Page 766​

DICOM PS3.3 2020a - Information Object Definitions​

Attribute Name​

Tag​

Type​

Attribute Description​

>Total Reference Air Kerma​

(300A,0250)​

1​ Total Reference Air Kerma for current Application Setup, i.e., the​







product of Air Kerma Rate of all Sources in all Channels with their​







respective Channel Times (µGy at 1 m). Value shall be zero for​







non-gamma sources.​

>Brachy Accessory Device​

(300A,0260)​

3​ Sequence of Brachy Accessory Devices associated with current​

Sequence​





Application Setup.​







One or more Items are permitted in this Sequence.​

>>Brachy Accessory Device​

(300A,0262)​

2​ Identification number of the Brachy Accessory Device. The value​

Number​





of Brachy Accessory Device Number (300A,0262) shall be unique​







within the Application Setup in which it is created.​

>>Brachy Accessory Device ID​

(300A,0263)​

2​ User or machine supplied identifier for Brachy Accessory Device.​

>>Brachy Accessory Device​

(300A,0264)​

1​ Type of Brachy Accessory Device.​

Type​





Defined Terms:​













SHIELD​







DILATATION​







MOLD​







PLAQUE​







FLAB​

>>Brachy Accessory Device​

(300A,0266)​

3​ User-defined name for Brachy Accessory Device.​

Name​







>>Material ID​

(300A,00E1)​

3​ User-supplied identifier for material of Brachy Accessory Device.​







See Note.​

>>Brachy Accessory Device​

(300A,026A)​

3​ Nominal thickness of Brachy Accessory Device (mm). See​

Nominal Thickness​





Section C.8.8.15.12.​

>>Brachy Accessory Device​

(300A,026C)​

3​ NominalTransmissionthroughBrachyAccessoryDevice(between​

Nominal Transmission​





0 and 1). See Section C.8.8.15.12.​

>>Referenced ROI Number​

(3006,0084)​

2​ UniquelyidentifiesROIrepresentingtheBrachyAccessoryspecified​







by ROI Number (3006,0022) in Structure Set ROI Sequence​







(3006,0020) in Structure Set Module within RT Structure Set​







referencedbyReferencedRTStructureSetSequence(300C,0060)​







in RT General Plan Module. See Section C.8.8.15.2.​

>Channel Sequence​

(300A,0280)​

1​ Sequence of Channels for current Application Setup.​







One or more Items shall be included in this Sequence.​

>>Channel Number​

(300A,0282)​

1​ IdentificationnumberoftheChannel.ThevalueofChannelNumber​







(300A,0282) shall be unique within the Application Setup in which​







it is created.​

>>Channel Length​

(300A,0284)​

2​ Length of Channel (mm). See Section C.8.8.15.3.​

>>Channel Total Time​

(300A,0286)​

1​ Total amount of time between first and final Control Points of the​







Brachy Control Point Sequence (300A,02D0) for current Channel​







(sec).ChannelTotalTimecalculationisbasedupontheReference​







Air Kerma Rate (300A,022A) of the Referenced Source Number​







(300C,000E).​

>>Source Movement Type​

(300A,0288)​

1​ Type of Source movement. See Section C.8.8.15.4.​







Defined Terms:​

STEPWISE​

FIXED​

OSCILLATING​

UNIDIRECTIONAL​

- Standard -​



DICOM PS3.3 2020a - Information Object Definitions​

Page 767​

Attribute Name​

Tag​

Type​

Attribute Description​



>>Number of Pulses​

(300A,028A)​

1C​

Number of Pulses per fraction for current Channel. Required if​







Brachy Treatment Type (300A,0202) is PDR.​



>>Pulse Repetition Interval​

(300A,028C)​

1C​

Pulse repetition interval (sec) for current Channel. Required if​







Brachy Treatment Type (300A,0202) is PDR.​



>>Source Applicator Number​

(300A,0290)​

3​

IdentificationnumberoftheSourceApplicator.ThevalueofSource​







ApplicatorNumber(300A,0290)shallbeuniquewithintheChannel​







in which it is created.​



>>Source Applicator ID​

(300A,0291)​

2C​

UserormachinesuppliedidentifierforSourceApplicator.Required​







if Source Applicator Number (300A,0290) is present.​



>>Source Applicator Type​

(300A,0292)​

1C​

Type of Source Applicator. Required if Source Applicator Number​







(300A,0290) is present.​









Defined Terms:​









FLEXIBLE​









RIGID​



>>Source Applicator Name​

(300A,0294)​

3​

User-defined name for Source Applicator.​



>>Source Applicator Length​

(300A,0296)​

1C​

LengthofSourceApplicator(mm),definedasthedistancebetween​







the connector of the applicator and the distal-most position of the​







source.​









Required if Source Applicator Number (300A,0290) is present.​

>>SourceApplicatorTipLength​

(300A,0274)​

2C​

Length of Source Applicator Tip (in mm), defined as the distance​







between the outer tip of the applicator and the center of the​







distal-most possible position of the source.​









Required if Channel Effective Length (300A,0271) is present.​







See Section C.8.8.15.16.​



>>Source Applicator​

(300A,0298)​

3​

Manufacturer of Source Applicator.​



Manufacturer​









>>Material ID​

(300A,00E1)​

3​

User-supplied identifier for material of Source Applicator wall. See​







Note.​



>>Source Applicator Wall​

(300A,029C)​

3​

Nominal Thickness of Source Applicator wall (mm). See​

Nominal Thickness​





Section C.8.8.15.12.​



>>Source Applicator Wall​

(300A,029E)​

3​

Nominal Transmission through Source Applicator wall (between 0​

Nominal Transmission​





and 1). See Section C.8.8.15.12.​



>>Source Applicator Step Size​

(300A,02A0)​

1C​

Distanceofpathalongchannel(inmm)betweenadjacent(potential)​







dwell positions. Required if Source Movement Type (300A,0288)​







is STEPWISE.​



>>Referenced ROI Number​

(3006,0084)​

2C​

UniquelyidentifiesROIrepresentingtheSourceApplicatorspecified​







by ROI Number (3006,0022) in Structure Set ROI Sequence​







(3006,0020) in Structure Set Module within RT Structure Set​







referencedbyReferencedRTStructureSetSequence(300C,0060)​







inRTGeneralPlanModule.RequiredifSourceApplicatorNumber​







(300A,0290) is present. See Section C.8.8.15.2.​



>>Transfer Tube Number​

(300A,02A2)​

2​

Identification number of the Transfer Tube. The value of Transfer​







Tube Number (300A,02A2) shall be unique within the Channel in​







which it is created.​



>>Transfer Tube Length​

(300A,02A4)​

2C​

Length of Transfer Tube of current afterloading Channel (mm).​







Required if value Transfer Tube Number (300A,02A2) is non-null.​

- Standard -​

Page 768​

DICOM PS3.3 2020a - Information Object Definitions​

Attribute Name​

Tag​

Type​

Attribute Description​

>>Channel Effective Length​

(300A,0271)​

3​

Length of Channel (in mm) defined as the distance between the​







connector on the afterloader and the center of the distal-most​







possible position of the source.​







See Section C.8.8.15.16.​

>>Channel Inner Length​

(300A,0272)​

2C​

The total physical inner length of channel (in mm). Specifies the​







distance between the connector on the afterloader and the end of​







the channel.​







Required if Channel Effective Length (300A,0271) is present.​







See Section C.8.8.15.16.1.​

>>Afterloader Channel ID​

(300A,0273)​

3​

Identification of the Channel connection on the afterloader.​







See Section C.8.8.15.16.2.​

>>Channel Shield Sequence​

(300A,02B0)​

3​

Sequence of Channel Shields associated with current Channel.​







One or more Items are permitted in this Sequence.​







See Section C.8.8.15.5.​

>>>Channel Shield Number​

(300A,02B2)​

1​

Identification number of the Channel Shield. The value of Channel​







Shield Number (300A,02B2) shall be unique within the Channel in​







which it is created.​

>>>Channel Shield ID​

(300A,02B3)​

2​

User or machine supplied identifier for Channel Shield.​

>>>Channel Shield Name​

(300A,02B4)​

3​

User-defined name for Channel Shield.​

>>>Material ID​

(300A,00E1)​

3​

User-supplied identifier for material of Channel Shield. See Note.​

>>>Channel Shield Nominal​

(300A,02B8)​

3​

Nominal Thickness of Channel Shield (mm). See​

Thickness​





Section C.8.8.15.12.​

>>>Channel Shield Nominal​

(300A,02BA)​

3​

Nominal Transmission of Channel Shield (between 0 and 1). See​

Transmission​





Section C.8.8.15.12.​

>>>Referenced ROI Number​

(3006,0084)​

2​

Uniquely identifies ROI representing the Channel Shield specified​







by ROI Number (3006,0022) in Structure Set ROI Sequence​







(3006,0020) in Structure Set Module within RT Structure Set​







referencedbyReferencedRTStructureSetSequence(300C,0060)​







in RT General Plan Module. See Section C.8.8.15.2.​

>>Referenced Source Number​

(300C,000E)​

1​

UniquelyidentifiesthereferencedSourcewithinSourceSequence​







(300A,0210) for current Application Setup.​

>>Number of Control Points​

(300A,0110)​

1​

Number of control points in Channel. For an N-segment Channel​







there will be 2N (stepwise movement) or N+1 (continuous​







movement) control points.​

>>Final Cumulative Time​

(300A,02C8)​

1C​

Value of Cumulative Time Weight (300A,02D6) for final Control​

Weight​





Point in Brachy Control Point Sequence (300A,02D0). Required if​







CumulativeTimeWeight(300A,02D6)isnon-nullinControlPoints​







specifiedwithinBrachyControlPointSequence(300A,02D0).See​







Section C.8.8.15.6.​

>>Brachy Control Point​

(300A,02D0)​

1​

Sequence of machine configurations describing this Channel.​

Sequence​





The number of Items in this Sequence shall equal the value of​













Number of Control Points (300A,0110).​







See Section C.8.8.15.7.​

>>>Control Point Index​

(300A,0112)​

1​

Index of current Control Point, starting at 0 for first Control Point.​

- Standard -​



DICOM PS3.3 2020a - Information Object Definitions​

Page 769​

Attribute Name​

Tag​

Type​

Attribute Description​



>>>Cumulative Time Weight​

(300A,02D6)​

2​ Cumulative time weight to current Control Point (where the​







weighting is proportional to time values delivered). Cumulative​







Time Weight for first Item in Brachy Control Point Sequence​







(300A,02D0) is always zero. See Section C.8.8.15.6 and​







Section C.8.8.15.8.​



>>>Control Point Relative​

(300A,02D2)​

1​ Distance between current Control Point Position and the center of​

Position​





the distal-most possible Source position in current Channel (mm).​







See Section C.8.8.15.9.​



>>>Control Point 3D Position​

(300A,02D4)​

3​ Coordinates (x, y, z) of Control Point in the Patient-Based​







Coordinate System described in Section C.7.6.2.1.1 (mm). See​







Section C.8.8.15.10.​



>>>Control Point Orientation​

(300A,0412)​

3​ (x,y,z) component of the direction vector of the brachy source or​







seed at the Control Point 3D Position (300A,02D4). See​







Section C.8.8.15.14.​



>>>Brachy Referenced Dose​

(300C,0055)​

3​ A Sequence of Dose References for current Channel.​



Reference Sequence​





One or more Items are permitted in this Sequence.​











>>>>Referenced Dose​

(300C,0051)​

1​ Uniquely identifies Dose Reference described in Dose Reference​

Reference Number​





Sequence. (300A,0010) within RT Prescription Module of current​







RT Plan.​



>>>>Cumulative Dose​

(300A,010C)​

1​ Coefficientusedtocalculatecumulativedosecontributionfromthis​

Reference Coefficient​





Source to the referenced Dose Reference at the current Control​







Point. See Section C.8.8.15.11.​



Note​

Material ID (300A,00E1) may also be specified within a referenced ROI, if an ROI is used to describe the object.​

C.8.8.15.1 Permanent Implants​

In permanent implant techniques the value for Channel Total Time (300A,0286) shall be mean life time of the isotope. The Brachy​ Control Point Sequence (300A,02D0) shall consist of two Items: the first having Cumulative Time Weight (300A,02D6) = 0 and the​ second having Cumulative Time Weight (300A,02D6) = Final Cumulative Time Weight (300A,02C8).​

C.8.8.15.2 Referenced ROI Number​

TheStructureSetROIshallbeusedintheRTBrachyApplicationSetupsModuletodescribethe3DcoordinatesofAccessoryDevices,​ Applicators and Channel Shields, but not individual source positions (see Section C.8.8.15.9 and Section C.8.8.15.10).​

C.8.8.15.3 Channel Length​

If specified, Channel Length (300A,0284) shall be the sum of the Source Applicator Length (300A,0296) and Transfer Tube Length​ (300A,02A4).​

C.8.8.15.4 Oscillating Source Movement​

In brachytherapy treatment techniques involving oscillating source movement (i.e., when Source Movement Type (300A,0288) is​ OSCILLATING), the Brachy Control Point Sequence (300A,02D0) shall consist of two Items. The first Control Point shall have Cumu-​ lative Time Weight (300A,02D6) = 0, and Control Point Relative Position (300A,02D2) equal to one end point of the oscillation. The​ second Control Point shall have Cumulative Time Weight (300A,02D6) = Final Cumulative Time Weight (300A,02C8), and Control​ Point Relative Position (300A,02D2) equal to the other end point of the oscillation. Transit time shall not be modeled explicitly for os-​ cillating techniques.​

C.8.8.15.5 Channel Shields​

The effect of Channel Shields on dose contributions shall be specific to the Channel for which they are specified. There shall be no​ effect of these shields on the dose contributions from any other Channels.​

- Standard -​

Page 770​

DICOM PS3.3 2020a - Information Object Definitions​

C.8.8.15.6 Time Calculations​

ThetreatmenttimeatagivenControlPointisequaltotheChannelTotalTime(300A,0286),multipliedbytheCumulativeTimeWeight​ (300A,02D6) for the Control Point, divided by the Final Cumulative Time Weight (300A,02C8). If the calculation for treatment time​ results in a time value that is not an exact multiple of the timer resolution, then the result shall be rounded to the nearest allowed timer​ value (i.e., less than a half resolution unit shall be rounded down to the nearest resolution unit, and equal or greater than half a resol-​ ution unit shall be rounded up to the nearest resolution unit).​

Note also that if Final Cumulative Time Weight (300A,02C8) is equal to 100, then Cumulative Time Weight (300A,02D6) becomes​ equivalent to the percentage of Channel Total Time (300A,0286) delivered at each control point. If Final Cumulative Time Weight​ (300A,02C8)isequaltoChannelTotalTime(300A,0286),thentheCumulativeTimeWeight(300A,02D6)ateachcontrolpointbecomes​ equal to the cumulative treatment time delivered at that control point.​

If Treatment Type (300A,0202) is PDR, then the Channel Total Time (3008,0286) shall specify the duration of a single pulse.​

C.8.8.15.7 Brachy Control Point Sequence​

The Control Points shall be arranged such that the first Control Point for a particular Channel describes the first dwell position and​ the final Control Point for the Channel describes the final dwell position. If Brachy Treatment Type (300A,0202) is PDR, the Brachy​ Control Point Sequence (300A,02D0) shall specify the sequence of machine configurations for a single pulse. Similarly, if Source​ MovementType(300A,0288)isOSCILLATING,theBrachyControlPointSequence(300A,02D0)shallspecifythesequenceofmachine​ configurations for a single period.​

Some examples of Brachytherapy specification using control points are as follows:​

a) Stepwise motion; Four equally weighted dwell positions; Step size = 10; Final Cumulative Time Weight = 100:​

Control Point 0: Control Point Relative Position = 30, Cumulative Time Weight = 0​

Control Point 1: Control Point Relative Position = 30, Cumulative Time Weight = 25​

Control Point 2: Control Point Relative Position = 20, Cumulative Time Weight = 25​

Control Point 3: Control Point Relative Position = 20, Cumulative Time Weight = 50​

Control Point 4: Control Point Relative Position = 10, Cumulative Time Weight = 50​

Control Point 5: Control Point Relative Position = 10, Cumulative Time Weight = 75​

Control Point 6: Control Point Relative Position = 0, Cumulative Time Weight = 75​

Control Point 7: Control Point Relative Position = 0, Cumulative Time Weight = 100​

b) Fixed (manually placed) sources; Final Cumulative Time Weight = 100:​

Control Point 0: Control Point Relative Position = 0, Control Point 3D Position = (x,y,z), Cumulative Time Weight = 0​

Control Point 1: Control Point Relative Position = 0, Control Point 3D Position = (x,y,z), Cumulative Time Weight = 100​

c) Oscillating movement; Final Cumulative Time Weight = 100:​

Control Point 0: Control Point Relative Position = 100, Cumulative Time Weight = 0​

Control Point 1: Control Point Relative Position = 0, Cumulative Time Weight = 100​

d) Unidirectional movement; Final Cumulative Time Weight = 100:​

Control Point 0: Control Point Relative Position = 0, Cumulative Time Weight = 0​

Control Point 1: Control Point Relative Position = 100, Cumulative Time Weight = 100​

e) Stepwise motion with consideration of source transit times between dwell positions; Three equally weighted dwell positions; Step​ size = 10; Final Cumulative Time Weight = 79:​

- Standard -​

Смотрите также:

«ДОХОДЫ, РАСХОДЫ И ПРИБЫЛЬ КОММЕРЧЕСКОГО БАНКА.»
«ДОХОДЫ, РАСХОДЫ И ПРИБЫЛЬ КОММЕРЧЕСКОГО БАНКА.»
Значение, сущность и содержание социально — педагогической деятельности в организации для детей-сирот и детей, оставшихся без попечения родителей
__RGR2
__RGR2
_11_А. Франс для эл версии
_индив анализ данных
- Интерфейс 485 и оптопорт 11
:Конвергентный подход к проектированию дополнительных общеобразовательных общеразвивающих программ
