Page 446​

DICOM PS3.3 2020a - Information Object Definitions​

Modules referenced only by Normalized IODs do not contain Type designations. Modules referenced by both Normalized IODs and​ Composite IODs will contain a Type designation that only applies to Composite IODs and any specific conditions for Conditional​ Types (type 1C and 2C) also only apply to Composite IODs.​

C.1.2.4 Attribute Definition​

A brief definition will be provided for each Attribute in the Module definition table. The description shall provide a context for the use​ of the Attribute and provide general elucidation. Defined Terms and Enumerated Values applicable to the Attribute may also be listed​ in the Attribute Description.​

C.1.3 Attribute Descriptions​

Additional information may be provided if necessary for selected Attributes. Such information shall be placed following the Module​ definition table. Dependencies between Attributes may be specified in this Section.​

C.2 Patient Modules​

The following Sections specify Modules used for Patient management.​

C.2.1 Patient Relationship Module​

Table C.2-1 defines the Attributes that reference SOP Instances related to this SOP Class.​

Table C.2-1. Patient Relationship Module Attributes​

Attribute Name​

Tag​

Attribute Description​

Referenced Study Sequence​

(0008,1110)​

UniquelyidentifiestheStudySOPInstancesassociatedwith​





the Patient SOP Instance. One or more Items shall be​





included in this Sequence.​





See Section 10.6.1.​

>Include Table 10-11 “SOP Instance Reference Macro Attributes”​



Referenced Visit Sequence​

(0008,1125)​

Uniquely identifies the Visit SOP Instances associated with​





this Patient SOP Instance. One or more Items shall be​





included in this Sequence.​

>Include Table 10-11 “SOP Instance Reference Macro Attributes”​



Referenced Patient Alias Sequence​

(0038,0004)​

Uniquely identifies any Patient SOP Instances that also​





describe this Patient. These SOP Instances are aliases.​





Zero or more Items shall be included in this Sequence.​

>Include Table 10-11 “SOP Instance Reference Macro Attributes”​

C.2.2 Patient Identification Module​

Table C.2-2 defines the Attributes relevant to identifying a Patient.​

Table C.2-2. Patient Identification Module Attributes​

Attribute Name​

Tag​

Attribute Description​

Patient's Name​

(0010,0010)​

Patient's full name​

- Standard -​



DICOM PS3.3 2020a - Information Object Definitions​

Page 447​

Attribute Name​

Tag​

Attribute Description​



Patient ID​

(0010,0020)​

Primary identifier for the Patient.​







Note​







In the case of imaging a group of small animals​







simultaneously, the single value of this identifier corresponds​





to the identification of the entire group. See also​







Section C.7.1.4.1.1.​



Include Table 10-18 “Issuer of Patient ID Macro Attributes”​





Type of Patient ID​

(0010,0022)​

The type of identifier in the Patient ID (0010,0020).​







Defined Terms:​







TEXT​







RFID​







BARCODE​







Note​







1.​The identifier is coded as a string regardless of the type,​





not as a binary value.​







2.​When this Attribute has a value of BARCODE, Patient​





ID (0010,0020) may or may not have the same value as​





Barcode Value (2200,0005) in the Scheduled Procedure​





Step Module, if present.​



Other Patient IDs Sequence​

(0010,1002)​

A Sequence of identification numbers or codes used to identify the​





Patient, which may or may not be human readable, and may or may​

not have been obtained from an implanted or attached device such as​ an RFID or barcode.​

One or more Items are permitted in this Sequence.​





Note​





This Attribute replaces the use of Other Patient IDs​





(0010,1000), which did not specify an issuer for each other​





identifier, and which has been retired.​

>Patient ID​

(0010,0020)​

An identifier for the Patient.​

>Include Table 10-18 “Issuer of Patient ID Macro Attributes”​

>Type of Patient ID​

(0010,0022)​

The type of identifier in the Patient ID (0010,0020) in this Item.​





Defined Terms:​

TEXT​

RFID​

BARCODE​

Note​

1.​The identifier is coded as a string regardless of the type,​ not as a binary value.​

2.​When this Attribute has a value of BARCODE, Patient​ ID (0010,0020) may or may not have the same value as​ Barcode Value (2200,0005) in the Scheduled Procedure​ Step Module, if present.​

- Standard -​

Page 448​

DICOM PS3.3 2020a - Information Object Definitions​

Attribute Name​

Tag​

Attribute Description​

Other Patient Names​

(0010,1001)​

Other names used to identify the Patient.​

Patient's Birth Name​

(0010,1005)​

Patient's birth name.​

Patient's Mother's Birth Name​

(0010,1060)​

Birth name of Patient's mother.​

Referenced Patient Photo​

(0010,1100)​

A photo to confirm the identity of a Patient.​

Sequence​





Only a single Item is permitted in this Sequence.​

See C.2.2.1.1.​

>Include Table 10-3b “Referenced Instances and Access​

Macro Attributes”​

Include Table C.7.1.4-1 “Patient Group Macro Attributes”​

Note​

Previously,OtherPatientIDs(0010,1000)andMedicalRecordLocator(0010,1090)wereincludedinthistable.TheseAttributes​ have been retired. See PS3.3 2017a.​

C.2.2.1 Patient Identification Module Attributes​

C.2.2.1.1 Referenced Patient Photo Sequence​

A Patient Photo may be provided as an additional means to confirm the identity of the Patient.​

When the Referenced SOP Sequence (0008,1199) is present, the Referenced SOP Class UID (0008,1150) shall be either VL Photo-​ graphic Image Storage (1.2.840.10008.5.1.4.1.1.77.1.4) or Secondary Capture Image Storage (1.2.840.10008.5.1.4.1.1.7).​

When the WADO Retrieval Sequence (0040,E023) or WADO-RS Retrieval Sequence (0040,E025) is present, the Retrieve URI​ (0040,E010) shall refer to a JPEG image if the referenced server is not WADO-compliant.​

C.2.3 Patient Demographic Module​

Table C.2-3 defines the Attributes relevant to generally describing a Patient at a specific point in time, e.g., at the time of admission.​

Table C.2-3. Patient Demographic Module Attributes​

Attribute Name​

Tag​

Attribute Description​

Patient's Age​

(0010,1010)​

Age of the Patient.​

Occupation​

(0010,2180)​

Occupation of the Patient.​

ConfidentialityConstraintonPatient​

(0040,3001)​

Special indication to the modality operator about confidentiality of​

Data Description​



Patient information (e.g., that he should not use the Patient's name​





where other patients are present).​

Patient's Birth Date​

(0010,0030)​

Date of birth of the named Patient​

Patient's Birth Time​

(0010,0032)​

Time of birth of the named Patient​

Patient's Sex​

(0010,0040)​

Sex of the named Patient.​





Enumerated Values:​

M​male​

F​female​

O​other​

- Standard -​



DICOM PS3.3 2020a - Information Object Definitions​

Page 449​

Attribute Name​

Tag​

Attribute Description​



Quality Control Subject​

(0010,0200)​

Indicates whether or not the subject is a quality control phantom.​





Enumerated Values:​







YES​







NO​







If this Attribute is absent, then the subject may or may not be a​





phantom.​







This Attribute describes a characteristic of the Imaging Subject. It​





is distinct from Quality Control Image (0028,0300) in the General​





Image Module, which is used to describe an image acquired.​

Patient's Insurance Plan Code​

(0010,0050)​

ASequencethatconveysthePatient'sinsuranceplan.Zeroormore​

Sequence​



Items shall be included in this Sequence.​



>Include Table 8.8-1 “Code Sequence Macro Attributes”​

No Baseline CID is defined.​



Patient's Primary Language Code​

(0010,0101)​

The languages that can be used to communicate with the Patient.​

Sequence​



Zero or more Items shall be included in this Sequence. The Items​









are ordered by preference (most preferred language to least​





preferred language).​



>Include Table 8.8-1 “Code Sequence Macro Attributes”​

BCID 5000 “Languages”.​



>Patient's Primary Language​

(0010,0102)​

AmodifierforaPatient'sPrimaryLanguage.Canbeusedtospecify​

Modifier Code Sequence​



a national language variant.​







Only a single Item shall be included in this Sequence.​



>>Include Table 8.8-1 “Code Sequence Macro Attributes”​

BCID 5001 “Countries”.​



Patient's Size​

(0010,1020)​

Patient's height or length in meters​



Patient's Weight​

(0010,1030)​

Weight of the Patient in kilograms​



Patient's Size Code Sequence​

(0010,1021)​

Patient's size category code​







One or more Items are permitted in this Sequence.​



>Include Table 8.8-1 “Code Sequence Macro Attributes”​

Baseline CID is CID 7039 “Pediatric Size Categories” for pediatric​





patients.​



Patient's Address​

(0010,1040)​

Legal address of the named Patient​



Military Rank​

(0010,1080)​

Military rank of Patient​



Branch of Service​

(0010,1081)​

Branch of the military. The country allegiance may also be included​





(e.g., U.S. Army).​



Country of Residence​

(0010,2150)​

Country in which Patient currently resides​



Region of Residence​

(0010,2152)​

Region within Patient's country of residence​



Patient's Telephone Numbers​

(0010,2154)​

Telephone numbers at which the Patient can be reached​

- Standard -​

Page 450​

DICOM PS3.3 2020a - Information Object Definitions​

Attribute Name​

Tag​

Attribute Description​

Patient's Telecom Information​

(0010,2155)​

The Patient's personal telecommunication contact information,​





including telephone, email, or other telecom addresses.​





Note​





1.​This Attribute may have internal format or structure in​





accordance with local agreement or profile.​





2.​It is recommended that this Attribute be treated as​





equivalent to HL7v2 fields PID-13 and PID-14, or​





PID-40 (v2.7 and later), and be formatted in​





accordance with the HL7v2 XTN data type (without​





escapes for HL7 message structure reserved​





characters).​

Ethnic Group​

(0010,2160)​

Ethnic group or race of Patient​

Patient's Religious Preference​

(0010,21F0)​

The religious preference of the Patient​

Patient Comments​

(0010,4000)​

User-defined comments about the Patient​

Responsible Person​

(0010,2297)​

Name of person with medical or welfare decision making authority​





for the Patient.​

Responsible Person Role​

(0010,2298)​

Relationship of Responsible Person to the Patient.​





See Section C.7.1.1.1.2 for Defined Terms.​

Responsible Organization​

(0010,2299)​

Name of organization with medical or welfare decision making​





authority for the Patient.​

Patient Species Description​

(0010,2201)​

The taxonomic rank value (e.g., genus, subgenus, species or​





subspecies) of the Patient. See Section C.7.1.1.1.3.​

Patient Species Code Sequence​

(0010,2202)​

The taxonomic rank value (e.g., genus, subgenus, species or​





subspecies) of the Patient. See Section C.7.1.1.1.3.​





Only a single Item shall be included in this Sequence.​

>Include Table 8.8-1 “Code Sequence Macro Attributes”​

DCID 7454 “Animal Taxonomic Rank Values”.​

Patient Breed Description​

(0010,2292)​

The breed of the Patient. See Section C.7.1.1.1.1.​

Patient Breed Code Sequence​

(0010,2293)​

The breed of the Patient. See Section C.7.1.1.1.1.​





Zero or more Items shall be included in this Sequence.​

>Include Table 8.8-1 “Code Sequence Macro Attributes”​

DCID 7480 “Breed”.​

Breed Registration Sequence​

(0010,2294)​

Information identifying an animal within a breed registry.​





Zero or more Items shall be included in this Sequence.​

>Breed Registration Number​

(0010,2295)​

Identification number of a veterinary patient within the registry.​

>Breed Registry Code Sequence​

(0010,2296)​

Identification of the organization with which an animal is registered.​





Only a single Item shall be included in this Sequence.​

>>Include Table 8.8-1 “Code Sequence Macro Attributes”​

DCID 7481 “Breed Registry”.​

Strain Description​

(0010,0212)​

The strain of the Patient. See Section C.7.1.1.1.4.​

Strain Nomenclature​

(0010,0213)​

The nomenclature used for Strain Description (0010,0212). See​





Section C.7.1.1.1.4.​

- Standard -​
