Types of Matching:​

The types of Matching supported by the C-FIND SCU. An "S" indicates the identifier attribute uses Single Value Matching, an "R" in-​ dicates Range Matching, a n"*"indicates wild card matching, a 'U' indicates Universal Matching, and an 'L' indicates that UID lists are​ sent. "NONE" indicates that no matching is supported, but that values for this Element are requested to be returned (i.e., universal​ matching), and "UNIQUE" indicates that this is the Unique Key for that query level, in which case Universal Matching or Single Value​ Matching is used depending on the query level.​

D.4.2.4.3.1.3.2 Presentation Context Acceptance Criterion​

FIND-SCU does not accept associations.​

D.4.2.4.3.1.3.3 Transfer Syntax Selection Policies​

FIND-SCU prefers explicit Transfer Syntaxes. If offered a choice of Transfer Syntaxes in the accepted Presentation Contexts, it will​ apply the following priority to the choice of Presentation Context to use for the C-STORE operation:​

a.​first encountered explicit Transfer Syntax,​

- Standard -​

b.​default Transfer Syntax.​

D.4.2.4.3.1.3.4 Response Status​

FIND-SCUwillbehaveasdescribedinTableD.4.2-24inresponsetothestatusreturnedintheC-FINDresponsecommandmessage(s).​

Table D.4.2-24. Response Status for FIND-SCU and Query Remote AE Request​

D.4.2.4.4 Association Acceptance Policy​

FIND-SCU does not accept associations.​

D.4.2.5 MOVE-SCU​

D.4.2.5.1 SOP Classes​

MOVE-SCU provide Standard Conformance to the following SOP Class(es) :​

Table D.4.2-25. SOP Classes Supported By MOVE-SCU​

D.4.2.5.2 Association Policies​

D.4.2.5.2.1 General​

MOVE-SCU initiates but never accepts associations.​

Table D.4.2-26. Maximum PDU Size Received as a SCP for MOVE-SCU​

- Standard -​

D.4.2.5.2.3 Asynchronous Nature​

MOVE-SCU will only allow a single outstanding operation on an Association. Therefore, MOVE-SCU will not perform asynchronous​ operations window negotiation.​

D.4.2.5.2.4 Implementation Identifying Information​

Table D.4.2-28. DICOM Implementation Class and Version for MOVE-SCU​

D.4.2.5.3 Association Initiation Policy​

MOVE-SCU attempts to initiate a new association when the user performs the retrieve action from the user interface.​

D.4.2.5.3.1 Activity - Retrieve From Remote AE​

D.4.2.5.3.1.1 Description and Sequencing of Activities​

For the entity (study, series or instance) selected from the user interface to be retrieved, a single attempt will be made to retrieve it​ from the selected remote AE. If the retrieve fails, for whatever reason, no retry will be performed.​

D.4.2.5.3.1.2 Proposed Presentation Contexts​

Table D.4.2-29. Proposed Presentation Contexts for MOVE-SCU and Retrieve From Remote AE​

MOVE-SCU will propose multiple Presentation Contexts, one for each of the supported Transfer Syntaxes, and an additional​ Presentation Context with all of the supported Transfer Syntaxes, in order to determine which Transfer Syntaxes the remote SCP​ supports, and which it prefers.​

D.4.2.5.3.1.2.1 Extended Negotiation​

No extended negotiation is performed.​

In particular, relational retrievals are not supported.​

D.4.2.5.3.1.3 SOP Specific Conformance​

D.4.2.5.3.1.3.1 SOP Specific Conformance to C-FIND SOP Classes​

MOVE-SCU provides standard conformance to the supported C-MOVE SOP Classes.​

Only a single information model, Study Root, is supported.​

A retrieval will be performed at the STUDY, SERIES or IMAGE level depending on what level of entity has been selected by the user​ in the browser.​

- Standard -​

No CANCEL requests are ever issued.​

The retrieval is performed from the AE that was specified in the Retrieve AE attribute returned from the query performed by FIND-​ SCU.Theinstancesareretrievedtothecurrentapplication'slocaldatabasebyspecifyingthedestinationastheAETitleoftheSTORE-​ SCP AE of the local application. This implies that the remote C-MOVE SCP must be preconfigured to determine the presentation​ address corresponding to the STORE-SCP AE. The STORE-SCP AE will accept storage requests addressed to it from anywhere,​ so no pre-configuration of the local application to accept from the remote AE is necessary (except in so far as it was necessary to​ configure FIND-SCU).​

Table D.4.2-30. Study Root Request Identifier for MOVE-SCU​

D.4.2.5.3.1.3.2 Presentation Context Acceptance Criterion​

MOVE-SCU does not accept associations.​

D.4.2.5.3.1.3.3 Transfer Syntax Selection Policies​

MOVE-SCU prefers explicit Transfer Syntaxes. If offered a choice of Transfer Syntaxes in the accepted Presentation Contexts, it will​ apply the following priority to the choice of Presentation Context to use for the C-STORE operation:​

a.​first encountered explicit Transfer Syntax,​

D.4.2.5.3.1.3.4 Response Status​

MOVE-SCU will behave as described in the Table below in response to the status returned in the C-MOVE response command​ message(s).​

Table D.4.2-31. Response Status for MOVE-SCU and Retrieve From Remote AE Request​

- Standard -​

(0000,1021)​

(0000,1022)​

(0000,1023)​

D.4.2.5.3.1.3.5 Sub-Operation Dependent Behavior​

Since the C-MOVE operation is dependent on completion of C-STORE sub-operations that are occurring on a separate association,​ the question of failure of operations on the other association(s) must be considered.​

MOVE-SCUcompletelyignoreswhateveractivitiesaretakingplaceinrelationtotheSTORAGE-SCPAEthatisreceivingtheretrieved​ instances. Once the C-MOVE has been initiated it runs to completion (or failure) as described in the C-MOVE response command​ message(s). There is no attempt by MOVE-SCU to confirm that instances have actually been successfully received or locally stored.​

Whether or not completely or partially successfully retrievals are made available in the local database to the user is purely dependent​ on the success or failure of the C-STORE sub-operations, not on any explicit action by MOVE-SCU.​

Whether or not the remote AE attempts to retry any failed C-STORE sub-operations is beyond the control of MOVE-SCU.​

If the association on which the C-MOVE was issued is aborted for any reason, whether or not the C-STORE sub-operations continue​ is dependent on the remote AE; the local STORAGE-SCP will continue to accept associations and storage operations regardless.​

D.4.2.5.4 Association Acceptance Policy​

MOVE-SCU does not accept associations.​

D.4.3 Network Interfaces​

D.4.3.1 Physical Network Interface​

The application is indifferent to the physical medium over which TCP/IP executes, which is dependent on the underlying operating​ system and hardware.​
