DICOM PS3.2 2020a - Conformance |
|
Page 211 |
Attribute Name |
Tag |
VR |
Value |
Presence of |
Source |
|
|
|
|
Value |
|
Execution Status |
(2100,0030) |
CS |
If PRINTING or DONE: |
ALWAYS |
Printer |
Info |
|
|
•NORMAL |
|
|
|
|
|
|
|
|
|
|
|
If PENDING: |
|
|
|
|
|
•QUEUED |
|
|
|
|
|
•PROC INIT |
|
|
|
|
|
•PROC DOWN |
|
|
|
|
|
•PRINTER INIT |
|
|
|
|
|
•CALIBRATION ERR |
|
|
|
|
|
•PROC OVERFLOW |
|
|
|
|
|
•CHEMICALS EMPTY |
|
|
|
|
|
•CHECK CHEMISTRY |
|
|
|
|
|
•PROC OVERFLOW HI |
|
|
|
|
|
•CHEMICALS LOW |
|
|
|
|
|
•BAD SUPPLY MGZ |
|
|
|
|
|
•NO SUPPLY MGZ |
|
|
|
|
|
•SUPPLY MGZ ERR |
|
|
|
|
|
•SUPPLY EMPTY |
|
|
|
|
|
•SUPPLY LOW |
|
|
|
|
|
•RECEIVER FULL |
|
|
|
|
|
•NO RECEIVE MGZ |
|
|
|
|
|
•CALIBRATION ERR |
|
|
|
|
|
•COVER OPEN |
|
|
|
|
|
•FILM JAM |
|
|
|
|
|
If FAILURE: |
|
|
|
|
|
•JOB CANCELED |
|
|
|
|
|
•INVALID PAGE DES |
|
|
|
|
|
•ELEC SW ERROR |
|
|
|
|
|
•UNKNOWN |
|
|
For each status type: PENDING, PRINTING, DONE and FAILURE, the following print job attributes are returned to the SCU:
- Standard -
Page 212 DICOM PS3.2 2020a - Conformance
Table E.4.2-35. Print Job SOP Class N-EVENT-REPORT Notification Events Information
Event Type Name Event Type |
Attribute Name |
Tag |
||
|
ID |
|
|
|
Pending |
1 |
Execution Status Info |
(2100,0030) |
|
|
|
Print Job ID |
|
(2100,0010) |
|
|
Film Session Label |
(2000,0050) |
|
|
|
Printer Name |
|
(2110,0030) |
Printing |
2 |
Execution Status Info |
(2100,0030) |
|
|
|
Print Job ID |
|
(2100,0010) |
|
|
Film Session Label |
(2000,0050) |
|
|
|
Printer Name |
|
(2110,0030) |
Done |
3 |
Execution Status Info |
(2100,0030) |
|
|
|
Print Job ID |
|
(2100,0010) |
|
|
Film Session Label |
(2000,0050) |
|
|
|
Printer Name |
|
(2110,0030) |
Failure |
4 |
Execution Status Info |
(2100,0030) |
|
|
|
Print Job ID |
|
(2100,0010) |
|
|
Film Session Label |
(2000,0050) |
|
|
|
Printer Name |
|
(2110,0030) |
If the Event Type is Failure or Pending then the error/pending condition is sent to the SCU through the Execution Status Info element (2100,0030), as described in Table E.4.2-35.
When the Event Type is Done or Printing the Print Server is deleting the Print Job SOP Instance after receiving a confirmation from the Print SCU.
E.4.2.1.4.1.3.4.2 Specific Conformance for Print Job N-GET
The EXAMPLE-PRINT-SERVER-MANAGEMENT support the Print Job N-GET requests. When a Print SCU needs to monitor the status of a print job, it can either maintain its association until the Print Server Management System notifies the SCU that the print job has completed, or it may open a new association with the Print Server Management System to track the print job using the Print Job SOP Class N-GET status.
ThefollowingtabledescribesthePrintServerManagementSystemrespondstoaN-GETPrintJobDIMSEServicerequestandreturns the following attributes in support of Print Job SOP Class.
Table E.4.2-36. Print Job SOP Class N-GET Request Attributes
Attribute Name |
Tag |
VR |
Value |
Presence of Source |
|
|
|
|
|
Value |
|
Execution Status |
(2100,0020) |
CS |
PENDING |
ALWAYS |
Printer |
|
|
|
PRINTING |
|
|
|
|
|
DONE |
|
|
|
|
|
FAILURE |
|
|
Print Priority |
(2000,0020) |
CS |
HIGH |
ANAP |
Printer |
|
|
|
MED |
|
|
|
|
|
LOW |
|
|
- Standard -
|
|
|
DICOM PS3.2 2020a - Conformance |
|
Page 213 |
Attribute Name |
Tag |
VR |
Value |
Presence of Source |
|
|
|
|
|
Value |
|
Printer Name |
(2110,0030) |
LO |
Any value up to 16 characters in length. Chosen byANAP |
Printer |
|
|
|
|
user at time of installation |
|
|
Originator |
(2100,0070) |
AE |
16 bytes string for the SCU AE title that issued theANAP |
Printer |
|
|
|
|
print operation |
|
|
Creation Date |
(2100,0040) |
DA |
8bytesDateformatstring:YYYYMMDDfortheDateANAP |
Printer |
|
|
|
|
of print job creation |
|
|
Creation Time |
(2100,0050) |
TM |
Up to 16 bytes Time string format: hhmmss.fractionANAP |
Printer |
|
|
|
|
for Time of print job creation |
|
|
- Standard -
Page 214 |
|
|
DICOM PS3.2 2020a - Conformance |
|
Attribute Name |
Tag |
VR |
Value |
Presence of Source |
|
|
|
|
Value |
Execution Status |
(2100,0030) |
LO |
If PRINTING or DONE: |
ALWAYS Printer |
Info |
|
|
•NORMAL |
|
|
|
|
|
|
|
|
|
If PENDING: |
|
|
|
|
•QUEUED |
|
|
|
|
•PROC INIT |
|
|
|
|
•PROC DOWN |
|
|
|
|
•PRINTER INIT |
|
|
|
|
•CALIBRATION ERR |
|
|
|
|
•PROC OVERFLOW FL |
|
|
|
|
•CHEMICALS EMPTY |
|
|
|
|
•CHECK CHEMISTRY |
|
|
|
|
•PROC OVERFLOW HI |
|
|
|
|
•CHEMICALS LOW |
|
|
|
|
•BAD SUPPLY MGZ |
|
|
|
|
•NO SUPPLY MGZ |
|
|
|
|
•SUPPLY MGZ ERR |
|
|
|
|
•SUPPLY EMPTY |
|
|
|
|
•SUPPLY LOW |
|
|
|
|
•RECEIVER FULL |
|
|
|
|
•NO RECEIVE MGZ |
|
|
|
|
•CALIBRATION ERR |
|
|
|
|
•COVER OPEN |
|
|
|
|
•FILM JAM |
|
|
|
|
If FAILURE: |
|
|
|
|
•JOB CANCELED |
|
|
|
|
•INVALID PAGE DES |
|
|
|
|
•ELEC SW ERROR |
|
|
|
|
•UNKNOWN |
|
The following table describes the status codes and behavior of the Print Server reply in response to Print Job N-GET requested by the Print SCU:
- Standard -
DICOM PS3.2 2020a - Conformance Page 215
Table E.4.2-37. Print Job SOP Class N-GET Response Status Handling Behavior
Service Status |
Further Meaning |
Error Code |
Behavior |
Success |
Success |
0000 |
The request is successful; printer information is returned. |
Warning |
Attributes not recognized |
0107 |
Attributes not recognized within the context of this SOP |
|
|
|
class. |
|
|
|
A list of offending attribute tags is returned in Attribute List |
|
|
|
(0000,1005). |
|
|
|
A Data Set is still returned with valid attributes/values. |
Failure |
No such object instance |
0112 |
The instance UID given does not exist. |
E.4.2.1.4.1.3.5 Specific Conformance for Presentation LUT Box SOP Class
The Print Server Management System supports the Presentation LUT SOP class as SCP. Print SCU may negotiate this support and create a Presentation LUT instance prior to the creation of Film Boxes or Image Boxes. Multiple Presentation LUT instances are supported in an association, but only one instance will be supported for each image.
The SCU shall send either Presentation LUT Sequence or the Presentation LUT Shape. These values are mutually exclusive and the action will result in an error if neither or both are present. The presence of the Presentation LUT instance overrides any Data Set in the Configuration Information attribute (2010,0150) of the Film Box or Image Box.
The Print Server Management System provides support for the following DIMSE Services:
•N-CREATE
•N-DELETE
E.4.2.1.4.1.3.5.1 Presentation LUT Box SOP Class Operation for N-CREATE
The Print Server Management System supports the following attributes of the
N-CREATE DIMSE Service of the Presentation LUT SOP Class:
Table E.4.2-38. Presentation LUT SOP Class N-CREATE Request Attributes
Attribute & Usage |
Tag |
Supported Values |
Default Values if not sent by Response to |
|
|
|
SCUorinvalidvaluereceived Invalid Value |
Presentation LUT |
(2050,0010) |
|
None. |
Sequence |
|
|
|
>LUT Descriptor |
(0028,3002) The first value is the number of |
|
entries in the lookup table |
First value should be the |
Failure (0x0106) |
number of LUT entries. |
|
ThesecondvaluerepresentsthefirstSecond value should be 0
mapped value of the LUT. The third
value shall be 10-16 (which The third value default is 12. representsthebitdepthofeachLUT
entries.
>LUT Explanation |
(0028,3003) |
None. |
NA |
>LUT Data |
(0028,3006) |
None. |
|
PresentationLUTShape |
(2050,0020) |
Enumerated values: IDENTITY or None. |
Failure (0x0107) |
|
|
LIN OD. |
|
The Print Server Management behavior and specific status codes sent for the N-CREATE of a specific Presentation LUT is described in the following table:
