DICOM PS3.3 2020a - Information Object Definitions​

Page 341​

IE​

Module​

Reference​



Usage​



ICC Profile​

C.11.15.1​

M​





SOP Common​

C.12.1​

M​





Common Instance Reference​

C.12.2​

U​





Frame Extraction​

C.12.3​

C - Required if the SOP Instance was​







created in response to a Frame-Level​







retrieve request​



A.36.4.3.1 Enhanced MR Color Image IOD Content Constraints​

The General Image Module, Overlay Plane Module and VOI LUT Module shall not be used in a Standard Extended SOP Class of​ the Enhanced MR Color Image.​

Note​

In order to annotate images, whether during acquisition or subsequently, SOP Instances of the Color Softcopy Presentation​ State Storage or the Structured Report Storage SOP Classes that reference the image SOP Instance, may be used.​

NostandardmechanismisprovidedforinclusionofannotationswithintheimageSOPInstanceitself,andimplementersarediscouraged​ from using private extensions to circumvent this restriction.​

Color Softcopy Presentation State Storage Instances that are generated during acquisition may be referenced from the Image SOP​ Instance by using the Referenced Presentation State Sequence in the MR Image and Spectroscopy Instance Macro invoked from​ the Enhanced MR Image Module. See Section C.8.13.2.​

Photometric Interpretation (0028,0004) shall be RGB for uncompressed or lossless compressed Transfer Syntaxes that do not have​ defined color space transformations, YBR_ICT for irreversible JPEG2000 Transfer Syntaxes, YBR_RCT for reversible JPEG2000​ Transfer Syntaxes, YBR_PARTIAL_420 for MPEG2, MPEG-4 AVC/H.264, HEVC/H.265 Transfer Syntaxes and YBR_FULL_422 for​ JPEG lossy compressed Transfer Syntaxes and YBR_FULL or RGB for RLE Transfer Syntaxes.​

Note​

Future lossless and lossy Transfer Syntaxes may lead to the need for new definitions and choices for Photometric Interpret-​ ation.​

Pixel Presentation (0008,9205) shall be TRUE_COLOR.​

A.36.4.4 Enhanced MR Color Image Functional Group Macros​

Table A.36-2 specifies the use of the Functional Group Macros used in the Multi-frame Functional Groups Module for the Enhanced​ MR Color Image IOD.​

A.37 Raw Data IOD​

A.37.1 Raw Data IOD Description​

The Raw Data Information Object Definition (IOD) specifies raw data.​

A.37.2 Raw Data Entity-Relationship Model​

This IOD uses the E-R Model in Section A.1.2, with only the Raw Data IE below the Series IE.​

A.37.3 Raw Data IOD Module Table​

Table A.37-1 specifies the Modules of the Raw Data IOD.​

- Standard -​

Page 342​ DICOM PS3.3 2020a - Information Object Definitions​

Table A.37-1. Raw Data IOD Modules​

IE​

Module​

Reference​

Usage​

Patient​

Patient​

C.7.1.1​

M​



Clinical Trial Subject​

C.7.1.3​

U​

Study​

General Study​

C.7.2.1​

M​



Patient Study​

C.7.2.2​

U​



Clinical Trial Study​

C.7.2.3​

U​

Series​

General Series​

C.7.3.1​

M​



Clinical Trial Series​

C.7.3.2​

U​

Frame of​

Frame of Reference​

C.7.4.1​

U​

Reference​

Synchronization​

C.7.4.2​

C - Required if time​









synchronizationwasapplied.​

Equipment​

General Equipment​

C.7.5.1​

M​

Raw Data​

Acquisition Context​

C.7.6.14​

M​



Specimen​

C.7.6.22​

U​



Raw Data​

C.19.1​

M​



SOP Common​

C.12.1​

M​

Note​

The Specimen Identification Module was previously included in this IOD but has been retired, and its functionality replaced​ by the Specimen Module. See PS3.3-2008.​

A.38 Enhanced Computed Tomography Image IOD​

A.38.1 Enhanced CT Image IOD​

A.38.1.1 Enhanced CT Image IOD Description​

The Enhanced Computed Tomography (CT) Image Information Object Definition (IOD) specifies an image that has been created by​ a computed tomography imaging device.​

A.38.1.2 Enhanced CT Image IOD Entity-Relationship Model​

This IOD uses the E-R Model in Section A.1.2, with only the Image IE below the Series IE.​

A.38.1.3 Enhanced CT Image IOD Module Table​

Table A.38-1 specifies the Modules of the Enhanced CT Image IOD.​

Table A.38-1. Enhanced CT Image IOD Modules​

IE​

Module​

Reference​

Usage​

Patient​

Patient​

C.7.1.1​

M​



Clinical Trial Subject​

C.7.1.3​

U​

Study​

General Study​

C.7.2.1​

M​



Patient Study​

C.7.2.2​

U​



Clinical Trial Study​

C.7.2.3​

U​

Series​

General Series​

C.7.3.1​

M​

- Standard -​



DICOM PS3.3 2020a - Information Object Definitions​

Page 343​

IE​

Module​

Reference​

Usage​





CT Series​

C.8.15.1​

M​





Clinical Trial Series​

C.7.3.2​

U​



Frame of​ Frame of Reference​

C.7.4.1​

M​



Reference​Synchronization​

C.7.4.2​

C - Required if time synchronization was​







applied.​



Equipment​General Equipment​

C.7.5.1​

M​





Enhanced General Equipment​

C.7.5.2​

M​



Image​

Image Pixel​

C.7.6.3​

M​





Enhanced Contrast/Bolus​

C.7.6.4b​

C-Requiredifcontrastmediawasapplied.​



Multi-frame Functional Groups​

C.7.6.16​

M​





Multi-frame Dimension​

C.7.6.17​

M​





Cardiac Synchronization​

C.7.6.18.1​

C-Requiredifcardiacsynchronizationwas​







applied.​





Respiratory Synchronization​

C.7.6.18.2​

C - Required if respiratory synchronization​







was applied.​





Supplemental Palette Color Lookup Table​ C.7.6.19​

C - Required if Pixel Presentation​







(0008,9205) in the Enhanced CT Image​







Module equals COLOR or MIXED.​



Acquisition Context​

C.7.6.14​

M​





Device​

C.7.6.12​

U​





Specimen​

C.7.6.22​

U​





Enhanced CT Image​

C.8.15.2​

M​





Enhanced Multi-energy CT Acquisition​

C.8.15.4​

C-RequiredifMulti-energyCTAcquisition​







(0018,9361) is YES.​





ICC Profile​

C.11.15​

U​





SOP Common​

C.12.1​

M​





Common Instance Reference​

C.12.2​

U​





Frame Extraction​

C.12.3​

C - Required if the SOP Instance was​







created in response to a Frame-Level​







retrieve request​



A.38.1.3.1 Enhanced CT Image IOD Content Constraints​

The General Image Module, Overlay Plane Module and VOI LUT Module shall not be used in a Standard Extended SOP Class of​ the Enhanced CT Image.​

Note​

1.​In order to annotate images, whether during acquisition or subsequently, SOP Instances of the Grayscale Softcopy​ Presentation State Storage or the Structured Report Storage SOP Classes that reference the image SOP Instance,​ may be used.​

No standard mechanism is provided for inclusion of annotations within the image SOP Instance itself, and implementers​ are discouraged from using private extensions to circumvent this restriction.​

GrayscaleSoftcopyPresentationStateStorageInstancesthataregeneratedduringacquisitionmaybereferencedfrom​ the Image SOP Instance by using the Referenced Grayscale Presentation State Sequence in the Enhanced CT Image​ Module. See Section C.8.15.2.​

- Standard -​

Page 344​

DICOM PS3.3 2020a - Information Object Definitions​

2.​The Curve Module (Retired) was previously include in the list of Modules that shall not be present, but has been retired​ from DICOM. It is still not permitted to be present. See PS3.3-2004.​

3.​TheSpecimenIdentificationModulewaspreviouslyincludedinthisIODbuthasbeenretired,anditsfunctionalityreplaced​ by the Specimen Module. See PS3.3-2008.​

4.​TheEnhancedContrast/BolusModulewillbepresentevenifimagesareprocessedtoremovecontrastinformationfrom​ the pixels, e.g. Virtual Non-Contrast images.​

A.38.1.4 Enhanced CT Image Functional Group Macros​

Table A.38-2 specifies the use of the Functional Group Macros used in the Multi-frame Functional Groups Module for the Enhanced​ CT Image IOD.​

Table A.38-2. Enhanced CT Image Functional Group Macros​

Functional Group Macro​

Section​

Usage​

Pixel Measures​

C.7.6.16.2.1​

M​

Frame Content​

C.7.6.16.2.2​

M - May not be used as a Shared Functional Group.​

Plane Position (Patient)​

C.7.6.16.2.3​

M​

Plane Orientation (Patient)​

C.7.6.16.2.4​

M​

Referenced Image​

C.7.6.16.2.5​

C - Required if the image or frame has been planned on another​





image or frame, may be present otherwise.​

Derivation Image​

C.7.6.16.2.6​

C-Requirediftheimageorframehasbeenderivedfromanother​





SOP Instance.​

Cardiac Synchronization​

C.7.6.16.2.7​

C - Required if Cardiac Synchronization Technique (0018,9037)​





equals other than NONE and if Image Type (0008,0008) Value​





1 is ORIGINAL or MIXED. May be present otherwise.​

Frame Anatomy​

C.7.6.16.2.8​

M​

Frame VOI LUT​

C.7.6.16.2.10​

U​

Real World Value Mapping​

C.7.6.16.2.11​

C - Required if Multi-energy CT Acquisition (0018,9361) is YES.​





May be present otherwise.​

Contrast/Bolus Usage​

C.7.6.16.2.12​

C - Required if Contrast/Bolus Agent Sequence (0018,0012) is​





used.​

Respiratory Synchronization​

C.7.6.16.2.17​

C - Required if Respiratory Motion Compensation Technique​





(0018,9170) equals other than NONE, REALTIME or​





BREATH_HOLD and if Image Type (0008,0008) Value 1 is​





ORIGINAL or MIXED. May be present otherwise.​

Irradiation Event Identification​

C.7.6.16.2.18​

M​

CT Image Frame Type​

C.8.15.3.1​

M​

CT Acquisition Type​

C.8.15.3.2​

C - Required if Image Type (0008,0008) Value 1 is ORIGINAL​





or MIXED, may be present otherwise.​

CT Acquisition Details​

C.8.15.3.3​

C - Required if Image Type (0008,0008) Value 1 is ORIGINAL​





or MIXED, may be present otherwise.​

CT Table Dynamics​

C.8.15.3.4​

C - Required if Image Type (0008,0008) Value 1 is ORIGINAL​





or MIXED, may be present otherwise.​

CT Position​

C.8.15.3.5​

C - Required if Image Type (0008,0008) Value 1 is ORIGINAL​





or MIXED, may be present otherwise​

CT Geometry​

C.8.15.3.6​

C - Required if Image Type (0008,0008) Value 1 is ORIGINAL​





or MIXED, may be present otherwise.​

- Standard -​



DICOM PS3.3 2020a - Information Object Definitions​

Page 345​

Functional Group Macro​

Section​

Usage​



CT Reconstruction​

C.8.15.3.7​

C - Required if Image Type (0008,0008) Value 1 is ORIGINAL​





or MIXED and Acquisition Type (0018,9302) is other than​





CONSTANT_ANGLE, may be present otherwise.​



CT Exposure​

C.8.15.3.8​

C - Required if Image Type (0008,0008) Value 1 is ORIGINAL​





or MIXED, may be present otherwise.​



CT X-Ray Details​

C.8.15.3.9​

C - Required if Image Type (0008,0008) Value 1 is ORIGINAL​





or MIXED, may be present otherwise.​



CT Pixel Value Transformation​

C.8.15.3.10​

M​



CT Additional X-Ray Source​

C.8.15.3.11​

C - Required if the image is reconstructed from a system with​





multiple X-Ray sources.​



Multi-energy CT Processing​

C.8.15.3.13​

C - Required if the image pixel data contains the results of​





Multi-energy material processing.​



Multi-energy CT Characteristics​

C.8.15.3.12​

U​



Temporal Position​

C.7.6.16.2.23​

U​



The defined CID for Measurement Units Code Sequence (0040,08EA) in the Real World Value Mapping Sequence (0040,9096) is​ CID 301 “Multi-energy Material Units””.​

A.39 Spatial Registration Information Object Definitions​

A.39.1 Spatial Registration IOD​

A.39.1.1 Spatial Registration IOD Description​

The Registration IOD specifies the spatial relationship between Frames of Reference.​

A.39.1.2 Spatial Registration IOD Entity-Relationship Model​

This IOD uses the E-R Model in Section A.1.2, with only the Registration IE below the Series IE.​

A.39.1.3 Spatial Registration IOD Module Table​

Table A.39.1-1 specifies the Modules of the Spatial Registration IOD.​

Table A.39.1-1. Spatial Registration IOD Modules​

IE​

Module​

Reference​

Usage​

Patient​

Patient​

C.7.1.1​

M​



Clinical Trial Subject​

C.7.1.3​

U​

Study​

General Study​

C.7.2.1​

M​



Patient Study​

C.7.2.2​

U​



Clinical Trial Study​

C.7.2.3​

U​

Series​

General Series​

C.7.3.1​

M​



Clinical Trial Series​

C.7.3.2​

U​



Spatial Registration Series​

C.20.1​

M​

Frame of Reference​Frame of Reference​

C.7.4.1​

M​

Equipment​

General Equipment​

C.7.5.1​

M​

Spatial Registration​Spatial Registration​

C.20.2​

M​



Common Instance Reference​

C.12.2​

M​

- Standard -​
