Note​

1.​The HAS CONCEPT MOD relationship is used to modify the meaning of the Concept Name of a Source Content Item,​ for example to provide a more descriptive explanation, a different language translation, or to define a post-coordinated​ concept.​

A.35.16.3.1.3 Template Constraints​

The document may be constructed from Baseline TID 8101 “Preclinical Small Animal Image Acquisition Context” invoked at the root​ node.​

Note​

This IOD maybe used with other Templates defined for Acquisition Context.​

A.35.17 Simplified Adult Echo SR IOD​

A.35.17.1 Simplified Adult Echo SR IOD Description​

TheSimplifiedAdultEchoSRIODisusedtoconveymeasurementscollectedinassociationwithanadultechocardiographyprocedure.​

A.35.17.2 Simplified Adult Echo SR IOD Entity-Relationship Model​

This IOD uses the E-R Model in Section A.1.2, with only the SR Document IE below the Series IE.​

A.35.17.3 Simplified Adult Echo SR IOD Module Table​

Table A.35.17-1 specifies the Modules of the Simplified Adult Echo SR IOD.​

Table A.35.17-1. Simplified Adult Echo SR IOD Modules​

- Standard -​

A.35.17.3.1 Simplified Adult Echo SR IOD Content Constraints​

A.35.17.3.1.1 Template​

The document shall be constructed from TID 5300 “Simplified Echo Procedure Report” invoked at the root node.​

A.35.17.3.1.2 Value Type​

Value Type (0040,A040) in Content Sequence (0040,A730) of the SR Document Content Module is constrained to the following​ Enumerated Values (see Table C.17.3-7 for Value Type definitions):​

Enumerated Values:​

TEXT​

CODE​

NUM​

DATETIME​

UIDREF​

PNAME​

CONTAINER​

IMAGE​

SCOORD​

WAVEFORM​

TCOORD​

A.35.17.3.1.3 Relationship Constraints​

Relationships between Content Items in the content of this IOD shall be conveyed in the by-value mode. See Table C.17.3-8 for Re-​ lationship Type definitions.​

Note​

Relationships by-reference are forbidden. Therefore, Referenced Content Item Identifier (0040,DB73) is not present in any​ of the Content Items within the SR Document Content Module.​

Table A.35.17-2 specifies the relationship constraints of this IOD.​

Table A.35.17-2. Relationship Content Constraints for Simplified Adult Echo SR IOD​

- Standard -​

A.35.18 Patient Radiation Dose SR IOD​

A.35.18.1 Patient Radiation Dose SR IOD Description​

ThePatientRadiationDoseStructuredReportIODisusedtoconveytheinformationusedinthecalculationsforestimatingtheradiation​ dose to an individual Patient. The complexity of the calculations and the precision of the resulting dose estimate will vary depending​ on the need.​

This IOD is not intended for determining patient dose from therapeutic use of radiation in oncology settings. The therapeutic dose in​ oncology settings is reported by the RT Dose IOD.​

A.35.18.2 Patient Radiation Dose SR IOD Entity-Relationship Model​

This IOD uses the E-R Model in Section A.1.2, with only the SR Document IE below the Series IE. Table A.35.18-1 specifies the​ Modules of the Patient Radiation Dose SR IOD.​

A.35.18.3 Patient Radiation Dose SR IOD Module Table​

Table A.35.18-1. Patient Radiation Dose Structured Report IOD Modules​

A.35.18.3.1 Patient Radiation Dose SR IOD Content Constraints​

A.35.18.3.1.1 Template​

The document shall be constructed from Baseline TID 10030 “Patient Radiation Dose” invoked at the root node.​

A.35.18.3.1.2 Value Type​

Value Type (0040,A040) in Content Sequence (0040,A730) of the SR Document Content Module is constrained to the following​ Enumerated Values (see Table C.17.3-7 for Value Type definitions):​

Enumerated Values:​

TEXT​

CODE​

NUM​

DATETIME​

- Standard -​

UIDREF​

PNAME​

COMPOSITE​

IMAGE​

CONTAINER​

A.35.18.3.1.3 Relationship Constraints​

RelationshipsbetweenContentItemsinthecontentofthisIODshallbeconveyedby-value.TableA.35.18-2specifiestherelationship​ constraints of this IOD. See Table C.17.3-8 for Relationship Type definitions.​

Table A.35.18-2. Relationship Content Constraints for Patient Radiation Dose SR IOD​

Note​

TheSOPClassestowhichanIMAGEorCOMPOSITEValueTypemayreferaredocumentedintheConformanceStatement​ for an application (see PS3.2 and PS3.4).​

A.35.19 Planned Imaging Agent Administration SR IOD​

A.35.19.1 Planned Imaging Agent Administration SR IOD Description​

The Planned Imaging Agent Administration SR IOD is the plan for administering imaging agent material to a specific patient during​ an imaging study.​

A.35.19.2 Planned Imaging Agent Administration SR IOD Entity-Relationship Model​

This IOD uses the E-R Model in Section A.1.2, with only the SR Document IE below the Series IE. The Frame Reference IE is not a​ component of this IOD.​

A.35.19.3 Planned Imaging Agent Administration SR IOD Module Table​

Table A.35.19-1. Planned Imaging Agent Administration SR IOD ModuleS​

- Standard -​

A.35.19.3.1 Planned Imaging Agent Administration SR IOD Content Constraints​

A.35.19.3.1.1 Template​

The document shall be constructed from TID 11001 “Planned Imaging Agent Administration” invoked at the root node.​

A.35.19.3.1.2 Value Type​

Value Type (0040,A040) in the Content Sequence (0040,A730) of the SR Document Content Module is constrained to the following​ Enumerated Values (see Table C.17.3-7 for Value Type definitions):​

Enumerated Values:​

TEXT​

CODE​

NUM​

DATETIME​

DATE​

UIDREF​

PNAME​

CONTAINER​

A.35.19.3.1.3 Relationship Constraints​

RelationshipsbetweenContentItemsinthecontentofthisIODshallbeconveyedby-value.TableA.35.19-2specifiestherelationship​ constraints of this IOD. See Table C.17.3-8 for Relationship Type definitions.​

Table A.35.19-2. Relationship Content Constraints for Planned Imaging Agent Administration SR IOD​
