Page 486​

DICOM PS3.3 2020a - Information Object Definitions​

View from top of gantry

Gantry Rear

Gantry Front

Figure C.7.1.4-2. Example of Subject Relative Position in Image and differing Patient Position for group​ of 2 mice head-to-head​

- Standard -​

DICOM PS3.3 2020a - Information Object Definitions​

Page 487​

View from above gantry/table

Gantry Rear

1\1\2

FFP

Field of View

1\1\1

HFP

Gantry Front

View from front of gantry

Gantry Left

Gantry Right

Figure C.7.1.4-3. Example of Subject Relative Position in Image and overlapping narrow field of view​ group of 2 mice head-to-head​

C.7.1.5 Patient's Alternative Calendar​

Enumerated Values:​

PROLEPTICGREGN​

JULIAN​

PROLEPTIC JULIAN​

- Standard -​

Page 488​

DICOM PS3.3 2020a - Information Object Definitions​

EGYPTIAN REGNAL​

HEBREW​

HIJRI​

C.7.2 Common Study IE Modules​

ThefollowingStudyIEModulesarecommontoallCompositeImageIODsthatreferencetheStudyIE.TheseModulescontainAttributes​ of the Patient and Study that are needed for interpretation of the Composite Instances. They contain Attributes that are also in the​ Patient Modules in Section C.2 and Study Modules in Section C.4.​

C.7.2.1 General Study Module​

Table C.7-3 specifies the Attributes that describe and identify the Study performed upon the Patient.​

Table C.7-3. General Study Module Attributes​

Attribute Name​

Tag​

Type​

Attribute Description​

Study Instance UID​

(0020,000D)​

1​

Unique identifier for the Study.​

Study Date​

(0008,0020)​

2​

Date the Study started.​

Study Time​

(0008,0030)​

2​

Time the Study started.​

Referring Physician's Name​

(0008,0090)​

2​

Name of the Patient's referring physician​

ReferringPhysicianIdentification​

(0008,0096)​

3​

Identification of the Patient's referring physician.​

Sequence​





Only a single Item is permitted in this Sequence.​







>Include Table 10-1 “Person Identification Macro Attributes Description”​



Consulting Physician's Name​

(0008,009C)​

3​

Consulting physician(s) for this Patient Visit.​

Consulting Physician​

(0008,009D)​

3​

Identification of the consulting physician(s).​

Identification Sequence​





One or more Items shall be included in this Sequence.​













If more than one Item, the number and order shall​







correspondtothevalueofConsultingPhysician'sName​







(0008,009C), if present.​

>Include Table 10-1 “Person Identification Macro Attributes Description”​



Study ID​

(0020,0010)​

2​

User or equipment generated Study identifier.​

Accession Number​

(0008,0050)​

2​

ARISgeneratednumberthatidentifiestheorderforthe​







Study.​

Issuer of Accession Number​

(0008,0051)​

3​

Identifier of the Assigning Authority that issued the​

Sequence​





Accession Number.​







Only a single Item is permitted in this Sequence.​

>Include Table 10-17 “HL7v2 Hierarchic Designator Macro Attributes”​



Study Description​

(0008,1030)​

3​

Institution-generated description or classification of the​







Study (component) performed.​

Physician(s) of Record​

(0008,1048)​

3​

Names of the physician(s) who are responsible for​







overallPatientcareattimeofStudy(seeSectionC.7.3.1​







for Performing Physician)​

Physician(s) of Record​

(0008,1049)​

3​

Identification of the physician(s) who are responsible​

Identification Sequence​





for overall Patient care at time of Study.​

One or more Items are permitted in this Sequence. If​ more than one Item, the number and order shall​ correspond to the value of Physician(s) of Record​ (0008,1048), if present.​

- Standard -​



DICOM PS3.3 2020a - Information Object Definitions​

Page 489​

Attribute Name​

Tag​

Type​

Attribute Description​



>Include Table 10-1 “Person Identification Macro Attributes Description”​





Name of Physician(s) Reading​

(0008,1060)​

3​

Names of the physician(s) reading the Study.​

Study​









Physician(s) Reading Study​

(0008,1062)​

3​

Identificationofthephysician(s)readingtheStudy.One​

Identification Sequence​





or more Items are permitted in this Sequence. If more​







than one Item, the number and order shall correspond​







to the value of Name of Physician(s) Reading Study​







(0008,1060), if present.​



>Include Table 10-1 “Person Identification Macro Attributes Description”​





Requesting Service​

(0032,1033)​

3​

Institutional department, unit or service where the​







request initiated.​









See Note 1 and Note 2.​



Requesting Service Code​

(0032,1034)​

3​

Institutional department, unit or service where the​

Sequence​





request initiated.​









Only a single Item is permitted in this Sequence.​

>Include Table 8.8-1 “Code Sequence Macro Attributes”​



DCID 7030 “Institutional Departments, Units and​







Services”.​



Referenced Study Sequence​

(0008,1110)​

3​

A Sequence that provides reference to a Study SOP​







Class/Instance pair.​









One or more Items are permitted in this Sequence.​







See Section 10.6.1.​



>Include Table 10-11 “SOP Instance Reference Macro Attributes”​





Procedure Code Sequence​

(0008,1032)​

3​

A Sequence that conveys the type of procedure​







performed.​









One or more Items are permitted in this Sequence.​

>Include Table 8.8-1 “Code Sequence Macro Attributes”​



No Baseline CID is defined.​



Reason For Performed​

(0040,1012)​

3​

Coded reason(s) for performing this procedure.​

Procedure Code Sequence​





Note​

















May differ from the values in Reason for the​







RequestedProcedure(0040,100A)inRequest​







Attribute Sequence (0040,0275), for example​







if what was performed differs from what was​







requested.​









One or more Items are permitted in this Sequence.​

>Include Table 8.8-1 “Code Sequence Macro Attributes”​



No Baseline CID is defined.​



Note​

1.​Both Requesting Service (0032,1033) and Requesting Service Code Sequence (0032,1034) are defined in this table;​ the latter is preferred, but the former may be copied from an HL7 message whether or not there is also the ability to​ map it to a coded form (e.g., with only ORC-17 component 1 valued).​

2.​Requesting Service (0032,1033) and/or Requesting Service Code Sequence (0032,1034) may be used in the absence​ of a specific request or order, to describe the service involved or associated with acquiring the Study.​

- Standard -​

Page 490​

DICOM PS3.3 2020a - Information Object Definitions​

C.7.2.1.1 General Study Attribute Descriptions​

C.7.2.1.1.1 Referring Physician, Physician of Record, Physician Reading Study, Consulting Physician​

The model used for application of Attributes related to different functions of Physicians involved in the care of a Patient is shown in​ Figure C.7.2-1. Figure C.7.2-1 shows some of the relationships and information flows between physician roles that might be present​ in some healthcare business models.​

Referring Physician

Physician of Record

Refers Patient for study

Responsible for primary care of Patient during study

Performing Physician

Reading Physician





Creates the images and





evidence in a series within the





study (series attribute)





Interprets the images and









evidence of the study





Provides specialized advice





Consulting Physician

about Patient’s condition





Figure C.7.2-1. Functions of Physicians​

There can be an overlap of functions provided by any given physician. In this case, the various Attributes specifying the different roles​ would convey the same physician name.​

C.7.2.2 Patient Study Module​

Table C.7-4a defines Attributes that provide information about the Patient at the time the Study started.​

Note​

In the case of imaging a group of small animals simultaneously, the Attributes in this Module can only have values that apply​ to the entire group, otherwise they are absent (e.g., Patient's Weight (0010,1030)) or empty (e.g., Patient's Sex Neutered​ (0010,2203).​

Table C.7-4a. Patient Study Module Attributes​

Attribute Name​

Tag​

Type​

Attribute Description​

Admitting Diagnoses​

(0008,1080)​

3​

Description of the admitting diagnosis (diagnoses)​

Description​







Admitting Diagnoses Code​

(0008,1084)​

3​

ASequencethatconveystheadmittingdiagnosis(diagnoses).​

Sequence​





One or more Items are permitted in this Sequence.​







>Include Table 8.8-1 “Code Sequence Macro Attributes”​



No Baseline CID is defined.​

Patient's Age​

(0010,1010)​

3​

Age of the Patient.​

Patient's Size​

(0010,1020)​

3​

Length or size of the Patient, in meters.​

Patient's Weight​

(0010,1030)​

3​

Weight of the Patient, in kilograms.​

Patient's Body Mass Index​

(0010,1022)​

3​

Body Mass Index of the Patient in kg/m2.​

- Standard -​
