DICOM PS3.3 2020a - Information Object Definitions​

Page 751​

Attribute Name​

Tag​

Type​

Attribute Description​



>>Block Transmission​

(300A,0102)​

2C​

Transmission through the block (between 0 and 1) at the beam energy​







specified by the Nominal Beam Energy (300A,0114) of the first Control​







Point of the Control Point Sequence (300A,0111). Required if Material​







ID(300A,00E1)iszerolength.MaybepresentifMaterialID(300A,00E1)​







is non-zero length. See Section C.8.8.14.4 and Section C.8.8.14.11.​

>>Block Number of Points​

(300A,0104)​

2​

Number of (x,y) pairs defining the block edge.​



>>Block Data​

(300A,0106)​

2​

A data stream of (x,y) pairs that comprise the block edge. The number​







of pairs shall be equal to Block Number of Points (300A,0104), and the​







vertices shall be interpreted as a closed polygon. Coordinates are​







projected onto the machine isocentric plane in the IEC BEAM LIMITING​







DEVICE coordinate system (mm). See Note 4.​



>Applicator Sequence​

(300A,0107)​

3​

Sequence of Applicators associated with Beam.​









Only a single Item is permitted in this Sequence.​



>>Applicator ID​

(300A,0108)​

1​

User or machine supplied identifier for Applicator.​



>>Accessory Code​

(300A,00F9)​

3​

An identifier for the accessory intended to be read by a device such as​







a bar-code reader.​



>>Applicator Type​

(300A,0109)​

1​

Type of Applicator.​



Defined Terms:​

ELECTRON_SQUARE​square electron applicator​

ELECTRON_RECT​ rectangular electron applicator​

ELECTRON_CIRC​ circular electron applicator​

ELECTRON_SHORT​short electron applicator​

ELECTRON_OPEN​open (dummy) electron applicator​

PHOTON_SQUARE​square photon applicator​

PHOTON_RECT​ rectangular photon applicator​

PHOTON_CIRC​ circular photon applicator​

INTRAOPERATIVE​ intraoperative (custom) applicator​

STEREOTACTIC​ stereotactic applicator (deprecated)​

>>Applicator Geometry​

(300A,0431)​

3​ Describes the applicator aperture geometry.​

Sequence​



Only a single Item is permitted in this Sequence.​





>>>Applicator Aperture​

(300A,0432)​

1​ Aperture shape of the applicator.​

Shape​



Defined Terms:​





SYM_SQUARE​ Asquare-shapedaperturesymmetricaltothecentral​ axis.​

SYM_RECTANGLE​A rectangular-shaped aperture symmetrical to the​ central axis.​

SYM_CIRCULAR​Acircular-shapedaperturesymmetricaltothecentral​ axis.​

>>>Applicator Opening​

(300A,0433)​

1C​

Opening (in mm) of the applicator's aperture in IEC BEAM LIMITING​







DEVICEcoordinatesystem.Incaseofsquare-shapedapplicatorcontains​







the length of the sides of the square. In case of circular-shaped​







applicators, contains the diameter of the circular aperture.​







Required if Applicator Aperture Shape (300A,0432) is SYM_SQUARE or​







SYM_CIRCULAR.​

>>>Applicator Opening X​

(300A,0434)​

1C​

Opening (in mm) of the applicator's aperture in IEC BEAM LIMITING​







DEVICE coordinate system in X-Direction.​

RequiredifApplicatorApertureShape(300A,0432)isSYM_RECTANGLE.​

- Standard -​

Page 752​

DICOM PS3.3 2020a - Information Object Definitions​

Attribute Name​

Tag​

Type​



Attribute Description​

>>>Applicator Opening Y​

(300A,0435)​

1C​

Opening (in mm) of the applicator's aperture in IEC BEAM LIMITING​







DEVICE coordinate system in Y-Direction.​







RequiredifApplicatorApertureShape(300A,0432)isSYM_RECTANGLE.​

>> Source to Applicator​

(300A,0436)​

3​

Radiation source to applicator mounting position distance (in mm) for​

Mounting Position Distance​





current applicator.​



>>Applicator Description​

(300A,010A)​

3​

User-defined description for Applicator.​

>General Accessory​

(300A,0420)​

3​

A Sequence of General Accessories associated with this Beam.​

Sequence​





One or more Items are permitted in this Sequence.​







>>General Accessory​

(300A,0424)​

1​

IdentificationNumberoftheGeneralAccessory.Thevalueshallbeunique​

Number​





within the Sequence.​

>>General Accessory ID​

(300A,0421)​

1​

User or machine supplied identifier for General Accessory.​

>>General Accessory​

(300A,0422)​

3​

User supplied description of General Accessory.​

Description​









>>General Accessory Type​

(300A,0423)​

3​

Specifies the type of accessory.​







Defined Terms:​









GRATICULE​

Accessory tray with a radio-opaque grid​







IMAGE_DETECTOR​Image acquisition device positioned in the beam​









line​







RETICLE​

Accessory tray with radio-transparent markers or​









grid​

>>Accessory Code​

(300A,00F9)​

3​

Machine-readable identifier for this accessory​

>>Source to General​

(300A,0425)​

3​

Radiation source to general accessory distance (in mm) for current​

Accessory Distance​





accessory.​



>Referenced Dose​

(300C,0050)​

3​

A Sequence of Dose References for which verification control points are​

Reference Sequence​





defined.​









One or more Items are permitted in this Sequence.​

>>Referenced Dose​

(300C,0051)​

1​

UniquelyidentifiesDoseReferencespecifiedbyDoseReferenceNumber​

Reference Number​





(300A,0012)inDoseReferenceSequence(300A,0010)inRTPrescription​







Module.​



>>Depth Value Averaging​

(300A,0093)​

1C​

Whether or not the depth values have been averaged.​

Flag​





Enumerated Values:​













YES​The values represent average values from the current Verification​







Control Point to the next​







NO​ The values refer to a single location​







Required if the referenced beam describes an angular movement and​







the depth values change during movement.​

>>Beam Dose Verification​

(300A,008C)​

1​

SequenceofItemscontainingBeamDoseCoordinateVerificationControl​

Control Point Sequence​





Points.​









Two or more Items shall be included in this Sequence.​

>>>Cumulative Meterset​

(300A,0134)​

1​

The cumulative Meterset weight value, at which the beam dose point​

Weight​





geometrical parameters apply.​

- Standard -​



DICOM PS3.3 2020a - Information Object Definitions​

Page 753​

Attribute Name​

Tag​

Type​

Attribute Description​



>>>Referenced Control​

(300C,00F0)​

1C​

Uniquely identifies the Control Point specified by Control Point Index​

Point Index​





(300A,0112) within Beam referenced by Referenced Beam Number​







(300C,0006).​









See Section C.8.8.14.16.​









Required,iftheReferencedCumulativeMetersetcorrespondstoaControl​







Point in the Control Point Sequence (300A,0111).​



>>>BeamDosePointDepth​

(300A,0088)​

1C​

The depth (in mm) in the patient along a ray from the source to the dose​







point specified by the Dose Reference Point Coordinates (300A,0018) or​







the referenced ROI.​









Required for all but the last Item in this Sequence and for the last Item if​







Depth Value Averaging Flag (300A,0093) has a value of NO.​







See Note 6.​



>>>Beam Dose Point​

(300A,0089)​

1C​

The radiological depth in mm (water-equivalent depth, taking tissue​

Equivalent Depth​





heterogeneity into account) in the patient along a ray from the source to​







the dose point specified by the Dose Reference Point Coordinates​







(300A,0018) or the referenced ROI.​









Required for all but the last Item in this Sequence and for the last Item if​







Depth Value Averaging Flag (300A,0093) has a value of NO.​







See Note 6.​



>>>Beam Dose Point SSD​

(300A,008A)​

1C​

Source to patient surface (skin) distance in mm along a ray from the​







source to the dose point specified by the Dose Reference Point​







Coordinates (300A,0018) or the referenced ROI.​









Required for all but the last Item in this Sequence and for the last Item if​







Depth Value Averaging Flag (300A,0093) has a value of NO.​







See Note 6.​



>>>Beam Dose Point​

(300A,0094)​

3​

Source to External Contour distance in mm including devices associated​

Source to External Contour​





with the patient anatomy model along a ray from the source to the dose​

Distance​





point specified by the Dose Reference Point Coordinates (300A,0018) or​







the referenced ROI.​









May be present for all but the last Item in this Sequence and for the last​







Item if Depth Value Averaging Flag (300A,0093) has a value of NO.​







See Section C.8.8.14.15.​



>Final Cumulative Meterset​

(300A,010E)​

1C​

Value of Cumulative Meterset Weight (300A,0134) for final Control Point​

Weight​





inControlPointSequence(300A,0111).RequiredifCumulativeMeterset​







Weight is non-null in Control Points specified within Control Point​







Sequence (300A,0111). See Section C.8.8.14.1.​



>Number of Control Points​

(300A,0110)​

1​

Number of control points in Beam.​









Value shall be greater than or equal to 2.​



>Control Point Sequence​

(300A,0111)​

1​

Sequence of machine configurations describing treatment beam.​







The number of Items in this Sequence shall equal the value of Number​







of Control Points (300A,0110).​









See Section C.8.8.14.5 and Section C.8.8.14.6.​



>>Control Point Index​

(300A,0112)​

1​

Index of current Control Point, starting at 0 for first Control Point.​

- Standard -​

Page 754​

DICOM PS3.3 2020a - Information Object Definitions​

Attribute Name​

Tag​

Type​

Attribute Description​

>>Cumulative Meterset​

(300A,0134)​

2​

Cumulative weight to current control point. Cumulative Meterset Weight​

Weight​





for the first Item in Control Point Sequence shall always be zero.​







Cumulative Meterset Weight for the final Item in Control Point Sequence​







shall always be equal to Final Cumulative Meterset Weight. See​







Section C.8.8.14.1.​

>>Referenced Dose​

(300C,0050)​

3​

A Sequence of Dose References for current Beam. One or more Items​

Reference Sequence​





are permitted in this Sequence.​

>>>Referenced Dose​

(300C,0051)​

1​

UniquelyidentifiesDoseReferencespecifiedbyDoseReferenceNumber​

Reference Number​





(300A,0012)inDoseReferenceSequence(300A,0010)inRTPrescription​







Module.​

>>>Cumulative Dose​

(300A,010C)​

2​

CoefficientusedtocalculatecumulativedosecontributionfromthisBeam​

Reference Coefficient​





to the referenced Dose Reference at the current Control Point. See​







Section C.8.8.14.7.​

>>Referenced Dose​

(300C,0080)​

1C​

Sequence describing related instances of RT Dose (for grids, isodose​

Sequence​





curves, and named/unnamed point doses).​







One or more Items shall be included in this Sequence.​







Required if RT Dose is being transmitted, and Dose Summation Type​







(3004,000A) equals CONTROL_POINT.​

>>>Include Table 10-11 “SOP Instance Reference Macro​

Attributes”​







>>Nominal Beam Energy​

(300A,0114)​

3​

Nominal Beam Energy at control point (MV/MeV).​

>>Dose Rate Set​

(300A,0115)​

3​

Dose Rate to be set on treatment machine for segment beginning at​







current control point (e.g., MU/min).​

>>Wedge Position​

(300A,0116)​

1C​

A Sequence of Items describing Wedge Positions for the current control​

Sequence​





point.​







Required for first Item of Control Point Sequence if Number of Wedges​







(300A,00D0) is non-zero, and in subsequent control points if Wedge​







Position (300A,0118) changes during Beam. See Section C.8.8.14.5.​







The number of Items in this Sequence shall equal the value of Number​







of Wedges (300A,00D0).​

>>>Referenced Wedge​

(300C,00C0)​

1​

Uniquely references Wedge described by Wedge Number (300A,00D2)​

Number​





in Wedge Sequence (300A,00D1).​

>>>Wedge Position​

(300A,0118)​

1​

Position of Wedge at current Control Point.​







Enumerated Values:​







IN​







OUT​

>>Beam Limiting Device​

(300A,011A)​

1C​

Sequence of beam limiting device (collimator) jaw or leaf (element)​

Position Sequence​





positions.​

One or more Items shall be included in this Sequence.​

Required for first Item of Control Point Sequence, or if Beam Limiting​

Device changes during Beam.​

- Standard -​



DICOM PS3.3 2020a - Information Object Definitions​

Page 755​

Attribute Name​

Tag​

Type​



Attribute Description​



>>>RT Beam Limiting​

(300A,00B8)​

1​

Type of beam limiting device (collimator). The value of this Attribute shall​

Device Type​





correspond to RT Beam Limiting Device Type (300A,00B8) defined in an​







Item of Beam Limiting Device Sequence (300A,00B6).​









Enumerated Values:​









X​

symmetric jaw pair in IEC X direction​









Y​

symmetric jaw pair in IEC Y direction​









ASYMX​asymmetric jaw pair in IEC X direction​









ASYMY​asymmetric pair in IEC Y direction​









MLCX​multileaf (multi-element) jaw pair in IEC X direction​









MLCY​multileaf (multi-element) jaw pair in IEC Y direction​



>>>Leaf/Jaw Positions​

(300A,011C)​

1​

Positions of beam limiting device (collimator) leaf (element) or jaw pairs​







(in mm) in IEC BEAM LIMITING DEVICE coordinate axis appropriate to​







RT Beam Limiting Device Type (300A,00B8), e.g., X-axis for MLCX,​







Y-axisforMLCY.Contains2Nvalues,whereNistheNumberofLeaf/Jaw​







Pairs (300A,00BC) in Beam Limiting Device Sequence (300A,00B6).​







Values shall be listed in IEC leaf (element) subscript order 101, 102, …​







1N, 201, 202, … 2N. See Note 3.​



>>Gantry Angle​

(300A,011E)​

1C​

Gantry angle of radiation source, i.e., orientation of IEC GANTRY​







coordinate system with respect to IEC FIXED REFERENCE coordinate​







system (degrees). Required for first Item of Control Point Sequence, or​







if Gantry Angle changes during Beam.​









See Section C.8.8.14.13.​



>>GantryRotationDirection​

(300A,011F)​

1C​

Direction of Gantry Rotation when viewing gantry from isocenter, for​







segment following Control Point. Required for first Item of Control Point​







Sequence, or if Gantry Rotation Direction changes during Beam. See​







Section C.8.8.14.8.​









Enumerated Values:​









CW​ clockwise​









CC​

counter-clockwise​









NONE​no rotation​



>>Gantry Pitch Angle​

(300A,014A)​

3​

Gantry Pitch Angle. i.e., the rotation of the IEC GANTRY coordinate​







systemabouttheX-axisoftheIECGANTRYcoordinatesystem(degrees).​







If used, must be present for first Item of Control Point Sequence, or if​







used and Gantry Pitch Rotation Angle changes during Beam, must be​







present. See Section C.8.8.25.6.5.​









See Section C.8.8.14.13.​



>>Gantry Pitch Rotation​

(300A,014C)​

3​

Direction of Gantry Pitch Angle when viewing along the positive X-axis​

Direction​





of the IEC GANTRY coordinate system, for segment following Control​







Point. If used, must be present for first Item of Control Point Sequence,​







or if used and Gantry Pitch Rotation Direction changes during Beam,​







must be present. See Section C.8.8.14.8 and Section C.8.8.25.6.5.​







Enumerated Values:​









CW​ clockwise​









CC​

counter-clockwise​









NONE​no rotation​



- Standard -​

Смотрите также:

«ДОХОДЫ, РАСХОДЫ И ПРИБЫЛЬ КОММЕРЧЕСКОГО БАНКА.»
«ДОХОДЫ, РАСХОДЫ И ПРИБЫЛЬ КОММЕРЧЕСКОГО БАНКА.»
Значение, сущность и содержание социально — педагогической деятельности в организации для детей-сирот и детей, оставшихся без попечения родителей
__RGR2
__RGR2
_11_А. Франс для эл версии
_индив анализ данных
- Интерфейс 485 и оптопорт 11
:Конвергентный подход к проектированию дополнительных общеобразовательных общеразвивающих программ
