Page 1106​

DICOM PS3.3 2020a - Information Object Definitions​

Table C.8.21.6-1a. Defined Terms of Image Type (0008,0008) Value 3 for Contrast Enhanced,​ Tomosynthesis and Biopsy​

Defined Term​

Definition​

ACRMQCMEquivalent​

Contrast​





PRE_CONTRAST​

Collected before contrast was administered.​

n/a​

POST_CONTRAST​

Collected during or after contrast was administered.​

n/a​

Tomosynthesis​





TOMO_PROJ​

Identifies the image as a digital breast tomosynthesis projection image.​n/a​

TOMOSYNTHESIS​

Tomographic reconstruction from limited angle projection data.​

n/a​

Biopsy​





TOMO_SCOUT​

A localizer image set that may be used to determine positioning​

…SC​



coordinates prior to needle positioning.​



PREFIRE​

An image set obtained with the biopsy needle in position prior to needle​…PRF​



deployment.​



POSTFIRE​

Animagesetobtainedwiththebiopsyneedleinpositionfollowingneedle​…POF​



deployment through the targeted lesion.​



POSTBIOPSY​

AnimagesetobtainedfollowingtissueacquisitionwiththeX-Raysource​…POB​



in the scout position.​



POSTMARKER​

An image set obtained following micromarker placement with the X-Ray​…POM​



source in the scout position.​



Note​

There is no need for _MINUS or _PLUS because a single digital breast tomosynthesis acquisition produces a projection​ and/or reconstruction image set that replaces the _MINUS and _PLUS image pair used in conventional 2D breast biopsy​ imaging (see Section C.8.11.7.1.4).​

Ifmorethanonecharacteristic(biopsy,tomosynthesis,contrastenhanced)appliestoanimage,Value3shallcontainthebiopsyimage​ type. If biopsy is not involved, Value 3 shall contain the tomosynthesis image type.​

Note​

For example, Attributes of the Enhanced Contrast/Bolus Module may be used to identify contrast enhanced characteristics​ of a biopsy and/or tomosynthesis image that is also contrast enhanced.​

Value 4 shall be NONE except for applicable contrast enhanced images, mathematically generated 2D images and other tomosyn-​ thesisreconstructions.ThefollowingDefinedTermsarespecifiedforValue4ofImageType(0008,0008)andFrameType(0008,9007).​ For additional Defined Terms see Section C.8.16.1.4.​

Table C.8.21.6-1b. Defined Terms of Image Type (0008,0008) Value 4 for Contrast Enhanced and​ Tomosynthesis​

Defined Term​

Definition​

Tomosynthesis​



GENERATED_2D​

Mathematically generated 2D view.​

MAXIMUM​

Created through Pixel by pixel maximum operation.​

MEAN​

Created through Pixel by pixel mean operation.​

Contrast​



ADDITION​

Created through Pixel by pixel addition operation.​

SUBTRACTION​

Created through Pixel by pixel subtraction operation.​

- Standard -​

DICOM PS3.3 2020a - Information Object Definitions​

Page 1107​

If more than one characteristic (contrast enhanced, tomosynthesis) applies to an image, Value 4 shall contain the contrast enhanced​ image type. If contrast enhanced is not involved, Value 4 shall contain the tomosynthesis image type.​

Value 5 shall be present for images acquired using contrast enhanced digital X-Ray imaging of the breast, but may be empty if none​ of the Defined Terms applies. For non-contrast images Value 5 remains optional and implementation specific.​

Table C.8.21.6-1c. Defined Terms of Image Type (0008,0008) Value 5 for Contrast Enhanced Images​

Enumerated Value​

Definition​

LOW_ENERGY​

Low energy image.​

HIGH_ENERGY​

High energy image.​

Note​



A recipient may use the different values for biopsy, tomosynthesis and contrast views to determine how to display them, for​ example in hanging protocols:​



Image Type Value 3​

Image Type Value 4​

Image Type Value​







5​

Tomosynthesis thin reconstructed slices​

TOMOSYNTHESIS​

NONE​

-​

Tomosynthesis thick reconstructed slices​

TOMOSYNTHESIS​

MAXIMUM​

-​

Tomosynthesis generated 2D​

TOMOSYNTHESIS​

GENERATED_2D​

-​

Tomosynthesis projections​

TOMO_PROJ​

NONE​

-​

Tomosynthesis thin reconstructed slices biopsy​

POSTFIRE​

NONE​

-​

post-fire​







Tomosynthesisthickreconstructedslicespost-biopsy​

POSTBIOPSY​

MEAN​

-​

Tomosynthesis generated 2D biopsy pre-fire​

PREFIRE​

GENERATED_2D​

-​

Tomosynthesis projections biopsy scout​

TOMO_SCOUT​

NONE​

-​

Tomosynthesisthickreconstructedslicespre-contrast​

TOMOSYNTHESIS​

MAXIMUM​

empty​

Tomosynthesisthinreconstructedslicespost-contrast​

TOMOSYNTHESIS​

SUBTRACTION​

empty​

subtraction​







Tomosynthesisthickreconstructedslicespost-contrast​

TOMOSYNTHESIS​

SUBTRACTION​

empty​

subtraction​







Tomosynthesis generated 2D post-contrast addition​

TOMOSYNTHESIS​

ADDITION​

empty​

Tomosynthesisgenerated2Dpost-contrastlowenergy​

TOMOSYNTHESIS​

GENERATED_2D​ LOW_ENERGY​

Tomosynthesisprojectionspost-contrasthighenergy​

TOMO_PROJ​

NONE​

HIGH_ENERGY​

Tomosynthesisthickreconstructedslicesbiopsyscout​

TOMO_SCOUT​

MAXIMUM​

empty​

pre-contrast​







Tomosynthesis thin reconstructed slices biopsy​

PREFIRE​

SUBTRACTION​

empty​

pre-fire post-contrast subtraction​







Tomosynthesis thick reconstructed slices biopsy​

POSTFIRE​

SUBTRACTION​

empty​

post-fire post-contrast subtraction​







Tomosynthesis generated 2D post-biopsy​

POSTBIOPSY​

ADDITION​

empty​

post-contrast addition​







Tomosynthesis generated 2D biopsy scout​

TOMO_SCOUT​

GENERATED_2D​

LOW_ENERGY​

post-contrast low energy​







Tomosynthesis projections post-biopsy post-contrast​

POSTBIOPSY​

NONE​

HIGH_ENERGY​

high energy​







- Standard -​

Page 1108​

DICOM PS3.3 2020a - Information Object Definitions​

C.8.22 Enhanced PET Modules​

This section describes the specific Modules for the Enhanced PET Image IOD.​

C.8.22.1 Enhanced PET Series Module​

The Enhanced PET IODs use the General Series Module, specialized by the Enhanced PET Series Module, to describe the DICOM​ Series Entity described in Section A.1.2.3, and to define what constitutes a Series for the context of PET device.​

Table C.8.22-1 specifies the Attributes that identify and describe general information about the Enhanced PET Series.​

Table C.8.22-1. Enhanced PET Series Module Attributes​

Attribute Name​

Tag​

Type​

Attribute Description​

Modality​

(0008,0060)​

1​

Type of equipment that originally acquired the data used to​







create the images in this Series.​







Enumerated Values:​







PT​







See Section C.7.3.1.1.1 for further explanation.​

Referenced Performed​

(0008,1111)​

1C​

UniquelyidentifiesthePerformedProcedureStepSOPInstance​

Procedure Step Sequence​





to which the Series is related.​







Only a single Item shall be included in this Sequence.​







RequiredifaPerformedProcedureStepSOPClasswasinvolved​







in the creation of this Series.​

>Include Table 10-11 “SOP Instance Reference Macro Attributes”​



Related Series Sequence​

(0008,1250)​

1C​

Identifying the Series that was used for attenuation purposes.​







See Section C.7.3.1​







Required if another Series was used to perform attenuation​







correction and the SOP Class UID is not​







"1.2.840.10008.5.1.4.1.1.128.1" (Legacy Converted). May be​







present otherwise.​







One or more Items shall be included in this Sequence.​

>Study Instance UID​

(0020,000D)​

1​

Instance UID of Study to which the related Series belongs​

>Series Instance UID​

(0020,000E)​

1​

Instance UID of Related Series​

>PurposeofReferenceCode​

(0040,A170)​

2​

Describes the purpose for which the reference is made.​

Sequence​





Zero or more Items shall be included in this Sequence.​













When absent, implies that the reason for the reference is​







unknown.​

>>Include Table 8.8-1 “Code Sequence Macro Attributes”​

DCID 7210 “Related Series Purposes of Reference”.​

C.8.22.2 Enhanced PET Acquisition Module​

Table C.8.22-2 specifies the Attributes that describe PET Acquisitions.​

- Standard -​

DICOM PS3.3 2020a - Information Object Definitions​ Page 1109​

Table C.8.22-2. Enhanced PET Acquisition Module Attributes​

Attribute Name​

Tag​

Type​

Attribute Description​

Acquisition Start Condition​

(0018,0073)​

1C​

Description of how the data collection was started.​







See Section C.8.22.2.1.1 for Defined Terms.​







Required if Image Type (0008,0008) Value 1 is ORIGINAL. May be​







present otherwise.​

Start Density Threshold​

(0018,9715)​

1C​

The count density that triggered the start of the acquisition, in​







counts/sec. Required if Acquisition Start Condition (0018,0073) equals​







DENS.​

Start Relative Density​

(0018,9716)​

1C​

The relative count density that triggered the start of the acquisition, in​

Difference Threshold​





counts/sec. Required if Acquisition Start Condition (0018,0073) equals​







RDD.​

Start Cardiac Trigger Count​

(0018,9717)​

1C​

The number of cardiac triggers that occurred before starting the​

Threshold​





acquisition. Required if Acquisition Start Condition (0018,0073) equals​







CARD_TRIG.​

Start Respiratory Trigger​

(0018,9718)​

1C​

The number of respiratory triggers that occurred before starting the​

Count Threshold​





acquisition. Required if Acquisition Start Condition (0018,0073) equals​







RESP_TRIG.​

Acquisition Termination​

(0018,0071)​

1C​

Description of how the data collection for the Series was stopped.​

Condition​





See Section C.8.22.2.1.2 for Defined Terms.​













Required if Image Type (0008,0008) Value 1 is ORIGINAL. May be​







present otherwise.​

Termination Counts​

(0018,9719)​

1C​

The count value that triggered the termination of the acquisition.​

Threshold​





RequiredifAcquisitionTerminationCondition(0018,0071)equalsCNTS.​







Termination Density​

(0018,9720)​

1C​

The count density that triggered the termination of the acquisition, in​

Threshold​





counts/sec.​







RequiredifAcquisitionTerminationCondition(0018,0071)equalsDENS.​

TerminationRelativeDensity​

(0018,9721)​

1C​

The count relative density that triggered the termination of the​

Threshold​





acquisition, in counts/sec.​







RequiredifAcquisitionTerminationCondition(0018,0071)equalsRDD.​

Termination Time Threshold​

(0018,9722)​

1C​

The time duration after which the acquisition was terminated, in sec.​







RequiredifAcquisitionTerminationCondition(0018,0071)equalsTIME​

Termination Cardiac Trigger​

(0018,9723)​

1C​

The number of cardiac triggers that triggered the termination of the​

Count Threshold​





acquisition.​







Required if Acquisition Termination Condition (0018,0071) equals​







CARD_TRIG​

Termination Respiratory​

(0018,9724)​

1C​

The number of respiratory triggers that triggered the termination of the​

Trigger Count Threshold​





acquisition.​

Required if Acquisition Termination Condition (0018,0071) equals​

RESP_TRIG​

- Standard -​

Page 1110​

DICOM PS3.3 2020a - Information Object Definitions​

Attribute Name​

Tag​

Type​



Attribute Description​

Type of Detector Motion​

(0054,0202)​

1C​

Describes the type of detector motion during acquisition.​







Defined Terms:​









STATIONARY​

No motion​







STEP AND​

Interrupted motion, acquire only while detectors​







SHOOT​

are stationary​







CONTINUOUS​ Gantry motion and acquisition are simultaneous​









and continuous​







WOBBLE​

wobble motion​







CLAMSHELL​

clamshell motion​







Required if Image Type (0008,0008) Value 1 is ORIGINAL. May be​







present otherwise.​



Detector Geometry​

(0018,9725)​

1C​

Physical arrangement of the detectors in the acquisition system.​







The radiation entrance surface of a detector may be curved or flat. A​







curved surface is referred to as cylindrical.​







Detectors may simultaneously subtend all possible transverse angles​







from the center of the field of view. Detectors that do not are referred​







to as partial.​









Defined Terms:​









CYLINDRICAL_RING​







CYL_RING_PARTIAL​







MULTIPLE_PLANAR​







MUL_PLAN_PARTIAL​







Required if Image Type (0008,0008) Value 1 is ORIGINAL and Type​







of Detector Motion (0054,0202) equals STATIONARY. May be present​







otherwise, if Image Type (0008,0008) Value 1 is DERIVED and Type​







of Detector Motion (0054,0202) equals STATIONARY.​

Transverse Detector​

(0018,9726)​

1C​

Distance between opposing detectors, in mm.​

Separation​





Required if Image Type (0008,0008) Value 1 is ORIGINAL. May be​













present otherwise.​



Axial Detector Dimension​

(0018,9727)​

1C​

Axial detector size in mm. Size of the detector along the table axis.​







Required if Image Type (0008,0008) Value 1 is ORIGINAL May be​







present otherwise.​



Collimator Type​

(0018,1181)​

1C​

Collimator Type.​









Defined Terms:​









NONE​no collimator​







RING​transverse septa​







Required if Image Type (0008,0008) Value 1 is ORIGINAL. May be​







present otherwise.​



Coincidence Window Width​

(0054,1210)​

1C​

The width of the coincidence-timing window, in nanoseconds. The​







maximum time difference between two single events in two opposing​







detectors that will be accepted as a coincidence event.​

Required if Image Type (0008,0008) Value 1 is ORIGINAL. May be​ present otherwise.​

- Standard -​

Смотрите также:

«ДОХОДЫ, РАСХОДЫ И ПРИБЫЛЬ КОММЕРЧЕСКОГО БАНКА.»
«ДОХОДЫ, РАСХОДЫ И ПРИБЫЛЬ КОММЕРЧЕСКОГО БАНКА.»
Значение, сущность и содержание социально — педагогической деятельности в организации для детей-сирот и детей, оставшихся без попечения родителей
__RGR2
__RGR2
_11_А. Франс для эл версии
_индив анализ данных
- Интерфейс 485 и оптопорт 11
:Конвергентный подход к проектированию дополнительных общеобразовательных общеразвивающих программ
