DICOM PS3.3 2020a - Information Object Definitions​

Page 241​

IE​

Module​

Reference​

Usage​





Frame Pointers​

C.7.6.9​

U​





Device​

C.7.6.12​

U​





Multi-frame Functional Groups​

C.7.6.16​

U​





Multi-frame Dimension​

C.7.6.17​

U​





Specimen​

C.7.6.22​

U​





SC Image​

C.8.6.2​

U​





SC Multi-frame Image​

C.8.6.3​

M​





SC Multi-frame Vector​

C.8.6.4​

C - Required if Number of Frames is​







greater than 1​





ICC Profile​

C.11.15​

U​





SOP Common​

C.12.1​

M​





Common Instance Reference​

C.12.2​

U​





Frame Extraction​

C.12.3​

C - Required if the SOP Instance was​







created in response to a Frame-Level​







retrieve request​



A.8.5.4 Multi-frame True Color SC Image IOD Content Constraints​

The VOI LUT Module shall not be present.​

In the Image Pixel Module, the following constraints apply:​

•​Samples per Pixel (0028,0002) shall be 3​

•​Photometric Interpretation (0028,0004) shall be RGB for uncompressed or lossless compressed Transfer Syntaxes that do not​ have defined color space transformations, YBR_ICT for irreversible JPEG 2000 Transfer Syntaxes, YBR_RCT for reversible JPEG​ 2000TransferSyntaxes,YBR_PARTIAL_420forMPEG2,MPEG-4AVC/H.264,HEVC/H.265TransferSyntaxesandYBR_FULL_422​ for JPEG lossy compressed Transfer Syntaxes and YBR_FULL or RGB for RLE Transfer Syntaxes​

Note​

Future lossless and lossy Transfer Syntaxes may lead to the need for new definitions and choices for Photometric Inter-​ pretation.​

•​Bits Allocated (0028,0100) shall be 8​

•​Bits Stored (0028,0101) shall be 8​

•​High Bit (0028,0102) shall be 7​

•​Pixel Representation (0028,0103) shall be 0​

•​Planar Configuration (0028,0006) shall be 0 (color-by-pixel) if Photometric Interpretation (0028,0004) is RGB​

The Overlay Plane Module shall not be present.​

For images being referenced as texture maps that are not clinical images, a modality value of TEXTUREMAP may be used as the​ value of Modality (0008,0060).​

A.8.5.5 Multi-frame True Color SC Image Functional Group Macros​

Table A.8-5b specifies the use of the Functional Group Macros used in the Multi-frame Functional Groups Module for the Multi-frame​ True Color SC Image IOD.​

- Standard -​

Page 242​ DICOM PS3.3 2020a - Information Object Definitions​

Table A.8-5b. Multi-frame True Color SC Image Functional Group Macros​

Functional Group Macro​

Section​

Usage​

Pixel Measures​

C.7.6.16.2.1​

C - Required if Plane Position (Patient) or Plane Orientation​





(Patient) Macros Present​

Plane Position (Patient)​

C.7.6.16.2.3​

C - Required if Pixel Measures or Plane Orientation (Patient)​





Macros Present​

Plane Orientation (Patient)​

C.7.6.16.2.4​

C - Required if Pixel Measures or Plane Position (Patient)​





Macros Present​

A.9 Standalone Overlay IOD​

Retired. See PS3.3-2004.​

A.10 Standalone Curve IOD​

Retired. See PS3.3-2004.​

A.11 Basic Study Descriptor IOD​

Retired. See PS3.3-2004.​

A.12 Standalone Modality LUT IOD​

Retired. See PS3.3-2004.​

A.13 Standalone VOI LUT IOD​

Retired. See PS3.3-2004.​

A.14 X-Ray Angiographic Image IOD​

A.14.1 XA Image IOD Description​

ThisSectiondefinestheInformationObjectforsingleplaneX-RayAngiographicImagingthatincludesthoseAttributesandInformation​ Objects necessary for the interchange of digital X-Ray Angiographic data. This includes images of the heart and all blood vessels.​

The XA IOD share a significant amount of common information with the XRF IOD. The differences between the two IODs are that​ the XRF Image IOD includes a tomography Module; and the two IODs utilize different methods to specify positioner angles. The XRF​ Image IOD contains a single column angulation Data Element that uses an Equipment-Based Coordinate System, while XA Image​ IOD c-arm positioner angles are specified in a Patient-Based Coordinate System. RF applications that support a Patient-Based Co-​ ordinate System with cranial/caudal, LAO/RAO angles may utilize the XA IOD.​

The XA IOD is also applicable to clinical areas other than angiography (e.g., Interventional Procedures, Myelography, Biopsy/Local-​ ization, and Neurology).​

Note​

1.​ForthepurposeofX-RayAngiography(XA),thisIODcanbeusedtoencodeasingle-frameimage,oraCineRunencoded​ in a single multi-frame image.​

2.​A typical Study might include all the images generated between the time a Patient gets on and gets off the procedure​ table. As several separable diagnostic or therapeutic processes may occur during a single Study (e.g., pre-intervention​ CA, left ventriculography, and post-intervention CA), a Series may be defined as comprising a set of images (single or​ multi-frame) associated with one such process within a Study.​

3.​This IOD can be used to encode a single plane acquisition, or one plane of a biplane acquisition.​

- Standard -​

DICOM PS3.3 2020a - Information Object Definitions​

Page 243​

A.14.2 XA Image IOD Entity-Relationship Model​

This IOD uses the E-R Model in Section A.1.2, with only the Image IE below the Series IE.​

A.14.3 XA Image IOD Module Table​

Table A.14-1 specifies the Modules of the XA Image IOD.​

Table A.14-1. X-Ray Angiographic Image IOD Modules​

IE​

Module​

Reference​

Usage​

Patient​

Patient​

C.7.1.1​

M​



Clinical Trial Subject​

C.7.1.3​

U​

Study​

General Study​

C.7.2.1​

M​



Patient Study​

C.7.2.2​

U​



Clinical Trial Study​

C.7.2.3​

U​

Series​

General Series​

C.7.3.1​

M​



Clinical Trial Series​

C.7.3.2​

U​

Frame of​ Synchronization​

C.7.4.2​

U​

Reference​





Equipment​General Equipment​

C.7.5.1​

M​

Image​

General Image​

C.7.6.1​

M​



General Reference​

C.12.4​

U​



Image Pixel​

C.7.6.3​

M​



Contrast/Bolus​

C.7.6.4​

C - Required if contrast media was used in​







this Image​



Cine​

C.7.6.5​

C - Required if pixel data is Multi-frame Cine​







data​



Multi-frame​

C.7.6.6​

C - Required if pixel data is Multi-frame Cine​







data​



Frame Pointers​

C.7.6.9​

U​



Mask​

C.7.6.10​

C - Required if the Image may be subtracted​



Display Shutter​

C.7.6.11​

U​



Device​

C.7.6.12​

U​



Intervention​

C.7.6.13​

U​



Specimen​

C.7.6.22​

U​



X-Ray Image​

C.8.7.1​

M​



X-Ray Acquisition​

C.8.7.2​

M​



X-Ray Collimator​

C.8.7.3​

U​



X-Ray Table​

C.8.7.4​

C - Required if Image is created with table​







motion, may be present otherwise​



XA Positioner​

C.8.7.5​

M​



DX Detector​

C.8.11.4​

U​



Overlay Plane​

C.9.2​

U​



Multi-frame Overlay​

C.9.3​

C-RequiredifOverlaydatacontainsmultiple​







frames.​

- Standard -​

Page 244​



DICOM PS3.3 2020a - Information Object Definitions​

IE​

Module​



Reference​

Usage​



Modality LUT​



C.11.1​

C - Required if Pixel Intensity Relationship​









(0028,1040) is LOG​









U - Optional if Pixel Intensity Relationship​









(0028,1040) is DISP​



VOI LUT​



C.11.2​

U​



SOP Common​



C.12.1​

M​



Common Instance Reference​

C.12.2​

U​



Frame Extraction​



C.12.3​

C-RequirediftheSOPInstancewascreated​









inresponsetoaFrame-Levelretrieverequest​

Note​

The Curve Module (Retired) was previously included in the Image IE for this IOD but has been retired. See PS3.3-2004.​

A.15X-RayAngiographicBi-planeImageInformationObjectDefinition(Retired)​

A.16 X-Ray Radiofluoroscopic Image IOD​

A.16.1 XRF Image IOD Description​

The focus for this X-Ray Radiofluoroscopic IOD is to address the requirements for image transfer found in general Radiofluoroscopic​ applications performed on a table with a column. For applications performed on X-Ray RF acquisition systems that support a Patient-​ Based Coordinate System with cranial/caudal, LAO/RAO angles, etc. the XA Image IOD may be used.​

Note​

An example of a case where the XA IOD may be preferred to the RF IOD are RF acquisition system equipped with an X-​ Ray source and an image Receptor positioned by what is generally called a c-arm (e.g., Interventional Procedures, Myelo-​ graphy, Biopsy, and Neurology).​

ThisSectiondefinestheInformationObjectforX-RayRadiofluoroscopicImagingthatincludesthoseAttributesandInformationObjects​ necessary for the interchange of digital X-Ray RF Image data. The XRF IOD is applicable to X-Ray acquisition systems equipped​ with an image receptor whose plane is parallel to the table plane where the Patient is. This Table has in general the ability to be tilted.​ Furthermore the X-Ray source may be supported by a column that can be angulated to adjust the incidence of the X-Ray beam on​ the image receptor plan. An equipment based coordinated system is used to track these angles.​

Note​

1.​ForthepurposeofX-RayRadiofluoroscopy,thisIODcanbeusedtoencodeasingle-frameimage,oracinerunencoded​ in a single multi-frame image.​

2.​A typical Study might include all the images generated between the time a Patient gets on and gets off the procedure​ table. As several separable diagnostic or therapeutic processes may occur during a single Study, a Series may be​ defined as comprising a set of images (single or multi-frame) associated with one such process within a Study.​

A.16.2 X-Ray Radiofluoroscopic Image IOD Entity-Relationship Model​

This IOD uses the E-R Model in Section A.1.2, with only the Image IE below the Series IE.​

Note​

WhenaStudy(orStudyComponent)containsanumberofMulti-frameimagesthatdonotneedtobegroupedunderdifferent​ Series, a single Series may be used with a Series number containing an arbitrary value (e.g., 1).​

- Standard -​

DICOM PS3.3 2020a - Information Object Definitions​

Page 245​

A.16.3 X-Ray Radiofluoroscopic Image IOD Module Table​

Table A.16-1 specifies the Modules of the X-Ray Radiofluoroscopic Image IOD.​

Table A.16-1. X-Ray Radiofluoroscopic Image IOD Modules​

IE​

Module​

Reference​

Usage​

Patient​

Patient​

C.7.1.1​

M​



Clinical Trial Subject​

C.7.1.3​

U​

Study​

General Study​

C.7.2.1​

M​



Patient Study​

C.7.2.2​

U​



Clinical Trial Study​

C.7.2.3​

U​

Series​

General Series​

C.7.3.1​

M​



Clinical Trial Series​

C.7.3.2​

U​

Frame of​ Synchronization​

C.7.4.2​

U​

Reference​





Equipment​General Equipment​

C.7.5.1​

M​

Image​

General Image​

C.7.6.1​

M​



General Reference​

C.12.4​

U​



Image Pixel​

C.7.6.3​

M​



Contrast/Bolus​

C.7.6.4​

C - Required if contrast media was used in​







this Image​



Cine​

C.7.6.5​

C-RequiredifpixeldataisMulti-frameCine​







Data​



Multi-frame​

C.7.6.6​

C-RequiredifpixeldataisMulti-frameCine​







Data​



Frame Pointers​

C.7.6.9​

U​



Mask​

C.7.6.10​

C-RequirediftheImagemaybesubtracted​



Display Shutter​

C.7.6.11​

U​



Device​

C.7.6.12​

U​



Intervention​

C.7.6.13​

U​



Specimen​

C.7.6.22​

U​



X-Ray Image​

C.8.7.1​

M​



X-Ray Acquisition​

C.8.7.2​

M​



X-Ray Collimator​

C.8.7.3​

U​



X-Ray Table​

C.8.7.4​

U​



XRF Positioner​

C.8.7.6​

U​



X-Ray Tomography Acquisition​

C.8.7.7​

C - Required if Scan Option (0018,0022) is​







TOMO​



DX Detector​

C.8.11.4​

U​



Overlay Plane​

C.9.2​

U​



Multi-frame Overlay​

C.9.3​

C - Required if Overlay Data contains​







multiple frames​

- Standard -​
