8.2.13 Constraints For SMPTE ST 2110-20 Uncompressed Active Video For DICOM-RTV​

This section describes the constraints applying to pixel data carried in the DICOM-RTV Flow (separated from DICOM-RTV Metadata​ Flow) and fully described in [SMPTE ST 2110-20] .​

The following table describes constraints on the [SMPTE ST 2110-20] Video Flow in terms of the valid values for the corresponding​ DICOM Attributes in the DICOM-RTV Metadata Flow:​

•​Samples per pixel​

•​Bits Allocated​

•​Bits Stored​

•​High Bit​

Table 8.2.13-1. Constraints Applicable to Attributes describing Pixel Data​

DICOM Photometric Interpretation is based on CCIR 601 (aka ITU-R BT.601), therefore some restrictions apply to the possible​ combination of Sampling System and Colorimetry parameters as stated by [SMPTE ST 2110-20] .​

Table 8.2.13-2. List of supported SMPTE ST 2110-20 Parameter Combinations​

Some other [SMPTE ST 2110-20] parameter combinations do not correspond to existing DICOM photometric interpretations, so their​ use is currently not permitted. Table 8.2.13-3 lists the unsupported combinations.​

Table 8.2.13-3. List of unsupported SMPTE ST 2110-20 Parameter Combinations​

- Standard -​

8.3 Waveform Data and Related Data Elements​

The DICOM protocol provides for the exchange of encoded time-based signals, or waveforms, encoded in the Waveform Data​ 5400,1010).​

Note​

Per Section 7.6, an IOD supporting multiple sets of Waveform Data will encapsulate Waveform Data (5400,1010) within a​ Sequence.​

Encoded Waveform Data of various bit depths is accommodated through the Waveform Bits Allocated (5400,1004) Data Element.​ This element defines the size of each waveform data sample within the Waveform Data (5400,1010). Allowed values are 8, 16, 32​ and 64 bits.​

TheValueRepresentationoftheWaveformData(5400,1010)shallbeOW;OBshallbeusedincaseswhereWaveformBitsAllocated​ has a value of 8, but only with Transfer Syntaxes where the Value Representation is explicitly conveyed.​

Note​

1.​Under the Default Transfer Syntax, OB and OW VRs have the identical byte transfer order.​

2.​ConversionofaSOPInstancefromtheDefaultTransferSyntaxtoanExplicitVRTransferSyntax(uncompressed)requires​ theinterpretationoftheWaveformBitsAllocated(5400,1004)DataElement,todeterminetheproperVRoftheWaveform​ Data.​

The following data elements related to Waveform Data shall be encoded with the same VR as Waveform Data: Channel Minimum​ Value (5400,0110), Channel Maximum Value (5400,0112) and Waveform Padding Value (5400,100A).​

8.4 Pixel Data Provider Service​

Specific Transfer Syntaxes allow for the pixel data of the message to be replaced with a reference to a pixel data provider service.​ The pixel data provider service that is referenced supplies the pixel data using a network protocol that is defined outside DICOM.​

Note​

The Pixel Data Provider Service is not applicable to Pixel Data encoded as Float Pixel Data (7FE0,0008) or Double Float​ Pixel Data (7FE0,0009).​

8.4.1 JPIP Referenced Pixel Data​

DICOM provides a mechanism for supporting the use of JPEG 2000 Interactive Protocol through the inclusion of a URL reference to​ a pixel data provider service. Annex A defines two Transfer Syntaxes that utilize URL references to a JPIP pixel data provider service.​

The use of the these Transfer Syntaxes requires that the Pixel Data Provider URL specify a URL that will represent the JPIP request​ includingthespecifictargetinformation.AdditionalparametersrequiredbytheapplicationmaybeappendedtotheURLwhenaccessing​ the pixel data provider.​

Note​

For example, a JPIP request for a 200 by 200 pixel rendition of the entire image can be constructed from the Pixel Data​ Provider URL as follows:​

Pixel Data Provider URL (0028,7FE0) = http://server.xxx/jpipserver.cgi?target=imgxyz.jp2​

URL Generated by the application = http://server.xxx/jpipserver.cgi?target=imgxyz.jp2&fsiz=200,200​

The JPIP client shall only request a JPEG 2000 bit stream.​

The JPIP server shall return a Content-type of image/jp2, image/jpp-stream or image/jpt-stream, all of which shall be supported by​ the JPIP client.​

- Standard -​

The Number of Frames (0028,0008) attribute, if present in the Data Set, identifies the number of frames available for this image. Each​ frame is accessible as a separate JPIP code stream. Code streams referenced in the URL Target shall be sequentially numbered​ starting with stream 1.​

Note​

For example, a JPIP request for a 200 by 200 pixel rendition of frame 17 of a multi-frame image can be constructed from​ Pixel Data Provider URL as follows:​

Pixel Data Provider URL (0028,7FE0) = http://server.xxx/multiframeimage.jp2​

URL Generated by the application = http://server.xxx/multiframeimage.jp2?fsiz=200,200&stream=17​

A valid stream query parameter value is always less than or equal to the value in the Number of Frames (0028,0008).​

The syntax of the Pixel Data Provider URL (0028,7FE0) is defined in [ISO/IEC 15444-9] Annex C (Client Request). That standard​ respects the URI recommendations [RFC3986]. The transport protocol shall be HTTP or HTTPS.​

Note​

1.​According to [ISO/IEC 15444-9], "Each JPIP request is directed to a specific representation of a specific original named​ resource or a specific portion of that resource. That resource may be a physically stored file or object, or may be​ something that is created virtually by the server upon request."​

"The Target request field specifies the original named resource to which the request is directed. It is specified using a​ PATH, which could be a simple string or a URI. If the Target field is not specified and the request is carried over HTTP,​ then the JPIP request shall be directed to the resource specified through the path component of the JPIP request URL."​

2.​Transport over UDP or other protocols is not supported.​

8.5 Security Considerations for Encoding of Pixel, Overlay, and Waveform Data (Informative)​

The encapsulated formats conform to other standards, e.g., JPEG. Many of these formats have had their own security issues, both​ with the format itself and with common implementations for processing the format.​

Implementations that support encapsulated format encoding may need to:​

•​Perform input validation and sanitation to detect and perhaps remove invalid or malicious content.​

•​Perform output validation to ensure safe compliance with format specification.​

•​Monitor library implementations for vulnerability reports, updates, and have a process for managing these updates.​

Tracking, notification, and remediation of these security problems will normally be in the context of the encapsulated format and not​ in the context of DICOM. This means those implementing and deploying the encapsulated format must consider security issues from​ those other contexts.​
