Page 86 |
DICOM PS3.20 2020a - Imaging Reports using HL7 Clinical Document Architecture |
|
||||||
Description |
|
|
DICOM Object Catalog lists all referenced objects and their parent Series and |
|||||
|
|
|
Studies,plusotherDICOMattributesrequiredforretrievingtheobjects.TheDICOM |
|||||
|
|
|
Object Catalog section is not intended for viewing and may contain empty section |
|||||
|
|
|
text. |
|
|
|
|
|
Classification |
|
CDA Section Level |
|
|
|
|
||
Relationships |
|
Included in 9.3 Imaging Procedure Description |
|
|||||
Context |
|
|
parent node |
|
|
|
|
|
Open/Closed |
|
|
Open |
|
|
|
|
|
Revision History |
|
From Consolidated CDA r1.1 |
|
|
|
|||
Business |
Nest |
Element/ |
Card |
Elem/AttrConf Data |
Value |
Value |
Subsidiary |
|
Name |
Level |
Attribute |
|
|
Type |
Conf |
|
Template |
DICOMCatalog |
section |
1..1 |
SHALL |
|
|
|
|
|
|
> |
templateId |
1..1 |
SHALL |
II |
|
|
|
|
>@ |
@root |
1..1 |
SHALL |
UID |
SHALL2.16.840.1.113883. |
||
|
|
|
|
|
|
|
10.20.6.1.1 |
|
|
> |
id |
1..* |
SHALL |
II |
|
|
|
|
> |
code |
1..1 |
SHALL |
CD |
SHALL(121181, DCM, |
|
|
|
|
|
|
|
|
|
"Dicom Object |
|
|
|
|
|
|
|
|
Catalog") |
|
Title |
> |
title |
1..1 |
SHALL |
ST |
|
|
|
Text |
> |
text |
1..1 |
SHALL |
ED |
|
|
9.1.1 Section Text |
|
|
|
|
|
|
|
|
1.2.840.10008.9.19 |
|
> |
entry |
0..* |
SHOULD |
|
|
|
|
Study[*] |
>> |
act |
1..1 |
SHALL |
|
|
|
10.6 Study Act |
|
|
|
|
|
|
|
|
2.16.840.1.113883. |
|
|
|
|
|
|
|
|
10.20.6.2.6 |
Example 9.8.7-1. DICOM object catalog section example
<section classCode="DOCSECT" moodCode="EVN"> <templateId root="2.16.840.1.113883.10.20.6.1.1"/> <id root="1.2.840.10213.2.62.70447834679.11429737"/> <code code="121181" codeSystem="1.2.840.10008.2.16.4" codeSystemName="DCM"
displayName="DICOM Object Catalog"/> <entry>
<!-- **** Study Act **** -->
<act classCode="ACT" moodCode="EVN"> <templateId root="2.16.840.1.113883.10.20.6.2.6"/>
<id root="1.2.840.113619.2.62.994044785528.114289542805"/> <code code="113014" codeSystem="1.2.840.10008.2.16.4" codeSystemName="DCM" displayName="Study"/>
<!-- **** Series Act ****--> <entryRelationship typeCode="COMP"> <act classCode="ACT" moodCode="EVN">
<id root="1.2.840.113619.2.62.994044785528.20060823223142485051"/> <code code="113015" codeSystem="1.2.840.10008.2.16.4" codeSystemName="DCM" displayName="Series">
...
- Standard -
|
DICOM PS3.20 2020a - Imaging Reports using HL7 Clinical Document Architecture |
Page 87 |
||||||
</code> |
|
|
|
|
|
|
|
|
<!-- **** SOP Instance UID *** --> |
|
|
|
|
|
|||
<!-- 2 References --> |
|
|
|
|
|
|
||
<entryRelationship typeCode="COMP"> |
|
|
|
|
|
|||
<observation classCode="DGIMG" moodCode="EVN"> |
|
|
|
|
||||
<templateId root="2.16.840.1.113883.10.20.6.2.8"/> |
|
|
|
|
||||
... |
|
|
|
|
|
|
|
|
</observation> |
|
|
|
|
|
|
|
|
</entryRelationship> |
|
|
|
|
|
|
||
<entryRelationship typeCode="COMP"> |
|
|
|
|
|
|||
<observation classCode="DGIMG" moodCode="EVN"> |
|
|
|
|
||||
<templateId root="2.16.840.1.113883.10.20.6.2.8"/> |
|
|
|
|
||||
... |
|
|
|
|
|
|
|
|
</observation> |
|
|
|
|
|
|
|
|
</entryRelationship> |
|
|
|
|
|
|
||
</act> |
|
|
|
|
|
|
|
|
</entryRelationship> |
|
|
|
|
|
|
|
|
</act> |
|
|
|
|
|
|
|
|
</entry> |
|
|
|
|
|
|
|
|
9.8.8 Fetus Findings |
|
|
|
|
|
|
||
Template ID |
|
|
1.2.840.10008.9.9 |
|
|
|
||
Name |
|
|
|
Fetus Findings |
|
|
|
|
Effective Date |
|
|
2015/03/24 |
|
|
|
|
|
Version Label |
|
|
DICOM-20150324 |
|
|
|
||
Status |
|
|
|
Active |
|
|
|
|
Description |
|
|
Records observations related to a fetus confirmed or discovered during |
|||||
|
|
|
|
an imaging procedure. |
|
|
|
|
Classification |
|
|
CDA Section Level |
|
|
|
||
Relationships |
|
|
Included in 9.5 Findings |
|
|
|||
Context |
|
|
|
parent node |
|
|
|
|
Open/Closed |
|
|
Open |
|
|
|
|
|
Revision History |
|
|
DICOM-20150324: Initial version |
|
|
|||
Business |
Nest |
Element/ |
Card |
Elem/Attr Conf Data |
Value |
Value |
Subsidiary |
|
Name |
Level |
Attribute |
|
|
Type |
Conf |
|
Template |
Fetus |
|
section |
1..1 |
SHALL |
|
|
|
|
Findings[*] |
|
|
|
|
|
|
|
|
|
> |
templateId |
1..1 |
SHALL |
II |
|
|
|
|
>@ |
@root |
1..1 |
SHALL |
UID |
SHALL1.2.840.10008.9.9 |
||
|
> |
id |
1..* |
SHALL |
II |
|
|
|
|
> |
code |
1..1 |
SHALL |
CD |
SHALL(76514-9, LOINC, |
||
|
|
|
|
|
|
"Fetal Study |
|
|
|
|
|
|
|
|
observation") |
|
|
Title |
> |
title |
1..1 |
SHALL |
ST |
|
|
|
Text |
> |
text |
1..1 |
COND |
ED |
|
|
9.1.1 Section Text |
|
|
|
|
|
|
|
|
1.2.840.10008.9.19 |
|
> |
subject |
1..1 |
SHALL |
|
|
|
|
- Standard -
Page 88 |
|
DICOM PS3.20 2020a - Imaging Reports using HL7 Clinical Document Architecture |
|||
|
>> |
relatedSubject1..1 |
SHALL |
|
|
|
>>> |
code |
1..1 |
SHALL |
CE SHALL(121026, DCM, |
|
|
|
|
|
"Fetus") |
|
>>> |
subject |
1..1 |
SHALL |
|
FetusID |
>>>> |
name |
1..1 |
SHALL |
PN |
|
> |
component |
0..* |
MAY |
|
Subsection[*]>> |
section |
1..1 |
SHALL |
9.8.9 Labeled |
|
|
|
|
|
|
Subsection |
|
|
|
|
|
1.2.840.10008.9.10 |
|
> |
|
0.1 |
MAY |
9.1.2 General |
|
|
|
|
|
Section Entries |
|
|
|
|
|
1.2.840.10008.9.23 |
For reports on mothers and their fetus(es), information on a mother is mapped to recordTarget/PatientRole/Patient in the CDA header.Informationonthefetusismappedtosubject/relatedSubject/SubjectPersonattheCDAsectionlevel.Bothcontextinformation on the mother and fetus must be included in the document if observations on fetus(es) are contained in the document.
9.8.8.1 name - FetusID
The subject/relatedSubject/subject/name element is used to store the fetus ID, typically a pseudonym such as "fetus A". This shall be present even if only one fetus is identified in the document.
Example 9.8.8-1. Fetus Findings section example
<section classCode="DOCSECT" moodCode="EVN">
<templateId root="2.16.840.1.113883.10.20.22.2.27" /> <id root="1.2.840.10213.2.62.70447834679.11429737"/> <code code="76514-9" codeSystem="2.16.840.1.113883.6.1"
codeSystemName="LOINC" displayName="Fetal Study observation" /> <title>Fetus #1</title>
<text>Estimated gestational age of 27 weeks... </text> <relatedSubject>
<code code="121026" codeSystem="1.2.840.10008.2.16.4" displayName="Fetus"/> <subject>
<name>Fetus 1</name> </subject>
</relatedSubject>
</section>
9.8.9 Labeled Subsection
Template ID |
1.2.840.10008.9.10 |
Name |
Labeled Subsection |
Effective Date |
2015/03/24 |
Version Label |
DICOM-20150324 |
Status |
Active |
Description |
Narrative or coded subsection that allows organization of content for a labeled |
|
topic (a particular organ or anatomic feature, a lesion, a tumor, etc.). The |
|
section.code shall be absent, but the section.title shall be present. |
Classification |
CDA Section Level |
- Standard -
|
DICOM PS3.20 2020a - Imaging Reports using HL7 Clinical Document Architecture |
Page 89 |
Relationships |
Included in 9.5 Findings |
|
Context |
parent node |
|
Open/Closed |
Open |
|
Revision History |
DICOM-20150324: Initial version |
|
Business |
Nest |
Element/ |
Card |
Elem/Attr Conf Data Value |
Value |
Subsidiary |
||
Name |
Level |
Attribute |
|
|
Type Conf |
|
Template |
|
Subsection[*] |
section |
1..1 |
SHALL |
|
|
|
|
|
|
> |
templateId |
1..1 |
SHALL |
II |
|
|
|
|
>@ |
@root |
1..1 |
SHALL |
UID |
SHALL1.2.840.10008.9.10 |
||
|
> |
id |
1..* |
SHALL |
II |
|
|
|
|
> |
code |
0..0 |
SHALL NOT |
|
|
|
|
Title |
> |
title |
1..1 |
SHALL |
ST |
[See 9.8.9.1 title] |
|
|
|
|
|
|
noNull |
|
|
|
|
Text |
> |
text |
1..1 |
COND |
ED |
|
|
9.1.1 Section Text |
|
|
|
|
|
|
|
|
1.2.840.10008.9.19 |
|
> |
component |
0..* |
MAY |
|
|
|
|
Subsection[*]>> |
section |
1..1 |
SHALL |
|
|
|
9.8.9 Labeled |
|
|
|
|
|
|
|
|
|
Subsection |
|
|
|
|
|
|
|
|
1.2.840.10008.9.10 |
|
> |
|
0..1 |
MAY |
|
|
|
9.1.2 General |
|
|
|
|
|
|
|
|
Section Entries |
|
|
|
|
|
|
|
|
1.2.840.10008.9.23 |
9.8.9.1 title
The title element is used to identify the topic (specific organ or anatomic feature, abnormality, lesion, etc.) as the subject of the sub- sectionfindingsinthehumanreadabledocument.Asthereisnosection.code,thisistherequiredmechanismtorepresentthesection purpose as free text.
9.8.9.2 component/section Labeled Subsection
This template invokes itself recursively to allow arbitrarily deep nested subsections.
Example 9.8.9.2-1. Labeled sub-section example
<section classCode="DOCSECT" moodCode="EVN"> <templateId root="1.2.840.10008.9.10" />
<id root="1.2.840.10213.2.62.7044794679.114296787"/> <title>Liver</title>
<text>No evidence of cirrhosis, nodular regeneration, or ... </text> </section>
9.8.10 Communication of Actionable Findings
Template ID |
1.2.840.10008.9.11 |
Name |
Communication of Actionable Findings |
Effective Date |
2015/03/24 |
- Standard -
Page 90 |
DICOM PS3.20 2020a - Imaging Reports using HL7 Clinical Document Architecture |
Version Label |
DICOM-20150324 |
Status |
Active |
Description |
A section that documents the notification of an actionable finding to a provider or other |
|
person responsible for patient care. The documentation in narrative text, and optionally in |
|
a coded entry, includes by whom, to whom, and at what date/time. |
|
Specificfindings,includingactionable(aka.critical)findingsdocumentedintextorascoded |
|
entries, are typically found in the 9.5 Findings. The actionable findings may be duplicated |
|
in the 9.6 Impression in either text or as coded entries. The actionable findings may be new |
|
(critical) or a change to a previous report/diagnosis (discrepant). |
Classification |
CDA Section and Entry Level |
Relationships |
Included in 9.6 Impression and 9.7 Addendum |
Context |
parent node |
Open/Closed |
Open |
Revision History |
DICOM-20150324: Initial version |
Business NameNest Level Element/ |
Card |
Elem/Attr DataTypeValue |
Value |
Subsidiary |
|||||
|
|
Attribute |
|
Conf |
|
Conf |
|
Template |
|
Actionable |
|
section |
1..1 |
SHALL |
|
|
|
|
|
Findings |
|
|
|
|
|
|
|
|
|
|
> |
templateId |
1..1 |
SHALL |
II |
|
|
|
|
|
>@ |
@root |
1..1 |
SHALL |
UID |
SHALL1.2.840.10008.9.11 |
|||
|
> |
id |
1..* |
SHALL |
II |
|
|
|
|
|
> |
code |
1..1 |
SHALL |
CD |
SHALL(73568-8, LOINC, |
|
||
|
|
|
|
|
|
|
"Communication of |
||
|
|
|
|
|
|
|
Critical Results") |
|
|
Title |
> |
title |
1..1 |
SHALL |
ST |
|
|
|
|
|
> |
text |
1..1 |
SHALL |
ED |
|
|
|
|
Content[*] |
>> |
content |
0..* |
SHALL |
ST |
|
[See 9.8.10.1 |
|
|
|
|
|
|
|
|
|
section/text/content |
||
|
|
|
|
|
|
|
- narrative] |
|
|
* |
>>@ |
@ID |
1..1 |
SHALL |
XML ID |
|
|
|
|
FindingRef |
>>> |
linkHtml |
0..* |
MAY |
ST |
|
|
|
|
FindingURI |
>>>@ |
@href |
1..1 |
SHALL |
URL(XML |
#findingRef |
|
||
|
|
|
|
|
IDREF) |
|
|
|
|
|
> |
entry |
0..* |
SHOULD |
|
|
|
|
|
Communication[*]>> |
act |
1..1 |
SHALL |
|
SHALL |
|
|
||
|
>>@ |
@classCode |
1..1 |
SHALL |
CS |
SHALLACT |
|
|
|
|
>>@ |
@moodCode |
1..1 |
SHALL |
CS |
SHALLEVN |
|
||
* |
>>@ |
@ID |
1..1 |
SHALL |
XML ID |
|
|
|
|
|
>>> |
code |
1..1 |
SHALL |
CD |
SHALL(121291, DCM, |
|
||
|
|
|
|
|
|
|
"Results |
|
|
|
|
|
|
|
|
|
communicated") |
|
|
CommTime |
>>> |
effectiveTime |
1..1 |
SHALL |
TS |
|
|
|
|
|
>>> |
text |
1..1 |
SHALL |
ED |
|
|
|
|
Ref |
>>>> |
reference |
1..1 |
SHALL |
URL(XML |
# contentRef |
|
||
|
|
|
|
|
IDREF) |
|
|
|
|
|
>>> |
performer |
1..1 |
SHALL |
|
|
|
|
|
- Standard -
