DICOM PS3.3 2020a - Information Object Definitions​

Page 471​

C.4.20 General Purpose Performed Procedure Step Relationship Module (Retired)​

Retired. See PS3.3-2011.​

C.4.21 General Purpose Performed Procedure Step Information Module (Retired)​

Retired. See PS3.3-2011.​

C.4.22 General Purpose Results (Retired)​

Retired. See PS3.3-2011.​

C.4.23 Instance Availability Notification Module​

Table C.4.23-1 specifies the Attributes used to describe which Instances are available and their relationships.​

Table C.4.23-1. Instance Availability Notification Module Attributes​

Attribute Name​

Tag​

Attribute Description​

Referenced Performed Procedure​

(0008,1111)​

Uniquely identifies the Performed Procedure Step SOP Instance to​

Step Sequence​



which this availability notification instance is related, if any.​





Zero or one Item shall be included in this Sequence.​





Note​





1.​This may refer to a different PPS than that encoded in​





the Composite Instances themselves.​





2.​Itistypicallyusedfornotificationaboutinstancescreated​





as a consequence of some scheduled activity.​

>Include Table 10-11 “SOP Instance Reference Macro​



Attributes”​





>Performed Workitem Code​

(0040,4019)​

A Sequence that conveys the (single) type of procedure performed.​

Sequence​



Only a single Item shall be included in this Sequence.​





>>Include Table 8.8-1 “Code Sequence Macro Attributes”​

BCID 9231 “Workitem Definition”.​

Study Instance UID​

(0020,000D)​

Unique identifier for the Study of which all the Instances referenced​





in this notification are part.​

Referenced Series Sequence​

(0008,1115)​

Sequence of Items where each Item includes references to Instances​





within the same Series.​





One or more Items shall be included in this Sequence.​

>Series Instance UID​

(0020,000E)​

Unique identifier of the Series of which all the Instances referenced​





in this Item are part.​

>Referenced SOP Sequence​

(0008,1199)​

Sequence of Items where each Item includes a reference to a single​





Instance within this Series.​





One or more Items shall be included in this Sequence.​

>>Include Table 10-11 “SOP Instance Reference Macro​



Attributes”​





>>Instance Availability​

(0008,0056)​

The availability of the referenced Instance.​





See Section C.4.23.1.1​

- Standard -​

Page 472​

DICOM PS3.3 2020a - Information Object Definitions​

Attribute Name​

Tag​

Attribute Description​

>>Retrieve AE Title​

(0008,0054)​

Title of the DICOM Application Entity from which the referenced​





Instance may or may not be retrievable, i.e., the scope for which​





Instance Availability (0008,0056) applies. See Section C.4.23.1.1.​

>>Retrieve Location UID​

(0040,E011)​

Unique identifier of the system where the Composite Object(s) may​





be retrieved on the network.​

>>Retrieve URI​

(0040,E010)​

FullyspecifiedURI/URL(see[RFC3986])thelocationofthereferenced​





instance.​





Note​





The VR of this Data Element has changed from UT to UR.​

>>Retrieve URL​

(0008,1190)​

URL specifying the location of the referenced instance(s).​





See Section 10.4 “Retrieve Transaction” in PS3.18.​

>>Storage Media File-Set ID​

(0088,0130)​

The user or implementation specific human readable identifier that​





identifies the offline storage media on which the instance resides.​

>>Storage Media File-Set UID​

(0088,0140)​

Uniquely identifies the offline storage media on which the instance​





resides.​

C.4.23.1 Instance Availability Notification Module Attribute Definitions​

C.4.23.1.1 Instance Availability​

Enumerated Values:​

ONLINE​ The instances are immediately available from the Retrieve AE Title (0008,0054), and if a C-MOVE were to be re-​ quested, it would succeed in a reasonably short time.​

NEARLINE​ The instances need to be retrieved from relatively slow media such as optical disk or tape, and if a C-MOVE were​ to be requested from the Retrieve AE Title (0008,0054), it would succeed, but may take a considerable time.​

OFFLINE​ A manual intervention is needed before the instances may be retrieved, and if a C-MOVE were to be requested from​ the Retrieve AE Title (0008,0054), it would fail (e.g., by timeout) without such manual intervention.​

UNAVAILABLE​The instances cannot be retrieved from the Retrieve AE Title (0008,0054), and if a C-MOVE were to be requested,​ it would fail.​

Note​

SOPInstancesthatareunavailablefromthisAEmaybeavailablefromotherAEs,ormayhaveanalternate​ representation that is available from this AE.​

C.5 Results Modules​

Retired. See PS3.3-2004.​

C.6 Interpretation Modules​

Retired. See PS3.3-2004.​

C.7 Common Composite Image IOD Modules​

This Section defines the Modules that are common to all Composite Image IODs.​

C.7.1 Common Patient IE Modules​

The following Patient IE Module is common to all Composite Image IODs that reference the Patient IE.​

- Standard -​

DICOM PS3.3 2020a - Information Object Definitions​

Page 473​

C.7.1.1 Patient Module​

Table C.7-1 specifies the Attributes of the Patient that describe and identify the Patient who is the subject of a Study. This Module​ containsAttributesofthePatientthatareneededforinterpretationoftheCompositeInstancesandarecommonforallStudiesperformed​ on the Patient. It contains Attributes that are also included in the Patient Modules in Section C.2.​

Table C.7-1. Patient Module Attributes​

Attribute Name​

Tag​

Type​

Attribute Description​

Patient's Name​

(0010,0010)​

2​

Patient's full name.​

Patient ID​

(0010,0020)​

2​

Primary identifier for the Patient.​







Note​







In the case of imaging a group of small animals​







simultaneously, the single value of this identifier​







corresponds to the identification of the entire group. See​







also Section C.7.1.4.1.1.​

Include Table 10-18 “Issuer of Patient ID Macro Attributes”​



Type of Patient ID​

(0010,0022)​

3​

The type of identifier in the Patient ID (0010,0020).​







Defined Terms:​







TEXT​







RFID​







BARCODE​







Note​







1.​The identifier is coded as a string regardless of the​







type, not as a binary value.​







2.​WhenthisAttributehasavalueofBARCODE,Patient​







ID (0010,0020) may or may not have the same value​







as Barcode Value (2200,0005) in the SOP Common​







Module, if present.​

Patient's Birth Date​

(0010,0030)​

2​

Birth date of the Patient.​

Patient's Birth Date in​

(0010,0033)​

3​

Date of birth of the named Patient in the Alternative Calendar​

Alternative Calendar​





(0010,0035).​







Note​







No format is specified for alternative calendar dates so​







none should be assumed.​

Patient's Death Date in​

(0010,0034)​

3​

Date of death of the named Patient in the Alternative Calendar​

Alternative Calendar​





(0010,0035).​

Note​

No format is specified for alternative calendar dates so​ none should be assumed.​

- Standard -​

Page 474​

DICOM PS3.3 2020a - Information Object Definitions​

Attribute Name​

Tag​

Type​

Attribute Description​

Patient's Alternative​

(0010,0035)​

1C​

TheAlternativeCalendarusedforPatient'sBirthDateinAlternative​

Calendar​





Calendar (0010,0033) and Patient's Death Date in Alternative​







Calendar (0010,0034).​







See Section C.7.1.5 for Defined Terms.​







Required if either Patient's Birth Date in Alternative Calendar​







(0010,0033) or Patient's Alternative Death Date in Calendar​







(0010,0034) is present.​

Patient's Sex​

(0010,0040)​

2​

Sex of the named Patient.​







Enumerated Values:​







M​male​







F​female​







O​other​

Referenced Patient Photo​

(0010,1100)​

3​

A photo to confirm the identity of a Patient.​

Sequence​





Only a single Item is permitted in this Sequence.​













See C.2.2.1.1.​

>Include Table 10-3b “Referenced Instances and Access Macro​

Attributes”​







Quality Control Subject​

(0010,0200)​

3​

Indicates whether or not the subject is a quality control phantom.​







Enumerated Values:​







YES​







NO​







If this Attribute is absent, then the subject may or may not be a​







phantom.​







This Attribute describes a characteristic of the Imaging Subject. It​







is distinct from Quality Control Image (0028,0300) in the General​







Image Module, which is used to describe an image acquired.​

Referenced Patient​

(0008,1120)​

3​

ASequencethatprovidesreferencetoaPatientSOPClass/Instance​

Sequence​





pair.​







Only a single Item is permitted in this Sequence.​

>IncludeTable10-11“SOPInstanceReferenceMacroAttributes”​

Patient's Birth Time​

(0010,0032)​

3​

Birth time of the Patient.​

OtherPatientIDsSequence​

(0010,1002)​

3​

A Sequence of identification numbers or codes used to identify the​

Patient,whichmayormaynotbehumanreadable,andmayormay​ not have been obtained from an implanted or attached device such​ as an RFID or barcode.​

One or more Items are permitted in this Sequence.​

Note​

This Attribute replaces the use of Other Patient IDs​ (0010,1000),whichdidnotspecifyanissuerforeachother​ identifier, and which has been retired.​

- Standard -​



DICOM PS3.3 2020a - Information Object Definitions​

Page 475​

Attribute Name​

Tag​

Type​

Attribute Description​



>Patient ID​

(0010,0020)​

1​

An identifier for the Patient.​









Note​









In the case of imaging a group of small animals​









simultaneously, the single value of this identifier​









corresponds to the identification of the entire group. See​







also Section C.7.1.4.1.1.​



>Include Table 10-18 “Issuer of Patient ID Macro Attributes”​





>Type of Patient ID​

(0010,0022)​

1​

The type of identifier in the Patient ID (0010,0020) in this Item.​







Defined Terms:​









TEXT​









RFID​









BARCODE​









Note​









1.​The identifier is coded as a string regardless of the​







type, not as a binary value.​









2.​WhenthisAttributehasavalueofBARCODE,Patient​







ID (0010,0020) may or may not have the same value​







as Barcode Value (2200,0005) in the SOP Common​







Module, if present.​



Other Patient Names​

(0010,1001)​

3​

Other names used to identify the Patient.​



Ethnic Group​

(0010,2160)​

3​

Ethnic group or race of the Patient.​



Patient Comments​

(0010,4000)​

3​

User-defined additional information about the Patient.​



PatientSpeciesDescription​

(0010,2201)​

1C​

The taxonomic rank value (e.g., genus, subgenus, species or​







subspecies) of the Patient. See Section C.7.1.1.1.3.​









Required if the Patient is an animal and if Patient Species Code​







Sequence (0010,2202) is not present. May be present otherwise.​

Patient Species Code​

(0010,2202)​

1C​

The taxonomic rank value (e.g., genus, subgenus, species or​

Sequence​





subspecies) of the Patient. See Section C.7.1.1.1.3.​









Only a single Item shall be included in this Sequence.​









Required if the Patient is an animal and if Patient Species​







Description (0010,2201) is not present. May be present otherwise.​

>Include Table 8.8-1 “Code Sequence Macro Attributes”​

DCID 7454 “Animal Taxonomic Rank Values”.​



Patient Breed Description​

(0010,2292)​

2C​

The breed of the Patient. See Section C.7.1.1.1.1.​









Required if the Patient is an animal and if Patient Breed Code​







Sequence (0010,2293) is empty. May be present otherwise.​

Patient Breed Code​

(0010,2293)​

2C​

The breed of the Patient. See Section C.7.1.1.1.1.​



Sequence​





Zero or more Items shall be included in this Sequence.​

















Required if the Patient is an animal.​



>Include Table 8.8-1 “Code Sequence Macro Attributes”​

DCID 7480 “Breed”.​



- Standard -​
