Page 466​

DICOM PS3.3 2020a - Information Object Definitions​

Attribute Name​

Tag​

Attribute Description​

>>>Include Table 10-2 “Content Item Macro Attributes Description”​No Baseline TID is defined.​

>>>Content Item Modifier Sequence​

(0040,0441)​

Sequence that specifies modifiers for a Protocol Context​





Content Item.​

One or more Items shall be included in this Sequence.​

See Section C.4.10.1.​

>>>>Include Table 10-2 “Content Item Macro Attributes Description”​No Baseline TID is defined.​

Note​

1.​The Patient information is included in order to relate the Modality Performed Procedure Step SOP Instance to the Study​ Management SOP Instance and other associated IODs in case the SCU (the modality) is unable to obtain or use the​ Study Instance UID created by the Information System.2. Attributes (0040,2016) and (0040,2017) Placer Order Number​ and Filler Order Number/Imaging Service Request are intended to convey the corresponding order numbers as defined​ in HL7, in the case where interoperability with an HL7 environment is the objective.​

2.​Attributes (0040,2006) and (0040,2007) were previously defined in DICOM. They are now retired (see PS3.3-1998).​

3.​Attributes(0040,1006)PlacerOrderNumber/Procedureand(0040,1007)FillerOrderNumber/Procedurewerepreviously​ defined in DICOM. They are now retired (see PS3.3-1998).​

C.4.14 Performed Procedure Step Information​

Table C.4-14 defines the general Attributes that may be used by all specific Procedure Steps.​

Table C.4-14. Performed Procedure Step Information Module Attributes​

Attribute Name​

Tag​

Attribute Description​

Performed Station AE Title​

(0040,0241)​

AE title of the modality on which the Performed Procedure Step was​





performed.​

Performed Station Name​

(0040,0242)​

An institution defined name for the modality on which the Performed​





Procedure Step was performed.​

Performed Location​

(0040,0243)​

Description of the location at which the Performed Procedure Step​





was performed.​

PerformedProcedureStepStartDate​

(0040,0244)​

Date on which the Performed Procedure Step started.​





Note​





This value may be used to determine the earliest date to​





useasStudyDate(0008,0020)inCompositeInstancesand​





in updated Modality Scheduled Procedure Steps in order to​





allow Study level Attributes to have consistent values if​





additional Procedure Steps are performed.​

PerformedProcedureStepStartTime​

(0040,0245)​

Time at which the Performed Procedure Step started.​





Note​





This value may be used to determine the earliest time to​





useasStudyTime(0008,0030)inCompositeInstancesand​





in updated Modality Scheduled Procedure Steps in order to​





allow Study level Attributes to have consistent values if​





additional Procedure Steps are performed.​

Performed Procedure Step ID​

(0040,0253)​

User or equipment generated identifier of that part of a Procedure​





that has been carried out within this step.​

Performed Procedure Step End Date​

(0040,0250)​

Date on which the Performed Procedure Step ended.​

- Standard -​

DICOM PS3.3 2020a - Information Object Definitions​

Page 467​

Attribute Name​

Tag​

Attribute Description​



Performed Procedure Step End Time​

(0040,0251)​

Time at which the Performed Procedure Step ended.​



Performed Procedure Step Status​

(0040,0252)​

Contains the state of the Performed Procedure Step.​







Enumerated Values:​







IN PROGRESS​ Started but not complete​







DISCONTINUED​Canceled or unsuccessfully terminated​





COMPLETED​ Successfully completed​



Performed Procedure Step​

(0040,0254)​

Institution-generated description or classification of the Procedure​

Description​



Step that was performed.​



Comments on the Performed​

(0040,0280)​

User-defined comments on the Performed Procedure Step.​

Procedure Step​







Performed Procedure Type​

(0040,0255)​

A description of the type of procedure performed.​



Description​







Procedure Code Sequence​

(0008,1032)​

A Sequence that conveys the (single) type of procedure performed.​





Only a single Item shall be included in this Sequence.​



>Include Table 8.8-1 “Code Sequence Macro Attributes”​

No Baseline CID is defined.​



Reason For Performed Procedure​

(0040,1012)​

Coded reason(s) for performing this procedure.​



Code Sequence​



Note​













May differ from the values in Reason for the Requested​





Procedure (0040,100A) in Request Attribute Sequence​





(0040,0275),forexampleifwhatwasperformeddiffersfrom​





what was requested.​







One or more Items shall be included in this Sequence.​



>Include Table 8.8-1 “Code Sequence Macro Attributes”​

No Baseline CID is defined.​



Performed Procedure Step​

(0040,0281)​

The reason the Performed Procedure Step Status (0040,0252) was​

Discontinuation Reason Code​



set to DISCONTINUED.​



Sequence​







>Include Table 8.8-1 “Code Sequence Macro Attributes”​

DCID 9300 “Procedure Discontinuation Reasons”.​



C.4.15 Image Acquisition Results Module​

Table C.4-15 specifies Attributes that describe the acquisition of images during the performance of the Procedure Step and that​ provide references to the Series, Images and other Composite SOP Instances associated with this Modality Performed Procedure​ Step.​

- Standard -​

Page 468​

DICOM PS3.3 2020a - Information Object Definitions​

Table C.4-15. Image Acquisition Results Module Attributes​

Attribute Name​

Tag​

Modality​

(0008,0060)​

Study ID​

(0020,0010)​

Performed Protocol Code​

(0040,0260)​

Sequence​



>Include Table 8.8-1 “Code Sequence Macro Attributes”​

>Protocol Context Sequence​

(0040,0440)​

>>Include Table 10-2 “Content Item Macro Attributes​ Description”​

>>ContentItemModifierSequence​

(0040,0441)​

>>>Include Table 10-2 “Content Item Macro Attributes​ Description”​

Performed Series Sequence​

(0040,0340)​

>Performing Physician's Name​

(0008,1050)​

>Performing Physician​

(0008,1052)​

Identification Sequence​



Attribute Description​

Type of equipment that originally acquired the data used to create the​ imagesassociatedwiththisModalityPerformedProcedureStep.See​ Section C.7.3.1.1.1 for Defined Terms.​

Note​

A Modality value in the created SOP Instances may be​ different from the MPPS Modality value. For example,​ multiple Series may have been created during the MPPS​ (images, waveforms, softcopy presentation states and/or​ structured reports) with SOP Instances in different Series​ having different modality values.​

User or equipment generated Study Identifier.​ Sequencedescribing the ProtocolperformedforthisProcedure Step.​

Zero or more Items shall be included in this Sequence.​

No Baseline CID is defined.​

Sequence that specifies the context for the Performed Protocol Code​ Sequence (0040,0260) Item.​

One or more Items shall be included in this Sequence.​

See Section C.4.10.1.​

No Baseline TID is defined.​

SequencethatspecifiesmodifiersforaProtocolContextContentItem.​

One or more Items shall be included in this Sequence.​

See Section C.4.10.1.​

No Baseline TID is defined.​

Attributes of the Series that comprise this Modality Performed​ Procedure Step.​

Zero or more Items shall be included in this Sequence.​ Name of the physician(s) administering this Series.​ Identification of the physician(s) administering the Series.​

One or more Items shall be included in this Sequence. If more than​ one Item, the number and order shall correspond to the value of​ Performing Physician's Name (0008,1050), if present.​

>>Include Table 10-1 “Person Identification Macro Attributes​ Description”​

>Operators' Name​

(0008,1070)​

Name(s) of the operator(s) who supporting this Series.​

>OperatorIdentificationSequence​

(0008,1072)​

Identification of the operator(s) supporting the Series.​

One or more Items shall be included in this Sequence. If more than​ one Item, the number and order shall correspond to the value of​ Operators' Name (0008,1070), if present.​

>>Include Table 10-1 “Person Identification Macro Attributes Description”​

- Standard -​



DICOM PS3.3 2020a - Information Object Definitions​

Page 469​

Attribute Name​

Tag​

Attribute Description​



>Protocol Name​

(0018,1030)​

User-defineddescriptionoftheconditionsunderwhichtheSerieswas​

performed.​

Note​

This Attribute conveys Series-specific protocol identification​ and may or may not be identical to the one presented in the​ Performed Protocol Code Sequence (0040,0260).​

>Series Instance UID​

(0020,000E)​

>Series Description​

(0008,103E)​

>Series Description Code​

(0008,103F)​

Sequence​



>>Include Table 8.8-1 “Code Sequence Macro Attributes”​

>Retrieve AE Title​

(0008,0054)​

>Archive Requested​

(0040,A494)​

>Referenced Image Sequence​

(0008,1140)​

>>Include Table 10-11 “SOP Instance Reference Macro​ Attributes”​

>>Container Identifier​

(0040,0512)​

>>Specimen Description​

(0040,0560)​

Sequence​



Unique Identifier of the Series.​

Description of the Series​

A coded description of the Series.​

Only a single Item shall beincludedin this Sequence.​

No Baseline CID is defined.​

Title of the DICOM Application Entity where the Images and other​ Composite SOP Instances in this Series may be retrieved on the​ network.​

Note​

The duration for which this location remains valid is​ unspecified.​

The instances in this Series are expected to be archived in the long​ term archive.​

Enumerated Values:​

NO​

YES​

A Sequence that provides reference to Composite SOP Instances​ created during the acquisition of the procedure step.​

Zero or more Items shall be included in this Sequence.​

Note​

The use of Referenced Image Sequence is historical, and​ in this context it allows the reference of any Composite SOP​ Instance.​

The identifier for the container that contains the specimen(s) imaged.​

Sequence of identifiers and detailed description of the specimen(s)​ imaged.​

One or more Items shall be included in this Sequence.​

>>>Specimen Identifier​

(0040,0551)​

A departmental information system identifier for the Specimen.​

>>>Specimen UID​

(0040,0554)​

Unique identifier for the Specimen.​

>Referenced Non-Image​

(0040,0220)​

Uniquely identifies instances, other than images, of any SOP Class​

Composite SOP Instance​



that conforms to the DICOM Composite IOD Information Model, such​

Sequence​



as Waveforms, Presentation States or Structured Reports, created​





during the acquisition of the procedure step, and that are not​





referenced in Referenced Image Sequence (0008,1140).​

Zero or more Items shall be included in this Sequence.​

- Standard -​

Page 470​

DICOM PS3.3 2020a - Information Object Definitions​

Attribute Name​

Tag​

Attribute Description​

>>Include Table 10-11 “SOP Instance Reference Macro​ Attributes”​

C.4.16 Radiation Dose Module​

This Module has been retired. See PS3.3 2017c​

C.4.17 Billing and Material Management Code Module​

The Attributes defined in Table C.4-17 provide a means to transmit billing and material management codes from a modality to an In-​ formation System. It is beyond the scope of this Standard to define all the required coding schemes and the relevant codes.​

Table C.4-17. Billing and Material Management Code Module Attributes​

Attribute name​

Tag​

Attribute Description​

Billing Procedure Step Sequence​

(0040,0320)​

Contains billing codes for the Procedure Type performed within​





the Procedure Step.​





Zero or more Items shall be included in this Sequence.​

>Include Table 8.8-1 “Code Sequence Macro Attributes”​

No Baseline CID is defined.​

Film Consumption Sequence​

(0040,0321)​

Information about the film consumption for this Performed​





Procedure Step.​





Zero or more Items shall be included in this Sequence.​

>Number of Films​

(2100,0170)​

Number of films actually printed.​

>Medium Type​

(2000,0030)​

Type(s) of medium on which images were printed. For Defined​





Terms see Table C.13-1.​

>Film Size ID​

(2010,0050)​

Size(s) of film on which images were printed. For Defined Terms​





see Table C.13-3.​

Billing Supplies and Devices​

(0040,0324)​

Chemicals,suppliesanddevicesforbillingusedinthePerformed​

Sequence​



Procedure Step.One or more Items shall be included in this​





Sequence.​

>Billing Item Sequence​

(0040,0296)​

Codevaluesofchemicals,suppliesordevicesrequiredforbilling.​





Zero or one Item shall be included in this Sequence.​

>>Include Table 8.8-1 “Code Sequence Macro Attributes”​

No Baseline CID is defined.​

>Quantity Sequence​

(0040,0293)​

Sequence containing the quantity of used chemicals or devices.​





Zero or one Item shall be included in this Sequence.​

>>Quantity​

(0040,0294)​

Numerical quantity value.​

>>Measuring Units Sequence​

(0040,0295)​

Unit of measurement.​





Zero or one Item shall be included in this Sequence.​

>>>Include Table 8.8-1 “Code Sequence Macro Attributes”​

BCID 82 “Units of Measurement”.​

C.4.18 General Purpose Scheduled Procedure Step Relationship Module (Retired)​

Retired. See PS3.3-2011.​

C.4.19 General Purpose Scheduled Procedure Step Information Module (Retired)​

Retired. See PS3.3-2011.​

- Standard -​

Смотрите также:

«ДОХОДЫ, РАСХОДЫ И ПРИБЫЛЬ КОММЕРЧЕСКОГО БАНКА.»
«ДОХОДЫ, РАСХОДЫ И ПРИБЫЛЬ КОММЕРЧЕСКОГО БАНКА.»
Значение, сущность и содержание социально — педагогической деятельности в организации для детей-сирот и детей, оставшихся без попечения родителей
__RGR2
__RGR2
_11_А. Франс для эл версии
_индив анализ данных
- Интерфейс 485 и оптопорт 11
:Конвергентный подход к проектированию дополнительных общеобразовательных общеразвивающих программ
