Page 496​

DICOM PS3.3 2020a - Information Object Definitions​

Attribute Name​

Tag​

Type​

Attribute Description​

Performing Physician​

(0008,1052)​

3​

Identification of the physician(s) administering the Series.​

Identification Sequence​





One or more Items are permitted in this Sequence. If more than one​













Item,thenumberandordershallcorrespondtothevalueofPerforming​







Physician's Name (0008,1050), if present.​

>Include Table 10-1 “Person Identification Macro Attributes​



Description”​







Protocol Name​

(0018,1030)​

3​

User-defineddescriptionoftheconditionsunderwhichtheSerieswas​







performed.​







Note​







This Attribute conveys Series-specific protocol identification​







and may or may not be identical to the protocol described in​







the Performed Protocol Code Sequence (0040,0260) in the​







Performed Protocol Code Sequence (0040,0260) in​







Table 10-16 “Performed Procedure Step Summary Macro​







Attributes”.​

Referenced Defined​

(0018,990C)​

1C​

DefinedProcedureProtocolSOPInstance(s)thatwereusedtocreate​

Protocol Sequence​





Instances in this Series.​

Required if this instance is a Performed Procedure Protocol that​ resulted from a Defined Procedure Protocol.​

May be present otherwise.​

One or more Items shall be included in this Sequence.​

Note​

Multiple Items in this Sequence may represent a group case​ where several Defined Procedure Protocols were performed​ together as a single Performed Procedure Protocol.​

>Include Table 10-11 “SOP Instance Reference Macro​

Attributes”​

Referenced Performed​

(0018,990D)​

1C​

UniquelyidentifiesthePerformedProcedureProtocolSOPInstance(s)​

Protocol Sequence​





that describe the conditions by which this Series was generated.​

Required if a related Performed Procedure Protocol SOP Instance​ was created.​

One or more Items shall be included in this Sequence.​

Note​

Iftheacquisitionandreconstructionwererecordedinseparate​ Performed Procedure Protocol SOP Instances, it is​ recommended to reference both. However, it is not intended​ that this Sequence reference Defined or prior Performed​ Protocol SOP Instances on which the current Performed​ Procedure Protocol SOP Instance was based. Such​ references may be found inside the current Performed​ Procedure Protocol SOP Instance itself.​

>Include Table 10-11 “SOP Instance Reference Macro​

Attributes”​

Series Description​

(0008,103E)​

3​

Description of the Series​

- Standard -​



DICOM PS3.3 2020a - Information Object Definitions​

Page 497​

Attribute Name​

Tag​

Type​

Attribute Description​



Series Description Code​

(0008,103F)​

3​

A coded description of the Series.​



Sequence​





Only a single Item is permitted in this Sequence.​











>Include Table 8.8-1 “Code Sequence Macro Attributes”​

No Baseline CID is defined.​



Operators' Name​

(0008,1070)​

3​

Name(s) of the operator(s) supporting the Series.​



Operator Identification​

(0008,1072)​

3​

Identification of the operator(s) supporting the Series.​



Sequence​





One or more Items are permitted in this Sequence. If more than one​













Item,thenumberandordershallcorrespondtothevalueofOperators'​







Name (0008,1070), if present.​



>Include Table 10-1 “Person Identification Macro Attributes​





Description”​









Referenced Performed​

(0008,1111)​

3​

Uniquely identifies the Performed Procedure Step SOP Instance to​

Procedure Step​





which the Series is related.​



Sequence​





Only a single Item is permitted in this Sequence.​











>Include Table 10-11 “SOP Instance Reference Macro​





Attributes”​









RelatedSeriesSequence​

(0008,1250)​

3​

Identification of Series significantly related to this Series.​









One or more Items are permitted in this Sequence.​









Note​









1.​For example, for a combined CT and PET acquisition,​







the CT images and PET images would be in separate​







Seriesthatcouldcross-referenceeachotherwithmultiple​







purpose of reference codes meaning same anatomy,​







simultaneously acquired and same indication.​









2.​The related Series may have different Frames of​







Reference and hence require some sort of registration​







before spatial coordinates can be directly compared.​







3.​This Attribute is not intended for conveying localizer​







reference information, for which Referenced Image​







Sequence (0008,1140) should be used.​



>Study Instance UID​

(0020,000D)​

1​

Instance UID of Study to which the related Series belongs​

>Series Instance UID​

(0020,000E)​

1​

Instance UID of Related Series​



>Purpose of Reference​

(0040,A170)​

2​

Describes the purpose for which the reference is made.​



Code Sequence​





Zero or more Items shall be included in this Sequence.​

















When absent, implies that the reason for the reference is unknown.​

>>Include Table 8.8-1 “Code Sequence Macro Attributes”​

DCID 7210 “Related Series Purposes of Reference”.​



Body Part Examined​

(0018,0015)​

3​

Text description of the part of the body examined. See Annex L​

“CorrespondenceofAnatomicRegionCodesandBodyPartExamined​ Defined Terms” in PS3.16 for Defined Terms​

Note​

Some IODs support the Anatomic Region Sequence​ (0008,2218), which can provide a more comprehensive​ mechanism for specifying the body part being examined.​

- Standard -​

Page 498​

DICOM PS3.3 2020a - Information Object Definitions​

Attribute Name​

Tag​

Type​

Attribute Description​

Patient Position​

(0018,5100)​

2C​

Patient position descriptor relative to the equipment. Required for​







images where Patient Orientation Code Sequence (0054,0410) is not​







present and whose SOP Class is one of the following: CT​







("1.2.840.10008.5.1.4.1.1.2") or MR ("1.2.840.10008.5.1.4.1.1.4") or​







EnhancedCT("1.2.840.10008.5.1.4.1.1.2.1")orEnhancedMRImage​







("1.2.840.10008.5.1.4.1.1.4.1") or Enhanced Color MR Image​







("1.2.840.10008.5.1.4.1.1.4.3") or MR Spectroscopy​







("1.2.840.10008.5.1.4.1.1.4.2") Storage SOP Classes.​







May be present for other SOP Classes if Patient Orientation Code​







Sequence (0054,0410) is not present.​







See Section C.7.3.1.1.2 for Defined Terms and further explanation.​

Smallest Pixel Value in​

(0028,0108)​

3​

The minimum value of all images in this Series.​

Series​







Largest Pixel Value in​

(0028,0109)​

3​

The maximum value of all images in this Series.​

Series​







Request Attributes​

(0040,0275)​

3​

Sequence that contains Attributes from the Imaging Service Request.​

Sequence​





One or more Items are permitted in this Sequence.​







>Include Table 10-9 “Request Attributes Macro Attributes”​

No Baseline CID is defined.​

Include Table 10-16 “Performed Procedure Step Summary​ No Baseline CID is defined.​

Macro Attributes”​







Anatomical Orientation​

(0010,2210)​

1C​

The anatomical orientation type used in instances generated by this​

Type​





equipment.​

Enumerated Values:​

BIPED​

QUADRUPED​

Required if the Patient is an animal and the anatomical Frame of​

Reference is not bipedal. May be present otherwise. See​

Section C.7.6.1.1.1 and Section C.7.6.2.1.1.​

Note​

If this Attribute is not present, the default human standard​ anatomical position is used to define the patient orientation​ of projection images and the Patient-Based Coordinate​ System of cross-sectional images.​

Note​

1.​IfanyPerformedProcedureStepSOPClassissupportedasanSCUbyaStorageSCU,theSCUisstronglyencouraged​ to support the Attribute Referenced Performed Procedure Step Sequence (0008,1111). This Attribute references the​ Performed Procedure Step SOP Instance, and extraction of this Attribute from a Composite Instance may allow retrieval​ of the Performed Procedure Step SOP Instance.​

2.​If the Storage SCU does not conform to any Performed Procedure Step SOP Class, it is still advisable to include the​ Attributes Performed Procedure Step Start Date (0040,0244), Performed Procedure Step Start Time (0040,0245) and​ Performed Procedure Step Description (0040,0254) into the Composite Instances.​

- Standard -​

DICOM PS3.3 2020a - Information Object Definitions​

Page 499​

C.7.3.1.1 General Series Attribute Descriptions​

C.7.3.1.1.1 Modality​

Defined Terms:​

AR​

Autorefraction​

ASMT​

Content Assessment Results​

AU​

Audio​

BDUS​

Bone Densitometry (ultrasound)​

BI​

Biomagnetic imaging​

BMD​

Bone Densitometry (X-Ray)​

CR​

Computed Radiography​

CT​

Computed Tomography​

CTPROTOCOL​CT Protocol (Performed)​

DG​

Diaphanography​

DOC​

Document​

DX​

Digital Radiography​

ECG​

Electrocardiography​

EPS​

Cardiac Electrophysiology​

ES​

Endoscopy​

FID​

Fiducials​

GM​

General Microscopy​

HC​

Hard Copy​

HD​

Hemodynamic Waveform​

IO​

Intra-Oral Radiography​

IOL​

Intraocular Lens Data​

IVOCT​

Intravascular Optical Coherence Tomography​

IVUS​

Intravascular Ultrasound​

KER​

Keratometry​

KO​

Key Object Selection​

LEN​

Lensometry​

LS​

Laser surface scan​

MG​

Mammography​

MR​

Magnetic Resonance​

M3D​

Model for 3D Manufacturing​

NM​

Nuclear Medicine​

OAM​

Ophthalmic Axial Measurements​

OCT​

Optical Coherence Tomography (non-Ophthalmic)​

OP​

Ophthalmic Photography​

OPM​

Ophthalmic Mapping​

OPT​

Ophthalmic Tomography​

OPTBSV​

Ophthalmic Tomography B-scan Volume Analysis​

OPTENF​

Ophthalmic Tomography En Face​

OPV​

Ophthalmic Visual Field​

OSS​

Optical Surface Scan​

OT​

Other​

PLAN​

Plan​

PR​

Presentation State​

PT​

Positron emission tomography (PET)​

PX​

Panoramic X-Ray​

REG​

Registration​

RESP​

Respiratory Waveform​

RF​

Radio Fluoroscopy​

RG​

Radiographic imaging (conventional film/screen)​

RTDOSE​

Radiotherapy Dose​

RTIMAGE​

Radiotherapy Image​

RTINTENT​

Radiotherapy Intent​

RTPLAN​

Radiotherapy Plan​

RTRAD​

RT Radiation​

- Standard -​

Page 500​ DICOM PS3.3 2020a - Information Object Definitions​

RTRECORD​ RT Treatment Record​

RTSEGANN​ Radiotherapy Segment Annotation​

RTSTRUCT​ Radiotherapy Structure Set​

RWV​

Real World Value Map​

SEG​

Segmentation​

SM​

Slide Microscopy​

SMR​

Stereometric Relationship​

SR​

SR Document​

SRF​

Subjective Refraction​

STAIN​

Automated Slide Stainer​

TEXTUREMAP​Texture Map​

TG​

Thermography​

US​

Ultrasound​

VA​

Visual Acuity​

XA​

X-Ray Angiography​

XC​

External-camera Photography​

Retired Defined Terms:​

AS​ Angioscopy​

CD​ Color flow Doppler​

CF​ Cinefluorography​

CP​ Culposcopy​

CS​ Cystoscopy​

DD​ Duplex Doppler​

DF​ Digital fluoroscopy​

DM​ Digital microscopy​

DS​ Digital Subtraction Angiography​

EC​ Echocardiography​

FA​ Fluorescein angiography​

FS​ Fundoscopy​

LP​ Laparoscopy​

MA​ Magnetic resonance angiography​

MS​ Magnetic resonance spectroscopy​

OPR​Ophthalmic Refraction​

ST​ Single-photon emission computed tomography (SPECT)​

VF​ Videofluorography​

Note​

1.​The XA modality incorporates the retired modality DS.​

2.​The RF modality incorporates the retired modalities CF, DF, VF.​

3.​The modality listed in the Modality Data Element (0008,0060) may not match the name of the IOD in which it appears.​ Forexample,aSOPinstancefromXAIODmaylisttheRFmodalitywhenanRFimplementationproducesanXAobject.​

4.​The MR modality incorporates the retired modalities MA and MS.​

5.​The US modality incorporates the retired modalities EC, CD, and DD.​

6.​The NM modality incorporates the retired modality ST.​

C.7.3.1.1.2 Patient Position​

Patient Position (0018,5100) specifies the position of the patient relative to the imaging equipment space. This Attribute is intended​ for annotation purposes only. It does not provide an exact mathematical relationship of the patient to the imaging equipment.​

When multiple subjects are present in the same image, and arranged with different positions, then the Patient Position (0018,5100)​ intheGeneralSeriesModuleisnominal,doesnotapplytoeachsubject,butdoesdefinetherelationshipofthenominalPatient-Based​ Coordinate System to the machine.​

- Standard -​
