Page 1496​

DICOM PS3.3 2020a - Information Object Definitions​

Attribute Name​

Tag​

Product Expiration DateTime​

(0044,000B)​

Product Parameter Sequence​

(0044,0013)​

>Include Table 10-2 “Content Item Macro Attributes​

Description”​

PertinentDocumentsSequence​

(0038,0100)​

>Referenced SOP Class UID​

(0008,1150)​

>ReferencedSOPInstanceUID​

(0008,1155)​

>HL7 Instance Identifier​

(0040,E001)​

>Retrieve URI​

(0040,E010)​

Attribute Name​

Tag​

Attribute Description​

Substance Administration​

Approval​

Enumerated Values:​

APPROVED​

Use of the substance for the patient is approved, with​

related notes (e.g., appropriate dose for age/weight)​

in Approval Status Further Description (0044,0003)​

WARNING​

The substance may be used for the patient subject to​

warnings described in Approval Status Further​

Description (0044,0003)​

the reasons described in Approval Status Further​

Description (0044,0003)​

Approval Status Further​

Description​

Approval Status DateTime​

Attribute Name​

Tag​

Attribute Description​

Patient's Name​

(0010,0010)​

Patient's full name​

Patient ID​

(0010,0020)​

Primary identification number or code for the patient.​

Include Table 10-18 “Issuer of Patient ID Macro Attributes”​

Admission ID​

(0038,0010)​

Identification number of the Visit as assigned by the healthcare​

provider​

Issuer of Admission ID Sequence​

(0038,0014)​

Identifier of the Assigning Authority that issued the Admission ID.​

Only a single Item shall be included in this Sequence.​

>Include Table 10-17 “HL7v2 Hierarchic Designator Macro​

Attributes”​

Product Package Identifier​

(0044,0001)​

Identifierofthecontrastagent,drug,ordeviceadministered,typically​

from a package bar code, RFID, or other materials management​

ID.ThisIDmightnotbegloballyuniqueandmightconflictwithother​

IDs used within the scope of the institution.​

Product Name​

(0044,0008)​

Trade or generic name of product.​

Note​

May be multi-valued.​

Product Description​

(0044,0009)​

Textdescriptionofthecontrastagent,drug,ordeviceadministered.​

SubstanceAdministrationDateTime​

(0044,0010)​

Date and Time of Substance Administration​

Substance Administration Notes​

(0044,0011)​

Comments provided by the operator responsible for the substance​

administration.​

SubstanceAdministrationDeviceID​

(0044,0012)​

Identifier for a device that controls substance administration, e.g.,​

injector, infusion pump, etc.​

Administration Route Code​

(0054,0302)​

Route of administration for drug or contrast.​

Sequence​

Only a single Item shall be included in this Sequence.​

>Include Table 8.8-1 “Code Sequence Macro Attributes”​

BCID 11 “Route of Administration”.​

SubstanceAdministrationParameter​

(0044,0019)​

Parameters of the substance as administered to the patient, e.g.,​

Sequence​

volume, quantity.​

Page 1498​

Attribute Name​

Tag​

Attribute Description​

Operator Identification Sequence​

(0008,1072)​

Person administering the substance to the patient, or legally​

responsible for the administration, and authorized to add an entry​

to the Medication Administration Record.​

One or more Items shall be included in this Sequence.​

>Person Identification Code​

(0040,1101)​

Coded identifier of the person administering the contrast agent,​

Sequence​

drug, or device.​

Only a single Item shall be included in this Sequence.​

>>Include Table 8.8-1 “Code Sequence Macro Attributes”​

No Baseline CID is defined.​

Attribute Name​

Tag​

Type​

Number of Surfaces​

(0066,0001)​

1​

Surface Sequence​

(0066,0002)​

1​

>Surface Number​

(0066,0003)​

1​

>Surface Comments​

(0066,0004)​

3​

>Segmented Property​

(0062,0003)​

3​

Category Code Sequence​

>>Include Table 8.8-1 “Code Sequence Macro Attributes”​

DICOM PS3.3 2020a - Information Object Definitions​

Page 1499​

Attribute Name​

Tag​

Type​

Attribute Description​

>Segmented Property Type​

(0062,000F)​

3​

Sequence defining the specific property the surface represents.​

Code Sequence​

Note​

>Recommended Display​

(0062,000C)​

1​

A default single gray unsigned value in which it is recommended that​

Grayscale Value​

the maximum pixel value in this surface be rendered on a​

monochrome display. The units are specified in P-Values from a​

minimum of 0000H (black) up to a maximum of FFFFH (white).​

Note​

The maximum P-Value for this Attribute may be different​

from the maximum P-Value from the output of the​

Presentation LUT, which may be less than 16 bits in depth.​

>Recommended Display​

(0062,000D)​

1​

A default triplet value in which it is recommended that the surface be​

CIELab Value​

rendered on a color display. The units are specified in PCS-Values,​

and the value is encoded as CIELab.​

See Section C.10.7.1.1​

>Recommended​

(0066,000C)​

1​

Specifies the opacity in which it is recommended that the surface be​

Presentation Opacity​

rendered.​

See Section C.27.1.1.3.​

>Recommended​

(0066,000D)​

1​

Specifies the presentation type in which it is recommended that the​

Presentation Type​

surface be rendered.​

Page 1500​

Attribute Name​

Tag​

Type​

Attribute Description​

>Recommended Point​

(0066,0037)​

3​

Specifies the radius of the vertex points defined in the Long Vertex​

Radius​

Point Index List (0066,0043) with which it is recommended that the​

point be rendered.​

The units shall be the same as the units of the coordinate system in​

which the point coordinates are specified.​

>Recommended Line​

(0066,0038)​

3​

SpecifiesthethicknessofeachedgeorlinedefinedintheLongEdge​

Thickness​

Point Index List (0066,0042) or Line Sequence (0066,0028) with​

which it is recommended that the line be rendered.​

The units shall be the same as the units of the coordinate system in​

which the point coordinates are specified.​

>Finite Volume​

(0066,000E)​

1​

Indicates,whetherthesurfacerepresentsasolid("waterproof")object​

with an outside and an inside.​

Enumerated Values:​

YES​

Contains a finite volume​

NO​

Does not contain a finite volume​

UNKNOWN​Might or might not contain a finite volume​

See Section C.27.1.1.4.​

>Manifold​

(0066,0010)​

1​

Indicates whether the surface is describing an n-1 dimensional​

manifold in the underlying n-dimensional vector space.​

Enumerated Values:​

YES​

Manifold in every point​

NO​

Does contain non-manifold points​

UNKNOWN​Might or might not contain non-manifold points​

See Section C.27.1.1.5.​

>Surface Points Sequence​

(0066,0011)​

1​

The point positions representing vertices of the surface.​

Only a single Item shall be included in this Sequence.​

>>Include Table C.27-2 “Points Macro Attributes”​

>Surface Points Normals​

(0066,0012)​

2​

The normals on the surface for each point.​

Sequence​

Zero or one Item shall be included in this Sequence.​

See Section C.27.1.1.6.​

>>Include Table C.27-3 “Vectors Macro Attributes”​

NumberofVectors(0066,001E)shallequalNumberofSurfacePoints​

(0066,0015) in this Surface Sequence (0066,0002) Item.​

Vector Dimensionality (0066,001F) shall be 3.​

IfFiniteVolume(0066,000E)isYES,thenormalsoftheverticesshall​

point toward the outside of the object. If Finite Volume (0066,000E)​

is not YES, the direction of the normals shall be consistent where​

possible.​

>Surface Mesh Primitives​

(0066,0013)​

1​

Only a single Item shall be included in this Sequence.​

Sequence​
