DICOM PS3.3 2020a - Information Object Definitions​

Page 831​

Attribute Name​

Tag​

Type​

Description​

>Scan Mode​

(300A,0308)​

1​

The method of beam scanning used during treatment.​

Defined Terms:​

NONE​

No beam scanning is performed.​

UNIFORM​

Between control points, the beam is scanned to​

create a uniform lateral fluence distribution across​

the field.​

MODULATED​

Between control points, the beam is scanned to​

create a modulated lateral fluence distribution​

across the field.​

create a modulated lateral fluence distribution​

across the field. The specific scan mode is defined​

by Modulated Scan Mode Type (300A,0309).​

>Modulated Scan Mode​

(300A,0309)​

1C​

Defines the specialization of a modulated scan mode.​

Type​

Defined Terms:​

specified position.​

position begins when the spot is at the previous spot​

position but the spot moves as quickly as possible to the​

currentspecifiedspotpositionwheremostoftheMeterset​

is delivered.​

LINEAR​

The beam spot is delivered with uniform flux while​

traveling from one position to the next position​

(continuous).​

MIXED​

Between control points the beam may be delivered by a​

combination of STATIONARY, LEAPING or LINEAR​

modes.​

See Section C.8.8.25.8.​

>Referenced Tolerance​

(300C,00A0)​

3​

Table Number​

of treatment machine settings.​

>Beam Limiting Device Leaf​

(3008,00A0)​

3​

Pairs Sequence​

One or more Items are permitted in this Sequence.​

>>RT Beam Limiting Device​

(300A,00B8)​

1​

Type of beam limiting device (collimator).​

Type​

Enumerated Values:​

X​

symmetric jaw pair in IEC X direction​

Y​

symmetric jaw pair in IEC Y direction​

ASYMX​asymmetric jaw pair in IEC X direction​

ASYMY​asymmetric pair in IEC Y direction​

MLCX​multileaf (multi-element) jaw pair in IEC X direction​

MLCY​multileaf (multi-element) jaw pair in IEC Y direction​

>>NumberofLeaf/JawPairs​

(300A,00BC)​

1​

limiting device jaws).​

Page 832​

Attribute Name​

Tag​

Type​

Description​

>Referenced Patient Setup​

(300C,006A)​

3​

UniquelyidentifiesIonPatientSetuptobeusedforcurrentbeam,specified​

Number​

by Patient Setup Number (300A,0182) within Patient Setup Sequence of​

RT Patient Setup Module.​

>Referenced Verification​

(300C,0040)​

3​

Sequenceofverificationimagesobtainedduringdeliveryofcurrentbeam.​

Image Sequence​

One or more Items are permitted in this Sequence.​

See Section C.8.8.14.2.​

>>Include Table 10-11 “SOP Instance Reference Macro​

Attributes”​

>Referenced Measured​

(3008,0080)​

3​

SequenceofdosesmeasuredduringtreatmentdeliveryforcurrentBeam.​

Dose Reference Sequence​

One or more Items are permitted in this Sequence.​

>>Referenced Dose​

(300C,0051)​

1C​

Uniquely references Dose Reference specified by Dose Reference​

Reference Number​

Number (300A,0012) in Dose Reference Sequence (300A,0010) in RT​

Prescription Module of referenced RT Ion Plan. Required if Referenced​

Measured Dose Reference Number (3008,0082) is not present.​

>>Referenced Measured​

(3008,0082)​

1C​

Uniquely references Measured Dose Reference specified by Measured​

Dose Reference Number​

Dose Reference Number (3008,0064) in Measured Dose Reference​

Sequence(3008,0010).RequiredifReferencedDoseReferenceNumber​

(300C,0051) is not present.​

>>Measured Dose Value​

(3008,0016)​

1​

MeasuredDoseinunitsspecifiedbyDoseUnits(3004,0002)inSequence​

referencedbyMeasuredDoseReferenceSequence(3008,0010)orDose​

Reference Sequence (300A,0010) in RT Prescription Module of​

Referenced RT Ion Plan as defined above.​

>Referenced Calculated​

(3008,0090)​

3​

Sequence of doses estimated for each treatment delivery.​

Dose Reference Sequence​

One or more Items are permitted in this Sequence.​

>>Referenced Dose​

(300C,0051)​

1C​

UniquelyidentifiesDoseReferencespecifiedbyDoseReferenceNumber​

Reference Number​

(300A,0012)inDoseReferenceSequence(300A,0010)inRTPrescription​

Module of referenced RT Ion Plan. Required if Referenced Calculated​

Dose Reference Number (3008,0092) is not present.​

>>Referenced Calculated​

(3008,0092)​

1C​

Uniquely identifies Calculated Dose Reference specified by Calculated​

Dose Reference Number​

DoseReferenceNumber(3008,0072)withinCalculatedDoseReference​

Sequence(3008,0070).RequiredifReferencedDoseReferenceNumber​

(300C,0051) is not present.​

>>Calculated Dose​

(3008,0076)​

1​

Calculated Dose (Gy).​

Reference Dose Value​

>Number of Wedges​

(300A,00D0)​

1​

Number of wedges associated with current beam.​

>Recorded Wedge​

(3008,00B0)​

1C​

Sequence of treatment wedges.​

Sequence​

Required if Number of Wedges (300A,00D0) is non-zero.​

One or more Items shall be included in this Sequence.​

ThenumberofItemsshallbeidenticaltothevalueofNumberofWedges​

(300A,00D0).​

>>Wedge Number​

(300A,00D2)​

1​

Identification number of the Wedges. The value of Wedge Number​

(300A,00D2) shall be unique within the Beam in which it was created.​

DICOM PS3.3 2020a - Information Object Definitions​

Page 833​

Attribute Name​

Tag​

Type​

Description​

>>Wedge Type​

(300A,00D3)​

2​

Type of wedge (if any) defined for Beam.​

Defined Terms:​

STANDARD​

standard (static) wedge​

MOTORIZED​

single wedge that can be removed from beam​

remotely.​

and is operated manually.​

and can be removed from beam remotely.​

>>Wedge ID​

(300A,00D4)​

3​

User-supplied identifier for Wedge.​

>>Accessory Code​

(300A,00F9)​

3​

>>Wedge Angle​

(300A,00D5)​

2​

Nominal wedge angle (degrees).​

>>Wedge Orientation​

(300A,00D8)​

2​

systems (degrees).​

>Number of Compensators​

(300A,00E0)​

1​

>Recorded Compensator​

(3008,00C0)​

1C​

Sequence of treatment compensators.​

Sequence​

One or more Items shall be included in this Sequence.​

Compensators (300A,00E0).​

>>ReferencedCompensator​

(300C,00D0)​

1​

Number​

(300C,0006).​

>>Compensator ID​

(300A,00E5)​

3​

User-supplied identifier for compensator.​

>>Accessory Code​

(300A,00F9)​

3​

>Number of Boli​

(300A,00ED)​

1​

Number of boli associated with current Beam.​

>Referenced Bolus​

(300C,00B0)​

1C​

Sequence of boli associated with Beam.​

Sequence​

Required if Number of Boli (300A,00ED) is non-zero.​

One or more Items shall be included in this Sequence.​

(300A,00ED).​

>>Referenced ROI Number​

(3006,0084)​

1​

(300C,0060) in RT General Plan Module.​

>>Accessory Code​

(300A,00F9)​

3​

>Number of Blocks​

(300A,00F0)​

1​

Number of shielding blocks associated with Beam.​

>Recorded Block Sequence​

(3008,00D0)​

1C​

Sequence of blocks associated with Beam.​

Required if Number of Blocks (300A,00F0) is non-zero.​

One or more Items shall be included in this Sequence.​

Page 834​

Attribute Name​

Tag​

Type​

>>Block Tray ID​

(300A,00F5)​

3​

User-supplied identifier for block tray.​

>>Accessory Code​

(300A,00F9)​

3​

An accessory identifier to be read by a device such as a bar code reader.​

>>ReferencedBlockNumber​

(300C,00E0)​

1​

Uniquely identifies block specified by Block Number (300A,00FC) within​

Beam referenced by Referenced Beam Number (300C,0006).​

>>Block Name​

(300A,00FE)​

3​

User-defined name for block.​

>RecordedSnoutSequence​

(3008,00F0)​

1C​

Sequence of Snouts associated with Beam.​

Required if Snout Sequence (300A,030C) is included in the RT Ion Plan​

referenced within the Referenced RT Plan Sequence (300C,0002).​

Only a single Item shall be included in this Sequence.​

>>Snout ID​

(300A,030F)​

1​

User or machine supplied identifier for Snout.​

>>Accessory Code​

(300A,00F9)​

3​

An accessory identifier to be read by a device such as a bar code reader.​

>Applicator Sequence​

(300A,0107)​

1C​

Sequence of Applicators associated with Beam.​

Required if Applicator Sequence (300A,0107) is included in the RT Ion​

Plan referenced within the Referenced RT Plan Sequence (300C,0002).​

Only a single Item shall be included in this Sequence.​

>>Applicator ID​

(300A,0108)​

1​

User or machine supplied identifier for Applicator.​

>>Accessory Code​

(300A,00F9)​

3​

An accessory identifier to be read by a device such as a bar code reader.​

>>Applicator Type​

(300A,0109)​

1​

Type of applicator.​

Defined Terms:​

ION_SQUARE​

ION_RECT​

ION_CIRC​

ION_SHORT​

ION_OPEN​

INTRAOPERATIVE​intraoperative (custom) applicator​

STEREOTACTIC​ stereotactic applicator​

>>Applicator Description​

(300A,010A)​

3​

User-defined description for Applicator.​

>General Accessory​

(300A,0420)​

3​

A Sequence of General Accessories associated with this Beam.​

Sequence​

One or more Items are permitted in this Sequence.​

>>General Accessory​

(300A,0424)​

1​

IdentificationNumberoftheGeneralAccessory.Thevalueshallbeunique​

Number​

within the Sequence.​

>>General Accessory ID​

(300A,0421)​

1​

User or machine supplied identifier for General Accessory.​

>>General Accessory​

(300A,0422)​

3​

User supplied description of General Accessory.​

Description​

>>General Accessory Type​

(300A,0423)​

3​

Specifies the type of accessory.​

Defined Terms:​

GRATICULE​

IMAGE_DETECTOR​Image acquisition device positioned in the beam​

RETICLE​

>>Accessory Code​

(300A,00F9)​

3​

Machine-readable identifier for this accessory​

>Number of Range Shifters​

(300A,0312)​

1​

Number of range shifters associated with current beam.​

Page 835​

Attribute Name​

Tag​

Type​

Description​

>Recorded Range Shifter​

(3008,00F2)​

1C​

Sequence of range shifters recorded with Beam.​

Sequence​

One or more Items shall be included in this Sequence.​

Shifters (300A,0312).​

>>ReferencedRangeShifter​

(300C,0100)​

1​

Number​

(300C,0006).​

>>Range Shifter ID​

(300A,0318)​

1​

User or machine supplied identifier for Range Modulator.​

>>Accessory Code​

(300A,00F9)​

3​

>Number of Lateral​

(300A,0330)​

1​

Spreading Devices​

>Recorded Lateral​

(3008,00F4)​

1C​

SpreadingDeviceSequence​

One or more Items shall be included in this Sequence.​

Spreading Devices (300A,0330).​

>>Referenced Lateral​

(300C,0102)​

1​

Spreading Device Number​

Beam Number (300C,0006).​

>>Lateral Spreading Device​

(300A,0336)​

1​

ID​

>>Accessory Code​

(300A,00F9)​

3​

>Number of Range​

(300A,0340)​

1​

Number of range modulators associated with current beam.​

Modulators​

>RecordedRangeModulator​

(3008,00F6)​

1C​

Sequence of range modulators associated with Beam.​

Sequence​

One or more Items shall be included in this Sequence.​

Modulators (300A,0340).​

>>Referenced Range​

(300C,0104)​

1​

Modulator Number​

(300C,0006).​

>>Range Modulator ID​

(300A,0346)​

1​

User or machine supplied identifier for Range Modulator.​

>>Accessory Code​

(300A,00F9)​

3​
