Page 16​

DICOM PS3.10 2020a - Media Storage and File Format for Media Interchange​

DICOM PS3.10 2020a - Media Storage and File Format for Media Interchange​

Page 17​

Application Entity​

See [ISO 7498-1].​

Application Process​

See [ISO 7498-1].​

Service​

See [ISO 7498-1].​

Transfer Syntax​

See [ISO 7498-1].​

Data Confidentiality​

See [ISO 7498-2].​

Note​

The definition is "the property that information is not made available or disclosed to​

unauthorized individuals, entities or processes."​

Data Origin Authentication​

See [ISO 7498-2].​

Note​

The definition is "the corroboration that the source of data received is as claimed."​

Data Integrity​

See [ISO 7498-2].​

Note​

The definition is "the property that data has not been altered or destroyed in an​

unauthorized manner."​

Service Provider​

See [ISO/TR 8509].​

Service User​

See [ISO/TR 8509].​

Abstract Syntax​

See [ISO 8822].​

Abstract Syntax Name​

See [ISO 8822].​

Information Object Definition​

Information Object Definition.​

(IOD)​

Data Element​

Data Element.​

Data Set​

Data Set.​

Data Element Type​

Data Element Type.​

Value​

Value.​

Value Multiplicity​

Value Multiplicity (VM).​

Value Representation​

Value Representation (VR).​

Service Object Pair Instance​

Service-Object Pair Instance (SOP Instance).​

(SOP Instance)​

Implementation Class UID​

Implementation Class UID.​

Application Profile​

A Media Storage Application Profile defines a selection of choices at the various layers of the​

DICOM Media Storage Model that are applicable to a specific need or context in which the media​

interchange is intended to be performed.​

DICOM File Service​

The DICOM File Service specifies a minimum abstract view of files to be provided by the Media​

Format Layer. Constraining access to the content of files by the Application Entities through such​

a DICOM File Service boundary ensures Media Format and Physical Media independence.​

DICOM File​

A DICOM File is a File with a content formatted according to the requirements of this Part of the​

DICOM Standard. In particular such files shall contain, the File Meta Information and a properly​

formatted Data Set.​

DICOMDIR File​

A unique and mandatory DICOM File within a File-set that contains the Media Storage Directory​

SOP Class. This File is given a single component File ID, DICOMDIR.​

File​

A File is an ordered string of zero or more bytes, where the first byte is at the beginning of the​

file and the last byte at the end of the File. Files are identified by a unique File ID and may by​

written, read and/or deleted.​

File ID​

Files are identified by a File ID that is unique within the context of the File-set they belong to. A​

set of ordered File ID Components (up to a maximum of eight) forms a File ID.​

File ID Component​

A string of one to eight characters of a defined character set.​

DICOM PS3.10 2020a - Media Storage and File Format for Media Interchange​

Page 19​

File Meta Information​

The File Meta Information includes identifying information on the encapsulated Data Set. It is a​

mandatory header at the beginning of every DICOM File.​

File-set​

A File-set is a collection of DICOM Files (and possibly non-DICOM Files) that share a common​

naming space within which File IDs are unique.​

File-set Creator​

AnApplicationEntitythatcreatestheDICOMDIRFile(seeSection8.6)andzeroormoreDICOM​

Files.​

File-set Reader​

An Application Entity that accesses one or more files in a File-set.​

File-set Updater​

An Application Entity that accesses Files, creates additional Files, or deletes existing Files in a​

File-set. A File-set Updater makes the appropriate alterations to the DICOMDIR file reflecting the​

additions or deletions.​

DICOM File Format​

The DICOM File Format provides a means to encapsulate in a File the Data Set representing a​

SOP Instance related to a DICOM Information Object.​

Media Format​

Data structures and associated policies that organize the bit streams defined by the Physical​

Media format into data file structures and associated file directories.​

Media Storage Model​

The DICOM Media Storage Model pertains to the data structures used at different layers to​

achieve interoperability through media interchange.​

Media Storage Services​

DICOM Media Storage Services define a set of operations with media that facilitate storage to​

and retrieval from the media of DICOM SOP Instances.​

Physical Media​

A piece of material with recording capabilities for streams of bits. Characteristics of a Physical​

Mediaincludeformfactor,mechanicalcharacteristics,recordingpropertiesandrulesforrecording​

and organizing bit streams in accessible structures​

Secure DICOM File​

ADICOMFilethatisencapsulatedwiththeCryptographicMessageSyntaxspecifiedinRFC2630.​

Secure File-set​

A File-set in which all DICOM Files are Secure DICOM Files.​

Secure Media Storage​

A DICOM Media Storage Application Profile that requires a Secure File-set.​

Application Profile​

Page 20​

DICOM PS3.10 2020a - Media Storage and File Format for Media Interchange​
