A.35.10.3.1 Colon CAD SR IOD Content Constraints​

A.35.10.3.1.1 Template Constraints​

The document shall be constructed from TID 4120 “Colon CAD Document Root” invoked at the root node.​

Note​

All Template and Context Group definitions are located in Annex A “Structured Reporting Templates (Normative)” in PS3.16​ and Annex B “DCMR Context Groups (Normative)” in PS3.16, respectively.​

A.35.10.3.1.2 Value Type​

Value Type (0040,A040) in Content Sequence (0040,A730) of the SR Document Content Module is constrained to the following​ Enumerated Values (see Table C.17.3-7 for Value Type definitions):​

Enumerated Values:​

TEXT​

CODE​

NUM​

DATE​

TIME​

UIDREF​

PNAME​

SCOORD​

SCOORD3D​

TCOORD​

COMPOSITE​

IMAGE​

CONTAINER​

A.35.10.3.1.3 Relationship Constraints​

The Colon CAD SR IOD makes use of by-reference INFERRED FROM and by-reference HAS ACQ CONTEXT relationships. Other​ relationships by-reference are forbidden. Table A.35.10-2 specifies the relationship constraints of this IOD. See Table C.17.3-8 for​ Relationship Type definitions.​

Table A.35.10-2. Relationship Content Constraints for Colon CAD SR IOD​

- Standard -​

Note​

1.​WhichSOPClassestheIMAGEorCOMPOSITEValueTypemayreferto,isdocumentedintheConformanceStatement​ for an application (see PS3.2 and PS3.4).​

2.​The HAS CONCEPT MOD relationship is used to modify the meaning of the Concept Name of a Source Content Item,​ for example to provide a more descriptive explanation, a different language translation, or to define a post-coordinated​ concept.​

A.35.11 Macular Grid Thickness and Volume Report IOD​

A.35.11.1 Macular Grid Thickness and Volume Report IOD Description​

The Macular Grid Thickness and Volume Report IOD is used to represent the macular grid thickness and volume values derived from​ ophthalmic images.​

A.35.11.2 Macular Grid Thickness and Volume Report IOD Entity-Relationship Model​

This IOD uses the E-R Model in Section A.1.2, with only the SR Document IE below the Series IE. The Frame of Reference IE is not​ a component of this IOD.​

A.35.11.3 Macular Grid Thickness and Volume Report IOD Module Table​

Table A.35.11-1 specifies the Modules of the Macular Grid Thickness and Volume Report IOD.​

Table A.35.11-1. Macular Grid Thickness and Volume Report IOD Modules​

- Standard -​

A.35.11.3.1 Macular Grid Thickness and Volume Report IOD Content Constraints​

A.35.11.3.1.1 Value Type​

Value Type (0040,A040) in Content Sequence (0040,A730) of the SR Document Content Module is constrained to the following​ Enumerated Values (see Table C.17.3-7 for Value Type definitions):​

Enumerated Values:​

TEXT​

CODE​

NUM​

DATE​

UIDREF​

PNAME​

IMAGE​

CONTAINER​

A.35.11.3.1.2 Relationship Constraints​

Relationships between Content Items in the content of this IOD shall be conveyed in the by-value mode. See Table C.17.3-8 for Re-​ lationship Type definitions.​

Note​

Relationships by-reference are forbidden. Therefore, Referenced Content Item Identifier (0040,DB73) is not present in any​ of the Content Items within the SR Document Content Module.​

Table A.35.11-2 specifies the relationship constraints of this IOD.​

Table A.35.11-2. Relationship Content Constraints for Macular Grid Thickness and Volume Report IOD​

A.35.11.3.1.3 Template Constraints​

The document shall be constructed from TID 2100 “Macular Grid Thickness and Volume Report” invoked at the root node.​

A.35.12 Implantation Plan SR Document IOD​

A.35.12.1 Implantation Plan SR Document IOD Description​

The Implantation Plan SR Document IOD contains the results of a planning process for an individual Patient, wherein specific implant​ templates are selected and positioned using images of the Patient. The Implantation Plan SR Document references the implant​ templates, the images, and the registration SOP instances that are used in the planning.​

A.35.12.2 Implantation Plan SR Document IOD Entity-Relationship Model​

This IOD uses the E-R Model in Section A.1.2, with only the SR Document IE below the Series IE. The Frame of Reference IE is not​ a component of this IOD.​

A.35.12.3 Implantation Plan SR Document IOD Module Table​

Table A.35.12-1 specifies the Modules of the Implantation Plan SR Document IOD.​

- Standard -​

DICOM PS3.3 2020a - Information Object Definitions​ Page 319​

Table A.35.12-1. Implantation Plan SR Document IOD Modules​

A.35.12.3.1 Implantation Plan SR Document IOD Content Constraints​

A.35.12.3.1.1 Template Constraints​

The document shall be constructed from TID 7000 “Implantation Plan” invoked at the root node.​

Note​

All Template and Context Group definitions are located in Annex A “Structured Reporting Templates (Normative)” in PS3.16​ and Annex B “DCMR Context Groups (Normative)” in PS3.16, respectively.​

A.35.12.3.1.2 Value Type​

Value Type (0040,A040) in Content Sequence (0040,A730) of the SR Document Content Module is constrained to the following​ Enumerated Values (see Table C.17.3-7 for Value Type definitions):​

Enumerated Values:​

TEXT​

CODE​

NUM​

DATE​

UIDREF​

PNAME​

COMPOSITE​

IMAGE​

CONTAINER​

A.35.12.3.1.3 Relationship Constraints​

Relationships between Content Items in the content of this IOD may be conveyed by-value. Table A.35.12-2 specifies the relationship​ constraints of this IOD. See Table C.17.3-8 for Relationship Type definitions.​

Table A.35.12-2. Relationship Content Constraints for Implantation Plan SR Document IOD​

- Standard -​

Note​

1.​WhichSOPClassestheIMAGEorCOMPOSITEValueTypemayrefertoisdocumentedintheConformanceStatement​ for an application (see PS3.2 and PS3.4).​

2.​The HAS CONCEPT MOD relationship is used to modify the meaning of the Concept Name of a Source Content Item,​ for example, to provide a more descriptive explanation, a different language translation, or to define a post-coordinated​ concept.​

A.35.13 Comprehensive 3D SR IOD​

A.35.13.1 Comprehensive 3D SR IOD Description​

The Comprehensive 3D SR IOD is a superset of the Comprehensive SR IOD, which specifies a class of documents, the content of​ which may include textual and a variety of coded information, numeric measurement values, references to the SOP Instances and​ 2D or 3D spatial or temporal regions of interest within such SOP Instances. Relationships by-reference are enabled between Content​ Items.​

A.35.13.2 Comprehensive 3D SR IOD Entity-Relationship Model​

This IOD uses the E-R Model in Section A.1.2, with only the SR Document IE below the Series IE.​

A.35.13.3 Comprehensive 3D SR IOD Module Table​

Table A.35.13-1 specifies the Modules of the Comprehensive 3D SR IOD.​

Table A.35.13-1. Comprehensive 3D SR IOD Modules​

- Standard -​
