Information Object Definitions​

Attribute Name​

Tag​

Type​

Attribute Description​

Manufacturer​

(0008,0070)​

1​

Name of the manufacturer that produces the implant.​

Frame of Reference UID​

(0020,0052)​

1​

Defines a 3D Frame of Reference for this component.​

Implant Name​

(0022,1095)​

1​

The (product) name of the implant.​

Implant Size​

(0068,6210)​

1C​

The size descriptor of the component.​

Required if the component exists in different sizes and the​

size number is not part of the name or identifier.​

May be present otherwise.​

See Section C.29.1.1.1.1 for details.​

Implant Part Number​

(0022,1097)​

1​

The (product) identifier of the implant.​

Implant Template Version​

(0068,6221)​

1​

The version code of the implant template.​

If Implant Type (0068,6223) is DERIVED, this shall have the​

same value as the Implant Template Version (0068,6221) of​

the manufacturer's implant template from which this instance​

was derived.​

Page 1509​

Attribute Name​

Tag​

Type​

Attribute Description​

Replaced Implant Template​

(0068,6222)​

1C​

Reference to the Implant Template that is replaced by this​

Sequence​

template.​

Only a single Item shall be included in this Sequence.​

Required if this Instance replaces another Instance.​

>Include Table 10-11 “SOP Instance Reference Macro Attributes”​

Implant Type​

(0068,6223)​

1​

Indicates whether the Implant Template is derived from​

another Implant Template.​

Enumerated Values:​

ORIGINAL​

DERIVED​

Original Implant Template​

(0068,6225)​

1C​

ReferencetotheImplantTemplateInstancewithImplantType​

Sequence​

(0068,6223) ORIGINAL from which this Instance was​

ultimately derived.​

Only a single Item shall be included in this Sequence.​

Required if Implant Type (0068,6223) is DERIVED.​

>Include Table 10-11 “SOP Instance Reference Macro Attributes”​

Derivation Implant Template​

(0068,6224)​

1C​

Reference to Implant Template Instance from which this​

Sequence​

Instance was directly derived.​

Only a single Item shall be included in this Sequence.​

Required if Implant Type (0068,6223) is DERIVED.​

>Include Table 10-11 “SOP Instance Reference Macro Attributes”​

Effective DateTime​

(0068,6226)​

1​

Date and time from which this Instance is or will be valid.​

Implant Target Anatomy​

(0068,6230)​

3​

Sequence that identifies the anatomical region the implant is​

Sequence​

to be implanted to.​

One or more Items are permitted in this Sequence.​

>Anatomic Region Sequence​

(0008,2218)​

1​

Sequencethatidentifiestheanatomicregionofinterestinthis​

Instance (i.e., external anatomy,surface anatomy,or general​

region of the body).​

Only a single Item shall be included in this Sequence.​

>>Include Table 8.8-1 “Code Sequence Macro Attributes”​

DCID 7304 “Implant Target Anatomy”.​

NotificationFromManufacturer​

(0068,6265)​

1C​

Information from the manufacturer concerning a critical​

Sequence​

notification,recall,ordiscontinuationoftheimplantorimplant​

template.​

One or more Items shall be included in this Sequence.​

Required if such information has been issued.​

>Information Issue DateTime​

(0068,6270)​

1​

Date and Time the information was issued.​

>Information Summary​

(0068,6280)​

1​

Summary of the information.​

>Encapsulated Document​

(0042,0011)​

3​

The complete manufacturer notification describing the​

template.​

Page 1510​

Attribute Name​

Tag​

Type​

Attribute Description​

>MIME Type of Encapsulated​

(0042,0012)​

1C​

The type of the encapsulated document stream described​

Document​

using the MIME Media Type (see RFC 2046).​

Required if Encapsulated Document (0042,0011) is present​

in this Sequence Item.​

Enumerated Values:​

application/pdf​

InformationFromManufacturer​

(0068,6260)​

3​

Information from Manufacturer other than described in​

Sequence​

Notification From Manufacturer Sequence (0068,6265).​

One or more Items shall be included in this Sequence.​

>Information Issue DateTime​

(0068,6270)​

1​

Date and Time the information was issued.​

>Information Summary​

(0068,6280)​

1​

Summary of the information.​

>Encapsulated Document​

(0042,0011)​

3​

Encapsulated Document stream, containing a document​

encoded according to the MIME Type.​

The complete manufacturer information.​

>MIME Type of Encapsulated​

(0042,0012)​

1C​

The type of the encapsulated document stream described​

Document​

using the MIME Media Type (see RFC 2046).​

Required if Encapsulated Document (0042,0011) is present​

in this Sequence Item.​

Enumerated Values:​

application/pdf​

ImplantRegulatoryDisapproval​

(0068,62A0)​

1C​

Sequence containing countries and regions in which the​

Code Sequence​

implant is not approved for usage.​

One or more Items shall be included in this Sequence.​

Required if the implant has been disapproved in a country or​

a region.​

>Include Table 8.8-1 “Code Sequence Macro Attributes”​

DCID 5001 “Countries”.​

Overall Template Spatial​

(0068,62A5)​

2​

Tolerance in mm applying to all distance measurements and​

Tolerance​

spatial locations in this Implant Template.​

Materials Code Sequence​

(0068,63A0)​

1​

A Code Sequence specifying the materials the implant was​

built from.​

One or more Items shall be included in this Sequence.​

>Include Table 8.8-1 “Code Sequence Macro Attributes”​

BCID 7300 “Implant Materials”.​

Coating Materials Code​

(0068,63A4)​

1C​

A Code Sequence specifying the materials the implant is​

Sequence​

coated with.​

One or more Items shall be included in this Sequence.​

Required if the implant is coated.​

>Include Table 8.8-1 “Code Sequence Macro Attributes”​

BCID 7300 “Implant Materials”.​

Implant Type Code Sequence​

(0068,63A8)​

1​

Sequencecontainingacodeddescriptionofthetypeofimplant​

the template reflects.​
