Note​

The Specimen Identification Module was previously included in this IOD but has been retired. See PS3.3-2008.​

A.35.4.3.1 Key Object Selection Document IOD Content Constraints​

A.35.4.3.1.1 Value Type​

Value Type (0040,A040) in Content Sequence (0040,A730) of the SR Document Content Module is constrained to the following​ Enumerated Values (see Table C.17.3-7 for Value Type definitions):​

Enumerated Values:​

TEXT​

CODE​

UIDREF​

PNAME​

COMPOSITE​

IMAGE​

WAVEFORM​

CONTAINER​

A.35.4.3.1.2 Relationship Constraints​

Relationships between Content Items in the content of this IOD shall be conveyed in the by-value mode. See Table C.17.3-8 for Re-​ lationship Type definitions.​

Note​

Relationships by-reference are forbidden. Therefore, Referenced Content Item Identifier (0040,DB73) is not present in any​ of the Content Items within the SR Document Content Module.​

Table A.35.4-2 specifies the relationship constraints of this IOD.​

Table A.35.4-2. Relationship Content Constraints for Key Object Selection Document IOD​

A.35.4.3.1.3 Template Constraints​

The document shall be constructed from TID 2010 “Key Object Selection” invoked at the root node.​

A.35.5 Mammography CAD SR IOD​

A.35.5.1 Mammography CAD SR IOD Description​

The Mammography CAD SR IOD is used to convey the detection and analysis results of a mammography CAD device. The content​ may include textual and a variety of coded information, numeric measurement values, references to the SOP Instances, and spatial​ regions of interest within such SOP Instances. Relationships by-reference are enabled between Content Items.​

A.35.5.2 Mammography CAD SR IOD Entity-Relationship Model​

This IOD uses the E-R Model in Section A.1.2, with only the SR Document IE below the Series IE. The Frame of Reference IE is not​ a component of this IOD.​

- Standard -​

A.35.5.3 Mammography CAD SR IOD Module Table​

Table A.35.5-1 specifies the Modules of the Mammography CAD SR IOD.​

Table A.35.5-1. Mammography CAD SR IOD Modules​

Note​

The Specimen Identification Module was previously included in this IOD but has been retired. See PS3.3-2008.​

A.35.5.3.1 Mammography CAD SR IOD Content Constraints​

A.35.5.3.1.1 Template Constraints​

•​The document shall be constructed from TID 4000 “Mammography CAD Document Root” invoked at the root node.​

•​When a Content Item sub-tree from a prior document is duplicated by-value, its observation context shall be defined by TID 1001​ “Observation Context” and its subordinate templates.​

Note​

All Template and Context Group definitions are located in Annex A “Structured Reporting Templates (Normative)” in PS3.16​ and Annex B “DCMR Context Groups (Normative)” in PS3.16, respectively.​

A.35.5.3.1.2 Value Type​

Value Type (0040,A040) in Content Sequence (0040,A730) of the SR Document Content Module is constrained to the following​ Enumerated Values (see Table C.17.3-7 for Value Type definitions):​

Enumerated Values:​

TEXT​

CODE​

NUM​

DATE​

TIME​

PNAME​

SCOORD​

COMPOSITE​

IMAGE​

CONTAINER​

- Standard -​

A.35.5.3.1.3 Relationship Constraints​

The Mammography CAD SR IOD makes extensive use of by-reference INFERRED FROM, by-reference HAS PROPERTIES and​ by-referenceSELECTEDFROMrelationships.Otherrelationshipsby-referenceareforbidden.TableA.35.5-2specifiestherelationship​ constraints of this IOD. See Table C.17.3-8 for Relationship Type definitions.​

Table A.35.5-2. Relationship Content Constraints for Mammography CAD SR IOD​

Note​

1.​WhichSOPClassestheIMAGEorCOMPOSITEValueTypemayreferto,isdocumentedintheConformanceStatement​ for an application (see PS3.2 and PS3.4).​

2.​The HAS CONCEPT MOD relationship is used to modify the meaning of the Concept Name of a Source Content Item,​ for example to provide a more descriptive explanation, a different language translation, or to define a post-coordinated​ concept.​

A.35.6 Chest CAD SR IOD​

A.35.6.1 Chest CAD SR IOD Description​

The Chest CAD SR IOD is used to convey the detection and analysis results of a chest CAD device. The content may include textual​ and a variety of coded information, numeric measurement values, references to the SOP Instances, and spatial regions of interest​ within such SOP Instances. Relationships by-reference are enabled between Content Items.​

A.35.6.2 Chest CAD SR IOD Entity-Relationship Model​

This IOD uses the E-R Model in Section A.1.2, with only the SR Document IE below the Series IE. The Frame of Reference IE is not​ a component of this IOD.​

A.35.6.3 Chest CAD SR IOD Module Table​

Table A.35.6-1 specifies the Modules of the Chest CAD SR IOD.​

Table A.35.6-1. Chest CAD SR IOD Modules​

- Standard -​

Note​

The Specimen Identification Module was previously included in this IOD but has been retired. See PS3.3-2008.​

A.35.6.3.1 Chest CAD SR IOD Content Constraints​

A.35.6.3.1.1 Template Constraints​

•​The document shall be constructed from TID 4100 “Chest CAD Document Root” invoked at the root node.​

•​When a Content Item sub-tree from a prior document is duplicated by-value, its observation context shall be defined by TID 1001​ “Observation Context” and its subordinate templates.​

Note​

All Template and Context Group definitions are located in Annex A “Structured Reporting Templates (Normative)” in PS3.16​ and Annex B “DCMR Context Groups (Normative)” in PS3.16, respectively.​

A.35.6.3.1.2 Value Type​

Value Type (0040,A040) in Content Sequence (0040,A730) of the SR Document Content Module is constrained to the following​ Enumerated Values (see Table C.17.3-7 for Value Type definitions):​

Enumerated Values:​

TEXT​

CODE​

NUM​

DATE​

TIME​

UIDREF​

PNAME​

SCOORD​

TCOORD​

COMPOSITE​

IMAGE​

WAVEFORM​

CONTAINER​

A.35.6.3.1.3 Relationship Constraints​

The Chest CAD SR IOD makes use of by-reference INFERRED FROM, by-reference SELECTED FROM, and by-reference HAS​ PROPERTIES relationships. Other relationships by-reference are forbidden. Table A.35.6-2 specifies the relationship constraints of​ this IOD. See Table C.17.3-8 for Relationship Type definitions.​

- Standard -​

Page 310​ DICOM PS3.3 2020a - Information Object Definitions​

Table A.35.6-2. Relationship Content Constraints for Chest CAD SR IOD​

Note​

1.​WhichSOPClassestheIMAGEorCOMPOSITEValueTypemayreferto,isdocumentedintheConformanceStatement​ for an application (see PS3.2 and PS3.4).​

2.​The HAS CONCEPT MOD relationship is used to modify the meaning of the Concept Name of a Source Content Item,​ for example to provide a more descriptive explanation, a different language translation, or to define a post-coordinated​ concept.​

A.35.7 Procedure Log IOD​

A.35.7.1 Procedure Log IOD Description​

The Procedure Log IOD is intended for the representation of reports or logs of time-stamped events occurring during an extended​ diagnostic or interventional procedure, typical of the cardiac catheterization lab.​

A.35.7.2 Procedure Log IOD Entity-Relationship Model​

This IOD uses the E-R Model in Section A.1.2, with only the SR Document IE below the Series IE.​

Note​

UnlikesomeotherSRIODs,theFrameofReferenceIEiscriticaltothesynchronizedtimestampingofeventsintheProcedure​ Log IOD and to multi-modality coordination.​

A.35.7.3 Procedure Log IOD Module Table​

Table A.35.7-1 specifies the Modules of the Procedure Log IOD.​

Table A.35.7-1. Procedure Log IOD Modules​
