DICOM PS3.3 2020a - Information Object Definitions​

Page 681​

Attribute Name​

Tag​

Type​

Attribute Description​



Presentation LUT​

(2050,0020)​

1C​

Specifies an identity transformation for the Presentation LUT, such that the​

Shape​





outputofallgrayscaletransformationsdefinedintheIODcontainingthisModule​







are defined to be P-Values.​









Enumerated Values:​









IDENTITY​ Output is in P-Values.​









Required if Photometric Interpretation (0028,0004) is MONOCHROME2, and​







Bits Stored (0028,0101) is greater than 1.​









Note​









If the VOI LUT Module is required by the IOD but no VOI LUT​









Sequence (0028,3010) or Window Center (0028,1050) is present,​







then the VOI LUT stage is an identity transformation.​



Illumination​

(2010,015E)​

3​

Luminanceofahypotheticalviewingdeviceilluminatingapieceofmonochrome​







transmissivefilm,orforthecaseofreflectivemedia,luminanceobtainablefrom​







diffuse reflection of the illumination present. Expressed as L0, in candelas per​







square meter (cd/m2).​









Note​









May be used together with Reflected Ambient Light (2010,0160) to​







recover Optical Density information from P-Values. See​









Section C.8.6.3.1.​



Reflected Ambient​

(2010,0160)​

3​

For scanned monochrome transmissive film viewed on a hypothetical viewing​

Light​





device, the luminance contribution due to reflected ambient light. Expressed​







as La, in candelas per square meter (cd/m2).​









Note​









MaybeusedtogetherwithIllumination(2010,015E)torecoverOptical​







Density information from P-Values. See Section C.8.6.3.1.​



Rescale Intercept​

(0028,1052)​

1C​

The value b in the relationship between stored values (SV) in Pixel Data​







(7FE0,0010) and the output units specified in Rescale Type (0028,1054).​







Output units = m*SV + b.​









Required if Photometric Interpretation (0028,0004) is MONOCHROME2, and​







Bits Stored (0028,0101) is greater than 1.​









Note​









This specifies an identity Modality LUT transformation.​



Rescale Slope​

(0028,1053)​

1C​

m in the equation specified by Rescale Intercept (0028,1052).​



Required if Photometric Interpretation (0028,0004) is MONOCHROME2, and​

Bits Stored (0028,0101) is greater than 1.​

Note​

This specifies an identity Modality LUT transformation.​

- Standard -​

Page 682​

DICOM PS3.3 2020a - Information Object Definitions​

Attribute Name​

Tag​

Type​

Attribute Description​

Rescale Type​

(0028,1054)​

1C​

Specifies the output units of Rescale Slope (0028,1053) and Rescale Intercept​







(0028,1052).​







Defined Terms:​







US​Unspecified​







Required if Photometric Interpretation (0028,0004) is MONOCHROME2, and​







Bits Stored (0028,0101) is greater than 1.​







Note​







This specifies an identity Modality LUT transformation.​

Frame Increment​

(0028,0009)​

1C​

Contains the Data Element Tag of the Attribute that is used as the frame​

Pointer​





increment in Multi-frame pixel data. See Section C.7.6.6.1.2 for further​







explanation.​







ShallbepresentifNumberofFramesisgreaterthan1,overriding(specializing)​







the Type 1 requirement on this Attribute in the Multi-frame Module.​

NominalScannedPixel​ (0018,2010)​

1C​

Physical distance on the media being digitized or scanned between the center​

Spacing​





of each pixel, specified by a numeric pair - adjacent row spacing (delimiter)​







adjacent column spacing in mm. See Section 10.7.1.3 for further explanation​







of the value order.​







Required if Conversion Type (0008,0064) is DF (Digitized Film). May also be​







present if Conversion Type (0008,0064) is SD (Scanned Document) or SI​







(Scanned Image).​







Shall be consistent with Pixel Aspect Ratio (0028,0034), if present.​

Include Table 10-10 “Basic Pixel Spacing Calibration​

Macro Attributes”​







Digitizing Device​

(0018,2020)​

3​

Enumerated Values:​

Transport Direction​





ROW​













COLUMN​

Rotation of Scanned​

(0018,2030)​

3​

Angleoftheedgeofthefilmrelativetothetransportdirectionindegreesgreater​

Film​





than or equal to -45 and less than or equal to +45.​

C.8.6.3.1 Scanned Film, Optical Density and P-Values​

Illumination(2010,015E)andReflectedAmbientLight(2010,0160)maybeusedtorecoverOpticalDensityinformationfromP-Values.​

MonochromemediathatisbeingdigitizedisoftenmeasuredinOpticalDensityvalues.ThesevaluesneedtobeconvertedtoP-Values​ for storage and display. The P-Values used in an image correspond to the perception of a human observer viewing the film on a hy-​ pothetical viewing device (such as a light box), using the specified values of Illumination (2010,015E) and Reflected Ambient Light​ (2010,0160).​

The Grayscale Standard Display Function defined in PS3.14 is used to convert Luminance to P-Values. In the case of scanned film,​ the Luminance is derived from Optical Density using the specified values of Illumination (2010,015E) and Reflected Ambient Light​ (2010,0160). An example of this derivation, as well as typical "default" values for these parameters, is specified in PS3.14.​

C.8.6.4 SC Multi-frame Vector Module​

Table C.8-25c contains IOD Attributes that may be the target of the Frame Increment Pointer (0028,0009) for SC Multi-frame images.​

- Standard -​

DICOM PS3.3 2020a - Information Object Definitions​ Page 683​

Table C.8-25c. SC Multi-frame Vector Module Attributes​

Attribute Name​

Tag​

Type​

Attribute Description​

Frame Time Vector​

(0018,1065)​

1C​

An array that contains the real time increments (in msec) between frames for​







a Multi-frame image.​







See Section C.7.6.5.1.2 for further explanation.​







Required if Frame Increment Pointer (0028,0009) points to Frame Time Vector​







(0018,1065).​







Note​







Frame Time Vector arrays may not be properly encoded if Explicit VR​







Transfer Syntax is used and the VL of this Attribute exceeds 65534​







bytes.​

Page Number Vector​

(0018,2001)​

1C​

An array that contains, for each of the image frames, the corresponding page​







numbers of the original document.​







RequiredifFrameIncrementPointer(0028,0009)pointstoPageNumberVector​







(0018,2001).​

Frame Label Vector​

(0018,2002)​

1C​

An array that contains, for each of the image frames, a descriptive label.​







RequiredifFrameIncrementPointer(0028,0009)pointstoFrameLabelVector​







(0018,2002).​

Frame Primary Angle​

(0018,2003)​

1C​

Anarraythatcontains,foreachoftheimageframes,theprimaryangleofrotation​

Vector​





about an undefined axis, in degrees. May be used for annotative purposes for​







"cine loops" of 3D reprojected images​







RequiredifFrameIncrementPointer(0028,0009)pointstoFramePrimaryAngle​







Vector (0018,2003).​

FrameSecondaryAngle​ (0018,2004)​

1C​

An array that contains, for each of the image frames, the secondary angle of​

Vector​





rotationaboutanundefinedaxisthatisorthogonaltothatusedforFramePrimary​







Angle Vector (0018,2003), in degrees. May be used for annotative purposes​







for "cine loops" of 3D reprojected images​







Required if Frame Increment Pointer (0028,0009) points to Frame Secondary​







Angle Vector (0018,2004).​

Slice Location Vector​

(0018,2005)​

1C​

An array that contains, for each of the image frames, the relative position of the​







image plane expressed in mm, as defined for Slice Location (0020,1041). See​







Section C.7.6.2.1.2 for further explanation.​







RequiredifFrameIncrementPointer(0028,0009)pointstoSliceLocationVector​







(0018,2005).​

Display Window Label​

(0018,2006)​

1C​

An array that contains, for each of the image frames, a label or number of the​

Vector​





displaywindowofagraphicaluserinterfacefromwhichtheframewascaptured.​

Required if Frame Increment Pointer (0028,0009) points to Display Window​

Label Vector (0018,2006).​

C.8.7 X-Ray Modules​

ThisSectiondescribesModulesusedinoneormoreX-RayIODs.TheseModulescontainAttributesthatarespecifictoX-Rayimages.​

- Standard -​

Page 684​ DICOM PS3.3 2020a - Information Object Definitions​

C.8.7.1 X-Ray Image Module​

Table C.8-26. X-Ray Image Module Attributes​

Attribute Name​

Tag​

Type​

Attribute Description​

Frame Increment Pointer​

(0028,0009)​

1C​

Required if Multi-frame Image.​







Contains the Data Element Tag of the Attribute that is used as the​







Frame increment in Multi-frame image pixel data (see​







Section C.7.6.6).​







Enumerated Values:​







00181063H​ Frame Time (0018,1063)​







00181065H​ Frame Time Vector (0018,1065)​

Lossy Image Compression​

(0028,2110)​

1C​

Specifies whether an Image has undergone lossy compression (at​







a point in its lifetime).​







Enumerated Values:​







00​Image has NOT been subjected to lossy compression.​







01​Image has been subjected to lossy compression.​







Once this value has been set to 01 it shall not be reset.​







See Section C.7.6.1.1.5​







RequiredifLossyCompressionhasbeenperformedontheImage.​







May be present otherwise.​

Image Type​

(0008,0008)​

1​

Image identification characteristics.​







See Section C.8.7.1.1.1 for specialization.​

Pixel Intensity Relationship​

(0028,1040)​

1​

The relationship between the Pixel sample values and the X-Ray​







beam intensity.​







See Section C.8.7.1.1.2.​

Samples per Pixel​

(0028,0002)​

1​

Number of samples (color planes) in this image shall have a value​







of 1.​

Photometric Interpretation​

(0028,0004)​

1​

Specifies the intended interpretation of the pixel data. Only​







MONOCHROME2 may be used.​

Bits Allocated​

(0028,0100)​

1​

Number of bits allocated for each pixel sample.​







See Section C.8.7.1.1.6.​

Bits Stored​

(0028,0101)​

1​

Number of bits stored for each pixel sample.​







See Section C.8.7.1.1.7.​

High Bit​

(0028,0102)​

1​

Most significant bit for pixel sample data.​







See Section C.8.7.1.1.8.​

Pixel Representation​

(0028,0103)​

1​

Data representation of the pixel samples.​







Shall have the value:​







0000H = Unsigned Integer.​

Scan Options​

(0018,0022)​

3​

Parameters of scanning sequence.​







See Section C.8.7.1.1.4.​

- Standard -​



DICOM PS3.3 2020a - Information Object Definitions​

Page 685​

Attribute Name​

Tag​

Type​

Attribute Description​



Include Table 10-7 “General Anatomy Optional Macro Attributes”​No CID for the Anatomic Region Sequence is defined.​

R Wave Pointer​

(0028,6040)​

3​

Marks the location(s) of the R Wave in the cardiac cycles by​







referencing frame numbers; frame numbers begin with 1.​

Referenced Image​

(0008,1140)​

1C​

Other images significantly related to this image. Shall be present​

Sequence​





if Image Type (0008,0008) Value 3 is BIPLANE A or BIPLANE B.​







May be present otherwise.​









One or more Items shall be included in this Sequence.​







See Section C.8.7.1.1.13.​



>Include Table 10-3 “Image SOP Instance Reference Macro​





Attributes”​









>Purpose of Reference​

(0040,A170)​

3​

Describes the purpose for which the reference is made.​

Code Sequence​





Only a single Item is permitted in this Sequence.​











>>Include Table 8.8-1 “Code Sequence Macro Attributes”​

DCID 7201 “Referenced Image Purposes of Reference”.​

Derivation Description​

(0008,2111)​

3​

A text description of how this image was derived.​









See Section C.8.7.1.1.5 for further explanation.​



Acquisition Device​

(0018,1400)​

3​

Indicates any visual processing performed on the images prior to​

Processing Description​





exchange.​









See Section C.8.7.1.1.3.​



Frame Label Vector​

(0018,2002)​

3​

A multi-valued Attribute that contains a descriptive label for each​







oftheimageframes.Thenumberofvaluesshallequalthenumber​







of frames.​



Frame Dimension Pointer​

(0028,000A)​

3​

Contains the Data Element Tags of one or more Attributes that​







vary or increment for the frames of a multi-frame image. See​







Section C.8.7.1.1.12.​









Shall not be present if it would contain only one value and that​







value would be Frame Time (0018,1063) or Frame Time Vector​







(0018,1065).​



Calibration Image​

(0050,0004)​

3​

Indicates whether a reference object (phantom) of known size is​







present in the image and was used for calibration.​



Enumerated Values:​

YES​

NO​

DeviceisidentifiedusingtheDeviceModule.SeeSectionC.7.6.12.​

C.8.7.1.1 X-Ray Image Attribute Descriptions​

C.8.7.1.1.1 Image Type​

The Image Type Attribute identifies important image characteristics in a multiple valued Data Element. For X-Ray, Image Type is​ specialized as follows:​

•​Value 1 shall identify the Pixel Data Characteristics in accordance with Section C.7.6.1.1.2​

Enumerated Values:​

ORIGINAL​

DERIVED​

- Standard -​

Смотрите также:

«ДОХОДЫ, РАСХОДЫ И ПРИБЫЛЬ КОММЕРЧЕСКОГО БАНКА.»
«ДОХОДЫ, РАСХОДЫ И ПРИБЫЛЬ КОММЕРЧЕСКОГО БАНКА.»
Значение, сущность и содержание социально — педагогической деятельности в организации для детей-сирот и детей, оставшихся без попечения родителей
__RGR2
__RGR2
_11_А. Франс для эл версии
_индив анализ данных
- Интерфейс 485 и оптопорт 11
:Конвергентный подход к проектированию дополнительных общеобразовательных общеразвивающих программ
