Required if Referenced SOP Class UID (0008,1150) is RT​

Structure Set Storage ("1.2.840.10008.5.1.4.1.1.481.3").​

C.21.2.1 Spatial Fiducials Module Attribute Descriptions​

C.21.2.1.1 Shape Type​

For convenient registration, correlated Fiducials exist in each image set of the Registration Sequence. Correlated Fiducials are iden-​ tified with either Fiducial Identifier (0070,0310) or Fiducial Identifier Code Sequence (0070,0311).​

Shape Type (0070,0306) defines the geometric interpretation of Contour Data (3006,0050) and Graphic Data (0070,0022). A point​ is defined as a triplet (x,y,z) in the case of spatial data or a pair (x,y) in the case of graphic data.​

Defined Terms:​

POINT​ a single point designating a single fiducial point.​

Note​

A point may be the epicenter of a more complex shape such as sphere.​

LINE​ two points that specify a line or axis such as the inter-orbital line. The point locations have no significance other than​ identifying the line, i.e., they are not line segment end points.​

PLANE​ three points that identify a plane such as the laterality plane​

SURFACE​threeormorepoints(usuallymany)thatresideon,ornear,aregionofacurvedsurface.Thesurfacemaybeflatorcurved,​ closed or open. The point order has no significance.​

RULER​ two or more evenly spaced collinear points ordered sequentially along the line, such as a physical ruler placed in the​ imaging field.​

L_SHAPE​three points of two perpendicular line segments, AB and BC, having a common end point B. The order of the points is:​ ABC. May represent an L-shaped marker placed in the imaging field.​

T_SHAPE​three points of two perpendicular line segments AB and CD, such that C bisects AB. The order is ABD.​

SHAPE​ two or more points that specify the shape of a well-known fiducial type. The term in the Fiducial Identifier Code Sequence​ (0070,0311) defines the shape and the order of the points that represent it. A shape is closed if the first and last point are​ the same, but not otherwise. Two different points are a line segment.​

C.21.2.1.2 Contour Data​

ContourData(3006,0050)isanorderedsetoftripletsthatdefinesashape.Thetriplets(x,y,z)denotepointsintheReferenceCoordinate​

System of the Registration Instance.​

Note​

Contours may associate observational data with a set of Image features or specify coordinates that are input data for a​ measurement.​

C.21.2.1.3 Contour Uncertainty Radius​

The uncertainty is an estimate of the standard deviation of the fiducial location process.​

C.22 Media Creation Management Specific Modules​

The following Sections specify Modules used for Media Creation Management.​

- Standard -​

See Section C.22.1.1 for Defined Terms.​

- Standard -​

This is the label of the profile as defined in PS3.11, e.g.,​ "STD-XABC-CD".​

- Standard -​

C.22.1.1 Barcode Symbology​

Defined Terms:​

CODE128​ ISO/IEC15417:2000Informationtechnology-Automaticidentificationanddatacapturetechniques-Barcodesymbology​

specification - Code128​

- Standard -​

CODE39​ ISO/IEC16388:1999Informationtechnology-Automaticidentificationanddatacapturetechniques-Barcodesymbology​ specifications - Code 39​

INTER_2_5​ISO/IEC16390:1999Informationtechnology-Automaticidentificationanddatacapturetechniques-Barcodesymbology​ specifications - Interleaved 2 of 5 (also known as USS ITF 2/5, I-2/5, ITF 2of5)​

HIBC​ ANSI/HIBC 1-1996 Health Industry Bar Code (HIBC) Provider Applications Standard​

Note​

This doesn't list all the bar code symbologies in use (there are currently more than 400). Implementations supporting other​ symbologies can extend this list. Implementation specific code values shall be defined in the Conformance Statement.​

C.22.1.2 Execution Status​

Enumerated Values:​

IDLE​ The SCP has created the media creation management instance, but it has not been yet scheduled.​ PENDING​ This media creation management instance is still scheduled for processing​

CREATING​This media creation management instance is being processed​

DONE​ This media creation management instance has been successfully processed​ FAILURE​ This media creation management instance failed to be processed​

Note​

IDLE describes the status of a new media creation management instance (N-CREATE operation performed) for which the​ N-ACTION action has not been yet issued.​

C.22.1.3 Execution Status Info​

Defined Terms:​

CHECK_MCD_OP​ The media creation request could not be accomplished since the device is not ready at this time and needs​ to be checked by an operator (e.g., covers/doors opened or device jammed)​

CHECK_MCD_SRV​ The media creation request could not be accomplished since the device is not ready at this time and needs​ to be checked by a vendor service engineer (e.g., internal component failure)​

DIR_PROC_ERR​ The DICOMDIR building process failed for some unspecified reason (e.g., mandatory Attributes or values​ missing)​

DUPL_REF_INST​ Duplicated instances in the Referenced SOP Sequence (0008,1199)​

INST_AP_CONFLICT​One or more of the elements in the Referenced SOP Sequence (0008,1199) are in conflict (e.g., the SOP​

OUT_OF_SUPPLIES​No more supplies (e.g., blank media, labeling ink) are available for the media creation device; operator inter-​

1.​With respect to INST_OVERSIZED, DICOM media does not support spanning of instances across volumes.​

- Standard -​
