Page 746​

DICOM PS3.3 2020a - Information Object Definitions​

Attribute Name​

Tag​

Type​

Attribute Description​

>Referenced Patient Setup​

(300C,006A)​

3​

Uniquely identifies Patient Setup to be used for current beam, specified​

Number​





by Patient Setup Number (300A,0182) within Patient Setup Sequence of​







RT Patient Setup Module.​

>Referenced Reference​

(300C,0042)​

3​

Referenceimagesusedforvalidationofcurrentbeam.OneormoreItems​

Image Sequence​





are permitted in this Sequence.​

>>Include Table 10-11 “SOP Instance Reference Macro​



Attributes”​







>>ReferenceImageNumber​

(300A,00C8)​

1​

UniquelyidentifiesReferenceImagewithinReferencedReferenceImage​







Sequence (300C,0042).​

>>StartCumulativeMeterset​

(300C,0008)​

3​

Cumulative Meterset Weight within current Beam at which image​

Weight​





acquisition starts.​

>>EndCumulativeMeterset​

(300C,0009)​

3​

Cumulative Meterset Weight within current Beam at which image​

Weight​





acquisition ends.​

>PlannedVerificationImage​

(300A,00CA)​

3​

Sequence of planned verification images to be acquired during current​

Sequence​





beam.​







One or more Items are permitted in this Sequence.​







See Section C.8.8.14.2.​

>>StartCumulativeMeterset​

(300C,0008)​

3​

Cumulative Meterset Weight within current Beam at which image​

Weight​





acquisition will start.​

>>Meterset Exposure​

(3002,0032)​

3​

Metersetdurationoverwhichimageistobeacquired,specifiedinMonitor​







units(MU)orminutesasdefinedbyPrimaryDosimeterUnit(300A,00B3).​

>>EndCumulativeMeterset​

(300C,0009)​

3​

Cumulative Meterset Weight within current Beam at which image​

Weight​





acquisition will end.​

>>RT Image Plane​

(3002,000C)​

3​

Describes whether or not image plane is normal to beam axis.​







Enumerated Values:​







NORMAL​ image plane normal to beam axis​







NON_NORMAL​image plane non-normal to beam axis​

>>X-Ray Image Receptor​

(3002,000E)​

3​

X-Ray Image Receptor Angle i.e., orientation of IEC X-RAY IMAGE​

Angle​





RECEPTOR coordinate system with respect to IEC GANTRY coordinate​







system (degrees). See Section C.8.8.14.3.​

>>RT Image Orientation​

(3002,0010)​

3​

The direction cosines of the first row and the first column with respect to​







the IEC X-RAY IMAGE RECEPTOR coordinate system.​

>>RT Image Position​

(3002,0012)​

3​

The x and y coordinates (in mm) of the upper left hand corner of the​







image, in the IEC X-RAY IMAGE RECEPTOR coordinate system. This​







is the center of the first pixel transmitted.​

>>RT Image SID​

(3002,0026)​

3​

Radiation machine source to image plane distance (mm).​

>>Imaging Device-Specific​

(300A,00CC)​

3​

User-specified device-specific parameters that describe how the imager​

Acquisition Parameters​





will acquire the image.​

>>Referenced Reference​

(300C,0007)​

3​

Uniquely identifies Reference Image to which planned verification image​

Image Number​





is related, specified by Reference Image Number (300A,00C8) within​







Referenced Reference Image Sequence (300C,0042).​

- Standard -​



DICOM PS3.3 2020a - Information Object Definitions​

Page 747​

Attribute Name​

Tag​

Type​



Attribute Description​



>Treatment Delivery Type​

(300A,00CE)​

3​

Delivery Type of treatment.​









Defined Terms:​











TREATMENT​

normal patient treatment​









OPEN_PORTFILM​portal image acquisition with open field​









TRMT_PORTFILM​portal image acquisition with treatment port​







CONTINUATION​ continuation of interrupted treatment​









SETUP​

no treatment beam is applied for this RT Beam. To​









be used for specifying the gantry, couch, and other​









machine positions where X-Ray set-up images or​









measurements are to be taken​



>Referenced Dose​

(300C,0080)​

3​

Related instances of RT Dose (for grids, isodose curves, and​

Sequence​





named/unnamed point doses).​









One or more Items are permitted in this Sequence.​



>>Include Table 10-11 “SOP Instance Reference Macro​







Attributes”​











>Number of Wedges​

(300A,00D0)​

1​

Number of wedges associated with current Beam.​



>Wedge Sequence​

(300A,00D1)​

1C​

Sequence of treatment wedges. Required if Number of Wedges​







(300A,00D0) is non-zero. One or more Items shall be included in this​







Sequence.​





>>Wedge Number​

(300A,00D2)​

1​

Identification number of the Wedge. The value of Wedge Number​







(300A,00D2) shall be unique within the Beam in which it is created.​

>>Wedge Type​

(300A,00D3)​

2​

Type of wedge (if any) defined for Beam.​









Defined Terms:​











STANDARD​standard (static) wedge​









DYNAMIC​ moving beam limiting device (collimator) jaw simulating​







wedge​









MOTORIZED​single wedge that can be removed from beam remotely​

>>Wedge ID​

(300A,00D4)​

3​

User-supplied identifier for Wedge.​



>>Accessory Code​

(300A,00F9)​

3​

An identifier for the accessory intended to be read by a device such as​







a bar-code reader.​



>>Wedge Angle​

(300A,00D5)​

2​

Nominal wedge angle (degrees).​



>>Wedge Factor​

(300A,00D6)​

2​

Nominal wedge factor under machine calibration conditions at the beam​







energy specified by the Nominal Beam Energy (300A,0114) of the first​







Control Point of the Control Point Sequence (300A,0111).​



>>Wedge Orientation​

(300A,00D8)​

2​

Orientation of wedge, i.e., orientation of IEC WEDGE FILTER coordinate​







system with respect to IEC BEAM LIMITING DEVICE coordinate system​







(degrees).​





>>Source to Wedge Tray​

(300A,00DA)​

3​

Radiation source to wedge tray attachment edge distance (in mm) for​

Distance​





current wedge.​





>>Effective Wedge Angle​

(300A,00DE)​

3​

Effective wedge angle (degrees). See Section C.8.8.14.14.​



>Number of Compensators​

(300A,00E0)​

1​

Number of compensators associated with current Beam.​



>Total Compensator Tray​

(300A,00E2)​

3​

Compensator Tray transmission factor (between 0 and 1), at the beam​

Factor​





energy specified by the Nominal Beam Energy (300A,0114) of the first​







Control Point of the Control Point Sequence (300A,0111).​



- Standard -​

Page 748​

DICOM PS3.3 2020a - Information Object Definitions​

Attribute Name​

Tag​

Type​

Attribute Description​

>Compensator Sequence​

(300A,00E3)​

1C​

Sequence of treatment compensators.​







One or more Items shall be included in this Sequence.​







Required if Number of Compensators (300A,00E0) is non-zero.​

>>CompensatorDescription​

(300A,02EB)​

3​

User defined description for the compensator.​

>>Compensator Number​

(300A,00E4)​

1C​

Identification number of the Compensator. The value of Compensator​







Number (300A,00E4) shall be unique within the Beam in which it is​







created. Required if Number of Compensators (300A,00E0) is non-zero.​

>>Compensator Type​

(300A,00EE)​

3​

Type of compensator (if any).​







Defined Terms:​







STANDARD​physical (static) compensator​







DYNAMIC​movingBeamLimitingDevice(collimator)simulatingphysical​







compensator​

>>Material ID​

(300A,00E1)​

2C​

User-supplied identifier for material used to manufacture Compensator.​







Required if Number of Compensators (300A,00E0) is non-zero.​

>>Compensator ID​

(300A,00E5)​

3​

User-supplied identifier for compensator.​

>>Accessory Code​

(300A,00F9)​

3​

An identifier for the Compensator intended to be read by a device such​







as a bar-code reader.​

>>Compensator Tray ID​

(300A,00EF)​

3​

User-supplied identifier for compensator tray.​

>>Tray Accessory Code​

(300A,0355)​

3​

An identifier for the Tray intended to be read by a device such as a​







bar-code reader.​

>>Source to Compensator​

(300A,00E6)​

2​

Radiation source to compensator tray attachment edge distance (in mm)​

Tray Distance​





for current compensator.​

>>CompensatorDivergence​

(300A,02E0)​

3​

Indicates presence or absence of geometrical divergence of the​







compensator.​







Enumerated Values:​







PRESENT​thecompensatorisshapedaccordingtothebeamgeometrical​







divergence.​







ABSENT​the compensator is not shaped according to the beam​







geometrical divergence.​

>>Compensator Mounting​

(300A,02E1)​

3​

Indicates on which side of the Compensator Tray the compensator is​

Position​





mounted.​







Enumerated Values:​







PATIENT_SIDE​the compensator is mounted on the side of the​







Compensator Tray that is towards the patient.​







SOURCE_SIDE​the compensator is mounted on the side of the​







CompensatorTraythatistowardstheradiationsource.​







DOUBLE_SIDED​the compensator has a shaped (i.e., non-flat) surface​







on both sides of the Compensator Tray.​

>>Compensator Rows​

(300A,00E7)​

1​

Number of rows in the compensator. A row is defined to be in the X​







direction of the IEC Beam Limiting Device Coordinate system.​

>>Compensator Columns​

(300A,00E8)​

1​

Number of columns in the compensator. A column is defined to be in the​







Y direction of the IEC Beam Limiting Device Coordinate system.​

- Standard -​



DICOM PS3.3 2020a - Information Object Definitions​

Page 749​

Attribute Name​

Tag​

Type​

Attribute Description​



>>Compensator Pixel​

(300A,00E9)​

1​

Physical distance (in mm) between the center of each pixel projected​

Spacing​





ontomachineisocentricplane.Specifiedbyanumericpair-adjacentrow​







spacing (delimiter) adjacent column spacing. See Section 10.7.1.3 for​







further explanation of the value order.​



>>Compensator Position​

(300A,00EA)​

1​

The x and y coordinates of the upper left hand corner (first pixel​







transmitted) of the compensator, projected onto the machine isocentric​







plane in the IEC BEAM LIMITING DEVICE coordinate system (mm).​

>>Compensator​

(300A,00EB)​

1C​

A data stream of the pixel samples that comprise the compensator,​

Transmission Data​





expressed as broad-beam transmission values (between 0 and 1) along​







a ray line passing through the pixel, at the beam energy specified by the​







NominalBeamEnergy(300A,0114)ofthefirstControlPointoftheControl​







Point Sequence (300A,0111). The order of pixels encoded is left to right,​







top to bottom, i.e., the upper left pixel is encoded first followed by the​







remainder of the first row, followed by the first pixel of the 2nd row, then​







the remainder of the 2nd row and so on) when viewed from the radiation​







source.RequiredifMaterialID(300A,00E1)iszero-length.Maybepresent​







if Material ID (300A,00E1) is non-zero length. See Section C.8.8.14.10​







and Section C.8.8.14.11.​









Note​









Compensator Transmission Data may not be properly encoded​







ifExplicitVRTransferSyntaxisusedandtheVLofthisAttribute​







exceeds 65534 bytes.​



>>Compensator Thickness​

(300A,00EC)​

1C​

A data stream of the pixel samples that comprise the compensator,​

Data​





expressed as thicknesses (in mm). The order of pixels encoded is left to​







right, top to bottom, i.e., the upper left pixel is encoded first followed by​







the remainder of the first row, followed by the first pixel of the 2nd row,​







then the remainder of the 2nd row and so on) when viewed from the​







radiation source. Required if Material ID (300A,00E1) is non-zero length.​







May be present if Material ID (300A,00E1) is zero length. See​







Section C.8.8.14.9 and Section C.8.8.14.10 and Section C.8.8.14.11,​







“Block and Compensator Precedence for Dosimetric Calculations”.​







Note​









Compensator Thickness Data may not be properly encoded if​







Explicit VR Transfer Syntax is used and the VL of this Attribute​







exceeds 65534 bytes.​



>>Source to Compensator​

(300A,02E2)​

1C​

A data stream of the pixel samples that comprise the distance from the​

Distance​





radiationsourcetothecompensatorsurfaceclosesttotheradiationsource​







(in mm). The order of pixels encoded is left to right, top to bottom (upper​







left pixel, followed by the remainder of row 1, followed by the remainder​







of the columns). Required if Material ID (300A,00E1) is non-zero length,​







and Compensator Mounting Position (300A,02E1) is DOUBLE_SIDED.​







MaybepresentifMaterialID(300A,00E1)iszerolengthandCompensator​







Mounting Position (300A,02E1) is DOUBLE_SIDED. See​









Section C.8.8.14.9 and Section C.8.8.14.11.​



>Number of Boli​

(300A,00ED)​

1​

Number of boli associated with current Beam.​



>Referenced Bolus​

(300C,00B0)​

1C​

Sequence of boli associated with Beam. Required if Number of Boli​

Sequence​





(300A,00ED) is non-zero.​



One or more Items shall be included in this Sequence.​

- Standard -​

Page 750​

DICOM PS3.3 2020a - Information Object Definitions​

Attribute Name​

Tag​

Type​

Attribute Description​

>>Referenced ROI Number​

(3006,0084)​

1​

Uniquely identifies ROI representing the Bolus specified by ROI Number​







(3006,0022)inStructureSetROISequence(3006,0020)inStructureSet​







Module within RT Structure Set in Referenced Structure Set Sequence​







(300C,0060) in RT General Plan Module.​

>>Bolus ID​

(300A,00DC)​

3​

User-supplied identifier for the Bolus.​

>>Bolus Description​

(300A,00DD)​

3​

User-defined description for the Bolus.​

>>Accessory Code​

(300A,00F9)​

3​

An identifier for the accessory intended to be read by a device such as​







a bar-code reader.​

>Number of Blocks​

(300A,00F0)​

1​

Number of shielding blocks associated with Beam.​

>Total Block Tray Factor​

(300A,00F2)​

3​

Total block tray transmission for all block trays (between 0 and 1) at the​







beam energy specified by the Nominal Beam Energy (300A,0114) of the​







first Control Point of the Control Point Sequence (300A,0111).​

>Block Sequence​

(300A,00F4)​

1C​

Sequence of blocks associated with Beam.​







One or more Items shall be included in this Sequence.​







Required if Number of Blocks (300A,00F0) is non-zero.​

>>Block Tray ID​

(300A,00F5)​

3​

User-supplied identifier for block tray.​

>>Tray Accessory Code​

(300A,0355)​

3​

An identifier for the Tray intended to be read by a device such as a​







bar-code reader.​

>>Accessory Code​

(300A,00F9)​

3​

An identifier for the Block intended to be read by a device such as a​







bar-code reader.​

>>Source to Block Tray​

(300A,00F6)​

2​

Radiation Source to attachment edge of block tray assembly (mm).​

Distance​







>>Block Type​

(300A,00F8)​

1​

Type of block.​







Enumerated Values:​







SHIELDING​blocking material is inside contour​







APERTURE​blocking material is outside contour​

>>Block Divergence​

(300A,00FA)​

2​

Indicates presence or otherwise of geometrical divergence.​







Enumerated Values:​







PRESENT​block edges are shaped for beam divergence​







ABSENT​block edges are not shaped for beam divergence​

>>Block Mounting Position​

(300A,00FB)​

3​

Indicates on which side of the Block Tray the block is mounted.​







Enumerated Values:​







PATIENT_SIDE​the block is mounted on the side of the Block Tray that​







is towards the patient.​







SOURCE_SIDE​the block is mounted on the side of the Block Tray that​







is towards the radiation source.​

>>Block Number​

(300A,00FC)​

1​

Identification number of the Block. The value of Block Number​







(300A,00FC) shall be unique within the Beam in which it is created.​

>>Block Name​

(300A,00FE)​

3​

User-defined name for block.​

>>Material ID​

(300A,00E1)​

2​

User-supplied identifier for material used to manufacture Block.​

>>Block Thickness​

(300A,0100)​

2C​

Physical thickness of block (in mm) parallel to radiation beam axis.​







Required if Material ID (300A,00E1) is non-zero length. May be present​







if Material ID (300A,00E1) is zero length. See Section C.8.8.14.4 and​







Section C.8.8.14.11.​

- Standard -​

Смотрите также:

«ДОХОДЫ, РАСХОДЫ И ПРИБЫЛЬ КОММЕРЧЕСКОГО БАНКА.»
«ДОХОДЫ, РАСХОДЫ И ПРИБЫЛЬ КОММЕРЧЕСКОГО БАНКА.»
Значение, сущность и содержание социально — педагогической деятельности в организации для детей-сирот и детей, оставшихся без попечения родителей
__RGR2
__RGR2
_11_А. Франс для эл версии
_индив анализ данных
- Интерфейс 485 и оптопорт 11
:Конвергентный подход к проектированию дополнительных общеобразовательных общеразвивающих программ
