A.35.13.3.1 Comprehensive 3D SR IOD Content Constraints​

A.35.13.3.1.1 Value Type​

Value Type (0040,A040) in Content Sequence (0040,A730) of the SR Document Content Module is constrained to the following​ Enumerated Values (see Table C.17.3-7 for Value Type definitions):​

Enumerated Values:​

TEXT​

CODE​

NUM​

DATETIME​

DATE​

TIME​

UIDREF​

PNAME​

SCOORD​

SCOORD3D​

TCOORD​

COMPOSITE​

IMAGE​

WAVEFORM​

CONTAINER​

A.35.13.3.1.2 Relationship Constraints​

Relationships between Content Items in the content of this IOD may be conveyed either by-value or by-reference. Table A.35.13-2​ specifies the relationship constraints of this IOD. See Table C.17.3-8 for Relationship Type definitions.​

Table A.35.13-2. Relationship Content Constraints for Comprehensive 3D SR IOD​

1.​WhichSOPClassestheIMAGE,WAVEFORMorCOMPOSITEValueTypemayreferto,isdocumentedintheConform-​ ance Statement for an application (see PS3.2 and PS3.4).​

- Standard -​

2.​The HAS CONCEPT MOD relationship is used to modify the meaning of the Concept Name of a Source Content Item,​ for example to provide a more descriptive explanation, a different language translation, or to define a post-coordinated​ concept.​

3.​SCOORD3D has no children, since its coordinates are patient rather than image-relative.​

The HAS CONCEPT MOD and CONTAINS relationships shall not be conveyed by-reference.​

Relationships by-reference to ancestor Content Items are forbidden in this IOD to prevent loops.​

A.35.14 Radiopharmaceutical Radiation Dose SR IOD​

A.35.14.1 Radiopharmaceutical Radiation Dose SR IOD Description​

The Radiopharmaceutical Radiation Dose SR IOD is used to convey the exposure characteristics and dose from the administration​ of radiopharmaceuticals.​

A.35.14.2 Radiopharmaceutical Radiation Dose SR IOD Entity-Relationship Model​

This IOD uses the E-R Model in Section A.1.2, with only the SR Document IE below the Series IE.​

A.35.14.3 Radiopharmaceutical Radiation Dose SR IOD Module Table​

Table A.35.14-1 specifies the Modules of the Radiopharmaceutical Radiation Dose SR IOD.​

Table A.35.14-1. Radiopharmaceutical Radiation Dose SR IOD Modules​

A.35.14.3.1 Radiopharmaceutical Radiation Dose SR IOD Content Constraints​

A.35.14.3.1.1 Template​

The document may be constructed from Baseline TID 10021 “Radiopharmaceutical Radiation Dose” invoked at the root node.​

A.35.14.3.1.2 Value Type​

Value Type (0040,A040) in Content Sequence (0040,A730) of the SR Document Content Module is constrained to the following​ Enumerated Values (see Table C.17.3-7 for Value Type definitions):​

- Standard -​

Enumerated Values:​

TEXT​

CODE​

NUM​

DATETIME​

UIDREF​

PNAME​

CONTAINER​

A.35.14.3.1.3 Relationship Constraints​

RelationshipsbetweenContentItemsinthecontentofthisIODshallbeconveyedby-value.TableA.35.14-2specifiestherelationship​ constraints of this IOD. See Table C.17.3-8 for Relationship Type definitions.​

Table A.35.14-2. Relationship Content Constraints for Radiopharmaceutical Radiation Dose SR IOD​

A.35.15 Extensible SR IOD​

A.35.15.1 Extensible SR IOD Description​

The Extensible SR IOD specifies support for all SR Content Item and relationship types currently defined and that may be added in​ the future.​

It is designed specifically to support the possibility of future extensions, and the corresponding SOP Class defined in PS3.4 has​ specific behavior defined for a recipient in the presence of unrecognized or unsupported extensions.​

A.35.15.2 Extensible SR IOD Entity-Relationship Model​

This IOD uses the E-R Model in Section A.1.2, with only the SR Document IE below the Series IE.​

A.35.15.3 Extensible SR IOD Module Table​

Table A.35.15-1 specifies the Modules of the Extensible SR IOD.​

Table A.35.15-1. Extensible SR IOD Modules​

- Standard -​

A.35.15.3.1 Extensible SR IOD Content Constraints​

A.35.15.3.1.1 Value Type​

Value Type (0040,A040) in the Content Sequence (0040,A730) of the SR Document Content Module is constrained to any of the​ Enumerated Values defined in Section C.17.3.​

A.35.15.3.1.2 Relationship Constraints​

Relationships between Content Items in the content of this IOD may be conveyed either by-value or by-reference. Table A.35.15-2​ specifies the relationship constraints of this IOD. See Table C.17.3-8 for Relationship Type definitions.​

Table A.35.15-2. Relationship Content Constraints for Extensible SR IOD​

Thelackofexplicitconstraintsbetweenvaluetypesandrelationshiptypesisnecessarytosupportextensibilityinunanticipated​ ways (e.g., to support new coordinate value types that may be selected from new composite object value types), but that​ does not mean that all possible combinations will make sense or be usable (e.g., HAS OBS CONTEXT with source and​ target value types of IMAGE).​

Relationships by-reference to ancestor Content Items are forbidden in this IOD to prevent loops.​

A.35.16 Acquisition Context SR IOD​

A.35.16.1 Acquisition Context SR IOD Description​

The Acquisition Context SR IOD is used to represent the description of the conditions present during data acquisition of other data​ that is stored separately (such as images).​

A.35.16.2 Acquisition Context SR IOD Entity-Relationship Model​

This IOD uses the E-R Model in Section A.1.2, with only the SR Document IE below the Series IE.​

A.35.16.3 Acquisition Context SR IOD Module Table​

Table A.35.16-1 specifies the Modules of the Acquisition Context SR IOD.​

- Standard -​

DICOM PS3.3 2020a - Information Object Definitions​ Page 325​

Table A.35.16-1. Acquisition Context SR IOD Modules​

A.35.16.3.1 Acquisition Context SR IOD Content Constraints​

A.35.16.3.1.1 Value Type​

Value Type (0040,A040) in Content Sequence (0040,A730) of the SR Document Content Module is constrained to the following​ Enumerated Values (see Table C.17.3-7 for Value Type definitions):​

Enumerated Values:​

TEXT​

CODE​

NUM​

DATETIME​

DATE​

TIME​

UIDREF​

PNAME​

SCOORD3D​

CONTAINER​

A.35.16.3.1.2 Relationship Constraints​

Relationships between Content Items in the content of this IOD shall be conveyed in the by-value mode. See Table C.17.3-8 for Re-​ lationship Type definitions.​

Note​

Relationships by-reference are forbidden. Therefore, Referenced Content Item Identifier (0040,DB73) is not present in any​ of the Content Items within the SR Document Content Module.​

Table A.35.16-2 specifies the relationship constraints of this IOD.​

Table A.35.16-2. Relationship Content Constraints for Acquisition Context SR IOD​

- Standard -​
