Attribute Name |
Tag |
Type |
Description |
|
>Radiation Source |
(3010,0095) |
1C |
RotationangleindegreesoftheRadiationSourceCoordinateSystem |
Coordinate System Roll |
|
|
about its y-axis after the Radiation Source Coordinate System Yaw |
Angle |
|
|
Angle (3010,0094) is applied. |
|
|
|
|
Required if RT Record Flag (300A,0639) is NO and the conditions in |
|
|
|
Section C.36.2.2.5.1.1 are satisfied. |
|
|
|
|
May be present if RT Record Flag (300A,0639) is YES and the |
|
|
|
conditions in Section C.36.2.2.5.1.1 are satisfied. |
|
>Radiation Source |
(3010,0096) |
1C |
RotationangleindegreesoftheRadiationSourceCoordinateSystem |
Coordinate System Pitch |
|
|
about its x-axis after the Radiation Source Coordinate System Roll |
Angle |
|
|
Angle (3010,0095) is applied. |
|
Required if RT Record Flag (300A,0639) is NO and the conditions in
Section C.36.2.2.5.1.1 are satisfied.
May be present if RT Record Flag (300A,0639) is YES and the conditions in Section C.36.2.2.5.1.1 are satisfied.
>Include Table C.36.2.2.9-1 “RT Beam Limiting Device Opening Macro Attributes”.
Note
1.The values of Robotic Node Identifer (3010,0092) within the Robotic Path Control Point Sequence (3010,0097) may identify Robotic Node positions that are pre-defined in the device configuration. This Attribute is distinct from the RT ControlPointIndex(300A,0600),whichsimplyindexesitemswithintheRoboticPathControlPointSequence(3010,0097).
