Page 1436​

DICOM PS3.3 2020a - Information Object Definitions​

Attribute Name​

Tag​

Type​

Attribute Description​

Series Instance UID​

(0020,000E)​

1​

Unique identifier of the Series.​







Note​







No specific semantics are specified.​

Series Number​

(0020,0011)​

1​

A number that identifies the Series.​







Note​







No specific semantics are specified.​

Series Date​

(0008,0021)​

3​

Date the Series started.​

Series Time​

(0008,0031)​

3​

Time the Series started.​

Protocol Name​

(0018,1030)​

3​

DescriptionoftheconditionsunderwhichtheSerieswas​







performed.​







Note​







This may represent the type of analysis used​







in creation of the KO SOP Instances.​

Series Description​

(0008,103E)​

3​

Description of the Series​

Series Description Code​

(0008,103F)​

3​

A coded description of the Series.​

Sequence​





Only a single Item is permitted in this Sequence.​







>Include Table 8.8-1 “Code Sequence Macro Attributes”​



No Baseline CID is defined.​

Referenced Performed​

(0008,1111)​

2​

Uniquely identifies the Performed Procedure Step SOP​

Procedure Step Sequence​





Instance for which the Series is created.​

Zero or one Item shall be included in this Sequence.​

Note​

See notes on this Attribute in Section C.17.1​

>Include Table 10-11 “SOP Instance Reference Macro Attributes”​

C.17.6.2 Key Object Document Module​

Table C.17.6-2 defines the general Attributes of a Key Object Selection Document. These Attributes identify and provide context for​ the Key Object Selection Document.​

Table C.17.6-2. Key Object Document Module Attributes​

Attribute Name​

Tag​

Type​

Attribute Description​

Instance Number​

(0020,0013)​

1​

A number that identifies the Document.​

Content Date​

(0008,0023)​

1​

The date the document content creation started.​

Content Time​

(0008,0033)​

1​

The time the document content creation started.​

Referenced Request Sequence​

(0040,A370)​

1C​

IdentifiesRequestedProcedurestowhichthisDocument​







pertains.​







One or more Items shall be included in this Sequence.​







Required if this Document pertains to at least one​







Requested Procedure.​

>Study Instance UID​

(0020,000D)​

1​

Unique identifier for the Study.​

- Standard -​



DICOM PS3.3 2020a - Information Object Definitions​

Page 1437​

Attribute Name​

Tag​

Type​

Attribute Description​



>Referenced Study Sequence​

(0008,1110)​

2​

Uniquely identifies the Study SOP Instance.​







Zero or one Item shall be included in this Sequence.​







See Section 10.6.1.​



>>Include Table 10-11 “SOP Instance Reference Macro Attributes”​





>Accession Number​

(0008,0050)​

2​

A departmental IS generated number that identifies the​







order for the Study.​



>Issuer of Accession Number​

(0008,0051)​

3​

Identifier of the Assigning Authority that issued the​

Sequence​





Accession Number.​









Only a single Item is permitted in this Sequence.​

>>Include Table 10-17 “HL7v2 Hierarchic Designator Macro Attributes”​





>Placer Order Number/Imaging​

(0040,2016)​

2​

The order number assigned to the Imaging Service​

Service Request​





Request by the party placing the order.​



>Order Placer Identifier​

(0040,0026)​

3​

IdentifieroftheAssigningAuthoritythatissuedthePlacer​

Sequence​





Order Number.​









Only a single Item is permitted in this Sequence.​

>>Include Table 10-17 “HL7v2 Hierarchic Designator Macro Attributes”​





>Filler Order Number/Imaging​

(0040,2017)​

2​

The order number assigned to the Imaging Service​

Service Request​





Request by the party filling the order.​



>OrderFillerIdentifierSequence​

(0040,0027)​

3​

Identifier of the Assigning Authority that issued the Filler​







Order Number.​









Only a single Item is permitted in this Sequence.​

>>Include Table 10-17 “HL7v2 Hierarchic Designator Macro Attributes”​





>Requested Procedure ID​

(0040,1001)​

2​

Identifier of the related Requested Procedure​

>Requested Procedure​

(0032,1060)​

2​

Institution-generated administrative description or​

Description​





classification of Requested Procedure.​



>Requested Procedure Code​

(0032,1064)​

2​

A Sequence that conveys the requested procedure.​

Sequence​





Zero or one Item shall be included in this Sequence.​







>>Include Table 8.8-1 “Code Sequence Macro Attributes”​



No Baseline CID is defined.​



Current Requested Procedure​

(0040,A375)​

1​

List of all Composite SOP Instances referenced in​

Evidence Sequence​





Content Sequence (0040,A730), including all​

presentation states, real world value maps and other​ accompanyingCompositeInstancesthatarereferenced​ from the Content Items.​

One or more Items shall be included in this Sequence.​

Note​

In the context of the Key Object Selection, the​ current evidence is considered to be only the​ set of instances referenced within the Key​ Object Selection.​

>Include Table C.17-3 “Hierarchical SOP Instance Reference Macro​

Attributes”​

- Standard -​

Page 1438​

DICOM PS3.3 2020a - Information Object Definitions​

Attribute Name​

Tag​

Type​

Attribute Description​

Identical Documents Sequence​

(0040,A525)​

1C​

Duplicates of this document, stored with different SOP​

Instance UIDs.​

One or more Items shall be included in this Sequence.​

Required if this Key Object Selection document​ references instances in more than one Study.​

See Section C.17.2.2 and Section C.17.6.2.1 for further​ explanation and conditions.​

>Include Table C.17-3 “Hierarchical SOP Instance Reference Macro​

Attributes”​

C.17.6.2.1 Identical Documents​

If the Current Requested Procedure Evidence Sequence (0040,A375) references SOP Instances both in the current Study and in one​ or more other Studies, this document shall be duplicated into each of those other Studies, and the duplicates shall be referenced in​ the Identical Documents Sequence (0040,A525).​

Note​

ThusaKeyObjectSelectionDocumentthatreferencesimagesinthecurrentStudyaswellasinapriororcomparisonStudy,​ wouldbeduplicatedintotheotherStudy.ThisallowsanapplicationdisplayingthatotherStudytoeasilyaccessnotesrelevant​ to that Study's SOP Instances.​

C.18 Content Macros​

C.18.1 Numeric Measurement Macro​

Table C.18.1-1 specifies the Attributes that convey a NUM (numeric measurement) value.​

Note​

TheMeasuredValueSequence(0040,A300)maybeemptytoconveytheconceptofameasurementwhosevalueisunknown​ or missing, or a measurement or calculation failure.​

Table C.18.1-1. Numeric Measurement Macro Attributes​

Attribute Name​

Tag​

Type​

Attribute Description​

Measured Value Sequence​

(0040,A300)​

2​

This is the value of the Content Item.​







Shall consist of a Sequence of Items conveying the measured​







value(s), which represent integers or real numbers and units of​







measurement.​







Zero or one Item shall be included in this Sequence.​

>Numeric Value​

(0040,A30A)​

1​

Numeric measurement value.​







Only a single value shall be present.​

>Floating Point Value​

(0040,A161)​

1C​

The floating point representation of Numeric Value (0040,A30A).​







Only a single value shall be present.​

Required if Numeric Value (0040,A30A) has insufficient precision​ to represent the value as a string. May be present otherwise.​

- Standard -​



DICOM PS3.3 2020a - Information Object Definitions​

Page 1439​

Attribute Name​

Tag​

Type​



Attribute Description​



>Rational Numerator Value​

(0040,A162)​

1C​

TheintegernumeratorofarationalrepresentationofNumericValue​







(0040,A30A). Encoded as a signed integer value. Only a single​







value shall be present.​









Required if Numeric Value (0040,A30A) has insufficient precision​







to represent a rational value as a string. May be present otherwise.​

>Rational Denominator​

(0040,A163)​

1C​

The integer denominator of a rational representation of Numeric​

Value​





Value(0040,A30A).Encodedasanon-zerounsignedintegervalue.​







Only a single value shall be present.​









Required if Rational Numerator Value (0040,A162) is present.​

>Measurement Units Code​

(0040,08EA)​

1​

Units of measurement.​



Sequence​





Only a single Item shall be included in this Sequence.​







>>Include Table 8.8-1 “Code Sequence Macro Attributes”​

DCID 82 “Units of Measurement”.​



Numeric Value Qualifier​

(0040,A301)​

3​

Qualification of Numeric Value (0040,A30A) in Measured Value​

Code Sequence​





Sequence (0040,A300), or reason for absence of Measured Value​







Sequence (0040,A300) Item.​









Only a single Item is permitted in this Sequence.​



>Include Table 8.8-1 “Code Sequence Macro Attributes”​

DCID 42 “Numeric Value Qualifier”.​



C.18.2 Code Macro​











Table C.18.2-1 specifies the Attributes that convey a CODE value.​







Table C.18.2-1. Code Macro Attributes​



Attribute Name​

Tag​



Type​

Attribute Description​



Concept Code Sequence​

(0040,A168)​



1​

This is the value of the Content Item.​









Only a single Item shall be included in this​









Sequence.​



>Include Table 8.8-1 “Code Sequence Macro Attributes”​



No Baseline CID is defined.​



C.18.3 Composite Object Reference Macro​

TableC.18.3-1specifiestheAttributesthatconveyareferencetoaDICOMCompositeObjectthatisnotaDICOMImageorWaveform​ (such as an SR Document), or to an HL7 Structured Document.​

Note​

1.​If a Softcopy Presentation State is to be applied to an Image, it should be referenced by an Image Reference Macro.​

2.​Other SR Documents may be referenced by this Macro, but there is no facility to reference individual Content Items​ within those reports.​

3.​HL7 Structured Documents include, in particular, those conforming to the Clinical Document Architecture (CDA). See​ Section C.12.1.1.6 for further details about this type of referenced object.​

- Standard -​

Page 1440​ DICOM PS3.3 2020a - Information Object Definitions​

Table C.18.3-1. Composite Object Reference Macro Attributes​

Attribute Name​

Tag​

Type​

Attribute Description​

Referenced SOP Sequence​

(0008,1199)​

1​

ReferencestoCompositeObjectSOPClass/SOP​







Instance pairs.​

Only a single Item shall be included in this​ Sequence.​

>Include Table 10-11 “SOP Instance Reference Macro Attributes”​

C.18.4 Image Reference Macro​

Table C.18.4-1 specifies the Attributes that convey a reference to a DICOM image.​

Table C.18.4-1. Image Reference Macro Attributes​

Attribute Name​

Tag​

Type​

Attribute Description​

Include Table C.18.3-1 “Composite Object Reference Macro Attributes”​

>Referenced Frame Number​

(0008,1160)​

1C​

Identifies the frame numbers within the Referenced SOP​







Instancetowhichthereferenceapplies.Thefirstframeshall​







be denoted as frame number 1.​







Note​







This Attribute may be multi-valued.​







Required if the Referenced SOP Instance is a multi-frame​







image and the reference does not apply to all frames, and​







Referenced Segment Number (0062,000B) is not present.​

>Referenced Segment​

(0062,000B)​

1C​

Identifies the segments to which the reference applies​

Number​





identifiedbySegmentNumber(0062,0004).Requiredifthe​







Referenced SOP Instance is a Segmentation and the​







reference does not apply to all segments and Referenced​







Frame Number (0008,1160) is not present.​

>Referenced SOP Sequence​

(0008,1199)​

3​

ReferencetoaSoftcopyPresentationStateSOPClass/SOP​







Instance pair.​







Only a single Item is permitted in this Sequence.​

>>Include Table 10-11 “SOP Instance Reference Macro Attributes”​



>Referenced Real World​

(0008,114B)​

3​

ReferencetoaRealWorldValueMappingSOPClass/SOP​

Value Mapping Instance​





Instance pair.​

Sequence​





Only a single Item is permitted in this Sequence.​







>>Include Table 10-11 “SOP Instance Reference Macro Attributes”​



>Icon Image Sequence​

(0088,0200)​

3​

This Icon Image is representative of the Image.​







Only a single Item is permitted in this Sequence.​







The Icon Image shall be no greater than 128 rows by 128​







columns.​

>>Include Table C.7-11b “Image Pixel Macro Attributes”​



See Section C.7.6.1.1.6​

C.18.5 Waveform Reference Macro​

Table C.18.5-1 specifies the Attributes that convey a reference to a DICOM waveform.​

- Standard -​

Смотрите также:

«ДОХОДЫ, РАСХОДЫ И ПРИБЫЛЬ КОММЕРЧЕСКОГО БАНКА.»
«ДОХОДЫ, РАСХОДЫ И ПРИБЫЛЬ КОММЕРЧЕСКОГО БАНКА.»
Значение, сущность и содержание социально — педагогической деятельности в организации для детей-сирот и детей, оставшихся без попечения родителей
__RGR2
__RGR2
_11_А. Франс для эл версии
_индив анализ данных
- Интерфейс 485 и оптопорт 11
:Конвергентный подход к проектированию дополнительных общеобразовательных общеразвивающих программ
