D.4.2.3.2 Association Policies​

D.4.2.3.2.1 General​

STORAGE-SCU initiates but never accepts associations.​

Table D.4.2-13. Maximum PDU Size Received as a SCP for STORAGE-SCU​

- Standard -​

D.4.2.3.2.3 Asynchronous Nature​

STORAGE-SCU will only allow a single outstanding operation on an Association. Therefore, STORAGE-SCU will not perform asyn-​ chronous operations window negotiation.​

D.4.2.3.2.4 Implementation Identifying Information​

Table D.4.2-15. DICOM Implementation Class and Version for STORAGE-SCU​

D.4.2.3.3 Association Initiation Policy​

STORAGE-SCU attempts to initiate a new association for each instance it attempts to transfer.​

D.4.2.3.3.1 Activity - Send Storage Request​

D.4.2.3.3.1.1 Description and Sequencing of Activities​

For each instance selected from the user interface to be transferred, a single attempt will be made to transmit it to the selected remote​ AE. If the send fails, for whatever reason, no retry will be performed, and an attempt will be made to send the next instance.​

D.4.2.3.3.1.2 Proposed Presentation Contexts​

Table D.4.2-16. Proposed Presentation Contexts for STORAGE-SCU and Receive Storage Request​

STORAGE-SCU will propose Presentation Contexts only for the SOP Class of the instance that is to be transferred.​

For that SOP Class, STORAGE-SCU will propose multiple Presentation Contexts, one for each of the supported Transfer Syntaxes,​ and an additional Presentation Context with all of the supported Transfer Syntaxes, in order to determine which Transfer Syntaxes​ the remote SCP supports, and which it prefers.​

D.4.2.3.3.1.2.1 Extended Negotiation​

No extended negotiation is performed.​

D.4.2.3.3.1.3 SOP Specific Conformance​

D.4.2.3.3.1.3.1 SOP Specific Conformance to Storage SOP Classes​

STORAGE-SCU provides standard conformance to the Storage Service Class.​

D.4.2.3.3.1.3.2 Presentation Context Acceptance Criterion​

STORAGE-SCU does not accept associations.​

- Standard -​

D.4.2.3.3.1.3.3 Transfer Syntax Selection Policies​

STORAGE-SCU prefers explicit Transfer Syntaxes. If offered a choice of Transfer Syntaxes in the accepted Presentation Contexts,​ it will apply the following priority to the choice of Presentation Context to use for the C-STORE operation:​

a.​first encountered explicit Transfer Syntax,​

b.​default Transfer Syntax.​

D.4.2.3.3.1.3.4 Response Status​

STORAGE-SCU will behave as described in the Table below in response to the status returned in the C-STORE response command​ message.​

Table D.4.2-17. Response Status for STORAGE-SCU and Receive Storage Request​

D.4.2.3.4 Association Acceptance Policy​

STORAGE-SCU does not accept associations.​

D.4.2.4 FIND-SCU​

D.4.2.4.1 SOP Classes​

FIND-SCU provide Standard Conformance to the following SOP Class(es) :​

Table D.4.2-18. SOP Classes Supported By FIND-SCU​

D.4.2.4.2 Association Policies​

D.4.2.4.2.1 General​

FIND-SCU initiates but never accepts associations.​

Table D.4.2-19. Maximum PDU Size Received as a SCP for FIND-SCU​

- Standard -​

D.4.2.4.2.3 Asynchronous Nature​

FIND-SCU will only allow a single outstanding operation on an Association. Therefore, FIND-SCU will not perform asynchronous​ operations window negotiation.​

D.4.2.4.2.4 Implementation Identifying Information​

Table D.4.2-21. DICOM Implementation Class and Version for FIND-SCU​

D.4.2.4.3 Association Initiation Policy​

FIND-SCU attempts to initiate a new association when the user performs the query action from the user interface. If this involves re-​ cursive queries for lower query levels in the hierarchy, these will be performed on the same association.​

D.4.2.4.3.1 Activity - Query Remote AE​

D.4.2.4.3.1.1 Description and Sequencing of Activities​

A single attempt will be made to query the remote AE. If the query fails, for whatever reason, no retry will be performed.​

D.4.2.4.3.1.2 Proposed Presentation Contexts​

Table D.4.2-22. Proposed Presentation Contexts for FIND-SCU and Query Remote AE​

FIND-SCU will propose multiple Presentation Contexts, one for each of the supported Transfer Syntaxes, and an additional​ Presentation Context with all of the supported Transfer Syntaxes, in order to determine which Transfer Syntaxes the remote SCP​ supports, and which it prefers.​

D.4.2.4.3.1.2.1 Extended Negotiation​

No extended negotiation is performed.​

In particular, relational queries are not supported.​

D.4.2.4.3.1.3 SOP Specific Conformance​

D.4.2.4.3.1.3.1 SOP Specific Conformance to C-FIND SOP Classes​

FIND-SCU provides standard conformance to the supported C-FIND SOP Classes.​

Only a single information model, Study Root, is supported.​

Allqueriesareinitiatedatthehighestleveloftheinformationmodel(theSTUDYlevel),andthenforeachresponsereceived,recursively​ repeatedatthenextlowerlevels(theSERIESandthenIMAGElevels),inordertocompletelyelucidatethe"tree"ofinstancesavailable​ on the remote AE (from which the user may subsequently request a retrieval at any level).​

No CANCEL requests are ever issued.​

UnexpectedattributesreturnedinaC-FINDresponse(thosenotrequested)arelistedinthebrowserattheappropriatelevelifpresent​ in the dictionary. Requested return attributes not returned by the SCP are ignored. Non-matching responses returned by the SCP​

- Standard -​

due to unsupported (hopefully optional) matching keys are not filtered locally by the FIND-SCU and thus will still be presented in the​ browser. No attempt is made to filter out duplicate responses.​

Specific Character Set will always be included at every query level. If present in the response, Specific Character Set will be used to​ identify character sets other than the default character set for display of strings in the browser.​

Table D.4.2-23. Study Root Request Identifier for FIND-SCU​
