DICOM PS3.3 2020a - Information Object Definitions​

Page 271​

IE​

Module​

Reference​

Usage​

Equipment​General Equipment​

C.7.5.1​

M​



Enhanced General Equipment​

C.7.5.2​

M​

Image​

General Image​

C.7.6.1​

M​



General Reference​

C.12.4​

U​



Image Pixel​

C.7.6.3​

M​



Acquisition Context​

C.7.6.14​

M​



Multi-frame Functional Groups​

C.7.6.16​

M​



Multi-frame Dimension​

C.7.6.17​

M​



Specimen​

C.7.6.22​

M​



Whole Slide Microscopy Image​

C.8.12.4​

M​



Optical Path​

C.8.12.5​

M​



Multi-Resolution Navigation​

C.8.12.7​

C - Required if Image Type​







(0008,0008) Value 3 is LOCALIZER​



Slide Label​

C.8.12.8​

C - Required if Image Type​







(0008,0008) Value 3 is LABEL; may​







be present otherwise​



SOP Common​

C.12.1​

M​



Common Instance Reference​

C.12.2​

M​



Frame Extraction​

C.12.3​

C-RequirediftheSOPInstancewas​







createdinresponsetoaFrame-Level​







retrieve request​

A.32.8.3.1 VL Whole Slide Microscopy Image IOD Content Constraints​

A.32.8.3.1.1 Optical Path Module​

TheCodeSequenceswithintheOpticalPathSequence(0048,0105)oftheOpticalPathModule(seeSectionC.8.12.5)areconstrained​ as follows:​

Baseline CID for Illuminator Type Code Sequence (0048,0100) is CID 8125 “Microscopy Illuminator Type”.​

Baseline CID for Illumination Color Code Sequence (0048,0108) is CID 8122 “Microscopy Illuminator and Sensor Color”.​

Baseline CID for Illumination Type Code Sequence (0022,0016) is CID 8123 “Microscopy Illumination Method”.​

Baseline CID for Lenses Code Sequence (0022,0019) is CID 8121 “Microscopy Lens Type”.​

Baseline CID for Light Path Filter Type Stack Code Sequence (0022,0017) and for Image Path Filter Type Stack Code Sequence​ (0022,0018) is CID 8124 “Microscopy Filter”.​

Baseline CID for Channel Description Code Sequence (0022,001A) is CID 8122 “Microscopy Illuminator and Sensor Color”.​

A.32.8.4 VL Whole Slide Microscopy Image Functional Group Macros​

Table A.32.8-2 specifies the use of the Functional Group Macros used in the Multi-frame Functional Groups Module for the VL Whole​

Slide Microscopy Image IOD.​

Table A.32.8-2. VL Whole Slide Microscopy Image Functional Group Macros​

Functional Group Macro​

Section​

Usage​

Pixel Measures​

C.7.6.16.2.1​

M - Shall be used as a Shared Functional Group.​

Frame Content​

C.7.6.16.2.2​

U - Shall not be used as a Shared Functional Group.​

- Standard -​

Page 272​

DICOM PS3.3 2020a - Information Object Definitions​

Functional Group Macro​

Section​

Usage​

Referenced Image​

C.7.6.16.2.5​

U​

Derivation Image​

C.7.6.16.2.6​

C - Required if the image or frame has been derived from​





another SOP Instance.​

Real World Value Mapping​

C.7.6.16.2.11​

U-MaybeusedonlyifPhotometricInterpretation(0028,0004)​





is MONOCHROME2.​

Plane Position (Slide)​

C.8.12.6.1​

C - Required if Dimension Organization Type (0020,9311) is​





not TILED_FULL; may be present otherwise.​

Optical Path Identification​

C.8.12.6.2​

C - Required if Dimension Organization Type (0020,9311) is​





not TILED_FULL; may be present otherwise.​

Specimen Reference​

C.8.12.6.3​

U​

Whole Slide Microscopy Image Frame​C.8.12.9​

M - Shall be used as a Shared Functional Group.​

Type​





Note​

The Plane Position (Slide) and Optical Path Identification Macros are Type C, which allows the Per-Frame Functional Group​ Sequence(5200,9230)tobeentirelyomittedinthosecasesinwhichtherearenootherPer-FrameFunctionalGroupMacros​ with content (i.e., the Frame Content Macro is empty or absent).​

A.32.8.4.1 VL Whole Slide Microscopy Image Functional Group Macros Content Constraints​

A.32.8.4.1.1 Referenced Image​

Defined CID for Purpose of Reference Code Sequence (0040,A170) in the Referenced Image Functional Group is CID 8120 “WSI​ Referenced Image Purposes of Reference”.​

A.32.8.4.1.2 Plane Position (Slide)​

Frames shall occupy plane positions in a regular tiling of the Total Image Matrix; the frames may extend beyond the edges of the​ Total Image Matrix. Therefore, the value of Column Position In Total Pixel Matrix (0048,021E) shall be an integer multiple of the value​ of Columns (0028,0011) plus a constant, and the value of Row Position In Total Pixel Matrix (0048,021F) shall be an integer multiple​ of the value of Rows (0028,0010) plus a (possibly different) constant.​

Note​

Pixels beyond the edge of the Total Image Matrix may be encoded with a fixed padding value. For images with MONO-​ CHROME2 Photometric Interpretation, see Pixel Padding Value (0028,0120) in Section C.7.5.1.1.2.​

The encoding of tiles may be sparse; i.e., some tiles may not be encoded in frames. There are no constraints on the ordering of​ frames within the pixel data; each frame specifies its position in the Plane Position (Slide) Functional Group.​

Note​

Different SOP Instances within a Series may have different tiling boundaries and sizes.​

Frames associated with different optical paths may coincide in any spatial dimension.​

A.32.9 Real-Time Video Endoscopic Image IOD​

A.32.9.1 Real-Time Video Endoscopic Image IOD Description​

The Real-Time Video Endoscopic Image IOD specifies the Attributes of Multi-frame Video Endoscopic Images transmitted in real-​ time.​

A.32.9.2 Real-Time Video Endoscopic Image IOD Entity-Relationship Model​

This IOD uses the E-R Model in Section A.1.2, with only the Image IE and Frame of Reference IE below the Series IE.​

- Standard -​

DICOM PS3.3 2020a - Information Object Definitions​ Page 273​

Table A.32.9-1. Real-Time Video Endoscopic Image IOD Modules​

IE​

Module​

Reference​

Usage​

Patient​

Patient​

C.7.1.1​

M​



Clinical Trial Subject​

C.7.1.3​

U​

Study​

General Study​

C.7.2.1​

M​



Patient Study​

C.7.2.2​

U​



Clinical Trial Study​

C.7.2.3​

U​

Series​

General Series​

C.7.3.1​

M​



Clinical Trial Series​

C.7.3.2​

U​

Equipment​General Equipment​

C.7.5.1​

M​



Enhanced General Equipment​

C.7.5.2​

M​

Frame of​ Frame of Reference​

C.7.4.1​

C - Required if multiple instances are​

Reference​



spatially related or if the Camera​







Position Functional Group Macro is​







present in the Current Frame​







Functional Groups Module​



Synchronization​

C.7.4.2​

M​

Image​

General Image​

C.7.6.1​

M​



General Reference​

C.12.4​

U​



Real-Time Bulk Data Flow​

C.7.6.26​

M​



Acquisition Context​

C.7.6.14​

M​



Device​

C.7.6.12​

U​



Specimen​

C.7.6.22​

C - Required if the Imaging Subject​







is a Specimen​



VL Image​

C.8.12.1​

M​



ICC Profile​

C.11.15​

M​



SOP Common​

C.12.1​

M​



Common Instance Reference​

C.12.2​

M​



Real-Time Acquisition​

C.7.6.28​

M​



Current Frame Functional Groups​

C.7.6.27​

M​

A.32.9.3 Real-Time Video Endoscopic Image IOD Content Constraints​

The IOD shall not include audio. Captured patient voice or physiological sounds, healthcare professionals' commentary, or environ-​ mental sounds will be transported in a separate IOD.​

A.32.9.3.1 Modality​

The value of Modality (0008,0060) shall be ES.​

Note​

The use of a single value for Modality recognizes the fact that the same acquisition equipment is often used for different​ purposes (e.g., laparoscopy and colonoscopy). This means that Modality is not useful to distinguish one type of endoscopy​ from another when browsing a collection of studies. Therefore, the use of Procedure Code Sequence (0008,1032) and​ Anatomic Region Sequence (0008,2218) in the image instances and in the query response is recommended, though gath-​ ering sufficient information to populate these attributes in an unscheduled workflow environment (i.e.; in the absence of​ Modality Worklist) may require operator intervention.​

- Standard -​

Page 274​

DICOM PS3.3 2020a - Information Object Definitions​

A.32.9.3.2 Image Related Data Encoding​

The Modality LUT Module, VOI LUT Module, Volumetric Graphic Annotation Module and Overlay Plane Module shall not be present.​

A.32.9.3.3 Anatomic Region Sequence​

The Defined Context Group for Anatomic Region Sequence (0008,2218) shall be CID 4040 “Endoscopy Anatomic Regions”.​

A.32.9.3.4 Current Frame Functional Groups​

The C.7.6.27 Current Frame Functional Groups Module shall be placed in the dynamic part of the RTP Payload.​

Table A.32.9-2 specifies the Functional Group Macros included in the Current Frame Functional Groups Module for the Real-Time​ Video Endoscopic Image IOD.​

Table A.32.9-2. Real-Time Video Endoscopic Image Functional Groups Macros​

Functional Group Macro​

Section​

Usage​

Time of Frame​

C.7.6.16.2.29​

M - shall not be used as a Shared Functional Group​

Frame Content​

C.7.6.16.2.2​

M - shall not be used as a Shared Functional Group​

Frame Usefulness​

C.7.6.16.2.27​

U - shall not be used as a Shared Functional Group​

Camera Position​

C.7.6.16.2.28​

U​

A.32.9.3.5 Time Distribution Protocol​

The Time Distribution Protocol (0018,1802) of the Synchronization Module shall be set to "PTP".​

A.32.10 Real-Time Video Photographic Image IOD​

A.32.10.1 Real-Time Video Photographic Image IOD Description​

The Real-Time Video Photographic Image IOD specifies Multi-frame photographic Images, transmitted in real-time.​

A.32.10.2 Real-Time Video Photographic Image IOD Entity-Relationship Model​

This IOD uses the E-R Model in Section A.1.2, with only the Image IE below the Series IE.​

Note​

The Frame Pointers Module is included to managed the temporal synchronization with the video signal the IOD is referring,​ and optionally the spatial reference if each frame information contains a spatial position.​

Table A.32.10-1. Real-Time Video Photographic Image IOD Modules​

IE​

Module​

Reference​

Usage​

Patient​

Patient​

C.7.1.1​

M​



Clinical Trial Subject​

C.7.1.3​

U​

Study​

General Study​

C.7.2.1​

M​



Patient Study​

C.7.2.2​

U​



Clinical Trial Study​

C.7.2.3​

U​

Series​

General Series​

C.7.3.1​

M​



Clinical Trial Series​

C.7.3.2​

U​

Equipment​General Equipment​

C.7.5.1​

M​



Enhanced General Equipment​

C.7.5.2​

M​

- Standard -​



DICOM PS3.3 2020a - Information Object Definitions​

Page 275​

IE​

Module​

Reference​

Usage​



Frame of​ Frame of Reference​

C.7.4.1​

C - Required if multiple instances are​

Reference​



spatially related or if the Camera​







Position Functional Group Module is​







present in the Current Frame​







Functional Groups Module​



Synchronization​

C.7.4.2​

M​



Image​

General Image​

C.7.6.1​

M​





General Reference​

C.12.4​

U​





Real-Time Bulk Data Flow​

C.7.6.26​

M​





Acquisition Context​

C.7.6.14​

M​





Device​

C.7.6.12​

U​





Specimen​

C.7.6.22​

C - Required if the Imaging Subject​







is a Specimen​





VL Image​

C.8.12.1​

M​





ICC Profile​

C.11.15​

U​





SOP Common​

C.12.1​

M​





Common Instance Reference​

C.12.2​

M​





Real-Time Acquisition​

C.7.6.28​

M​





Current Frame Functional Groups​

C.7.6.27​

M​



A.32.10.3 Real-Time Video Photographic Image IOD Content Constraints​

The IOD shall not include audio. Captured patient voice or physiological sounds, healthcare professionals' commentary, or environ-​ mental sounds will be transported in a separate IOD.​

A.32.10.3.1 Modality​

The value of Modality (0008,0060) shall be XC.​

A.32.10.3.2 Image Related Data Encoding​

The Modality LUT Module, VOI LUT Module, Volumetric Graphic Annotation Module and Overlay Plane Module shall not be present.​

A.32.10.3.3 Current Frame Functional Groups​

The C.7.6.27 Current Frame Functional Groups Module shall be placed in the dynamic part of the RTP Payload.​

Table A.32.10-2 specifies the Functional Group Macros included in the Current Frame Functional Groups Module for the Real-Time​ Video Photographic Image IOD.​

Table A.32.10-2. Real-Time Video Photographic Image Functional Group Macros​

Functional Group Macro​

Section​

Usage​

Time of Frame​

C.7.6.16.2.29​

M - shall not be used as a Shared Functional Group​

Frame Content​

C.7.6.16.2.2​

M - shall not be used as a Shared Functional Group​

Frame Usefulness​

C.7.6.16.2.27​

U - shall not be used as a Shared Functional Group​

Camera Position​

C.7.6.16.2.28​

U​

A.32.10.3.4 Time Distribution Protocol​

The Time Distribution Protocol (0018,1802) of the Synchronization Module shall be set to "PTP".​

- Standard -​
