Page 1486​

Attribute Name​

Tag​

Type​

Attribute Description​

Selector DS Value​

(0072,0072)​

1C​

The value(s) of the Attribute identified by Selector Attribute (0072,0026).​

Required if Selector Attribute VR (0072,0050) is present and the value​

is DS. Some leniency in precision and format (including padding and​

scientific notation) will be required.​

Selector FD Value​

(0072,0074)​

1C​

The value(s) of the Attribute identified by Selector Attribute (0072,0026).​

Required if Selector Attribute VR (0072,0050) is present and the value​

is FD.​

Selector FL Value​

(0072,0076)​

1C​

The value(s) of the Attribute identified by Selector Attribute (0072,0026).​

Required if Selector Attribute VR (0072,0050) is present and the value​

is FL.​

Selector UL Value​

(0072,0078)​

1C​

The value(s) of the Attribute identified by Selector Attribute (0072,0026).​

Required if Selector Attribute VR (0072,0050) is present and the value​

is UL.​

Selector US Value​

(0072,007A)​

1C​

The value(s) of the Attribute identified by Selector Attribute (0072,0026).​

Required if Selector Attribute VR (0072,0050) is present and the value​

is US.​

Selector SL Value​

(0072,007C)​

1C​

The value(s) of the Attribute identified by Selector Attribute (0072,0026).​

Required if Selector Attribute VR (0072,0050) is present and the value​

is SL.​

Selector SS Value​

(0072,007E)​

1C​

The value(s) of the Attribute identified by Selector Attribute (0072,0026).​

Required if Selector Attribute VR (0072,0050) is present and the value​

is SS.​

SelectorCodeSequence​

(0072,0080)​

1C​

The value(s) of the Attribute identified by Selector Attribute (0072,0026).​

Value​

One or more Items shall be included in this Sequence. See​

Section C.23.4.2.1.2.​

Required if Selector Attribute VR (0072,0050) is present and the value​

is SQ, and Selector Attribute (0072,0026) is a Code Sequence.​

>Include Table 8.8-1 “Code Sequence Macro Attributes”​

No Baseline CID is defined.​

Selector UI Value​

(0072,007F)​

1C​

The value of the Attribute identified by Selector Attribute (0072,0026).​

Required if Selector Attribute VR (0072,0050) is present and the value​

is UI.​

DICOM PS3.3 2020a - Information Object Definitions​

Page 1487​

Attribute Name​

Tag​

Type​

Attribute Description​

Modality​

(0008,0060)​

1​

Themodalityappropriatefortheencapsulateddocument.​

This Type definition shall override the definition in the​

SC Equipment Module.​

See Section C.7.3.1.1.1 for Defined Terms.​

Note​

SR may be an appropriate value for an​

EncapsulatedCDAdocumentwithastructured​

XML Body.​

Series Instance UID​

(0020,000E)​

1​

Unique identifier of the Series.​

Series Number​

(0020,0011)​

1​

A number that identifies the Series.​

Series Date​

(0008,0021)​

3​

Date the Series started.​

Series Time​

(0008,0031)​

3​

Time the Series started.​

Referenced Performed​

(0008,1111)​

3​

Uniquely identifies the Performed Procedure Step SOP​

Procedure Step Sequence​

Instance for which the Series is created.​

Only a single Item is permitted in this Sequence.​

Note​

The Performed Procedure Step referred to by​

this Attribute is the Step during which this​

Document is generated.​

Protocol Name​

(0018,1030)​

3​

DescriptionoftheconditionsunderwhichtheSerieswas​

performed.​

Series Description​

(0008,103E)​

3​

Description of the Series​

Series Description Code​

(0008,103F)​

3​

A coded description of the Series.​

Sequence​

Only a single Item is permitted in this Sequence.​

>Include Table 8.8-1 “Code Sequence Macro Attributes”​

No Baseline CID is defined.​

Request Attributes Sequence​

(0040,0275)​

3​

Sequence that contains Attributes from the Imaging​

Service Request.​

One or more Items are permitted in this Sequence.​

>Include Table 10-9 “Request Attributes Macro Attributes”​

No Baseline CID is defined.​

Page 1488​

DICOM PS3.3 2020a - Information Object Definitions​

Attribute Name​

Tag​

Type​

Attribute Description​

Instance Number​

(0020,0013)​

1​

A number that identifies this SOP Instance. The value shall be unique​

within a Series.​

Content Date​

(0008,0023)​

2​

The date the document content creation was started.​

Content Time​

(0008,0033)​

2​

The time the document content creation was started.​

Acquisition DateTime​

(0008,002A)​

2​

The date and time that the original generation of the data in the​

document started.​

Image Laterality​

(0020,0062)​

3​

Laterality of the (possibly paired) body part that is the subject of the​

encapsulated document.​

Enumerated Values:​

R​right​

L​left​

U​unpaired​

B​both left and right​

If Modality (0008,0060) is M3D, then values for this Attribute shall refer​

to the intended placement of the created object regardless of how it​

was generated (see also Section C.35.1 “Manufacturing 3D Model​

Module”).​

Burned In Annotation​

(0028,0301)​

1​

Indicateswhetherornottheencapsulateddocumentcontainssufficient​

burned in annotation to identify the patient and date the data was​

acquired.​

Enumerated Values:​

YES​

NO​

Identification of patient and date as text in an encapsulated document​

(e.g., in an XML attribute or element) is equivalent to "burned in​

annotation". A de-identified document may use the value NO.​

If Modality (0008,0060) is M3D, the presence of identifying information​

embossed or engraved on any part of the model shall be indicated by​

a value of YES.​

Recognizable Visual​

(0028,0302)​

3​

Indicateswhetherornottheinstancecontainssufficientlyrecognizable​

Features​

visual features to allow the instance or a reconstruction from a set of​

instances to identify the patient.​

Page 1489​

Attribute Name​

Tag​

Type​

Attribute Description​

Source Instance​

(0042,0013)​

1C​

Sequence​

the encapsulated document.​

Page 1490​

DICOM PS3.3 2020a - Information Object Definitions​

Attribute Name​

Tag​

Type​

Attribute Description​

Document Title​

(0042,0010)​

2​

The title of the document.​

Note​

In the case of a PDF encapsulated document, this may be​

the value of the "Title" entry in the "Document Information​

Directory" as encoded in the PDF data.​

Concept Name Code​

(0040,A043)​

2​

A coded representation of the document title.​

Sequence​

Zero or one Item shall be included in this Sequence.​

>Include Table 8.8-1 “Code Sequence Macro Attributes”​

For documents with Modality (0008,0060) equal to M3D, CID 7061​

“Model Document Titles”.​

For all other Encapsulated documents, Baseline CID 7020 “Document​

Titles”.​

Document Class Code​

(0040,E008)​

3​

Additionalclassificationsofthedocument,beyondthetitlerepresented​

Sequence​

in Concept Name Code Sequence. May be equivalent to HL7 v2.x​

TXA-2.​

One or more Items are permitted in this Sequence.​

>Include Table 8.8-1 “Code Sequence Macro Attributes”​

No Baseline CID is defined.​

Verification Flag​

(0040,A493)​

3​

Indicates whether the Encapsulated Document is Verified.​

Enumerated Values:​

UNVERIFIED​Not attested by a legally accountable person.​

VERIFIED​ Attested to (signed) by a Verifying Observer or Legal​

Authenticator named in the document, who is​

accountable for its content.​

HL7 Instance Identifier​

(0040,E001)​

1C​

Instance Identifier of the encapsulated HL7 Structured Document,​

encoded as a UID (OID or UUID), concatenated with a caret ("^") and​

Extension value (if Extension is present in Instance Identifier).​

Required if encapsulated document is a CDA document.​

Predecessor Documents​

(0040,A360)​

3​

References to SOP Instances whose content has been wholly or​

Sequence​

partially included in this document with or without modification.​
