Note​

1.​WhichSOPClassestheIMAGE,WAVEFORMorCOMPOSITEValueTypemayreferto,isdocumentedintheConform-​ ance Statement for an application (see PS3.2 and PS3.4).​

2.​The HAS CONCEPT MOD relationship is used to modify the meaning of the Concept Name of a Source Content Item,​ for example to provide a more descriptive explanation, a different language translation, or to define a post-coordinated​ concept.​

A.35.2 Enhanced SR IOD​

A.35.2.1 Enhanced SR IOD Description​

The Enhanced Structured Report (SR) IOD is a superset of the Basic Text SR IOD. It is also intended for the representation of reports​ with minimal usage of coded entries (typically Document Title and headings) and a hierarchical tree of headings under which may​ appear text and subheadings. In addition, it supports the use of numeric measurements with coded measurement names and units.​ Reference to SOP Instances (e.g., images or waveforms or SR Documents) is restricted to appear at the level of the leaves of this​ primarily textual tree. It enhances references to SOP Instances with spatial regions of interest (points, lines, circle, ellipse, etc.) and​ temporal regions of interest.​

A.35.2.2 Enhanced SR IOD Entity-Relationship Model​

This IOD uses the E-R Model in Section A.1.2, with only the SR Document IE below the Series IE. The Frame of Reference IE is not​ a component of this IOD.​

A.35.2.3 Enhanced SR IOD Module Table​

Table A.35.2-1 specifies the Modules of the Enhanced SR IOD.​

Table A.35.2-1. Enhanced SR IOD Modules​

- Standard -​

Note​

The Specimen Identification Module was previously included in this IOD but has been retired. See PS3.3-2008.​

A.35.2.3.1 Enhanced SR IOD Content Constraints​

A.35.2.3.1.1 Value Type​

Value Type (0040,A040) in Content Sequence (0040,A730) of the SR Document Content Module is constrained to the following​ Enumerated Values (see Table C.17.3-7 for Value Type definitions):​

Enumerated Values:​

TEXT​

CODE​

NUM​

DATETIME​

DATE​

TIME​

UIDREF​

PNAME​

SCOORD​

TCOORD​

COMPOSITE​

IMAGE​

WAVEFORM​

CONTAINER​

A.35.2.3.1.2 Relationship Constraints​

Relationships between Content Items in the content of this IOD shall be conveyed in the by-value mode. See Table C.17.3-8 for Re-​ lationship Type definitions.​

Note​

Relationships by-reference are forbidden. Therefore, Referenced Content Item Identifier (0040,DB73) is not present in any​ of the Content Items within the SR Document Content Module.​

Table A.35.2-2 specifies the relationship constraints of this IOD.​

Table A.35.2-2. Relationship Content Constraints for Enhanced SR IOD​

- Standard -​

1.​WhichSOPClassestheIMAGE,WAVEFORMorCOMPOSITEValueTypemayreferto,isdocumentedintheConform-​ ance Statement for an application (see PS3.2 and PS3.4).​

2.​The HAS CONCEPT MOD relationship is used to modify the meaning of the Concept Name of a Source Content Item,​ for example to provide a more descriptive explanation, a different language translation, or to define a post-coordinated​ concept.​

A.35.3 Comprehensive SR IOD​

A.35.3.1 Comprehensive SR IOD Description​

TheComprehensiveSRIODisasupersetoftheBasicTextSRIODandtheEnhancedSRIOD,whichspecifiesaclassofdocuments,​ the content of which may include textual and a variety of coded information, numeric measurement values, references to the SOP​ Instances and spatial or temporal regions of interest within such SOP Instances. Relationships by-reference are enabled between​ Content Items.​

A.35.3.2 Comprehensive SR IOD Entity-Relationship Model​

This IOD uses the E-R Model in Section A.1.2, with only the SR Document IE below the Series IE. The Frame of Reference IE is not​ a component of this IOD.​

A.35.3.3 Comprehensive SR IOD Module Table​

Table A.35.3-1 specifies the Modules of the Comprehensive SR IOD.​

Table A.35.3-1. Comprehensive SR IOD Modules​

- Standard -​

Note​

The Specimen Identification Module was previously included in this IOD but has been retired. See PS3.3-2008.​

A.35.3.3.1 Comprehensive SR IOD Content Constraints​

A.35.3.3.1.1 Value Type​

Value Type (0040,A040) in Content Sequence (0040,A730) of the SR Document Content Module is constrained to the following​ Enumerated Values (see Table C.17.3-7 for Value Type definitions):​

Enumerated Values:​

TEXT​

CODE​

NUM​

DATETIME​

DATE​

TIME​

UIDREF​

PNAME​

SCOORD​

TCOORD​

COMPOSITE​

IMAGE​

WAVEFORM​

CONTAINER​

A.35.3.3.1.2 Relationship Constraints​

Relationships between Content Items in the content of this IOD may be conveyed either by-value or by-reference. Table A.35.3-2​ specifies the relationship constraints of this IOD. See Table C.17.3-8 for Relationship Type definitions.​

Table A.35.3-2. Relationship Content Constraints for Comprehensive SR IOD​

- Standard -​

Note​

1.​WhichSOPClassestheIMAGE,WAVEFORMorCOMPOSITEValueTypemayreferto,isdocumentedintheConform-​ ance Statement for an application (see PS3.2 and PS3.4).​

2.​The HAS CONCEPT MOD relationship is used to modify the meaning of the Concept Name of a Source Content Item,​ for example to provide a more descriptive explanation, a different language translation, or to define a post-coordinated​ concept.​

The HAS CONCEPT MOD and CONTAINS relationships shall not be conveyed by-reference.​

Relationships by-reference to ancestor Content Items are forbidden in this IOD to prevent loops.​

A.35.4 Key Object Selection Document IOD​

A.35.4.1 Key Object Selection Document IOD Description​

The Key Object Selection Document IOD is intended for flagging one or more significant images, waveforms, or other composite SOP​

Instances.​

A.35.4.2 Key Object Selection Document IOD Entity-Relationship Model​

This IOD uses the E-R Model in Section A.1.2, with only the SR Document IE below the Series IE. The Frame of Reference IE is not​ a component of this IOD.​

A.35.4.3 Key Object Selection Document IOD Module Table​

Table A.35.4-1 specifies the Modules of the Key Object Selection Document IOD.​

Table A.35.4-1. Key Object Selection Document IOD Modules​

- Standard -​
