TheFrameofReferenceidentifiesthePatientCoordinateSystemusedtodefinethegeometricsetupoftheradiationbeamwithrespect​ to the patient. The relationship of the patient-based coordinates to the Equipment Frame of Reference is specified by a transformation​ (see Section 10.39).​

The following code sequences shall have a value from the identified CID:​

TheRTDeviceDistanceReferenceLocationCodeSequence(300A,0659)shallcontainthevalue(130358,DCM,“NominalRadiation​

Source Location”).​

A.86.1.7.4.3 RT Radiation Common Module​

The value of RT Record Flag (300A,0639) shall be NO.​

The following code sequences shall have a value from the identified CID:​

- Standard -​

B Normalized Information Object Definitions​ (Normative)​

B.1 Patient Information Object Definition​

Retired. See PS3.3-2004.​

B.2 Visit Information Object Definition​

Retired. See PS3.3-2004.​

B.3 Study Information Object Definition​

Retired. See PS3.3-2004.​

B.4 Study Component Information Object Definition​

Retired. See PS3.3-2004.​

B.5 Results Information Object Definition​

Retired. See PS3.3-2004.​

B.6 Interpretation Information Object Definition​

Retired. See PS3.3-2004.​

B.7 Basic Film Session Information Object Definition​

B.7.1 IOD Description​

The Basic Film Session Information Object Definition describes the presentation parameters that are common for all the films of a​ film session (e.g., number of films, film destination).​

B.7.2 IOD Modules​

Table B.7-1. Film Session IOD Modules​

B.8 Basic Film Box Information Object Definition​

B.8.1 IOD Description​

The Basic Film Box Information Object Definition is an abstraction of the presentation of one film of the film session. The Basic Film​ Box IOD describes the presentation parameters that are common for all images on a given sheet of film.​

- Standard -​

Page 438​ DICOM PS3.3 2020a - Information Object Definitions​

B.8.2 IOD Modules​

Table B.8-1. Basic Film Box IOD Modules​

B.9 Basic Image Box Information Object Definition​

B.9.1 IOD Description​

The Basic Image Box Information Object Definition is an abstraction of the presentation of an image and image related data in the​ image area of a film. The Basic Image Box IOD describes the presentation parameters and image pixel data that apply to a single​ image of a sheet of film.​

B.9.2 IOD Modules​

Table B.9-1. Basic Image Box IOD Modules​

The Image Box Relationship Module (Retired) was previously defined in DICOM. It is now retired. See PS3.3-1998.​

B.10 Basic Annotation Box Information Object Definition​

B.10.1 IOD Description​

The Basic Annotation Box Information Object Definition is an abstraction of the presentation of an annotation (e.g., text string) on a​ film. The Basic Annotation Box IOD describes the most used text related presentation parameters.​

B.10.2 IOD Modules​

Table B.10-1. Basic Annotation Box IOD Modules​

B.11 Print Job Information Object Definition​

B.11.1 IOD Description​

The Print Job Information Object Definition is an abstraction of the print job transaction and is the basic information entity to monitor​ the execution of the print process. A print job contains one film or multiple films, all belonging to the same film session.​

- Standard -​

B.12 Printer Information Object Definition​

B.12.1 IOD Description​

The Printer Information Object Definition is an abstraction of the hardcopy printer and is the basic information entity to monitor the​ status of the printer.​

B.12.2 IOD Modules​

Table B.12-1. Printer IOD Modules​

B.13 VOI LUT Box Information Object Definition (Retired)​

This section was previously defined in DICOM. It is now retired. See PS3.3-1998.​

B.14 Image Overlay Box Information Object Definition (Retired)​

This section was previously defined in DICOM. It is now retired. See PS3.3-1998.​

B.15 Storage Commitment Information Object Definition​

B.15.1 Storage Commitment IOD Description​

The Storage Commitment IOD describes the Attributes that may be present in a Storage Commitment Request or Response. The​ SOP Instances referenced by the Storage Commitment IOD are not restricted to images and may include other SOP Instances.​

B.15.2 Storage Commitment IOD Modules​

Table B.15-1 identifies and defines the Modules that comprise this IOD. The requirements for whether Attributes in these Modules​ are mandatory or optional are as specified in PS3.4.​

Table B.15-1. Storage Commitment IOD Modules​

B.16 Print Queue Information Object Definition​

Retired. See PS3.3-2004.​

- Standard -​

B.17 Modality Performed Procedure Step Information Object Definition​

B.17.1 IOD Description​

A "Modality Performed Procedure Step Information Object Definition" is an abstraction of the information that describes the activities,​ conditions and results of an imaging procedure performed on a modality. It contains information about the Modality Performed Pro-​ cedure Step (MPPS) and its relations to other Information Entities of the DICOM real-world model as introduced in this Part.​

A Modality Performed Procedure Step is related to the actual imaging procedure carried out at the modality. Other types of Performed​ ProcedureSteps,e.g.,reportingorimageprocessing,arenotcoveredbytheModalityPerformedProcedureStepIOD.Theinformation​ gathered includes data about the performance of the procedure itself, and data for billing and material management. The Modality​ Performed Procedure Step IOD includes general PPS Modules and image acquisition specific ones, such as Image Acquisition​ Results, and Billing and Material Management.​

B.17.2 IOD Modules​

Table B.17.2-1 lists the Modules that make up the Modality Performed Procedure Step IOD.​

Table B.17.2-1. Modality Performed Procedure Step IOD Modules​

Note​

The Radiation Dose Module has been retired. See PS3.3 2017c.​

B.18 Presentation LUT Information Object Definition​

B.18.1 IOD Description​

The Presentation LUT Information Object is an abstraction of a Presentation LUT. The objective of the Presentation LUT is to realize​ image display tailored for specific modalities, applications, and user preferences. It is used to prepare image pixel data for display on​ devices that conform to the Grayscale Standard Display Function defined in PS3.14.​

The output of the Presentation LUT is Presentation Values (P-Values). P-Values are approximately related to human perceptual re-​ sponse. They are intended to facilitate common input for both hardcopy and softcopy display devices. P-Values are intended to be​ independent of the specific class or characteristics of the display device.​

B.18.2 IOD Modules​

Table B.18.2-1. Presentation LUT IOD Modules​

B.19 Pull Print Request Information Object Definition​

Retired. See PS3.3-2004.​
