DICOM PS3.3 2020a - Information Object Definitions​

Page 1411​

Attribute Name​

Tag​

Attribute Description​



>Decimate/Crop Result​

(2020,00A2)​ Indicates whether the printer will decimate or crop image pixels if the image​

rows or columns is greater than the available printable pixels in an Image​ Box.​

See Section C.13.5.​

Enumerated Values when the printer does not support Requested​

Decimate/Crop Behavior (2020,0040):​

DECIMATE​image will be decimated to fit.​

CROP​ image will be cropped to fit.​

FAIL​ N-SET of the Image Box will fail.​

Enumerated Values when the printer supports Requested Decimate/Crop​

Behavior (2020,0040):​

DEFDECIMATE​image will be decimated to fit.​

DEF CROP​ image will be cropped to fit.​

DEF FAIL​ N-SET of the Image Box will fail.​

This value indicates the printer default if the SCU does not create or set​

Requested Decimate/Crop Behavior for the Image Box.​

C.14 Storage Commitment Module​

Table C.14-1 defines the Attributes for referencing SOP Instances that are contained in a Storage Commitment Request/Response.​

Table C.14-1. Storage Commitment Module Attributes​

Attribute Name​

Tag​

Attribute Description​

Transaction UID​

(0008,1195)​

Uniquely identifies this Storage Commitment transaction.​

Retrieve AE Title​

(0008,0054)​

ApplicationEntityTitlewheretheSOPInstance(s)mayberetrieved​





via a network based retrieve service.​

Storage Media File-Set ID​

(0088,0130)​

User or implementation specific human readable identification of​





a Storage Media on which the SOP Instances reside.​

Storage Media File-Set UID​

(0088,0140)​

Uniquely identifies a Storage Media on which the SOP Instances​





reside.​

Referenced SOP Sequence​

(0008,1199)​

A Sequence of Items where each Item references a single SOP​





Instanceforwhichstoragecommitmentisrequested/orhasbeen​





provided.​

>Include Table 10-11 “SOP Instance Reference Macro Attributes”​

>Retrieve AE Title​

(0008,0054)​

Application Entity Title from which the SOP Instance may be​





retrieved via a network based retrieve service.​

>Storage Media File-Set ID​

(0088,0130)​

Theuserorimplementationspecifichumanreadableidentifierthat​





identifies a Storage Media on which this SOP Instance resides.​

>Storage Media File-Set UID​

(0088,0140)​

Uniquely identifies a Storage Media on which this SOP Instance​





resides.​

Failed SOP Sequence​

(0008,1198)​

A Sequence of Items where each Item references a single SOP​





Instance for which storage commitment could not be provided.​

>Include Table 10-11 “SOP Instance Reference Macro Attributes”​

>Failure Reason​

(0008,1197)​

The reason that storage commitment could not be provided for​





this SOP Instance.​

See Section C.14.1.1.​

- Standard -​

Page 1412​

DICOM PS3.3 2020a - Information Object Definitions​

Note​

1.​Conditions under which Attributes are required (i.e., Retrieve AE Title, etc.) are defined in the Storage Commitment​ Service Class in PS3.4.​

2.​Referenced Performed Procedure Step Sequence (0008,1111) was included in this Module in earlier versions, but its​ useherehasbeenretired.SeePS3.4-2001,inwhichtheAttributewasformerlyknownasReferencedStudyComponent​ Sequence.​

C.14.1 Storage Commitment Attribute Description​

C.14.1.1 Failure Reason​

The following values and semantics shall be used for Failure Reason (0008,1197):​

Enumerated Values:​

0110H​Processing failure​

A general failure in processing the operation was encountered.​

0112H​No such object instance​

One or more of the elements in the Referenced SOP Instance Sequence was not available.​

0213H​Resource limitation​

The SCP does not currently have enough resources to store the requested SOP Instance(s).​

0122H​Referenced SOP Class not supported​

Storage Commitment has been requested for a SOP Instance with a SOP Class that is not supported by the SCP.​

0119H​Class/Instance conflict​

The SOP Class of an element in the Referenced SOP Instance Sequence did not correspond to the SOP class registered​ for this SOP Instance at the SCP.​

0131H​Duplicate transaction UID​

The Transaction UID of the Storage Commitment Request is already in use.​

C.15 Queue Management Specific Modules​

Retired. See PS3.3-2004.​

C.16 Stored Print Specific Modules​

Retired. See PS3.3-2004.​

C.17 SR Document Modules​

C.17.1 SR Document Series Module​

TableC.17-1definestheAttributesoftheSRDocumentSeries.ASeriesofSRDocumentsmaycontainanynumberofSRDocuments.​

Note​

Series of SR Documents are separate from Series of Images or other Composite SOP Instances. SR Documents do not​ reside in a Series of Images or other Composite SOP Instances.​

- Standard -​

DICOM PS3.3 2020a - Information Object Definitions​ Page 1413​

Table C.17-1. SR Document Series Module Attributes​

Attribute Name​

Tag​

Type​

Attribute Description​

Modality​

(0008,0060)​

1​

Modality type.​







Enumerated Values:​







SR​SR Document​

Series Instance UID​

(0020,000E)​

1​

Unique identifier of the Series.​







Note​







No SR-specific semantics are specified.​

Series Number​

(0020,0011)​

1​

A number that identifies the Series.​







Note​







No SR-specific semantics are specified.​

Series Date​

(0008,0021)​

3​

Date the Series started.​

Series Time​

(0008,0031)​

3​

Time the Series started.​

Protocol Name​

(0018,1030)​

3​

Description of the conditions under which the Series was​







performed.​







Note​







Thismayrepresentthetypeofanalysisusedincreation​







of the SR SOP Instances.​

Series Description​

(0008,103E)​

3​

Description of the Series​

Series Description Code​

(0008,103F)​

3​

A coded description of the Series.​

Sequence​





Only a single Item is permitted in this Sequence.​







>Include Table 8.8-1 “Code Sequence Macro Attributes”​

No Baseline CID is defined.​

Referenced Performed​

(0008,1111)​

2​

Uniquely identifies the Performed Procedure Step SOP Instance​

Procedure Step Sequence​





for which the Series is created.​

Zero or one Item shall be included in this Sequence.​

Note​

1.​The Performed Procedure Step referred to by this​ Attribute is the Step during which this Document is​ generated.​

2.​If this Document is generated during the same​ Performed Procedure Step as the evidence in the​ current interpretation procedure, this Attribute may​ contain reference to that Performed Procedure​ Step.​

3.​This Attribute is not used to convey reference to​ theevidenceinthecurrentinterpretationprocedure.​ See Current Requested Procedure Evidence​ Sequence (0040,A375).​

4.​ThisSequencemaybezerolengthifthePerformed​ Procedure Step is unknown.​

>Include Table 10-11 “SOP Instance Reference Macro Attributes”​

- Standard -​

Page 1414​

DICOM PS3.3 2020a - Information Object Definitions​

C.17.2 SR Document General Module​

Table C.17-2 defines the general Attributes of an SR Document Instance. These Attributes identify the SR Document and provide​ context for the entire document.​

Table C.17-2. SR Document General Module Attributes​

Attribute Name​

Tag​

Type​



Attribute Description​

Instance Number​

(0020,0013)​

1​

A number that identifies the SR Document.​

Preliminary Flag​

(0040,A496)​

3​

IndicateswhetherthisSRDocumentisintendedtoberegarded​







as a preliminary or final report.​







Enumerated Values:​







PRELIMINARY​This report precedes the final report and may​









contain limited information; it may be time​









sensitive, and it is not expected to contain all​









the reportable findings.​







FINAL​

This report is the definitive means of​









communicating the results of a procedure.​







Note​









The definitions of the Enumerated Values are derived​







from the ACR Practice Guideline for Communication​







of Diagnostic Imaging Findings, Revised 2005.​

Completion Flag​

(0040,A491)​

1​

The estimated degree of completeness of this SR Document.​







See Section C.17.2.7.​







Enumerated Values:​







PARTIAL​ Partial content.​







COMPLETE​Complete content.​

Completion Flag Description​

(0040,A492)​

3​

Explanation of the value of Completion Flag (0040,A491).​

Verification Flag​

(0040,A493)​

1​

Indicates whether this SR Document is Verified.​







Enumerated Values:​

UNVERIFIED​Not attested to.​

VERIFIED​ Attested to by a Verifying Observer Name​ (0040,A075)whoisaccountableforitscontent.​

A value of "VERIFIED" shall be used only when the value of​

Completion Flag (0040,A491) is "COMPLETE".​







Note​







The intent of this specification is that the "prevailing​







finalversion"ofanSRDocumentistheversionhaving​







the most recent Verification DateTime (0040,A030),​







Verification Flag (0040,A493) of VERIFIED and​







Preliminary Flag (0040,A496) of FINAL.​

Content Date​

(0008,0023)​

1​

The date the document content creation started.​

Content Time​

(0008,0033)​

1​

The time the document content creation started.​

- Standard -​



DICOM PS3.3 2020a - Information Object Definitions​

Page 1415​

Attribute Name​

Tag​

Type​

Attribute Description​



VerifyingObserverSequence​

(0040,A073)​

1C​

The person or persons authorized to verify documents of this​







type and accept responsibility for the content of this document.​







One or more Items shall be included in this Sequence.​







Required if Verification Flag (0040,A493) is VERIFIED.​







Note​









InHL7StructuredDocuments,thecomparableattribute​







is the "legalAuthenticator".​



>Verifying Observer Name​

(0040,A075)​

1​

The person authorized by the Verifying Organization​







(0040,A027) to verify documents of this type and who accepts​







responsibility for the content of this document.​



>Verifying Observer​

(0040,A088)​

2​

Coded identifier of Verifying Observer.​



IdentificationCodeSequence​





Zero or one Item shall be included in this Sequence.​







>>Include Table 8.8-1 “Code Sequence Macro Attributes”​

No Baseline CID is defined.​



>Verifying Organization​

(0040,A027)​

1​

OrganizationtowhichtheVerifyingObserverName(0040,A075)​







is accountable in the current interpretation procedure.​

>Verification DateTime​

(0040,A030)​

1​

Date and Time of verification by the Verifying Observer Name​







(0040,A075).​



Author Observer Sequence​

(0040,A078)​

3​

The person or device that created the clinical content of this​







document. This Attribute sets the default Observer Context for​







the root of the content tree.​









One or more Items are permitted in this Sequence.​

>IncludeTableC.17-3b“IdentifiedPersonorDeviceMacroAttributes”​



Participant Sequence​

(0040,A07A)​

3​

Persons or devices related to the clinical content of this​







document.​









One or more Items are permitted in this Sequence.​

>Participation Type​

(0040,A080)​

1​

Participant's role with respect to the clinical content of this​







document. See Section C.17.2.5.​









Defined Terms:​









SOURCE​Equipment that contributed to the content​







ENT​ Data enterer (e.g., transcriptionist)​









ATTEST​Attestor​









Note​









In HL7 Structured Documents, the participation​







comparable to Attestor is the "Authenticator".​

>Participation DateTime​

(0040,A082)​

2​

DateTime of participation with respect to the clinical content of​







this document.​



>IncludeTableC.17-3b“IdentifiedPersonorDeviceMacroAttributes”​

- Standard -​
