Page 236​

DICOM PS3.3 2020a - Information Object Definitions​

•​Planar Configuration (0028,0006) shall not be present​

Note​

As a consequence of these Attribute values, single bit pixels are packed eight to a byte as defined by the encoding rules in​ PS3.5.​

The VOI LUT Module shall not be present.​

The Overlay Plane Module shall not be present.​

A.8.3 Multi-frame Grayscale Byte Secondary Capture Image IOD​

A.8.3.1 Multi-frame Grayscale Byte Image IOD Description​

The Multi-frame Grayscale Byte Secondary Capture (SC) Image Information Object Definition (IOD) specifies Grayscale Byte images​ that are converted from a non-DICOM format to a modality independent DICOM format.​

This IOD is typically used for screen captured images for modalities that have pixel values of 8 bits, but may also be appropriate for​ scanned grayscale documents.​

A.8.3.2 Multi-frame Grayscale Byte SC Image IOD Entity-Relationship Model​

This IOD uses the E-R Model in Section A.1.2, with only the Image IE below the Series IE.​

A.8.3.3 Multi-frame Grayscale Byte SC Image IOD Module Table​

Table A.8-3 specifies the Modules of the Multi-frame Grayscale Byte SC Image IOD.​

Table A.8-3. Multi-frame Grayscale Byte SC Image IOD Modules​

IE​

Module​

Reference​

Usage​

Patient​

Patient​

C.7.1.1​

M​



Clinical Trial Subject​

C.7.1.3​

U​

Study​

General Study​

C.7.2.1​

M​



Patient Study​

C.7.2.2​

U​



Clinical Trial Study​

C.7.2.3​

U​

Series​

General Series​

C.7.3.1​

M​



Clinical Trial Series​

C.7.3.2​

U​

Equipment​General Equipment​

C.7.5.1​

U​



SC Equipment​

C.8.6.1​

M​

Frame of​ Frame of Reference​

C.7.4.1​

C - Required if Pixel Measures or Plane​

Reference​



Position (Patient) or Plane Orientation​







(Patient) Functional Group Macros Present​



Synchronization​

C.7.4.2​

U​

Image​

General Image​

C.7.6.1​

M​



General Reference​

C.12.4​

U​



Image Pixel​

C.7.6.3​

M​



Cine​

C.7.6.5​

C - Required if Frame Increment Pointer​







(0028,0009) is Frame Time (0018,1063) or​







Frame Time Vector (0018,1065)​



Multi-frame​

C.7.6.6​

M​



Frame Pointers​

C.7.6.9​

U​

- Standard -​



DICOM PS3.3 2020a - Information Object Definitions​

Page 237​

IE​

Module​

Reference​

Usage​





Device​

C.7.6.12​

U​





Multi-frame Functional Groups​

C.7.6.16​

U​





Multi-frame Dimension​

C.7.6.17​

U​





Specimen​

C.7.6.22​

U​





SC Image​

C.8.6.2​

U​





SC Multi-frame Image​

C.8.6.3​

M​





SC Multi-frame Vector​

C.8.6.4​

C - Required if Number of Frames is greater​







than 1​





VOI LUT​

C.11.2​

C - Required if the VOI LUT stage is not an​







identity transformation​





SOP Common​

C.12.1​

M​





Common Instance Reference​

C.12.2​

U​





Frame Extraction​

C.12.3​

C - Required if the SOP Instance was​







created in response to a Frame-Level​







retrieve request​



A.8.3.4 Multi-frame Grayscale Byte SC Image IOD Content Constraints​

TheVOILUTModuleisrequirediftheVOILUTstageisnotanidentitytransformation.SupportforbothwindowandLUTismandatory.​ The output grayscale space is defined to be in P-Values.​

Note​

If the VOI LUT Module is absent, then the stored pixel values are in P-Values.​

In the Image Pixel Module, the following constraints apply:​

•​Samples per Pixel (0028,0002) shall be 1​

•​Photometric Interpretation (0028,0004) shall be MONOCHROME2​

•​Bits Allocated (0028,0100) shall be 8​

•​Bits Stored (0028,0101) shall be 8​

•​High Bit (0028,0102) shall be 7​

•​Pixel Representation (0028,0103) shall be 0​

•​Planar Configuration (0028,0006) shall not be present​

•​Rescale Intercept shall be 0​

•​Rescale Slope shall be 1​

•​Rescale Type shall be US​

The Overlay Plane Module shall not be present.​

A.8.3.5 Multi-frame Grayscale Byte SC Image Functional Group Macros​

Table A.8-3b specifies the use of the Functional Group Macros used in the Multi-frame Functional Groups Module for the Multi-frame​ Grayscale Byte SC Image IOD.​

- Standard -​

Page 238​ DICOM PS3.3 2020a - Information Object Definitions​

Table A.8-3b. Multi-frame Grayscale Byte SC Image Functional Group Macros​

Functional Group Macro​

Section​

Usage​

Pixel Measures​

C.7.6.16.2.1​

C - Required if Plane Position (Patient) or Plane Orientation​





(Patient) Macros Present​

Plane Position (Patient)​

C.7.6.16.2.3​

C - Required if Pixel Measures or Plane Orientation (Patient)​





Macros Present​

Plane Orientation (Patient)​

C.7.6.16.2.4​

C - Required if Pixel Measures or Plane Position (Patient)​





Macros Present​

A.8.4 Multi-frame Grayscale Word Secondary Capture Image IOD​

A.8.4.1 Multi-frame Grayscale Word SC Image IOD Description​

TheMulti-frameGrayscaleWordSecondaryCapture(SC)ImageInformationObjectDefinition(IOD)specifiesGrayscaleWordimages​ that are converted from a non-DICOM format to a modality independent DICOM format.​

This IOD is typically used for screen captured images for modalities that have pixel values greater than 8 bits.​

A.8.4.2 Multi-frame Grayscale Word SC Image IOD Entity-Relationship Model​

This IOD uses the E-R Model in Section A.1.2, with only the Image IE below the Series IE.​

A.8.4.3 Multi-frame Grayscale Word SC Image IOD Module Table​

Table A.8-4 specifies the Modules of the Multi-frame Grayscale Word SC Image IOD.​

Table A.8-4. Multi-frame Grayscale Word SC Image IOD Modules​

IE​

Module​

Reference​

Usage​

Patient​

Patient​

C.7.1.1​

M​



Clinical Trial Subject​

C.7.1.3​

U​

Study​

General Study​

C.7.2.1​

M​



Patient Study​

C.7.2.2​

U​



Clinical Trial Study​

C.7.2.3​

U​

Series​

General Series​

C.7.3.1​

M​



Clinical Trial Series​

C.7.3.2​

U​

Equipment​General Equipment​

C.7.5.1​

U​



SC Equipment​

C.8.6.1​

M​

Frame of​ Frame of Reference​

C.7.4.1​

C - Required if Pixel Measures or Plane​

Reference​



Position (Patient) or Plane Orientation​







(Patient) Functional Group Macros Present​



Synchronization​

C.7.4.2​

U​

Image​

General Image​

C.7.6.1​

M​



General Reference​

C.12.4​

U​



Image Pixel​

C.7.6.3​

M​



Cine​

C.7.6.5​

C - Required if Frame Increment Pointer​







(0028,0009) is Frame Time (0018,1063) or​







Frame Time Vector (0018,1065)​



Multi-frame​

C.7.6.6​

M​



Frame Pointers​

C.7.6.9​

U​

- Standard -​



DICOM PS3.3 2020a - Information Object Definitions​

Page 239​

IE​

Module​

Reference​

Usage​





Device​

C.7.6.12​

U​





Multi-frame Functional Groups​

C.7.6.16​

U​





Multi-frame Dimension​

C.7.6.17​

U​





Specimen​

C.7.6.22​

U​





SC Image​

C.8.6.2​

U​





SC Multi-frame Image​

C.8.6.3​

M​





SC Multi-frame Vector​

C.8.6.4​

C - Required if Number of Frames is greater​







than 1​





VOI LUT​

C.11.2​

C - Required if the VOI LUT stage is not an​







identity transformation​





SOP Common​

C.12.1​

M​





Common Instance Reference​

C.12.2​

U​





Frame Extraction​

C.12.3​

C - Required if the SOP Instance was​







created in response to a Frame-Level​







retrieve request​



A.8.4.4 Multi-frame Grayscale Word SC Image IOD Content Constraints​

TheVOILUTModuleisrequirediftheVOILUTstageisnotanidentitytransformation.SupportforbothwindowandLUTismandatory.​ The output grayscale space is defined to be in P-Values.​

Note​

If the VOI LUT Module is absent, then the stored pixel values are in P-Values.​

In the Image Pixel Module, the following constraints apply:​

•​Samples per Pixel (0028,0002) shall be 1​

•​Photometric Interpretation (0028,0004) shall be MONOCHROME2​

•​Bits Allocated (0028,0100) shall be 16​

•​Bits Stored (0028,0101) shall be greater than or equal to 9 and less than or equal to 16​

•​High Bit (0028,0102) shall be one less than Bits Stored (0028,0101)​

•​Pixel Representation (0028,0103) shall be 0​

•​Planar Configuration (0028,0006) shall not be present​

Note​

Rescale Slope and Rescale Intercept are not constrained in this IOD to any particular values. E.g., they may be used to re-​ cover floating point values scaled to the integer range of the stored pixel values, Rescale Slope may be less than one, e.g.,​ a Rescale Slope of 1.0/65535 would allow represent floating point values from 0 to 1.0.​

The Overlay Plane Module shall not be present. Unused high bits shall be filled with zeroes.​

A.8.4.5 Multi-frame Grayscale Word SC Image Functional Group Macros​

Table A.8-4b specifies the use of the Functional Group Macros used in the Multi-frame Functional Groups Module for the Multi-frame​ Grayscale Word SC Image IOD.​

- Standard -​

Page 240​ DICOM PS3.3 2020a - Information Object Definitions​

Table A.8-4b. Multi-frame Grayscale Word SC Image Functional Group Macros​

Functional Group Macro​

Section​

Usage​

Pixel Measures​

C.7.6.16.2.1​

C - Required if Plane Position (Patient) or Plane Orientation​





(Patient) Macros Present​

Plane Position (Patient)​

C.7.6.16.2.3​

C - Required if Pixel Measures or Plane Orientation (Patient)​





Macros Present​

Plane Orientation (Patient)​

C.7.6.16.2.4​

C - Required if Pixel Measures or Plane Position (Patient)​





Macros Present​

A.8.5 Multi-frame True Color Secondary Capture Image IOD​

A.8.5.1 Multi-frame True Color Image IOD Description​

The Multi-frame True Color Secondary Capture (SC) Image Information Object Definition (IOD) specifies True Color images that are​ converted from a non-DICOM format to a modality independent DICOM format.​

This IOD is typically used for screen captured or synthetic images where true color is used, but may also be appropriate for scanned​ color documents.​

A.8.5.2 Multi-frame True Color SC Image IOD Entity-Relationship Model​

This IOD uses the E-R Model in Section A.1.2, with only the Image IE below the Series IE.​

A.8.5.3 Multi-frame True Color SC Image IOD Module Table​

Table A.8-5 specifies the Modules of the Multi-frame True Color SC Image IOD.​

Table A.8-5. Multi-frame True Color SC Image IOD Modules​

IE​

Module​

Reference​

Usage​

Patient​

Patient​

C.7.1.1​

M​



Clinical Trial Subject​

C.7.1.3​

U​

Study​

General Study​

C.7.2.1​

M​



Patient Study​

C.7.2.2​

U​



Clinical Trial Study​

C.7.2.3​

U​

Series​

General Series​

C.7.3.1​

M​



Clinical Trial Series​

C.7.3.2​

U​

Frame of​ Frame of Reference​

C.7.4.1​

C - Required if Pixel Measures or Plane​

Reference​



Position (Patient) or Plane Orientation​







(Patient)FunctionalGroupMacrosPresent​



Synchronization​

C.7.4.2​

U​

Equipment​General Equipment​

C.7.5.1​

U​



SC Equipment​

C.8.6.1​

M​

Image​

General Image​

C.7.6.1​

M​



General Reference​

C.12.4​

U​



Image Pixel​

C.7.6.3​

M​



Cine​

C.7.6.5​

C - Required if Frame Increment Pointer​







(0028,0009) is Frame Time (0018,1063)​







or Frame Time Vector (0018,1065)​



Multi-frame​

C.7.6.6​

M​

- Standard -​
