BAD RECEIVE MGZ​

There is a problem with the film receive magazine. Films from the printer cannot be​

transported into the magazine.​

BAD SUPPLY MGZ​

There is a problem with a film supply magazine. Films from this magazine cannot​

be transported into the printer.​

CALIBRATING​

Printerisperformingselfcalibration,itisexpectedtobeavailablefornormaloperation​

shortly.​

CALIBRATION ERR​

An error in the printer calibration has been detected, quality of processed films may​

not be optimal.​

CHECK CHEMISTRY​

A problem with the processor chemicals has been detected, quality of processed​

films may not be optimal.​

CHECK SORTER​

There is an error in the film sorter.​

CHEMICALS EMPTY​

There are no processing chemicals in the processor, films will not be printed and​

processed until the processor is back to normal.​

CHEMICALS LOW​

The chemical level in the processor is low, if not corrected, it will probably shut down​

soon.​

COVER OPEN​

One or more printer or processor covers, drawers, doors are open.​

ELEC CONFIG ERR​

Printer configured improperly for this job.​

ELEC DOWN​

Printer is not operating due to some unspecified electrical hardware problem.​

ELEC SW ERROR​

Printer not operating for some unspecified software error.​

EMPTY 8X10​

The 8x10 inch film supply magazine is empty.​

EMPTY 8X10 BLUE​

The 8x10 inch blue film supply magazine is empty.​

EMPTY 8X10 CLR​

The 8x10 inch clear film supply magazine is empty.​

EMPTY 8X10 PAPR​

The 8x10 inch paper supply magazine is empty.​

EMPTY 10X12​

The 10x12 inch film supply magazine is empty.​

EMPTY 10X12 BLUE​

The 10x12 inch blue film supply magazine is empty.​

EMPTY 10X12 CLR​

The 10x12 inch clear film supply magazine is empty.​

EMPTY 10X12 PAPR​

The 10x12 inch paper supply magazine is empty.​

EMPTY 10X14​

The 10x14 inch film supply magazine is empty.​

EMPTY 10X14 BLUE​

The 10x14 inch blue film supply magazine is empty.​

EMPTY 10X14 CLR​

The 10x14 inch clear film supply magazine is empty.​

EMPTY 10X14 PAPR​

The 10x14 inch paper supply magazine is empty.​

EMPTY 11X14​

The 11x14 inch film supply magazine is empty.​

EMPTY 11X14 BLUE​

The 11x14 inch blue film supply magazine is empty.​

EMPTY 11X14 CLR​

The 11x14 inch clear film supply magazine is empty.​

EMPTY 11X14 PAPR​

The 11x14 inch paper supply magazine is empty.​

DICOM PS3.3 2020a - Information Object Definitions​

Page 1407​

EMPTY 14X14​

The 14x14 inch film supply magazine is empty.​

EMPTY 14X14 BLUE​

The 14x14 inch blue film supply magazine is empty.​

EMPTY 14X14 CLR​

The 14x14 inch clear film supply magazine is empty.​

EMPTY 14X14 PAPR​

The 14x14 inch paper supply magazine is empty.​

EMPTY 14X17​

The 14x17 inch film supply magazine is empty.​

EMPTY 14X17 BLUE​

The 14x17 inch blue film supply magazine is empty.​

EMPTY 14X17 CLR​

The 14x17 inch clear film supply magazine is empty.​

EMPTY 14X17 PAPR​

The 14x17 inch paper supply magazine is empty.​

EMPTY 24X24​

The 24x24 cm film supply magazine is empty.​

EMPTY 24X24 BLUE​

The 24x24 cm blue film supply magazine is empty.​

EMPTY 24X24 CLR​

The 24x24 cm clear film supply magazine is empty.​

EMPTY 24X24 PAPR​

The 24x24 cm paper supply magazine is empty.​

EMPTY 24X30​

The 24x30 cm film supply magazine is empty.​

EMPTY 24X30 BLUE​

The 24x30 cm blue film supply magazine is empty.​

EMPTY 24X30 CLR​

The 24x30 cm clear film supply magazine is empty.​

EMPTY 24X30 PAPR​

The 24x30 cm paper supply magazine is empty.​

EMPTY A4 PAPR​

The A4 paper supply magazine is empty.​

EMPTY A4 TRANS​

The A4 transparency supply magazine is empty.​

EXPOSURE FAILURE​

The exposure device has failed due to some unspecified reason.​

FILM JAM​

A film transport error has occurred and a film is jammed in the printer or processor.​

FILM TRANSP ERR​

There is a malfunction with the film transport, there may or may not be a film jam.​

FINISHER EMPTY​

The finisher is empty.​

FINISHER ERROR​

The finisher is not operating due to some unspecified reason.​

FINISHER LOW​

The finisher is low on supplies​

LOW 8X10​

The 8x10 inch film supply magazine is low.​

LOW 8X10 BLUE​

The 8x10 inch blue film supply magazine is low.​

LOW 8X10 CLR​

The 8x10 inch clear film supply magazine is low.​

LOW 8X10 PAPR​

The 8x10 inch paper supply magazine is low.​

LOW 10X12​

The 10x12 inch film supply magazine is low.​

LOW 10X12 BLUE​

The 10x12 inch blue film supply magazine is low.​

LOW 10X12 CLR​

The 10x12 inch clear film supply magazine is low.​

LOW 10X12 PAPR​

The 10x12 inch paper supply magazine is low.​

LOW 10X14​

The 10x14 inch film supply magazine is low.​

LOW 10X14 BLUE​

The 10x14 inch blue film supply magazine is low.​

LOW 10X14 CLR​

The 10x14 inch clear film supply magazine is low.​

LOW 10X14 PAPR​

The 10x14 inch paper supply magazine is low.​

LOW 11X14​

The 11x14 inch film supply magazine is low.​

LOW 11X14 BLUE​

The 11x14 inch blue film supply magazine is low.​

LOW 11X14 CLR​

The 11x14 inch clear film supply magazine is low.​

LOW 11X14 PAPR​

The 11x14 inch paper supply magazine is low.​

LOW 14X14​

The 14x14 inch film supply magazine is low.​

LOW 14X14 BLUE​

The 14x14 inch blue film supply magazine is low.​

LOW 14X14 CLR​

The 14x14 inch clear film supply magazine is low.​

Page 1408​

DICOM PS3.3 2020a - Information Object Definitions​

LOW 14X14 PAPR​

The 14x14 inch paper supply magazine is low.​

LOW 14X17​

The 14x17 inch film supply magazine is low.​

LOW 14X17 BLUE​

The 14x17 inch blue film supply magazine is low.​

LOW 14X17 CLR​

The 14x17 inch clear film supply magazine is low.​

LOW 14X17 PAPR​

The 14x17 inch paper supply magazine is low.​

LOW 24X24​

The 24x24 cm film supply magazine is low.​

LOW 24X24 BLUE​

The 24x24 cm blue film supply magazine is low.​

LOW 24X24 CLR​

The 24x24 cm clear film supply magazine is low.​

LOW 24X24 PAPR​

The 24x24 cm paper supply magazine is low.​

LOW 24X30​

The 24x30 cm film supply magazine is low.​

LOW 24X30 BLUE​

The 24x30 cm blue film supply magazine is low.​

LOW 24X30 CLR​

The 24x30 cm clear film supply magazine is low.​

LOW 24X30 PAPR​

The 24x30 cm paper supply magazine is low.​

LOW A4 PAPR​

The A4 paper supply magazine is low.​

LOW A4 TRANS​

The A4 transparency supply magazine is low.​

NO RECEIVE MGZ​

The film receive magazine not available​

NO RIBBON​

The ribbon cartridge needs to be replaced.​

NO SUPPLY MGZ​

The film supply magazine specified for this job is not available.​

CHECK PRINTER​

The printer is not ready at this time, operator intervention is required to make the​

printer available.​

CHECK PROC​

The processor is not ready at this time, operator intervention is required to make the​

printer available.​

PRINTER DOWN​

The printer is not operating due to some unspecified reason.​

PRINTER BUSY​

Printerisnotavailableatthistime,butshouldbecomereadywithoutuserintervention.​

This is to handle non-initialization instances.​

PRINT BUFF FULL​

The Printer 's buffer capacity is full. The printer is unable to accept new images in​

thisstate.Theprinterwillcorrectthiswithoutuserintervention.TheSCUshouldretry​

later.​

PRINTER INIT​

The printer is not ready at this time, it is expected to become available without​

intervention. For example, it may be in a normal warm-up state.​

PRINTER OFFLINE​

The printer has been disabled by an operator or service person.​

PROC DOWN​

The processor is not operating due to some unspecified reason.​

PROC INIT​

The processor is not ready at this time, it is expected to become available without​

intervention. For example, it may be in a normal warm-up state.​

PROC OVERFLOW FL​

Processor chemicals are approaching the overflow full mark.​

PROC OVERFLOW HI​

Processor chemicals have reached the overflow full mark.​

QUEUED​

Print Job in Queue​

RECEIVER FULL​

The Film receive magazine is full.​

REQ MED NOT INST​

The requested film, paper, or other media supply magazine is installed in the printer,​

but may be available with operator intervention.​

REQ MED NOT AVAI​

The requested film, paper, or other media requested is not available on this printer.​

RIBBON ERROR​

There is an unspecified problem with the print ribbon.​

SUPPLY EMPTY​

The printer is out of film.​

SUPPLY LOW​

The film supply is low.​

UNKNOWN​

There is an unspecified problem.​

DICOM PS3.3 2020a - Information Object Definitions​

Page 1409​

Attribute Name​

Tag​

PrinterConfigurationSequence​

(2000,001E)​ Containsprinterconfigurationinformationfora single ApplicationEntity title.​

>SOP Classes Supported​

(0008,115A)​ The Meta-SOP Class and a list of optional SOP Classes supported. It shall​

>Maximum Memory Allocation​

(2000,0061)​

>Memory Bit Depth​

(2000,00A0)​ The maximum number of bits for each pixel that can be stored in printer​

>Printing Bit Depth​

(2000,00A1)​ The number of bits used by the print engine for internal LUT calculation and​

>Media Installed Sequence​

(2000,00A2)​ A Sequence that specifies the combinations of Medium Type and Film Size​

>>Item Number​

(0020,0019)​

>>Medium Type​

(2000,0030)​

>>Film Size ID​

(2010,0050)​

>>Min Density​

(2010,0120)​

>>Max Density​

(2010,0130)​

>Other Media Available​

(2000,00A4)​ A Sequence that specifies combinations of Medium Type and Film Size ID​

Sequence​

Page 1410​

DICOM PS3.3 2020a - Information Object Definitions​

Attribute Name​

Tag​

>>Medium Type​

(2000,0030)​

>>Film Size ID​

(2010,0050)​

>>Min Density​

(2010,0120)​

>>Max Density​

(2010,0130)​

>Supported Image Display​

(2000,00A8)​ A Sequence that specifies the Image Display Formats supported, rows and​

Formats Sequence​

>>Rows​

(0028,0010)​

>>Columns​

(0028,0011)​

>>Image Display Format​

(2010,0010)​

>>Film Orientation​

(2010,0040)​

>>Film Size ID​

(2010,0050)​

>>Printer Resolution ID​

(2010,0052)​

>>Printer Pixel Spacing​

(2010,0376)​

>>Requested Image Size Flag​

(2020,00A0)​ Indicates whether the printer supports Requested Image Size (2020,0030)​

>Default Printer Resolution ID​

(2010,0054)​

>Default Magnification Type​

(2010,00A6)​ Printer's default magnification type. See Section C.13.3 for Defined Terms.​

>Other Magnification Types​

(2010,00A7)​ Other magnification types available in the printer. See Section C.13.3 for​

Available​

>Default Smoothing Type​

(2010,00A8)​ Printer's default smoothing type. See Section C.13.3.​

>Other Smoothing Types​

(2010,00A9)​ Other smoothing types available in the printer. See Section C.13.3.​

Available​

>Configuration Information​

(2010,0152)​

Description​

>Maximum Collated Films​

(2010,0154)​
