Page 1416​

DICOM PS3.3 2020a - Information Object Definitions​

Attribute Name​

Tag​

Type​

Attribute Description​

Custodial Organization​

(0040,A07C)​

3​

Custodial organization for this SR Document instance.​

Sequence​





Representstheorganizationfromwhichthedocumentoriginates​







and that is in charge of maintaining the document, i.e., the​







steward of the original source document.​







Note​







This may or may not be identical to the Institution​







identified in the General Equipment Module.​







Only a single Item is permitted in this Sequence.​

>Institution Name​

(0008,0080)​

2​

Name of Custodial Institution or Organization.​

>Institution Code Sequence​

(0008,0082)​

2​

Coded identifier of Custodial Institution or Organization.​







Zero or one Item shall be included in this Sequence.​

>>Include Table 8.8-1 “Code Sequence Macro Attributes”​

No Baseline CID is defined.​

>Responsible Group Code​

(0008,0220)​

3​

The department, unit or service that is responsible for the​

Sequence​





management of this instance.​







See Section C.34.2.3.​







Only a single Item is permitted in this Sequence.​

>>Include Table 8.8-1 “Code Sequence Macro Attributes”​

BCID 7030 “Institutional Departments, Units and Services”.​

Predecessor Documents​

(0040,A360)​

1C​

ReferencestoSOPInstances(e.g.,priororpreliminaryreports)​

Sequence​





whose content has been wholly or partially included in this​







document with or without modification.​

One or more Items shall be included in this Sequence.​

Required if this document includes content from other​ documents.​

Note​

The amendment process of an existing SR Document​ may be described using the Purpose of Reference​ Code Sequence.​

>Include Table C.17-3 “Hierarchical SOP Instance Reference Macro​Defined CID for the Purpose of Reference Code Sequence in​

Attributes”​ the Hierarchical SOP Instance Reference Macro is CID 7009​ “Purpose of Reference to Predecessor Report”.​

Identical Documents​

(0040,A525)​

1C​

Duplicatesofthisdocument,storedwithdifferentSOPInstance​

Sequence​





UIDs.​

One or more Items shall be included in this Sequence.​

Required if this document is stored with different SOP Instance​

UIDs in one or more other Studies.​

See Section C.17.2.2 for further explanation.​

>Include Table C.17-3 “Hierarchical SOP Instance Reference Macro​ Attributes”​

- Standard -​



DICOM PS3.3 2020a - Information Object Definitions​

Page 1417​

Attribute Name​

Tag​

Type​

Attribute Description​



Referenced Request​

(0040,A370)​

1C​

Identifies Requested Procedures that are being fulfilled​

Sequence​





(completely or partially) by creation of this Document.​







One or more Items shall be included in this Sequence.​







Required if this Document fulfills at least one Requested​







Procedure. May be present otherwise.​



>Study Instance UID​

(0020,000D)​

1​

Unique identifier for the Study.​



>Referenced Study​

(0008,1110)​

2​

Uniquely identifies the Study SOP Instance.​



Sequence​





Zero or one Item shall be included in this Sequence.​













See Section 10.6.1.​



>>Include Table 10-11 “SOP Instance Reference Macro Attributes”​



>Accession Number​

(0008,0050)​

2​

A departmental IS generated number that identifies the order​







for the Study.​



>IssuerofAccessionNumber​

(0008,0051)​

3​

Identifier of the Assigning Authority that issued the Accession​

Sequence​





Number.​









Only a single Item is permitted in this Sequence.​



>>Include Table 10-17 “HL7v2 Hierarchic Designator Macro​





Attributes”​









>Placer Order​

(0040,2016)​

2​

The order number assigned to the Imaging Service Request by​

Number/Imaging Service​





the party placing the order.​



Request​









>Order Placer Identifier​

(0040,0026)​

3​

IdentifieroftheAssigningAuthoritythatissuedthePlacerOrder​

Sequence​





Number.​



Only a single Item is permitted in this Sequence.​

>>Include Table 10-17 “HL7v2 Hierarchic Designator Macro​ Attributes”​

>Filler Order​

(0040,2017)​

2​

Number/Imaging Service​





Request​





>Order Filler Identifier​

(0040,0027)​

3​

Sequence​





>>Include Table 10-17 “HL7v2 Hierarchic Designator Macro​ Attributes”​

>Requested Procedure ID​

(0040,1001)​

2​

>Requested Procedure​

(0032,1060)​

2​

Description​





>RequestedProcedureCode​

(0032,1064)​

2​

Sequence​





>>Include Table 8.8-1 “Code Sequence Macro Attributes”​

>Reason for the Requested​

(0040,1002)​

3​

Procedure​





>Reason for Requested​

(0040,100A)​

3​

Procedure Code Sequence​





>>Include Table 8.8-1 “Code Sequence Macro Attributes”​

The order number assigned to the Imaging Service Request by​ the party filling the order.​

Identifier of the Assigning Authority that issued the Filler Order​ Number.​

Only a single Item is permitted in this Sequence.​

Identifier of the related Requested Procedure​

Institution-generatedadministrativedescriptionorclassification​ of Requested Procedure.​

A Sequence that conveys the requested procedure. Zero or​ one Item shall be included in this Sequence.​

No Baseline CID is defined.​

Reason for requesting this procedure.​

Coded Reason for requesting this procedure.​

One or more Items are permitted in this Sequence.​

No Baseline CID is defined.​

- Standard -​

Page 1418​

DICOM PS3.3 2020a - Information Object Definitions​

Attribute Name​

Tag​

Type​

Attribute Description​

Performed Procedure Code​

(0040,A372)​

2​

A Sequence that conveys the codes of the performed​

Sequence​





procedurespertainingtothisSOPInstance.ZeroormoreItems​







shall be included in this Sequence.​

>Include Table 8.8-1 “Code Sequence Macro Attributes”​

No Baseline CID is defined.​

Current Requested​

(0040,A375)​

1C​

Full set of Composite SOP Instances, of which the creator is​

Procedure Evidence​





aware, which were created to satisfy the current Requested​

Sequence​





Procedure(s) for which this SR Document is generated or that​







are referenced in the content tree.​







One or more Items shall be included in this Sequence.​







Required if the creator is aware of Composite Objects acquired​







inordertosatisfytheRequestedProcedure(s)forwhichtheSR​







Document is or if instances are referenced in the content tree.​







May be present otherwise.​







See Section C.17.2.3 for further explanation.​

>Include Table C.17-3 “Hierarchical SOP Instance Reference Macro​

Attributes”​







Pertinent Other Evidence​

(0040,A385)​

1C​

Other Composite SOP Instances that are considered to be​

Sequence​





pertinent evidence by the creator of this SR Document. This​







evidencemusthavebeenacquiredinordertosatisfyRequested​







Procedures other than the one(s) for which this SR Document​







is generated.​







One or more Items shall be included in this Sequence.​







RequiredifpertinentevidencefromotherRequestedProcedures​







needs to be recorded.​







See Section C.17.2.3 for further explanation.​

>Include Table C.17-3 “Hierarchical SOP Instance Reference Macro​

Attributes”​







Referenced Instance​

(0008,114A)​

1C​

Sequence specifying SOP Instances significantly related to the​

Sequence​





current SOP Instance. Such referenced Instances may include​







equivalent documents or renderings of this document.​







One or more Items shall be included in this Sequence.​







Required if the identity of a CDA Document equivalent to the​







current SOP Instance is known at the time of creation of this​







SOPInstance(seeSectionC.17.2.6).Maybepresentotherwise.​

>Include Table 10-11 “SOP Instance Reference Macro Attributes”​



>PurposeofReferenceCode​

(0040,A170)​

1​

CodedescribingthepurposeofthereferencetotheInstance(s).​

Sequence​





Only a single Item shall be included in this Sequence.​







>>Include Table 8.8-1 “Code Sequence Macro Attributes”​

DCID 7006 “SR Document Purposes of Reference”.​

C.17.2.1 Hierarchical SOP Instance Reference Macro​

Table C.17-3 specifies the Attributes that reference a list of SOP Instances.​

- Standard -​

DICOM PS3.3 2020a - Information Object Definitions​ Page 1419​

Table C.17-3. Hierarchical SOP Instance Reference Macro Attributes​

Attribute Name​

Tag​



Type​

Attribute Description​

Study Instance UID​

(0020,000D)​

1​

Unique identifier for the Study​

Referenced Series Sequence​

(0008,1115)​

1​

Sequence of Items where each Item includes the​









Attributes of a Series containing referenced​









Composite Object(s).​









One or more Items shall be included in this​









Sequence​

>Include Table C.17-3a “Hierarchical Series Reference Macro Attributes”​



Table C.17-3a specifies the Attributes that reference a Series of SOP Instances.​

Table C.17-3a. Hierarchical Series Reference Macro Attributes​

Attribute Name​

Tag​

Type​



Attribute Description​

Series Instance UID​

(0020,000E)​

1​

Unique identifier of a Series that is part of this Study and contains the​







referenced Composite Object(s).​

Retrieve AE Title​

(0008,0054)​

3​

Title of the DICOM Application Entity where the Composite Object(s)​







may be retrieved on the network.​

Retrieve Location UID​

(0040,E011)​

3​

Unique identifier of the system where the Composite Object(s) may​







be retrieved on the network.​

Retrieve URL​

(0008,1190)​

3​

URL specifying the location of the referenced instance(s).​

Storage Media File-Set ID​

(0088,0130)​

3​

The user or implementation specific human readable identifier that​







identifiestheStorageMediaonwhichtheCompositeObject(s)reside.​

Storage Media File-Set UID​

(0088,0140)​

3​

Uniquely identifies the Storage Media on which the Composite​







Object(s) reside.​

ReferencedSOPSequence​

(0008,1199)​

1​

References to Composite Object SOP Class/SOP Instance pairs that​







are part of the Study defined by Study Instance UID and the Series​







defined by Series Instance UID (0020,000E).​







One or more Items shall be included in this Sequence.​

>Include Table 10-11 “SOP Instance Reference Macro​





Attributes”​









>Purpose of Reference​

(0040,A170)​

3​

Describes the purpose for which the reference is made.​

Code Sequence​





One or more Items are permitted in this Sequence.​







>>Include Table 8.8-1 “Code Sequence Macro Attributes”​

Baseline CID may be specified in Macro invocation.​

>Referenced Digital​

(0400,0402)​

3​

Sequence of references to Digital Signatures in the referenced SOP​

Signature Sequence​





Instance.​









One or more Items are permitted in this Sequence.​







Note​









The Attributes in this Sequence can be used to detect if the​







referenced SOP Instance has been altered.​

>>Digital Signature UID​

(0400,0100)​

1​

TheUniqueIdentifierofaDigitalSignatureheldinthereferencedSOP​







Instance.​



>>Signature​

(0400,0120)​

1​

The Signature Value identified by the Digital Signature UID within the​







Referenced SOP Instance UID.​

- Standard -​

Page 1420​

DICOM PS3.3 2020a - Information Object Definitions​

Attribute Name​

Tag​

Type​

Attribute Description​

>Referenced SOP Instance​

(0400,0403)​

3​ A MAC Calculation from data in the referenced SOP Instance that can​

MAC Sequence​





be used as a data integrity check.​







Only a single Item is permitted in this Sequence.​







Note​







This Attribute may be used in place of Referenced Digital​







Signature Sequence (0400,0402), particularly if the SOP​







Instance does not have appropriate Digital Signatures that​







can be referenced.​

>>MACCalculationTransfer​

(0400,0010)​

1​ The Transfer Syntax UID used to encode the values of the Data​

Syntax UID​





ElementsincludedintheMACcalculation.WhencomputingtheMAC,​







only Transfer Syntaxes that explicitly include the VR and use Little​







Endian encoding shall be used.​







Note​







1.​Certain Transfer Syntaxes, particularly those that are​







used with compressed data, allow the fragmentation of​







thepixeldatatochange.Ifsuchfragmentationchanges,​







DigitalSignaturesgeneratedwithsuchTransferSyntaxes​







could become invalid.​







2.​This does not constrain the Transfer Syntax used to​







transmit the object.​

>>MAC Algorithm​

(0400,0015)​

1​ The algorithm used in generating the MAC.​







Defined Terms:​







RIPEMD160​







MD5​







SHA1​







SHA256​







SHA384​







SHA512​







Note​







Digital Signature Security Profiles (see PS3.15) may require​







the use of a restricted subset of these terms.​

>>Data Elements Signed​

(0400,0020)​

1​ A list of Data Element Tags in the order they appear at the top level​







of the referenced SOP Instance that identify the Data Elements used​







in creating the MAC. See Section C.12.1.1.3.1.1.​

>>MAC​

(0400,0404)​

1​ The MAC generated as described in Section C.12.1.1.3, but​







unencryptedandwithoutinclusionoffieldsfromtheDigitalSignatures​







Sequence. See Section C.12.1.1.3.1.2.​

C.17.2.2 Identical Documents Sequence​

If identical copies of a document are to be included in multiple Studies then the entire document shall be duplicated with appropriate​ changesforinclusionintothedifferentStudies(i.e.,StudyInstanceUID,SeriesInstanceUID,SOPInstanceUID,IdenticalDocuments​ Sequence etc.). The Identical Documents Sequence Attribute in each SOP Instance shall contain references to all other duplicate​ SOP Instances.​

- Standard -​

Смотрите также:

«ДОХОДЫ, РАСХОДЫ И ПРИБЫЛЬ КОММЕРЧЕСКОГО БАНКА.»
«ДОХОДЫ, РАСХОДЫ И ПРИБЫЛЬ КОММЕРЧЕСКОГО БАНКА.»
Значение, сущность и содержание социально — педагогической деятельности в организации для детей-сирот и детей, оставшихся без попечения родителей
__RGR2
__RGR2
_11_А. Франс для эл версии
_индив анализ данных
- Интерфейс 485 и оптопорт 11
:Конвергентный подход к проектированию дополнительных общеобразовательных общеразвивающих программ
