Page 1246​

DICOM PS3.3 2020a - Information Object Definitions​

Attribute Name​

Tag​

Type​

Attribute Description​

Referenced Performed​

(0008,1111)​

1C​

Uniquely identifies the Performed Procedure Step SOP Instance​

Procedure Step Sequence​





to which the Series is related​







Only a single Item shall be included in this Sequence.​







RequiredifaPerformedProcedureStepSOPClasswasinvolved​







in the creation of this Series.​

>Include Table 10-11 “SOP Instance Reference Macro Attributes”​

C.8.32.2 Parametric Map Image Module​

Table C.8.32-2 defines the general Attributes of the Parametric Map Image Module.​

Table C.8.32-2. Parametric Map Image Module Attributes​

Attribute Name​

Tag​

Type​

Attribute Description​

Image Type​

(0008,0008)​

1​

Image identification characteristics.​







Enumerated Values for Value 1:​







DERIVED​







Enumerated Values for Value 2:​







PRIMARY​







Value3shallbeImageFlavor,commonDefinedTermsforwhicharespecified​







in Section C.8.16.1.3, CT-specific Defined Terms for which are specified in​







SectionC.8.15.2.1.1.3andMR-specificDefinedTermsforwhicharespecified​







in Section C.8.13.1.1.1.3.​







Value4shallbeDerivedPixelContrast,commonDefinedTermsforwhichare​







specified in Section C.8.16.1.4, CT-specific Defined Terms for which are​







specified in Section C.8.15.2.1.1.4 and MR-specific Defined Terms for which​







are specified in Section C.8.13.1.1.1.4.​

Include Table 10-12 “Content Identification Macro​



Attributes”​







Image Orientation​

(0048,0102)​

1C​

The direction cosines of the first row and the first column of the total pixel​

(Slide)​





matrix with respect to the Slide Coordinate System Frame of Reference. See​







Section C.8.12.4.1.4.​







Required if Plane Position (Slide) Sequence (0048,021A) is present within a​







Functional Group Sequence.​

Pixel Presentation​

(0008,9205)​

3​

Indication of the presence or absence of color information that may be used​







during rendering.​







Enumerated Values:​







COLOR_RANGE​A Palette Color LUT is supplied or referenced. Image is best​







displayedusingthatPaletteColorLUT,butcanbedisplayed​







in grayscale if current display does not support color.​







MONOCHROME​No Palette Color LUT is supplied or referenced. Image is​







intended to be displayed in grayscale only.​

Samples per Pixel​

(0028,0002)​

1​

Number of samples (planes) in this image.​







Enumerated Values:​







1​

- Standard -​



DICOM PS3.3 2020a - Information Object Definitions​

Page 1247​

Attribute Name​

Tag​

Type​

Attribute Description​



Photometric​

(0028,0004)​

1​

Specifies the intended interpretation of the pixel data.​



Interpretation​





Enumerated Values:​

















MONOCHROME2​



Bits Allocated​

(0028,0100)​

1​

Number of bits allocated for each pixel sample.​









Enumerated Values if Pixel Data (7FE0,0010) or Pixel Data Provider URL​







(0028,7FE0) is present:​









16​









Enumerated Values if Float Pixel Data (7FE0,0008) is present:​









32​









Enumerated Values if Double Float Pixel Data (7FE0,0009) is present:​







64​



Bits Stored​

(0028,0101)​

1C​

Number of bits stored for each pixel sample.​









Enumerated Values:​







16​







Required if Pixel Data (7FE0,0010) or Pixel Data Provider URL (0028,7FE0)​







is present.​

High Bit​

(0028,0102)​

1C​

Most significant bit for pixel sample data.​







Enumerated Values:​







15​







Required if Pixel Data (7FE0,0010) or Pixel Data Provider URL (0028,7FE0)​







is present.​

Presentation LUT​

(2050,0020)​

1​

Specifies an identity transformation for the Presentation LUT such that the​

Shape​





output of all grayscale transformations are defined to be in P-Values.​







Enumerated Values:​







IDENTITY​ output is in P-Values.​







Note​







The intent of specifying this Attribute for Parametric Maps is only to​







achieve consistency of rendering when displayed as grayscale, not​







toimplythatgrayscalecontrastofthedisplayedimageismeaningful.​







It is not applicable when the image is rendered with pseudo-color,​







for example.​

Lossy Image​

(0028,2110)​

1​

Specifies whether an Image has undergone lossy compression (at a point in​

Compression​





its lifetime), or is derived from lossy compressed images.​

Enumerated Values:​

00​Image has NOT been subjected to lossy compression.​ 01​Image has been subjected to lossy compression.​

Once this value has been set to 01 it shall not be reset.​

See Section C.8.32.2.1 and Section C.7.6.1.1.5.​

- Standard -​

Page 1248​

DICOM PS3.3 2020a - Information Object Definitions​

Attribute Name​

Tag​

Type​

Attribute Description​

Lossy Image​

(0028,2112)​

1C​

Describes the approximate lossy compression ratio(s) that have been applied​

Compression Ratio​





to this image.​







See Section C.7.6.1.1.5.2.​







Required if present in the source images or this IOD instance has been​







compressed.​

Lossy Image​

(0028,2114)​

1C​

A label for the lossy compression method(s) that have been applied to this​

Compression Method​





image.​







See Section C.7.6.1.1.5.1.​







Required if present in the source images or this IOD instance has been​







compressed. See Section C.8.32.2.1.​

Burned In Annotation​

(0028,0301)​

1​

Indicates whether or not image contains sufficient burned in annotation to​







identify the patient and date the image was acquired.​







Enumerated Values:​







NO​

Recognizable Visual​

(0028,0302)​

1​

Indicates whether or not the image contains sufficiently recognizable visual​

Features​





features to allow the image or a reconstruction from a set of images to identify​







the patient.​







Enumerated Values:​







YES​







NO​

Content Qualification​

(0018,9004)​

1​

Content Qualification Indicator​







Enumerated Values:​







PRODUCT​







RESEARCH​







SERVICE​







See Section C.8.13.2.1.1 for further explanation.​

Palette Color Lookup​

(0028,1199)​

1C​

Palette Color Lookup Table UID. See Section C.7.9.1 for further explanation.​

Table UID​





Required if Pixel Presentation (0008,9205) equals COLOR_RANGE and the​













Palette Color Lookup Table Module is not present.​

ICC Profile​

(0028,2000)​

1C​

An ICC Profile encoding the transformation of device-dependent color stored​







pixel values into PCS-Values.​







When present, defines the color space of the output of the Parametric Map​







See Section C.11.15.1.1.​







Required if Pixel Presentation (0008,9205) has a value of COLOR_RANGE.​

Color Space​

(0028,2002)​

3​

A label that identifies the well-known color space of the image. Shall be​







consistent with any ICC Profile (0028,2000) that is also present.​

See Section C.11.15.1.2.​

C.8.32.2.1 Lossy Image Compression and Lossy Image Compression Method​

If Lossy Image Compression (0028,2110) in any of the source images is "01", the value shall be "01" for the Parametric Map instance.​

- Standard -​

DICOM PS3.3 2020a - Information Object Definitions​

Page 1249​

The process of derivation of a Parametric Map itself is defined not to be lossy compression, even though it involves loss. If the Para-​ metric Map instance is encoded using a lossy compression Transfer Syntax, then the value shall be set to "01".​

Note​

To state the obvious, it is not advisable to lossy compress a Parametric Map SOP Instance, since that will alter the quantit-​ ative values that are the intent of the object.​

C.8.32.3 Parametric Map Functional Group Macros​

The following sections contain Functional Group Macros specific to the Parametric Map IOD.​

Note​

The Attribute descriptions in the Functional Group Macros are written as if they were applicable to a single frame (i.e., the​ Macro is part of the Per-frame Functional Groups Sequence). If an Attribute is applicable to all frames (i.e., the Macro is part​ of the Shared Functional Groups Sequence) the phrase "this frame" in the Attribute description shall be interpreted to mean​ "for all frames".​

C.8.32.3.1 Parametric Map Frame Type Macro​

Table C.8.32-3 specifies the Attributes of the Parametric Map Frame Type Functional Group Macro.​

Table C.8.32-3. Parametric Map Frame Type Macro Attributes​

Attribute Name​

Tag​

Type​

Attribute Description​

Parametric Map Frame Type​

(0040,9092)​

1​ Identifies the characteristics of this Parametric Map frame.​

Sequence​





Only a single Item shall be included in this Sequence.​







>Frame Type​

(0008,9007)​

1​ Type of Frame. A multi-valued Attribute analogous to Image Type​







(0008,0008).​

Enumerated Values and Defined Terms are the same as those for the​ four values of Image Type (0008,0008), except that the value MIXED​ is not allowed. See Section C.8.32.2.​

C.8.33 Tractography Results Modules​

This Section describes Tractography Results Modules.​

C.8.33.1 Tractography Results Series Module​

Table C.8.33-1 specifies the Attributes that identify and describe general information about a Tractography Results Series.​

Table C.8.33-1. Tractography Results Series Module Attributes​

Attribute Name​

Tag​

Type​

Attribute Description​

Modality​

(0008,0060)​

1​

Type of equipment that originally acquired the data used to​







create the instances in this Series.​







Enumerated Values:​







MR​







See Section C.7.3.1.1.1 for further explanation.​

Series Number​

(0020,0011)​

1​

A number that identifies this Series.​

- Standard -​

Page 1250​

DICOM PS3.3 2020a - Information Object Definitions​

Attribute Name​

Tag​

Type​

Attribute Description​

Referenced Performed​

(0008,1111)​

1C​

Uniquely identifies the Performed Procedure Step SOP​

Procedure Step Sequence​





Instance to which the Series is related.​

Only a single Item shall be included in this Sequence.​

Required if a Performed Procedure Step SOP Class was​ involved in the creation of this Series.​

>Include Table 10-11 “SOP Instance Reference Macro Attributes”​

C.8.33.2 Tractography Results Module​

Table C.8.33-2 specifies the Attributes that describe the tracks and measurements in the tractography results.​

Table C.8.33-2. Tractography Results Module Attributes​

Attribute Name​

Tag​

Type​

Attribute Description​

Include Table 10-12 “Content Identification Macro Attributes”​



Content Date​

(0008,0023)​

1​

The date the content creation started.​

Content Time​

(0008,0033)​

1​

The time the content creation started.​

Track Set Sequence​

(0066,0101)​

1​

Describes the track sets that are contained within the data.​







One or more Items shall be included in this Sequence.​

>Track Set Number​

(0066,0105)​

1​

Identification number of the Track Set. Uniquely identifies a track​







set within this SOP instance. Shall start at a value of 1, and​







increase monotonically by 1.​

>Track Set Label​

(0066,0106)​

1​

User-definedlabelidentifyingthisTrackSet.Thismaybethesame​







asCodeMeaning(0008,0104)ofTrackSetAnatomicalTypeCode​







Sequence (0066,0108).​

>Track Set Description​

(0066,0107)​

3​

User-defined description for this Track Set.​

>TrackSetAnatomicalType​

(0066,0108)​

1​

Sequence defining the specific property type of this Track Set.​

Code Sequence​





Only a single Item shall be included in this Sequence.​







>>Include Table 8.8-1 “Code Sequence Macro Attributes”​

BCID 7710 “Tractography Anatomic Sites”.​

>>ModifierCodeSequence​

(0040,A195)​

3​

A Sequence of Items modifying or specializing the Track Set​







Anatomical Type Code Sequence.​







One or more Items shall be included in this Sequence.​

>>>Include Table 8.8-1 “Code Sequence Macro Attributes”​

DCID 244 “Laterality”.​

>Track Sequence​

(0066,0102)​

1​

Describes individual tracks part of the track set.​







One or more Items shall be included in this Sequence.​

>>Point Coordinates Data​

(0066,0016)​

1​

Contains two or more point coordinates that define the track,​







encoded in x-y-z order, in mm in the Patient-Based Coordinate​

System associated with the Frame of Reference. The order of the​ encoded points is from the first point to the last point of the track.​

When referencing points in Point Coordinates Data (0066,0016)​ the index of the first point x,y,z triplet is 1​

See Section C.27.2.1.1.​

- Standard -​

Смотрите также:

«ДОХОДЫ, РАСХОДЫ И ПРИБЫЛЬ КОММЕРЧЕСКОГО БАНКА.»
«ДОХОДЫ, РАСХОДЫ И ПРИБЫЛЬ КОММЕРЧЕСКОГО БАНКА.»
Значение, сущность и содержание социально — педагогической деятельности в организации для детей-сирот и детей, оставшихся без попечения родителей
__RGR2
__RGR2
_11_А. Франс для эл версии
_индив анализ данных
- Интерфейс 485 и оптопорт 11
:Конвергентный подход к проектированию дополнительных общеобразовательных общеразвивающих программ
