Page 136​

DICOM PS3.3 2020a - Information Object Definitions​

Attribute Name​

Tag​

Type​

Attribute Description​

BASIC CODED ENTRY ATTRIBUTES​

Code Value​

(0008,0100)​

1C​

The identifier of the Coded Entry.​

See Section 8.1.​

Shall be present if the code value length is 16 characters or less, and​

the code value is not a URN or URL.​

Coding Scheme​

(0008,0102)​

1C​

The identifier of the coding scheme in which the Coded Entry is defined.​

Designator​

See Section 8.2.​

Shall be present if Code Value (0008,0100) or Long Code Value​

(0008,0119) is present. May be present otherwise.​

Coding Scheme Version​

(0008,0103)​

1C​

An identifier of the version of the coding scheme if necessary to resolve​

ambiguity.​

See Section 8.2. Required if the value of Coding Scheme Designator​

(0008,0102) is present and is not sufficient to identify the Code Value​

(0008,0100)orLongCodeValue(0008,0119)unambiguously.Shallnot​

be present if Coding Scheme Designator (0008,0102) is absent. May​

be present otherwise.​

Code Meaning​

(0008,0104)​

1​

Text that conveys the meaning of the Coded Entry.​

See Section 8.3.​

Long Code Value​

(0008,0119)​

1C​

The identifier of the Coded Entry.​

See Section 8.1.​

URN Code Value​

(0008,0120)​

1C​ The identifier of the Coded Entry.​

Attribute Name​

Tag​

Type​

Attribute Description​

Context Identifier​

(0008,010F)​

3​

The identifier of the Context Group from which the Coded Entry was​

selected.​

See Section 8.6.​

Context UID​

(0008,0117)​

3​

The unique identifier of the Context Group from which the Coded Entry​

was selected.​

See Section 8.6.​

Mapping Resource​

(0008,0105)​

1C​

The identifier of the Mapping Resource that defines the Context Group​

from which Coded Entry was selected.​

See Section 8.4. Required if Context Identifier (0008,010F) is present.​

Mapping Resource UID​

(0008,0118)​

3​

The unique identifier of the Mapping Resource that defines the Context​

Group from which Coded Entry was selected.​

Note​

TheuniqueidentifierfortheDICOMContentMappingResource​

"DCMR" is defined in PS3.6.​

Mapping Resource Name​

(0008,0122)​

3​

ThenameoftheMappingResourcethatdefinestheContextGroupfrom​

which Coded Entry was selected.​

See Section 8.4.​

Context Group Version​

(0008,0106)​

1C​

The identifier of the version of the Context Group from which the Coded​

Entry was selected.​

See Section 8.5.​

Required if Context Identifier (0008,010F) is present.​

Context Group Extension​

(0008,010B)​

3​

Indicates whether the triplet of Code Value (0008,0100) (or Long Code​

Flag​

Value (0008,0119) or URN Code Value (0008,0120))/Coding Scheme​

Designator (0008,0102)/Code Meaning (0008,0104) is selected from a​

private extension of the Context Group identified in Context Identifier​

(0008,010F). See Section 8.7.​

Enumerated Values:​

Y​

N​

Context Group Local​

(0008,0107)​

1C​

An implementation-specific version of a Context Group that contains​

Version​

private extensions.​

See Section 8.7. Required if the value of Context Group Extension Flag​

(0008,010B) is "Y".​

Context Group Extension​

(0008,010D)​

1C​

Identifies the person or organization who created an extension to the​

Creator UID​

Context Group. See Section 8.7.​

Attribute Name​

Tag​

Type​

Attribute Description​

BASIC CODED ENTRY ATTRIBUTES​

Page 138​

DICOM PS3.3 2020a - Information Object Definitions​

Attribute Name​

Tag​

Type​

Attribute Description​

Include Table 8.8-1a​

Equivalent Code Sequence​

(0008,0121)​

3​

Codes that are considered equivalent by the​

creating system.​

Nesting​

Attribute Name​

Tag​

VR​

Value​

%item​

>​

Coding Scheme Designator​

(0008,0102)​

SH​

SCT​

>​

Code Meaning​

(0008,0104)​

LO​

Invasive diagnostic procedure​

>​

Long Code Value​

(0008,0119)​

UC​

621566751000087104​

%enditem​

DICOM PS3.3 2020a - Information Object Definitions​

Page 139​

An example of a short SNOMED CT with equivalent SNOMED SRT and CTV3 (Read) codes as an Item in a Sequence:​

Nesting​

Attribute Name​

Tag​

VR​

Value​

%item​

>​

Code Value​

(0008,0100)​

SH​

406400000​

>​

Coding Scheme Designator​

(0008,0102)​

SH​

SCT​

>​

Code Meaning​

(0008,0104)​

LO​

Dimeglumine gadopentetate​

469.01mg/mL inj soln 15mL pfld​

syr​

>​

Equivalent Code Sequence​

(0008,0121)​

SQ​

%sequence​

%item​

>>​

Code Value​

(0008,0100)​

SH​

C-B0478​

>>​

Coding Scheme Designator​

(0008,0102)​

SH​

SRT​

>>​

Code Meaning​

(0008,0104)​

LO​

Dimeglumine gadopentetate​

469.01mg/mL inj soln 15mL pfld​

syr​

%enditem​

%item​

>>​

Code Value​

(0008,0100)​

SH​

XUaZB​

>>​

Coding Scheme Designator​

(0008,0102)​

SH​

CTV3​

>>​

Code Meaning​

(0008,0104)​

LO​

Dimeglumine gadopentetate​

469.01mg/mL inj soln 15mL pfld​

syr​

An example of encoding a long URN as an Item in a Sequence.​

Nesting​

Attribute Name​

Tag​

VR​

Value​

%item​

>​

Code Meaning​

(0008,0104)​

LO​

HIPAA Privacy Rule​

>​

URN Code Value​

(0008,0120)​

UR​

urn:lex:us:federal:codified.regulation:2013-04-25;45CFR164​

%enditem​
