A.32.4.3 VL Photographic Image IOD Content Constraints​

A.32.4.3.1 Modality​

The value of Modality (0008,0060) shall be XC.​

A.32.4.3.2 Anatomic Region Sequence​

For dermatology applications:​

•​the Baseline CID for Anatomic Region Sequence (0008,2218) is CID 4029 “Dermatology Anatomic Sites”​ •​the Baseline CID for Anatomic Region Modifier Sequence (0008,2220) is CID 245 “Laterality with Median”​

A.32.5 Video Endoscopic Image IOD​

A.32.5.1 Video Endoscopic Image IOD Description​

The Video Endoscopic Image IOD specifies the Attributes of Multi-frame Video Endoscopic Images.​

A.32.5.2 Video Endoscopic Image IOD Entity-Relationship Model​

This IOD uses the E-R Model in Section A.1.2, with only the Image IE below the Series IE. The Frame of Reference IE is not a com-​ ponent of this IOD.​

Note​

1.​The video may include audio channel(s) for acquiring Patient voice or physiological sounds, healthcare professionals'​ commentary, or environmental sounds.​

2.​The Frame Pointers Module has not been included because the selection of relevant sub-sequence(s) is usually made​ in a second workflow step and stored into separate Key Object Selection Documents.​

3.​The Curve entity was previously include in the list of entities that are not used, but has been retired from DICOM. It is​ still not used in this IOD. See PS3.3-2004.​

Table A.32.5-1. Video Endoscopic Image IOD Modules​

- Standard -​

A.32.5.3 Video Endoscopic Image IOD Content Constraints​

A.32.5.3.1 Modality​

The value of Modality (0008,0060) shall be ES.​

Note​

The use of a single value for Modality recognizes the fact that the same acquisition equipment is often used for different​ purposes (e.g., laparoscopy and colonoscopy). This means that Modality is not useful to distinguish one type of endoscopy​ from another when browsing a collection of Studies. Therefore, the use of Procedure Code Sequence (0008,1032) and​ Anatomic Region Sequence (0008,2218) in the image instances and in the query response is recommended, though gath-​ ering sufficient information to populate these Attributes in an unscheduled workflow environment (i.e., in the absence of​ Modality Worklist) may require operator intervention.​

A.32.5.3.2 Image Related Data Encoding​

The Modality LUT Module, VOI LUT Module, Graphic Annotation Module and Overlay Plane Module shall not be present.​

Note​

The Curve Module (Retired) was previously include in the list of Modules that shall not be present, but has been retired from​ DICOM. It is still not permitted to be present. See PS3.3-2004.​

A.32.5.3.3 Anatomic Region Sequence​

The Defined Context Group for Anatomic Region Sequence (0008,2218) shall be CID 4040 “Endoscopy Anatomic Regions”.​

A.32.6 Video Microscopic Image IOD​

A.32.6.1 Video Microscopic Image IOD Description​

The Video Microscopic Image IOD specifies the Attributes of Video Microscopic Images, including both imaging of specimens and​ direct microscopic imaging of the Patient (e.g., perioperative microscopy). Microscopic Images with Slide Coordinates shall not be​ encoded with this IOD.​

A.32.6.2 Video Microscopic Image IOD Entity-Relationship Model​

This IOD uses the E-R Model in Section A.1.2, with only the Image IE below the Series IE. The Frame of Reference IE is not a com-​ ponent of this IOD.​

Note​

1.​The video may include audio channel for acquiring Patient voice or physiological sounds, healthcare professionals​ comment, or environment sounds.​

- Standard -​

2.​The Frame Pointers Module has not been included because the selection of relevant sub-sequence(s) is usually made​ in a second step and stored into separate Key Object Selection Documents.​

3.​The Curve entity was previously include in the list of entities that are not used, but has been retired from DICOM. It is​ still not used in this IOD. See PS3.3-2004.​

4.​TheSpecimenIdentificationModulewaspreviouslyincludedinthisIODbuthasbeenretired,anditsfunctionalityreplaced​ by the Specimen Module. See PS3.3-2008.​

Table A.32.6-1. Video Microscopic Image IOD Modules​

A.32.6.3 Video Microscopic Image IOD Content Constraints​

A.32.6.3.1 Modality​

The value of Modality (0008,0060) shall be GM.​

A.32.6.3.2 Image Related Data Encoding​

The Modality LUT Module, VOI LUT Module, Graphic Annotation Module and Overlay Plane Module shall not be present.​

Note​

The Curve Module (Retired) was previously include in the list of Modules that shall not be present, but has been retired from​ DICOM. It is still not permitted to be present. See PS3.3-2004.​

- Standard -​

A.32.7 Video Photographic Image IOD​

A.32.7.1 Video Photographic Image IOD Description​

The Video Photographic Image IOD specifies the Attributes of VL Multi-frame photographic Images.​

A.32.7.2 Video Photographic Image IOD Entity-Relationship Model​

This IOD uses the E-R Model in Section A.1.2, with only the Image IE below the Series IE. The Frame of Reference IE is not a com-​ ponent of this IOD.​

Note​

1.​The video may include audio channel for acquiring Patient voice or physiological sounds, healthcare professionals​ comment, or environment sounds.​

2.​The Frame Pointers Module has not been included because the selection of relevant sub-sequence(s) is usually made​ in a second step and stored into separate Key Object Selection Documents.​

3.​The Curve entity was previously include in the list of entities that are not used, but has been retired from DICOM. It is​ still not used in this IOD. See PS3.3-2004.​

4.​TheSpecimenIdentificationModulewaspreviouslyincludedinthisIODbuthasbeenretired,anditsfunctionalityreplaced​ by the Specimen Module. See PS3.3-2008.​

Table A.32.7-1. Video Photographic Image IOD Modules​

- Standard -​

A.32.7.3 Video Photographic Image IOD Content Constraints​

A.32.7.3.1 Modality​

The value of Modality (0008,0060) shall be XC.​

A.32.7.3.2 Image Related Data Encoding​

The Modality LUT Module, VOI LUT Module, Graphic Annotation Module and Overlay Plane Module shall not be present.​

Note​

The Curve Module (Retired) was previously include in the list of Modules that shall not be present, but has been retired from​ DICOM. It is still not permitted to be present. See PS3.3-2004.​

A.32.8 VL Whole Slide Microscopy Image IOD​

A.32.8.1 VL Whole Slide Microscopy Image IOD Description​

TheVLWholeSlideMicroscopyImageIODspecifiestheAttributesofamulti-framevisiblelightwholeslidemicroscopyimageencoded​ as a tiled decomposition. Each frame encodes a single tile within a three-dimensional imaged volume at a uniform resolution.​

Note​

An entire set of tiles for an acquisition may be encoded in the frames of a single SOP Instance, in multiple SOP Instances​ ofasingleconcatenation,orinmultipleSOPInstancesinaSeries(withorwithoutconcatenations).E.g.,asingleSOPInstance​ may contain an entire low resolution image as a single tile (single frame), or a single SOP Instance may contain an entire​ high resolution, multi-focal depth, multi-spectral acquisition (multiple frames).​

A.32.8.2 VL Whole Slide Microscopy Image IOD Entity-Relationship Model​

This IOD uses the E-R Model in Section A.1.2, with only the Image IE below the Series IE.​

A.32.8.3 VL Whole Slide Microscopy Image IOD Module Table​

Table A.32.8-1 specifies the Modules of the VL Whole Slide Microscopy Image IOD.​

Table A.32.8-1. VL Whole Slide Microscopy Image IOD Modules​

- Standard -​
