1.​The HAS CONCEPT MOD relationship is used to modify the meaning of the concept name of a parent node (or Source​ Content Item), with a modifier or qualifier in a child (target node) to provide a more descriptive explanation, a different​ coded language translation, or to define a post-coordinated concept.​

A.35.20 Performed Imaging Agent Administration SR IOD​

A.35.20.1 Performed Imaging Agent Administration SR IOD Description​

The Performed Imaging Agent Administration SR IOD describes the imaging agent delivery whether manual methods or automated​ power-injector devices were used. It includes a reference to the Planned Imaging Agent Administration Procedure SR SOP instance​ if based on a plan.​

A.35.20.2 Performed Imaging Agent Administration SR IOD Entity-Relationship Model​

This IOD uses the E-R Model in Section A.1.2, with only the SR Document IE below the Series IE.​

A.35.20.3 Performed Imaging Agent Administration SR IOD Module Table​

Table A.35.20-1. Performed Imaging Agent Administration SR IOD Modules​

A.35.20.3.1 Performed Imaging Agent Administration SR IOD Content Constraints​

A.35.20.3.1.1 Template​

The document shall be constructed from TID 11020 “Performed Imaging Agent Administration” invoked at the root node.​

A.35.20.3.1.2 Value Type​

Value Type (0040,A040) in the Content Sequence (0040,A730) of the SR Document Content Module is constrained to the following​ Enumerated Values (see Table C.17.3-7 for Value Type definitions):​

Enumerated Values:​

TEXT​

CODE​

NUM​

DATETIME​

DATE​

- Standard -​

UIDREF​

PNAME​

COMPOSITE​

IMAGE​

WAVEFORM​

CONTAINER​

A.35.20.3.1.3 Relationship Constraints​

RelationshipsbetweenContentItemsinthecontentofthisIODshallbeconveyedby-value.TableA.35.20-2specifiestherelationship​ constraints of this IOD. See Table C.17.3-8 for Relationship Type definitions.​

Table A.35.20-2. Relationship Content Constraints for Performed Imaging Agent Administration SR IOD​

1.​The SOP Classes to which an IMAGE or WAVEFORM or COMPOSITE Value Type may refer, is documented in the​ Conformance Statement for an application (see PS3.2 and PS3.4).​

2.​The HAS CONCEPT MOD relationship is used to modify the meaning of the concept name of a parent node (or Source​ Content Item), with a modifier or qualifier in a child (target node) to provide a more descriptive explanation, a different​ coded language translation, or to define a post-coordinated concept.​

A.35.21 Rendition Selection Document IOD​

A.35.21.1 Rendition Selection Document IOD Description​

The Rendition Selection Document IOD associates a group of time-synchronized Flows produced for a simultaneous presentation,​ transported using DICOM-RTV.​

A.35.21.2 Rendition Selection Document IOD Entity-Relationship Model​

This IOD uses the E-R Model in Section A.1.2, with only the SR Document IE below the Series IE.​

A.35.21.3 Rendition Selection Document IOD Module Table​

Table A.35.21-1 specifies the Modules of the Rendition Selection Document IOD.​

- Standard -​

DICOM PS3.3 2020a - Information Object Definitions​ Page 333​

Table A.35.21-1. Rendition Selection Document IOD Modules​

A.35.21.3.1 Rendition Selection Document IOD Content Constraints​

A.35.21.3.1.1 Value Type​

Value Type (0040,A040) in Content Sequence (0040,A730) of the SR Document Content Module is constrained to the following​ Enumerated Values (see Table C.17.3-7 for Value Type definitions):​

Enumerated Values:​

TEXT​

CODE​

UIDREF​

PNAME​

COMPOSITE​

IMAGE​

WAVEFORM​

CONTAINER​

The IMAGE and WAVEFORM Content Items shall only include references to SOP Instance UIDs of DICOM-RTV Metadata Flows.​

A.35.21.3.1.2 Relationship Constraints​

Relationships between Content Items in the content of this IOD shall be conveyed in the by-value mode. See Table C.17.3-8 for Re-​ lationship Type definitions.​

Note​

Relationships by-reference are forbidden. Therefore, Referenced Content Item Identifier (0040,DB73) is not present in any​ of the Content Items within the SR Document Content Module.​

Table A.35.21-2 specifies the relationship constraints of this IOD.​

Table A.35.21-2. Relationship Content Constraints for Rendition Selection Document IOD​

- Standard -​

A.35.21.3.1.3 Template Constraints​

The document shall be constructed from TID 2010 “Key Object Selection” invoked at the root node.​

A.36 Enhanced MR Information Object Definitions​

A.36.1 Relationship Between Enhanced MR IODs​

Figure A.36-1 illustrates the relationships between the Enhanced MR IODs described in Section A.36.​

Source Image Sequence (0008,2112), Referenced Image Sequence (0008,1140) and Referenced Raw Data Sequence (0008,9121)​ provide references between SOP Instances.​

Note​

Many Attributes have names and descriptions that include the terms "pixel" and "image". Although MR spectroscopy is not​ pixel based, some of these "pixel" and "image" Attributes encode concepts that are still relevant for this technique. Where​ such Attributes appear in the MR Spectroscopy IOD, it may be helpful to consider the term "pixel" to be equivalent to a​ spectroscopy "voxel", and the term "image" to be equivalent to "MR Spectroscopy SOP Instance".​


Figure A.36-1. Relationships between Enhanced MR IODs​

A.36.2 Enhanced MR Image IOD​

A.36.2.1 Enhanced MR Image IOD Description​

The Enhanced Magnetic Resonance (MR) Image Information Object Definition (IOD) specifies an image, which has been created by​ a magnetic resonance device.​

A.36.2.2 Enhanced MR Image Entity-Relationship Model​

This IOD uses the E-R Model in Section A.1.2, with only the Image IE below the Series IE.​

A.36.2.3 Enhanced MR Image IOD Module Table​

Table A.36-1 specifies the Modules of the Enhanced MR Image IOD.​

- Standard -​

Table A.36-1. Enhanced MR Image IOD Modules​

A.36.2.3.1 Enhanced MR Image IOD Content Constraints​

The General Image Module, Overlay Plane Module and VOI LUT Module shall not be used in a Standard Extended SOP Class of​ the Enhanced MR Image.​
