DICOM PS3.3 2020a - Information Object Definitions​

Page 931​

Attribute Name​

Tag​

Type​

Attribute Description​

Spectral Sensitivity​

(0016,0017)​

the ASTM Technical Committee.​

Photographic Sensitivity​

(0016,0018)​

Sensitivity Type​

(0016,001A)​

Sensitivity (0016,0018).​

Defined Terms:​

0​Unknown​

1​Standard output sensitivity (SOS)​

2​Recommended exposure index (REI)​

3​ISO speed​

(REI)​

5​Standard output sensitivity (SOS) and ISO speed​

6​Recommended exposure index (REI) and ISO speed​

(REI) and ISO speed​

StandardOutputSensitivity​

(0016,001B)​

in [ISO 12232].​

Recommended Exposure​

(0016,001C)​

Index​

defined in [ISO 12232].​

ISO Speed​

(0016,001D)​

12232].​

ISO Speed Latitude yyy​

(0016,001E)​

defined in [ISO 12232].​

ISO Speed Latitude zzz​

(0016,001F)​

defined in [ISO 12232].​

EXIF Version​

(0016,0020)​

3​ The version of the EXIF standard.​

Shutter Speed Value​

(0016,0021)​

3​ The shutter speed. The unit is the APEX value.​

Aperture Value​

(0016,0022)​

3​ The lens aperture. The unit is the APEX value.​

Brightness Value​

(0016,0023)​

3​ The value of brightness. The unit is the APEX value.​

Exposure Bias Value​

(0016,0024)​

3​ The exposure bias. The unit is the APEX value.​

Max Aperture Value​

(0016,0025)​

Subject Distance​

(0016,0026)​

3​ The distance to the subject in meters.​

Metering Mode​

(0016,0027)​

3​ The metering mode.​

Defined Terms:​

0​

unknown​

1​

Average​

2​

CenterWeightedAverage​

3​

Spot​

4​

MultiSpot​

5​

Pattern​

6​

Partial​

DICOM PS3.3 2020a - Information Object Definitions​

Page 933​

Attribute Name​

Tag​

Type​

Attribute Description​

Flash Function Present​

(0016,0014)​

Defined Terms:​

0​Flash function present​

1​No flash function​

Flash Red Eye Mode​

(0016,0015)​

3​ Whether or not the camera supports red-eye reduction.​

Defined Terms:​

0​No red-eye reduction mode or unknown​

1​Red-eye reduction supported​

Focal Length​

(0016,0029)​

3​ The actual focal length of the lens, in mm.​

Subject Area​

(0016,002A)​

Iftwovaluesarepresent,theyaretheXandYimage-relativecoordinates​

of a location.​

If three values are present, they are the X and Y image-relative center​

coordinates and the diameter in pixels of a circle.​

If four values are present, they are the the center X image-relative​

coordinate, the center Y image-relative coordinate, the width in pixels,​

and the height in pixels of a rectangle.​

The coordinate values, width, and height are expressed in relation to​

the upper left as origin.​

Maker Note​

(0016,002B)​

Temperature​

(0016,0030)​

3​ The ambient temperature at the time of acquisition, in °C.​

Humidity​

(0016,0031)​

3​ The ambient humidity at the time of acquisition, in %.​

Pressure​

(0016,0032)​

3​ The ambient pressure at the time of acquisition, in hPa.​

Water Depth​

(0016,0033)​

3​ The water depth at the time of acquisition, in m.​

When the value is negative, the absolute value of it indicates the height​

(elevation) above the water level.​

Acceleration​

(0016,0034)​

acquisition, in mGal (10-5 m/s2).​

Camera Elevation Angle​

(0016,0035)​

optical axis) in degrees from -180 to less than 180, at the time of​

acquisition.​

Flash Energy​

(0016,0036)​

in Beam Candle Power Seconds (BCPS).​

A single value if the exact flash energy is known, otherwise two values,​

the minimum value and the maximum value.​

Subject Location​

(0016,0037)​

representsthepixelatthecenterofthemainsubjectrelativetotheupper​

left corner. The first value indicates the X column number and second​

indicates the Y row number.​

Photographic Exposure​

(0016,0038)​

Index​

the image is captured.​

DICOM PS3.3 2020a - Information Object Definitions​

Page 935​

Attribute Name​

Tag​

Type​

Attribute Description​

Gain Control​

(0016,0047)​

3​ The degree of overall image gain adjustment.​

Defined Terms:​

0​None​

1​Low gain up​

2​High gain up​

3​Low gain down​

4​High gain down​

Contrast​

(0016,0048)​

Defined Terms:​

0​Normal​

1​Soft​

2​Hard​

Saturation​

(0016,0049)​

Defined Terms:​

0​Normal​

1​Low saturation​

2​High saturation​

Sharpness​

(0016,004A)​

Defined Terms:​

0​Normal​

1​Soft​

2​Hard​

Device Setting Description​

(0016,004B)​

encoded as defined in [EXIF 2.31].​

Subject Distance Range​

(0016,004C)​

3​ The distance to the subject.​

Defined Terms:​

0​unknown​

1​Macro​

2​Close view​

3​Distant view​

Self Timer Mode​

(0016,0019)​

capture was initiated by the camera operator. If the value is zero, the​

self-timer is off.​

Interoperability Index​

(0016,0061)​

Defined Terms:​
