C.11.6.1.2 Presentation LUT Shape​

A value of INVERSE shall mean the same as a value of IDENTITY, except that the minimum output value shall convey the meaning​ of the maximum available luminance, and the maximum value shall convey the minimum available luminance. In other words:​

•​P-Value = maximum value - output value​

C.11.7 Overlay Activation Module​

This Module defines a manner of controlling whether or not bit-mapped overlay and curve information are displayed.​

If the corresponding Overlay Group activated is present within the Presentation State, then that Overlay shall be activated and any​ corresponding Overlay in the referenced image(s) ignored, otherwise the Overlay within the referenced image(s) shall be activated.​

An Overlay Group referenced in the Bitmap Display Shutter Module described in Section C.7.6.15 shall not be activated using the​ Overlay Activation Module.​

Table C.11.7-1 specifies the Attributes that describe the Overlay Activation Module.​

Table C.11.7-1. Overlay Activation Module Attributes​

1.​Previously, those bits that are stored in Pixel Data (7FE0,0010) above High Bit (0028,0102) could be used as overlay​ bitplanesiftheywerereferencedbyanOverlayBitPosition(60xx,0102).Thisusagehasbeenretired.SeePS3.3-2004.​ Their contents are unspecified in DICOM and should not be displayed. Usually they will be zero, though if the pixel data​ is signed, i.e., Pixel Representation (0028,0103) is0001H, then it is possible that the sign bit maybe "extended" through​ these values. Alternatively, they may have been "masked off" even if the value is signed and negative.​

2.​Previously,CurveActivationLayer(50xx,1001)wasdefinedinthisModule.Itsusagehasbeenretired.SeePS3.3-2004.​

C.11.8 Softcopy VOI LUT Module​

Table C.11.8-1 specifies the Attributes that describe the Softcopy VOI LUT. These Attributes have the same meaning and behavior​ as defined in the Section C.11.2 VOI LUT Module.​

Table C.11.8-1. Softcopy VOI LUT Module Attributes​

- Standard -​

Table C.11.9-1 contains Attributes that identify and describe a Presentation Series.​

Table C.11.9-1. Presentation Series Module Attributes​

This implies that presentation states will be in different Series from the images to which they apply, which will have different​ values for Modality.​

C.11.10 Presentation State Identification Module​

Table C.11.10-1 contains Attributes that identify a Presentation State.​

Table C.11.10-1. Presentation State Identification Module Attributes​

This date may be different from the date that the DICOM SOP​ Instancewascreated,sincethepresentationstateinformation​ contained may have been recorded earlier.​

Presentation Creation​ (0070,0083)​ 1​ Time at which this presentation was created.​

Time​

Note​

This time may be different from the time that the DICOM SOP​ Instancewascreated,sincethepresentationstateinformation​ contained may have been recorded earlier.​

- Standard -​

The Content Label value may be used by an application as a​ Defined Term in order to imply some grouping of different​ presentation states, i.e., it may have the same value for​ differentpresentationstateinstancesthatsharesomecommon​ concept.​

C.11.11 Presentation State Relationship Module​

Table C.11.11-1 contains Attributes that describe the images to which a Presentation State applies.​

Table C.11.11-1. Presentation State Relationship Module Attributes​

Attribute Name​ Tag​ Type​ Attribute Description​

Include Table C.11.11-1b “Presentation State Relationship Macro Attributes”​

Table C.11.11-1b. Presentation State Relationship Macro Attributes​

One or more Items shall be included in this Sequence.​

The referenced SOP Class shall be the same for all Images in any Item​ of this Referenced Series Sequence (0008,1115).​

>>IncludeTable10-3“ImageSOPInstanceReferenceMacro​ Attributes”​

C.11.12 Presentation State Shutter Module​

Table C.11.12-1 contains Attributes that specialize Attributes in other Modules included in a Presentation State.​

- Standard -​

DICOM PS3.3 2020a - Information Object Definitions​ Page 1309​

Table C.11.12-1. Presentation State Shutter Module Attributes​

RequirediftheDisplayShutterModuleorBitmapDisplayShutterModuleispresent​ and the SOP Class is other than Grayscale Softcopy Presentation State Storage.​

Note​

The requirement in this Module is type 1C, which overrides the type 3​ in the Display Shutter Module and Bitmap Display Shutter Module.​

C.11.13 Presentation State Mask Module​

Table C.11.13-1 contains Attributes that specialize the use of masks in a Presentation State.​

Table C.11.13-1. Presentation State Mask Module Attributes​

Applicable Frame Range (0028,6102) shall not be included in the Sequence Item.​

See Section C.7.6.10 for a complete definition of the Attributes in the Items of this​ Sequence other than Mask Operation (0028,6101) and Applicable Frame Range​ (0028,6102).​

Note​

1.​This Sequence is replicated here in order to specify one Item,​ additional conditions on Mask Operation (0028,6101) and to forbid​ Applicable Frame Range (0028,6102).​

2.​The role of Applicable Frame Range (0028,6102) is replaced by​ Referenced Frame Number (0008,1160).​

- Standard -​

Viewing Mode​

Enumerated Values:​

SUB​for subtraction with mask images​

Required if Mask Subtraction Sequence (0028,6100) is present.​

Note​

TherequirementsinthisModulearetype1CandaspecifiedEnumerated​

Value, which override the requirements of the Mask Module.​

C.11.14 Presentation State Blending Module​

Table C.11.14-1 contains Attributes that describe the identification of two sets of grayscale images and the grayscale transformations​ to be applied to them, for the purpose of blending.​

Table C.11.14-1. Presentation State Blending Module Attributes​

Enumerated Values:​

SUPERIMPOSED​

UNDERLYING​
