DICOM PS3.3 2020a - Information Object Definitions​

Page 1401​

Attribute Name​



Tag​

Attribute Description​

>Include Table 10-11 “SOP Instance Reference Macro Attributes”​





Referenced Basic Annotation Box Sequence​

(2010,0520)​

A set of Basic Annotation Boxes.​









Zero or more Items shall be included in this​







Sequence.​



>Include Table 10-11 “SOP Instance Reference Macro Attributes”​





Referenced Presentation LUT Sequence​

(2050,0500)​

A Presentation LUT.​









Only a single Item shall be included in this​







Sequence.​



>Include Table 10-11 “SOP Instance Reference Macro Attributes”​





C.13.5 Image Box Pixel Presentation Module​





Table C.13-5. Image Box Pixel Presentation Module Attributes​



Attribute Name​

Tag​

Attribute Description​



Image Box Position​

(2020,0010)​

The position of the image on the film, based on Image Display Format​





(2010,0010). See Section C.13.5.1 for specification.​



Polarity​

(2020,0020)​

Specifies whether minimum pixel values (after VOI LUT transformation) are​





to printed black or white.​









Enumerated Values:​









NORMAL​pixelsshallbeprintedasspecifiedbyPhotometricInterpretation​





(0028,0004)​









REVERSE​pixels shall be printed with the opposite polarity as specified by​





Photometric Interpretation (0028,0004)​







If Polarity (2020,0020) is not specified by the SCU, the SCP shall print with​





NORMAL polarity.​





Magnification Type​

(2010,0060)​

Description is the same as in Table C.13-3. Overrides the Magnification​





Type specified for the Film Box.​



Smoothing Type​

(2010,0080)​

Description is the same as in Table C.13-3. Overrides the Smoothing Type​





specified for the Film Box.​



Configuration Information​

(2010,0150)​

See Table C.13-3 for description of Configuration Information.​

Requested Image Size​

(2020,0030)​

Width (x-dimension) in mm of the image to be printed. This value overrides​





the size that corresponds with optimal filling of the Image Box.​

- Standard -​

Page 1402​

DICOM PS3.3 2020a - Information Object Definitions​

Attribute Name​

Tag​



Attribute Description​

Requested Decimate/Crop​

(2020,0040)​

Specifies whether image pixels are to be decimated or cropped if the image​

Behavior​



rows or columns is greater than the available printable pixels in an Image​





Box.​







Decimation means that a magnification factor <1 is applied to the image.​





The method of decimation shall be that specified by Magnification Type​





(2010,0060) or the SCP default if not specified​





Cropping means that some image rows and/or columns are deleted before​





printing​







Enumerated Values:​





DECIMATE​A magnification factor <1 to be applied to the image.​





CROP​

Some image rows and/or columns are to be deleted before​







printing. Thespecific algorithm for cropping shall be described​







in the SCP Conformance Statement.​





FAIL​

The SCP shall not crop or decimate​

Basic Grayscale Image​

(2020,0110)​

A Sequence that provides the content of the grayscale image pixel data to​

Sequence​



be printed. This is a specialization of the Image Pixel Module defined in​





Section C.7.6.3. It is encoded as a Sequence of Attributes of the Image​





Pixel Module.​





Zero or one Item shall be included in this Sequence.​





See PS3.4 for further description.​

>Samples Per Pixel​

(0028,0002)​

See Section C.7.6.3 for description.​





Enumerated Values:​





1​



>Photometric Interpretation​

(0028,0004)​

See Section C.7.6.3 for description.​





Enumerated Values:​





MONOCHROME1​





MONOCHROME2​

>Rows​

(0028,0010)​

See Section C.7.6.3 for description​

>Columns​

(0028,0011)​

See Section C.7.6.3 for description​

>Pixel Aspect Ratio​

(0028,0034)​

See Section C.7.6.3 for description​

>Bits Allocated​

(0028,0100)​

See Section C.7.6.3 for description.​





Enumerated Values if Bits Stored = 8:​





8​



Enumerated Values if Bits Stored = 12:​

16​

>Bits Stored​

(0028,0101)​

See Section C.7.6.3 for description.​

Enumerated Values:​

8​

12​

- Standard -​



DICOM PS3.3 2020a - Information Object Definitions​

Page 1403​

Attribute Name​

Tag​

Attribute Description​



>High Bit​

(0028,0102)​

See Section C.7.6.3 for description.​







Enumerated Values if Bits Stored = 8:​







7​







Enumerated Values if Bits Stored = 12:​







11​



>Pixel Representation​

(0028,0103)​

See Section C.7.6.3 for description.​







Enumerated Values:​







0​unsigned integer​



>Pixel Data​

(7FE0,0010)​

See Section C.7.6.3 for description​



Basic Color Image Sequence​

(2020,0111)​

A Sequence that provides the content of the color image pixel data to be​





printed. It is a specialization of the Image Pixel Module defined in​





Section C.7.6.3. It is encoded as a Sequence of Attributes of the Image​





Pixel Module.​







Zero or one Item shall be included in this Sequence.​







See PS3.4 for further description.​



>Samples Per Pixel​

(0028,0002)​

See Section C.7.6.3 for description.​







Enumerated Values:​







3​



>Photometric Interpretation​

(0028,0004)​

See Section C.7.6.3 for description.​







Enumerated Values:​







RGB​



>Planar Configuration​

(0028,0006)​

See Section C.7.6.3 for description.​







Enumerated Values:​







1​frame interleave​



>Rows​

(0028,0010)​

See Section C.7.6.3 for description.​



>Columns​

(0028,0011)​

See Section C.7.6.3 for description.​



>Pixel Aspect Ratio​

(0028,0034)​

See Section C.7.6.3 for description.​



>Bits Allocated​

(0028,0100)​

See Section C.7.6.3 for description.​







Enumerated Values:​







8​



>Bits Stored​

(0028,0101)​

See Section C.7.6.3 for description.​







Enumerated Values:​







8​



>High Bit​

(0028,0102)​

See Section C.7.6.3 for description.​







Enumerated Values:​







7​



- Standard -​

Page 1404​

DICOM PS3.3 2020a - Information Object Definitions​

Attribute Name​

Tag​

Attribute Description​

>Pixel Representation​

(0028,0103)​

See Section C.7.6.3 for description.​





Enumerated Values:​





0000H​unsigned integer​

>Pixel Data​

(7FE0,0010)​

See Section C.7.6.3 for description​

Note​





ReferencedImageOverlayBoxSequence(2020,0130)andOriginalImageSequence(2130,00C0)werepreviouslyincluded​ in this Module but have been retired. See PS3.3-2004.​

C.13.5.1 Image Box Position​

The position of the image on the film; the encoding of the image position sequence is based on the selected Image Display Format​ (2010,0010). The image position sequence shall be increasing order beginning with the value 1. Image Box Position (2020,0010) is​ defined as follows:​

•​STANDARD display format: image box sequence shall be major row order (from left-to-right and from top-to-bottom); top left image​ position shall be equal to 1.​

•​ROWdisplayformat:imageboxsequenceshallbemajorroworder(fromleft-to-rightandfromtop-to-bottom);topleftimageposition​ shall be set to 1.​

•​COL display format: image box sequence shall be major column order (from top-to-bottom and from left-to-right); top left image​ position shall be equal to 1.​

•​SLIDE display format: image box sequence shall be major row order (from left-to-right and from top-to-bottom); top left image pos-​ ition shall be set to 1.​

•​SUPERSLIDEdisplayformat:imageboxsequenceshallbemajorroworder(fromleft-to-rightandfromtop-to-bottom);topleftimage​ position shall be set to 1.​

•​CUSTOM STANDARD display format: image box sequence shall be defined in the Conformance Statement; top left image position​ shall be set to 1.​

C.13.6 Image Box Relationship Module (Retired)​

This section was previously defined in DICOM. It is now retired. See PS3.3-1998.​

C.13.7 Basic Annotation Presentation Module​

Table C.13-7. Basic Annotation Presentation Module Attributes​

Attribute Name​

Tag​

Attribute Description​

Annotation Position​

(2030,0010)​

The position of the annotation box in the parent film box. Annotation​





position sequence depends on the selected Annotation Display​





Format ID (2010,0030)​

Text String​

(2030,0020)​

Text string​

- Standard -​



DICOM PS3.3 2020a - Information Object Definitions​

Page 1405​

C.13.8 Print Job Module​









Table C.13-8. Print Job Module Attributes​



Attribute Name​

Tag​



Attribute Description​



Execution Status​

(2100,0020)​

Execution status of print job.​







Enumerated Values:​







PENDING​







PRINTING​







DONE​









FAILURE​



Execution Status Info​

(2100,0030)​

Additional information about Execution Status (2100,0020).​







Defined Terms if Execution Status (2100,0030) is DONE or PRINTING:​





NORMAL​









Defined Terms if Execution Status (2100,0030) is FAILURE:​







INVALID PAGE DES​ Thespecifiedpagelayoutcannotbeprintedorother​







page description errors have been detected.​





INSUFFIC MEMORY​ There is not enough memory available to complete​







this job.​







SeeSectionC.13.9.1foradditionalDefinedTermswhentheExecutionStatus​





is PENDING or FAILURE.​



Creation Date​

(2100,0040)​

Date of print job creation.​



Creation Time​

(2100,0050)​

Time of print job creation.​



Print Priority​

(2000,0020)​

Priority of print job (see Section C.13.1 for further explanation).​

Printer Name​

(2110,0030)​

User defined name identifying the printer.​



Originator​

(2100,0070)​

DICOM Application Entity Title that issued the print operation.​



C.13.9 Printer Module​











Table C.13-9. Printer Module Attributes​



Attribute Name​

Tag​



Attribute Description​



Printer Status​

(2110,0010)​

Printer device status.​









Enumerated Values:​









NORMAL​









WARNING​









FAILURE​



Printer Status Info​

(2110,0020)​

Additional information about Printer Status (2110,0010).​







Defined Terms if Printer Status (2110,0010) is NORMAL:​







NORMAL​









See Section C.13.9.1 for Defined Terms when the Printer Status​







is equal to WARNING or FAILURE.​



Printer Name​

(2110,0030)​

User defined name identifying the printer.​



Manufacturer​

(0008,0070)​

Manufacturer of the printer.​



Manufacturer Model Name​

(0008,1090)​

Manufacturer's model number of the printer.​



- Standard -​
