Page 356​



DICOM PS3.3 2020a - Information Object Definitions​

IE​

Module​

Reference​

Usage​



Frame Extraction​

C.12.3​

C - Required if the SOP Instance was created​







in response to a Frame-Level retrieve request​

A.47.3.1 Enhanced XA Image IOD Content Constraints​

A.47.3.1.1 Modality Attribute​

Modality (0008,0060) shall have the value XA.​

A.47.3.1.2 Overlay Plane, Curve, VOI LUT and Specimen Identification Modules​

The Overlay Plane Module, VOI LUT Module and Softcopy Presentation LUT Module shall not be used in a Standard Extended SOP​ Class of the Enhanced XA Image.​

Note​

1.​The VOI LUT function is provided by a Frame VOI LUT Functional Group.​

2.​The Curve Module (Retired) was previously include in the list of Modules that shall not be present, but has been retired​ from DICOM. It is still not permitted to be present. See PS3.3-2004.​

3.​TheSpecimenIdentificationModulewaspreviouslyincludedinthisIODbuthasbeenretired,anditsfunctionalityreplaced​ by the Specimen Module. See PS3.3-2008.​

A.47.3.1.3 Positioner Type​

Positioner Type (0018,1508) shall have the value CARM if the XA/XRF Acquisition Module is present.​

A.47.4 Enhanced XA Image Functional Group Macros​

Table A.47-2 specifies the use of the Functional Group Macros used in the Multi-frame Functional Groups Module for the Enhanced​ XA Image IOD.​

Table A.47-2. Enhanced XA Image Functional Group Macros​

Functional Group Macro​

Section​

Usage​

Frame Content​

C.7.6.16.2.2​

M - May not be used as a Shared Functional Group.​

Referenced Image​

C.7.6.16.2.5​

U​

Derivation Image​

C.7.6.16.2.6​

C - Required if the image or frame has been derived from​





another SOP Instance.​

Cardiac Synchronization​

C.7.6.16.2.7​

U​

Frame Anatomy​

C.7.6.16.2.8​

M​

Frame VOI LUT​

C.7.6.16.2.10​

M​

Contrast/Bolus Usage​

C.7.6.16.2.12​

C - Required if the Enhanced Contrast/Bolus Module is​





present.​

Pixel Intensity Relationship LUT​

C.7.6.16.2.13​

C - Required if Pixel Intensity Relationship (0028,1040)​





equals LOG. May be present otherwise.​

Frame Pixel Shift​

C.7.6.16.2.14​

U​

Patient Orientation in Frame​

C.7.6.16.2.15​

C - Required if C-arm Positioner Tabletop Relationship​





(0018,9474) is present and equals YES. May be present​





otherwise.​

Frame Display Shutter​

C.7.6.16.2.16​

U​

Respiratory Synchronization​

C.7.6.16.2.17​

U​

- Standard -​



DICOM PS3.3 2020a - Information Object Definitions​

Page 357​

Functional Group Macro​

Section​

Usage​



Irradiation Event Identification​

C.7.6.16.2.18​

M​



X-Ray Frame Characteristics​

C.8.19.6.1​

U​



X-Ray Field of View​

C.8.19.6.2​

C - Required if Isocenter Reference System Sequence​





(0018,9462) is present. May be present otherwise.​

X-RayExposureControlSensingRegions​C.8.19.6.3​

U​



X-Ray Frame Pixel Data Properties​

C.8.19.6.4​

M​



X-Ray Frame Detector Parameters​

C.8.19.6.5​

C-RequiredifX-RayReceptorType(0018,9420)ispresent​





and equals DIGITAL_DETECTOR.​



X-Ray Calibration Device Usage​

C.8.19.6.6​

U​



X-Ray Object Thickness​

C.8.19.6.7​

U​



X-Ray Frame Acquisition​

C.8.19.6.8​

U​



X-Ray Projection Pixel Calibration​

C.8.19.6.9​

C - Required if C-arm Positioner Tabletop Relationship​





(0018,9474) is present and equals YES.​



X-Ray Positioner​

C.8.19.6.10​

C - Required if Image Type (0008,0008) Value 1 equals​





ORIGINAL and C-arm Positioner Tabletop Relationship​





(0018,9474) is present and equals YES. May be present​





otherwise.​



X-Ray Table Position​

C.8.19.6.11​

C - Required if Image Type (0008,0008) Value 1 equals​





ORIGINAL and C-arm Positioner Tabletop Relationship​





(0018,9474) is present and equals YES. May be present​





otherwise.​



X-Ray Collimator​

C.8.19.6.12​

C - Required if Image Type (0008,0008) Value 1 equals​





ORIGINAL. May be present otherwise.​



X-Ray Isocenter Reference System​

C.8.19.6.13​

U - May not be used if C-arm Positioner Tabletop​





Relationship (0018,9474) is not present or equals NO.​

X-Ray Geometry​

C.8.19.6.14​

C - Required if Projection Pixel Calibration Sequence​





(0018,9401) is present. May be present otherwise.​

A.47.4.1 Enhanced XA Image Functional Group Macros Content Constraints​

A.47.4.1.1 Frame Anatomy Functional Group Macro​

The Defined CID for the Anatomic Region Sequence (0008,2218) shall be CID 4042 “XA/XRF Anatomy Imaged”.​

A.48 Enhanced XRF Image IOD​

A.48.1 Enhanced XRF Image IOD Description​

ThefocusforthisEnhancedXRFIODistoaddresstherequirementsforimagetransferfoundingeneralRadiofluoroscopicapplications​ performed on a table with a column. For applications performed on X-Ray RF acquisition systems that support a Patient-Based Co-​ ordinate System with cranial/caudal, LAO/RAO angles, etc. the enhanced XA Image IOD may be used.​

Note​

1.​AnexampleofacasewheretheenhancedXAIODmaybepreferredtotheenhancedRFIODareRFacquisitionsystem​ equipped with an X-Ray source and an image Receptor positioned by what is generally called a C-arm (e.g., Interven-​ tional Procedures, Myelography, Biopsy, and Neurology).​

2.​For the purpose of X-Ray Radiofluoroscopy, this IOD can be used to encode a single-frame image, or a cine run, or a​ single multi-frame image with non-time related dimensions.​

- Standard -​

Page 358​

DICOM PS3.3 2020a - Information Object Definitions​

3.​A typical Study might include all the images generated between the time a Patient gets on and gets off the procedure​ table. As several separable diagnostic or therapeutic processes may occur during a single Study, a Series may be​ defined as comprising a set of images (single or multi-frame) associated with one such process within a Study.​

A.48.2 Enhanced XRF Image IOD Entity-Relationship Model​

This IOD uses the E-R Model in Section A.1.2, with only the Image IE below the Series IE.​

A.48.3 Enhanced XRF Image IOD Module Table​

Table A.48-1 specifies the Modules of the Enhanced XRF Image IOD.​

Table A.48-1. Enhanced XRF Image IOD Modules​

IE​

Module​

Reference​

Usage​

Patient​

Patient​

C.7.1.1​

M​



Clinical Trial Subject​

C.7.1.3​

U​

Study​

General Study​

C.7.2.1​

M​



Patient Study​

C.7.2.2​

U​



Clinical Trial Study​

C.7.2.3​

U​

Series​

General Series​

C.7.3.1​

M​



XA/XRF Series​

C.8.19.1​

M​



Clinical Trial Series​

C.7.3.2​

U​

Frame of​ Frame of Reference​

C.7.4.1​

U​

Reference​Synchronization​

C.7.4.2​

U​

Equipment​General Equipment​

C.7.5.1​

M​



Enhanced General Equipment​

C.7.5.2​

M​

Image​

Image Pixel​

C.7.6.3​

M​



Enhanced Contrast/Bolus​

C.7.6.4b​

C - Required if contrast media was applied​







and the system is able to register contrast​







usage.​



Mask​

C.7.6.10​

U​



Device​

C.7.6.12​

U​



Intervention​

C.7.6.13​

U​



Acquisition Context​

C.7.6.14​

M​



Multi-frame Functional Groups​

C.7.6.16​

M​



Multi-frame Dimension​

C.7.6.17​

U​



Cardiac Synchronization​

C.7.6.18.1​

C-Requiredifcardiacsynchronizationwas​







applied.​



Respiratory Synchronization​

C.7.6.18.2​

C - Required if respiratory synchronization​







was applied.​



Specimen​

C.7.6.22​

U​



X-Ray Tomography Acquisition​

C.8.7.7​

U​



X-Ray Filtration​

C.8.7.10​

U​



X-Ray Grid​

C.8.7.11​

U​



Enhanced XA/XRF Image​

C.8.19.2​

M​

- Standard -​



DICOM PS3.3 2020a - Information Object Definitions​

Page 359​

IE​

Module​

Reference​

Usage​





XA/XRF Acquisition​

C.8.19.3​

C - Required if Image Type (0008,0008)​







Value1equalsORIGINAL.Maybepresent​







otherwise.​





X-Ray Image Intensifier​

C.8.19.4​

C - Required if X-Ray Receptor Type​







(0018,9420) is present and equals​







IMG_INTENSIFIER.​





X-Ray Detector​

C.8.19.5​

C - Required if X-Ray Receptor Type​







(0018,9420) is present and equals​







DIGITAL_DETECTOR.​





XA/XRF Multi-frame Presentation​

C.8.19.7​

U​





SOP Common​

C.12.1​

M​





Common Instance Reference​

C.12.2​

U​





Frame Extraction​

C.12.3​

C - Required if the SOP Instance was​







created in response to a Frame-Level​







retrieve request​



A.48.3.1 Enhanced XRF Image IOD Content Constraints​

A.48.3.1.1 Modality Attribute​

Modality (0008,0060) shall have the value RF.​

A.48.3.1.2 Overlay Plane, Curve, VOI LUT and Specimen Identification Modules​

The Overlay Plane Module, VOI LUT Module and Softcopy Presentation LUT Module shall not be used in a Standard Extended SOP​ Class of the Enhanced XRF Image.​

Note​

1.​The VOI LUT function is provided by a Frame VOI LUT Functional Group.​

2.​The Curve Module (Retired) was previously include in the list of Modules that shall not be present, but has been retired​ from DICOM. It is still not permitted to be present. See PS3.3-2004.​

3.​TheSpecimenIdentificationModulewaspreviouslyincludedinthisIODbuthasbeenretired,anditsfunctionalityreplaced​ by the Specimen Module. See PS3.3-2008.​

A.48.3.1.3 Positioner Type​

Positioner Type (0018,1508) shall have the value COLUMN if the XA/XRF Acquisition Module is present.​

A.48.4 Enhanced XRF Image Functional Group Macros​

Table A.48-2 specifies the use of the Functional Group Macros used in the Multi-frame Functional Groups Module for the Enhanced​ XRF Image IOD.​

Table A.48-2. Enhanced XRF Image Functional Group Macros​

Functional Group Macro​

Section​

Usage​

Frame Content​

C.7.6.16.2.2​

M - May not be used as a Shared​





Functional Group.​

Referenced Image​

C.7.6.16.2.5​

U​

Derivation Image​

C.7.6.16.2.6​

C - Required if the image or frame has​





been derived from another SOP Instance.​

- Standard -​

Page 360​

DICOM PS3.3 2020a - Information Object Definitions​

Functional Group Macro​

Section​

Usage​

Cardiac Synchronization​



C.7.6.16.2.7​

U​

Frame Anatomy​



C.7.6.16.2.8​

M​

Frame VOI LUT​



C.7.6.16.2.10​

M​

Contrast/Bolus Usage​



C.7.6.16.2.12​

C - Required if the Enhanced​







Contrast/Bolus Module is present.​

Pixel Intensity Relationship LUT​



C.7.6.16.2.13​

C-RequiredifPixelIntensityRelationship​







(0028,1040) equals LOG. May be present​







otherwise.​

Frame Pixel Shift​



C.7.6.16.2.14​

U​

Patient Orientation in Frame​



C.7.6.16.2.15​

U​

Frame Display Shutter​



C.7.6.16.2.16​

U​

Respiratory Synchronization​



C.7.6.16.2.17​

U​

Irradiation Event Identification​



C.7.6.16.2.18​

M​

X-Ray Frame Characteristics​



C.8.19.6.1​

U​

X-Ray Field of View​



C.8.19.6.2​

U​

X-Ray Exposure Control Sensing Regions​

C.8.19.6.3​

U​

X-Ray Frame Pixel Data Properties​



C.8.19.6.4​

M​

X-Ray Frame Detector Parameters​



C.8.19.6.5​

C - Required if X-Ray Receptor Type​







(0018,9420) is present and equals​







DIGITAL_DETECTOR.​

X-Ray Calibration Device Usage​



C.8.19.6.6​

U​

X-Ray Object Thickness​



C.8.19.6.7​

U​

X-Ray Frame Acquisition​



C.8.19.6.8​

U​

X-Ray Positioner​



C.8.19.6.10​

U​

X-Ray Table Position​



C.8.19.6.11​

U​

X-Ray Collimator​



C.8.19.6.12​

U​

X-Ray Geometry​



C.8.19.6.14​

U​

A.48.4.1 Enhanced XRF Image Functional Group Macros Content Constraints​

A.48.4.1.1 Frame Anatomy Functional Group Macro​

The Defined CID for the Anatomic Region Sequence (0008,2218) shall be CID 4042 “XA/XRF Anatomy Imaged”.​

A.49 RT Ion Plan IOD​

A.49.1 RT Ion Plan IOD Description​

ThefocusforthisRadiotherapyIonPlanIOD(RTIonPlanIOD)istoaddresstherequirementsfortransferoftreatmentplansgenerated​ by manual entry, a virtual simulation system, or a treatment planning system before or during a course of Ion therapy treatment. Such​ plans may contain fractionation information, and define Ion beams.​

A.49.2 RT Ion Plan IOD Entity-Relationship Model​

This IOD uses the E-R Model in Section A.1.2, with only the Plan IE below the Series IE.​

- Standard -​
